Ingeteam INGEREV FUSION Street FS1MW User manual

INGEREV FUSION
Street / Wall
Installation and Operation Manual
Manual de instalación y uso
Manuel d'installation et usage
Manuale d'installazione e uso

ABW2011IQM01_C
10/2020
SERVICE CALL CENTERS
SPAIN
Ingeteam Power Technology, S.A. - Energy
[phone]
GERMANY
Ingeteam GmbH
[phone]
FRANCE
Ingeteam SAS
[phone]
ITALY
Ingeteam S.r.l.
[phone]
CZECH REPUBLIC
Ingeteam, a.s.
[phone]
USA
Ingeteam INC.
1-414-934-4158
MEXICO
Ingeteam, S.A. de C.V.
[phone]
BRASIL
Ingeteam Ltda.
[phone]
SOUTH AFRICA
Ingeteam Pty Ltd.
[phone]
INDIA
Ingeteam Power Technology India Pvt. Ltd.
[phone]
AUSTRALIA
Ingeteam Australia Pty Ltd.
[phone]

ABW2011IQM01_C
English EN
Español ES
Français FR
Italiano IT
3
Ingeteam

ABW2011IQM01_C
The copy, distribution or use of this document or of its content requires written authorisation. Any breach thereof will be reported for
damages. All rights reserved including those of patent rights or design registration.
The conformity of the document content with the hardware described has been checked. However, discrepancies may exist. Liability
will not be assumed for total concordance. The information contained in this document is regularly reviewed and it is possible that
there may be changes in subsequent editions. Other functions may be available which are not covered by this document.
This document may be changed.
La copia, circulación o uso de este documento o de su contenido requiere un permiso por escrito. Su incumplimiento será
denunciado por daños y perjuicios. Todos los derechos están reservados, incluyendo aquellos que resulten de derechos de patentes
o registro del diseño.
La correspondencia del contenido del documento con el hardware ha sido comprobada. Sin embargo, pueden existir discrepancias.
No se asume ninguna responsabilidad por la concordancia total. La información que contiene este documento es revisada
regularmente y es posible que se produzcan cambios en siguientes ediciones.
El presente documento es susceptible de ser modificado.
La copie, distribution ou utilisation de ce document ou de son contenu requiert une autorisation écrite. Toute personne ne respectant
pas cette condition sera passible de poursuites. Tous les droits sont réservés, y compris ceux qui découlent des droits de brevets ou
d’enregistrement des conceptions.
La correspondance entre le contenu du document et le matériel a été vérifiée. Il peut toutefois exister des divergences. Aucune
responsabilité de concordance totale n’est assumée. Les informations contenues dans ce document sont régulièrement révisées et il
est possible que des changements surviennent dans les éditions à venir.
Le présent document est susceptible d’être modifié.
Per copiare, condividere o utilizzare il presente documento o il suo contenuto è necessaria un’autorizzazione scritta. Il mancato
rispetto di quest’obbligo sarà perseguito. Tutti i diritti sono riservati, compresi quelli risultanti da diritti di brevetti o dalla registrazione
del progetto.
La corrispondenza del contenuto del presente documento con l’hardware è stata verificata, tuttavia, possono sussistere discrepanze.
Si declina ogni responsabilità relativamente alla concordanza totale. Le informazioni contenute in questo documento sono
regolarmente sottoposte a revisione ed è possibile che siano inserite delle modifiche nelle prossime edizioni.
Questo documento può essere soggetto a modifiche.
4
Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
EN
ES
FR
IT
Important safety instructions
This section describes the safety warnings and the personal protective equipment and symbols used in the unit.
Safety conditions
General warnings
DANGER
Opening the enclosure does not imply there is no voltage inside.
Only qualified personnel may open it, following the instructions in this manual.
The risk of electric shock exists even after disconnecting from the grid.
It is strictly forbidden to gain access to the inside of the unit through any other point than the access cover
provided for this purpose. Always gain access when the unit is voltage-free.
CAUTION
The operations described in the manual may be performed only by qualified personnel.
The status of qualified personnel referred to in this manual will be, as a minimum, that which meets all the
standards, regulations and laws regarding safety applicable to the tasks of installing and operating this unit.
