INIM Air2-Smarty/W Assembly instructions

Air2-Smarty/WWirelessindoorsounder/flasherInstallationandprogrammingmanual

Table of contents
1.DescriptionoftheAir2system 3
2.DescriptionofAir2-Smarty/W 4
2.1Descriptionofparts 5
2.2TechnicalspecificationsofAir2-Smarty/W 6
3.Sounder/flasherfunctions 7
3.1Typesofsignalling 7
3.2Sounder/flasheractivations 7
3.3Faultsandtampers 8
4.InstallationofAir2-Smarty/W 9
4.1Enrollingawirelessdevice 10
4.2Batteryreplacement 11
5.ProgrammingofAir2-Smarty/W 12
5.1Wirelesssounder/flasherparameters 12
5.2Real-time 13
5.3Programmingthepatterns 14
6.Generalinformation 16
6.1Aboutthismanual 16
6.2Manufacturer'sdetails 16
6.3NotesfromtheManufacturer 16
6.4SimplifiedEUDeclarationofConformity 16
6.5Warranty 17
6.6Limitedwarranty 17
6.7Documentsfortheusers 17
6.8Disposaloftheproduct 17
2Installation and programming manual- 102

Air2-Smarty/W| © 2021 Inim Electronics S.r.l. 3
1. Description of the Air2 system
TheadvancedAir2two-waywirelessintrusionprotectionsystem(868MHzfrequency)integratesdirectly
withallmodelsinINIMintrusioncontrolpanelrange.
DescriptionoftheAir2systemdevices:
lAir2-BS200/50 transceiver module, 50 terminals
lAir2-BS200/30 transceiver module, 30 terminals
lAir2-BS200/10 transceiver module, 10 terminals
lAir2-KF100/S 4 button remote-control key
lAir2-Ergo/S 4 button remote-control key
lAir2-Pebble/S 4 button remote-control key
lAir2-MC200 magnetic contact with shock and tilt sensor
lAir2-MC300 magnetic contact with two I/O terminals
lAir2-FD100 smoke detector
lAir2-Aria/Wkeypadwithgraphicdisplay
lAir2-Smarty/W indoor sounder/flasher
lAir2-Hedera outdoor sounder/flasher
lAir2-DT200Tdualtechnologycurtaindetector
lAir2-XIR200WPIRdetector,12m
lAir2-XDT200Wdualtechnologycurtaindetector
lAir2-UT100universaltransceiver
lAir2-ODI100Woutdoorwirelessdual-infrareddetector
lAir2-OTT100Woutdoorwirelesstriple-technologydetector
Technical specifications of Air2 system
Operating frequency
range 868.0-868.6MHz
selectable channels 868.1,868.3,868.5MHz
RF output power 25mWe.r.p.
Communication type Two-way
Modulation GFSK
Device monitoring from12to250minutes
NoteIn order to comply with the EN 50131-1 standards the alarm system supervision time must be below 120 minu-
tes.

2. Description of Air2-Smarty/W
2. Description of Air2-Smarty/W
TheAir2-Smarty/WwirelesssounderinterfaceswithINIMcontrolpanelsviatheAir2-BS200transceiverand
throughitiscontrolledandsupervisedbythecontrolpanel.
Thesounder/flashercanbeprogrammedfromthecontrolpanelviasoftwarethatallowstheconfigurationof
thevariousparameters(tone,maximumalarmtime,flashrate,signallingactivationmode,etc.)andtheacti-
vationofdifferentsignalsfordifferentevents.
Thecontrolpanel,viatheAir2wirelesssystem,isatalltimescapableofsupervisingtamper,lowbattery,
faultandbatterylevelsignalsl.
TheAir2-Smarty/Wprovidesself-diagnosticfunctionsforpromptidentificationoffaultsand,duringtheinstal-
lationphase,allowstheoperatortochoosethetypeofsignalforwireless-signallossevents.
ThesuperbrightLEDflasherofferslongautonomyandreducedpowerconsumptionandhastwoancillary
signalLEDs.
FunctionslPiezoelectrichorn
lSuperbrightLED-technologyflasher
l3.6V2.8Ahbattery
lOpen-enclosuretamperprotection
lTamper-protectiondevice
lIPProtectionrating30
lCommunicateswithAir2-BS200transceiver@868
lDirectcontrolviacontrolpanel
lBatterywithtestcircuit
lProgrammablesound-outputtime
l4programmablevolumelevels
lProgrammableflashersequence
lProgrammableflashertime
lSTATUSandPRGLEDsactivationviacontrolpanel
BatteryThesounder/flasherispoweredbya3.6V2.8Ah(ER17505M)batterytobelocatedinitshousinginsidethe
casingandconnectedupduringtheinstallationphase.
Thebattery may not be capable of meetingthedeclareddurationasthisdepends on how the soun-
der/flasherisemployedandthenumberandlengthofactivations.
Usedbatteriesmustbedisposedofinaccordancewiththeinformationprovidedintheleafletinsidethepac-
kage.
Package contentslAir2-Smarty/Wsounder/flasher
l2wallplugsformountingthebackplateandtamperbracket
lDrillingpattern
lInstallationmanual
l1batterytobeconnected
4Installation and programming manual- 102