The responsibility for designating qualified personnel will always fall to the company to which the personnel
belong. It is necessary to decide which workers are suitable or not for carrying out specific work to preserve their
safety at the same time as complying with occupational safety legislation.
These companies are responsible for providing appropriate training in electrical equipment to their personnel
and for familiarizing them with the contents of this manual.
All applicable safety-related legislation for electrical work must be complied with.
Compliance with the safety instructions set out in this manual or in the suggested legislation does not imply
exemption from other specific standards for the installation, place, country or other circumstances that affect
the unit.
You must consider the set of conditions listed throughout this document as minimum requirements. It is always
preferable to shut off the main power supply. There may be faults in the installation that cause the unwanted
return of voltage. Danger of electric shock.
According to basic safety standards, the complete unit must be suitable to protect exposed workers against the
risk of direct and indirect contact. In any case the electrical parts of the work equipment must comply with the
provisions of the corresponding specific regulations.
According to basic safety standards, the electrical installation shall not entail a fire or explosion risk. Workers
must be duly protected against the risk of accidents caused by direct or indirect contact. The electrical
installation and protection devices must take into account the voltage, the external conditions and the
competence of persons who have access to parts of the installation.
To check the absence of voltage, it is compulsory to use measurement devices with category III-1100 V.
INFO
These instructions must be easily accessible close to the unit and located within reach of all users.
Before installation and start-up, please read these safety instructions and warnings carefully as well as all the
warning notices located on the unit. Ensure that all the warnings signs are perfectly legible and that those which
are damaged or have disappeared are restored.
Protection against direct contact is by means of the enclosure.
The unit has been tested according to the applicable regulations to comply with the safety requirements, the
values for insulation clearances and leakage paths for the voltages used.
5
Important safety instructions Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
Potential hazards for people
DANGER
Electric shock.
The equipment may remain charged after disconnecting the grid power.
Carefully follow the mandatory steps in the manual for removing the voltage.
Explosion.
There is a very low risk of explosion in very specific cases of malfunction.
The casing will protect people and property from the explosion only if it is correctly closed.
Crushing and joint injuries.
Always follow the indications in the manual on moving and placing the unit.
The weight of this unit can cause injury if not handled correctly.
Potential hazards for the equipment
DANGER
Do not touch boards or electronic components. The more sensitive components can be damaged or destroyed by
static electricity.
Do not disconnect or connect any terminal while the unit is operating. Disconnect and check for absence of
voltage first.
6
Important safety instructions
Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
EN
ES
FR
IT
Personal Protective Equipment (PPE)
When working on the unit, use the following safety equipment recommended by Ingeteam as a minimum.
Name Description
Safety footwear In compliance with standard UNE-EN-ISO 20345:2012 ANSI Z41.1-1991
Helmet with face shield In compliance with standard UNE-EN 397:1995, ANSI Z89.1-2014,provided
there are elements with voltage directly accessible.
Working clothes Close-fitting, non-flammable, 100% cotton
Dielectric gloves In compliance with standard EN 60903:2005 ASTM D 120-87
Tools and / or equipment used in live work must have at least Category III-1100 Volts insulation.
Should the country’s regulations demand another kind of personal protection, you should appropriately supplement
the equipment recommended by Ingeteam.
7
Important safety instructions Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
8
Contents
Ingeteam
Contents
Important safety instructions ....................................................................................................................... 5
Safety conditions................................................................................................................................... 5
Personal Protective Equipment (PPE) ...................................................................................................... 7
Contents ................................................................................................................................................... 8
1. About this manual................................................................................................................................ 10
1.1. Scope of application .................................................................................................................... 10
1.2. Recipients................................................................................................................................... 10
1.3. Warnings..................................................................................................................................... 10
2. Unit description................................................................................................................................... 11
2.1. Overview ..................................................................................................................................... 11
2.2. Models........................................................................................................................................ 11
2.3. Specification table ....................................................................................................................... 12
2.4. Power Sockets ............................................................................................................................. 13
2.5. Protection ................................................................................................................................... 14
2.6. EMC requirements ....................................................................................................................... 15
2.7. Cabling accesses ......................................................................................................................... 15
2.7.1. INGEREV FUSION Street...................................................................................................... 16
2.7.2. INGEREV FUSION Wall........................................................................................................ 16
3. Receipt of the unit and storage.............................................................................................................. 18
3.1. Reception ................................................................................................................................... 18
3.2. Unit identification........................................................................................................................ 18
3.3. Transport damage ........................................................................................................................ 18
3.4. Storage....................................................................................................................................... 18
3.5. Conservation................................................................................................................................ 18
4. Equipment transport ............................................................................................................................ 19
4.1. Transport..................................................................................................................................... 19
4.2. Unpacking .................................................................................................................................. 19
5. Preparation for installing the unit .......................................................................................................... 20
5.1. Environment................................................................................................................................ 20
5.2. Environmental conditions ............................................................................................................. 20
5.3. Supporting Surface and Fastening ................................................................................................. 21
6. Installing the unit ................................................................................................................................ 23
6.1. General requirements for installation ............................................................................................. 23
6.2. INGEREV FUSION Street.............................................................................................................. 23
6.3. INGEREV FUSION Wall ................................................................................................................ 25
7. Connection of accessories..................................................................................................................... 28
7.1. Safety instructions for connecting accessories ................................................................................ 28
7.2. Ethernet communication .............................................................................................................. 28
7.2.1. Cabling requirements ........................................................................................................... 28
7.2.2. Connection process.............................................................................................................. 28
7.3. Communication via 3G/4G (optional) ............................................................................................. 29
7.3.1. Connection process.............................................................................................................. 29
8. Power supply connection ...................................................................................................................... 33
8.1. Safety instructions for connecting the power supply ........................................................................ 33
8.2. Wiring requirements for connecting the power supply ...................................................................... 33
8.3. Power supply connection process .................................................................................................. 33
9. First connection to the electric grid........................................................................................................ 37
9.1. Unit inspection............................................................................................................................ 37
9.1.1. Inspection........................................................................................................................... 37
9.1.2. Hermetic sealing of the unit ................................................................................................. 37
10. Configuration..................................................................................................................................... 38
10.1. Local connection ....................................................................................................................... 38
10.1.1. Local connection via Ethernet ............................................................................................. 38
10.1.2. Local connection via Wi-Fi.................................................................................................. 39

ABW2011IQM01_C - Installation and Operation Manual
EN
ES
FR
IT
9
Contents Ingeteam
10.2. Remote connection .................................................................................................................... 39
11. Operation .......................................................................................................................................... 40
11.1. Status indication ....................................................................................................................... 40
11.2. User interface............................................................................................................................ 40
11.3. Charging process ....................................................................................................................... 40
11.3.1. Charging process with authentication................................................................................... 40
11.3.2. Charging process without authentication .............................................................................. 42
12. Troubleshooting ................................................................................................................................. 44
12.1. Alarms...................................................................................................................................... 44
13. Shutting down the unit ....................................................................................................................... 46
14. Maintenance ..................................................................................................................................... 47
14.1. Safety conditions ....................................................................................................................... 47
14.2. Condition of hoses and charging connectors ................................................................................. 47
14.3. Condition of the housing............................................................................................................. 47
14.4. Condition of cables and terminals................................................................................................ 47
15. Waste handling .................................................................................................................................. 48

ABW2011IQM01_C - Installation and Operation Manual
1. About this manual
The purpose of this manual is to describe the INGEREV electric vehicle charging stations and to provide
appropriate information for their correct reception, installation, start-up, maintenance and operation.
INFO
You can download the latest version of this Manual from the website www.ingeteam.com.
1.1. Scope of application
This manual is valid for the following charging stations:
INGEREV FUSION Street
FS1MW (single phase with manual protections
and wattmeters)
FS1AW (single phase with protections, residual
current device with automatic reset and
wattmeters)
FS3NN (three phase without protections,
without wattmeters)
FS3MW (three phase with manual protections
and wattmeters)
FS3AW (three phase with protections, residual
current device with automatic reset and
wattmeters)
INGEREV FUSION Wall
FW1MW (single phase with manual protections
and wattmeters)
FSFW1AW (single phase with protections,
residual current device with automatic reset
and wattmeters)
FW3NN (three phase without protections,
without wattmeters)
FW3MW (three phase with manual protections
and wattmeters)
FW3AW (three phase with protections, residual
current device with automatic reset and
wattmeters)
1.2. Recipients
This document is intended for qualified personnel.
The status of qualified personnel referred to in this manual will be, as a minimum, that which meets all the
standards, regulations and laws regarding safety applicable to the tasks of installing and operating this unit.
The responsibility for designating qualified personnel will always fall to the company to which the personnel
belong. It is necessary to decide which workers are suitable or not for carrying out specific work to preserve their
safety at the same time as complying with occupational safety legislation.
These companies are responsible for providing appropriate training in electrical equipment to their personnel and
for familiarizing them with the contents of this manual.
1.3. Warnings
Throughout this manual we include warnings to highlight certain information. Relative to the nature of the text,
there are three types of warnings:
Indicates importance.
CAUTION
This indicates a hazard to personnel or the inverter.
DANGER
Additional information or references to other parts of the document or documents.
INFO
10
About this manual
Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
EN
ES
FR
IT
2. Unit description
2.1. Overview
The INGEREV FUSION chargers are the alternating current model designed to meet all the requirements of electric
vehicle charging in public and private settings.
Allows simultaneous charging of two vehicles, and with its different power supply configurations it is compatible
with mode 3 as well as with modes 1 and 2.
They have been designed for use indoors and outdoors and may be installed in locations with unrestricted access.
2.2. Models
The INGEREV FUSION range is available in two versions: FUSION Street for installing on the ground, and FUSION
Wall for installing on the wall. These versions are available in the following variants:
Variants of models INGEREV FUSION Street / Wall
FS1MW /
FW1MW
FS1AW /
FW1AW
FS3NN /
FW3NN
FS3MW /
FW3MW
FS3AW /
FW3AW
Grid Single phase Single phase Three phase Three phase Three phase
Power meter
MID wattmeter
Residual current device Type A manual
Residual current device Type A
resettable
Overcurrent protection (Curve C)
11
Unit description Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
2.3. Specification table
INGEREV FUSION Street INGEREV FUSION Wall
Single phase
(FS1)
Three phase
(FS3)
Single phase
(FW1)
Three phase
(FW3)
AC inputs and outputs
Voltage 1 ph. + N +PE
230Vac±15%
3ph. + N +PE
400Vac±15%
1 ph. + N +PE
230Vac±15%
3ph. + N +PE
400Vac±15%
Maximum input power 14.8kW
(7.4kW+7.4kW)
44kW
(22kW+22kW)
14.8kW
(7.4kW+7.4kW)
44kW
(22kW+22kW)
Frequency 50 / 60Hz
Maximum input current 64A(32A + 32A)
Output connectors Configurable (type 1 and type 2 both in socket and in cable, Type 3A, CEE 7/3 Type F, CEE
7/5 Type E)
Connection mode 5 socket types and 2 cable types
Regulations and safety
Standard regulations IEC-61851-1, IEC-61851-21-2, IEC-61000
Overcurrent Overcurrent protection device (Curve C)
Indirect contacts Residual current device (RCD) 30mA Type A(1) / DC leak detector (optional)
Overvoltage (1) Overvoltage protection Type III
Functionalities and accessories
Communications Ethernet, Wi-Fi, Ethernet Switch
GPRS-3G/4G (optional)
Communication protocols OCPP
HMI 4.3” TFT color display, RFID (Mifare Classic 1K&4K, MifareDesFire WV1, NFC)
General information
Stand-by consumption <10W
Energy measurement 2 x MID Wattmeters
Operating temperature -25 ºC to 50 ºC
Humidity <95%
Maximum altitude 2000m
Weight 33kg (2 x Type 2) 24kg (2 x Type 2)
Dimensions (height x width x depth) 1400 x 320 x 215mm 800 x 320 x 215mm
Enclosure Galvanized steel
Protection class IP54 /IK10 (IK08 display)
Pollution degree PD3
Markings CE
Directives Low Voltage Directive: 2014/35/EU
EMC Directive: 2014/30/EU
(1) Manual or resettable protection depending on model
(2) Type B alternative exists
12
Unit description
Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
EN
ES
FR
IT
2.4. Power Sockets
CAUTION
The use of adaptors, converters or extenders for charging electric vehicles is not permitted.
These charging stations can be purchased with different connector and hose configurations relative to the client's
needs. They allow simultaneous charging of two vehicles, connecting them to either side of the charging point.
The most common configuration includes a single socket on each side, with it being possible to install a maximum
of two sockets on the right side. In this case, those two sockets cannot be used simultaneously.
The different available connectors are displayed below.
CEE 7/3 Type F CEE 7/5 Type E
IEC 62196-2 Type 3A IEC 62196-2 Type 2
Cable Type 1 Cable Type 2
13
Unit description Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
2.5. Protection
The charging station can have several protections according to the model, as described below.
CAUTION
In models that do not include protections (FS3NN/FW3NN), they must be installed upstream of the charger
so that each connection point is powered individually by a circuit that is protected by an overvoltage protection
device and a residual current device.
Q3
Q4
Q1
Q2
Q5
FS1MW / FW1MW (single phase with manual protections and
wattmeters)
Q3
Q4
Q1
Q2
Q5
FS3MW / FW3MW (three phase with manual protections and
wattmeters)
For both cases:
Q1: Main switch 80A
Q2, Q5: 30mA type A residual current circuit breaker
Q3, Q4: Curve C thermal magnetic circuit breaker
Q2 and Q3 protect the left power socket
Q4 and Q5 protect the right power socket
14
Unit description
Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
EN
ES
FR
IT
Q3
Q4
Q1
Q2
Q5
FS1AW / FW1AW (single phase with protections, residual
current device with automatic reset and wattmeters)
Q3
Q4
Q1
Q2
Q5
FS3AW / FW3AW (three phase with protections, residual
current device with automatic reset and wattmeters)
For both cases:
Q1: Main switch 80A
Q2, Q5: 30mA type A residual current circuit breaker
Q3, Q4: Curve C thermal magnetic circuit breaker
Q2 and Q3 protect the left power socket
Q4 and Q5 protect the right power socket
2.6. EMC requirements
These charging stations have the necessary filtering elements to comply with EMC requirements for domestic
applications in order to prevent disturbances in other equipment outside the installation.
2.7. Cabling accesses
At the lower part of the station there is a series of cable glands to insert the cabling inside.
15
Unit description Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
2.7.1. INGEREV FUSION Street
Lower view
B
A
C D
A Communications input. PG16, admitted cable
diameter 4~10mm
C Power supply input no. 1. PG40, admitted cable
diameter 16~28mm
B Communications output. PG16, admitted cable
diameter 4~10mm
D Power supply input no. 2. PG40, admitted cable
diameter 16~28mm
INFO
In the INGEREV FUSION Street ground stations, although it is preferable to insert the cabling through the
accesses indicated in this section, it is possible to uninstall the metal base where the cable glands are installed
in order to have a surface with greater access.
2.7.2. INGEREV FUSION Wall
Lower view
BA
C D
A Communications input. PG16, admitted cable
diameter 4~10mm
C Power supply input no. 1. PG40, admitted cable
diameter 16~28mm
B Communications output. PG16, admitted cable
diameter 4~10mm
D Power supply input no. 2. PG40, admitted cable
diameter 16~28mm
16
Unit description
Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
EN
ES
FR
IT
80 59 6330
17
Unit description Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
3. Receipt of the unit and storage
3.1. Reception
Keep the unit in its packaging until immediately before installation.
3.2. Unit identification
The serial number of the unit is its unique identifier. You must quote this number in any communication with
Ingeteam.
The unit’s serial number is marked on the specifications plate.
3.3. Transport damage
If the unit has been damaged during transport, proceed as follows:
1. Do not proceed with the installation.
2. Notify the distributor immediately within five days of receipt of the unit.
If ultimately the unit has to be returned to the manufacturer, the original packaging must be used.
3.4. Storage
CAUTION
Failure to follow the instructions in this section may lead to damage to the unit.
Ingeteam accepts no liability for damage resulting from the failure to follow these instructions.
If the unit is not installed immediately after reception, the following points should be taken into account in order to
avoid damage:
• The unit must be stored in its original packaging.
• Keep the unit free of dirt (dust, shavings, grease, etc.) and away from rodents.
• Keep it away from water splashes, welding sparks, etc.
• Cover the unit with a breathable protective material in order to prevent condensation due to ambient
humidity.
• Units in storage must not be subjected to weather conditions other than those indicated in section “2.3.
Specification table”.
• It is very important to protect the unit from chemical products which can cause corrosion, as well as from
salty atmospheres.
• Do not store the unit outdoors.
3.5. Conservation
In order to permit correct conservation of the units, they must not be removed from their original packaging until it
is time to install them.
In case of prolonged storage, use dry places, avoiding, as far as possible, sharp changes in temperature.
Deterioration of the packaging (tears, holes, etc.) prevents the units from being kept in optimum conditions before
installation. Ingeteam accepts no liability in the case of failing to observe this condition.
18
Receipt of the unit and storage
Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
EN
ES
FR
IT
4. Equipment transport
You must protect the unit, during transport, from mechanical knocks, vibrations, water splashes (rain) and any
other product or situation which may damage it or alter its behavior. Failure to observe these instructions may lead
to loss of warranty on the product, for which Ingeteam is not responsible.
4.1. Transport
Transport using a pallet truck
At least the following requirements should be observed:
1. Deposit the charging stations packaged and centered relative to the forks.
2. Try to place them as close as possible to the part where the forks and the steering unit meet.
3. In all cases, observe the instructions in the pallet truck’s user manual.
Transport using a forklift truck
At least the following requirements should be observed:
1. Deposit the charging stations packaged and centered relative to the forks.
2. Try to place them as close as possible to the part where the forks and the steering unit meet.
3. Ensure that the forks are perfectly level to avoid overturning the unit.
4. In any case, observe the instructions in the forklift truck's user manual.
Once the charging station has been transported to the place where it is to be located and only when it is to be
installed, unpack the station.
At this time, it can be transported vertically over a short distance without packaging.
Transport of the unpackaged unit
At least the following requirements should be observed:
1. Follow the necessary ergonomic advice for lifting weights.
2. Do not release the unit until it is perfectly secured or placed.
3. Ask someone else to guide the movements to be made.
4.2. Unpacking
Correct handling of the charging stations is vitally important in order to:
• Prevent damage to the packaging which enables them to be kept in optimum condition from shipping
until they are installed.
• Prevent the charging stations from receiving impacts and/or falling, which could deteriorate their
mechanical features.
• Avoid, as far as possible, vibrations which may cause subsequent malfunction.
• Disassemble the unit in horizontal position.
If you observe any anomaly, please contact Ingeteam immediately.
Separating the packaging
You can deliver all the packaging to an authorized non-hazardous waste management company.
In any event, each part of the packaging may be recycled as follows:
• Plastic (polystyrene, bag and bubble wrap): the appropriate container.
• Cardboard: the appropriate container.
19
Equipment transport Ingeteam

ABW2011IQM01_C - Installation and Operation Manual
5. Preparation for installing the unit
When deciding the location of the unit and planning your installation, you must follow a set of guidelines based on
the specifications of the unit.
5.1. Environment
• These units can be installed indoors and outdoors.
• Situate the units in a place that is accessible for installation and maintenance work, which permits them
to be operated and the indicator LEDs to be read.
• Avoid corrosive environments that may affect the proper operation of the unit.
• Do not leave objects leaning on the unit or against its sides.
• Keep the following minimum distances free of obstacles:
30 cm
30 cm 30 cm
30 cm
30 cm
30 cm
INGEREV FUSION Street INGEREV FUSION Wall
5.2. Environmental conditions
CAUTION
Ingeteam does not guarantee the proper operation of the equipment if the operation conditions for which it has
been designed are not fulfilled.
Avoid corrosive environments that may affect its proper operation. Do not install the unit in areas classified as
ATEX.
Environmental operating conditions indicated in section “2.3. Specification table” must be taken into account
when choosing the location of the unit.
20
Preparation for installing the unit
Ingeteam