Air2-Smarty/W| © 2021 Inim Electronics S.r.l. 5
2.1 Description of parts
2.1 Description of parts
[A]Locationsforthecoverpin
[B]Battery
[C]Batteryconnector
[D]ENROLLbutton
[E]Piezoelectrichorn
[F]Tampermicroswitch:Dislodgement
[G]Tampermicroswitch:Opencover
[H]RedSTATUSLED
[I]GreenPRGLED
[J]LEDflasher
[K]Coverscrew [L]Coverpin
[M]Cableentry
[N]Mountingscrewlocation
[O]Tamper-screwlocation

2. Description of Air2-Smarty/W
2.2 Technical specifications of Air2-Smarty/W
Warning device type Forindooruse,self-powered,typeW
Battery
type ER17505M3,6V2,8Ahwithconnector
estimated life 4years(dependingonactivations)
‘Low battery’ fault voltage Lessthan3.2V
Current draw
during standby 50µA
maximum 200mA
Acoustic output type tones
Sound pressure at 1m. 85dB(A)
Carrier frequency 1148Hz
Flash rate per minute (programmable) 36-56
Maximum alarm-time (programmable) 4min
Operating environmental conditions
Temperature from-10to+40°C
Relative humidity ≤93%withoutcondensation
Degree of protection IP30
Security grade 2
Environmental class II
Dimensions (W x H x D) 111x75x30mm
Weight 130g
(EN IEC 62368-1)
Terminal type BATTERY ES1,PS1
6Installation and programming manual- 102

Air2-Smarty/W| © 2021 Inim Electronics S.r.l. 7
3.1 Types of signalling
3. Sounder/flasher functions
TheAir2-Smarty/Wsounder/flasherprovidesvariousaudibleandvisualsignals.Thesignalswillactivateor
deactivateinaccordancewiththeprogrammedsettingsofthesounder/flasherortheconnectedcontrol
panel.Theparametersofeachsignalcanbeprogrammedindividually,combinedwithothersignals,ordeac-
tivated.
3.1 Types of signalling
FlasherThehighintensityluminoussignalisachievedbymeansofhigh-efficiencyLEDs(Description of parts, [J])
which,duetotheirextra-lowpowerconsumption,provideoptimumautonomy.
STATUS LED, PRG LEDThetwoLEDsonthesidesoftheflashercanbeusedforsignallingpurposesaswellasduringinstallation
operations(Description of parts, [H],Description of parts, [I]).
ThesetwoLEDs,ifsuitablyprogrammed,willsignaldevicefaultsandtamperevents.
Audible signallingThespeakeremits anaudiblesignal whichcanbe programmedfortone (3tonesavailable), duration,
volumeandassociatedevents.
3.2 Sounder/flasher activations
Air2-Smarty/Wsounders canbe activatedbothby signalsfrom theanti-intrusion controlpaneland by
eventsgeneratedbythesounderunititself.
Control-panel event activationsTheoccurrenceofcontrol-panelevents(activationsorresets)canactivateasounder/flasherandgenerate
signalling.
Eacheventcanbeassociatedwithoneormoresounder/flashers,configuredas‘Outputs’duringtheevent
programmingphase.Eacheventcanbeassociatedwithoneofthetonetypes(patterns)available.
Sounder/flasher eventsThesounder/flasherprocessesthesignalsdetectedbythedevicesitisequippedwith,insuchawayasto
generateeventstowhichoneormoresignalscanbeassociated:
lLowbattery
lOpencasing
lDevicedislodgement
lLossofwirelesscommunicationwiththecontrolpanel
lWirelessnoise

3. Sounder/flasher functions
NoteThe ‘Open casing’ event does not trigger audible signals when the connected intrusion control panel is operating
in ‘Programming’ mode.
DeactivationsSignallingwillceasewhenoneofthefollowingconditionsoccurs:
lDeactivationsfromthecontrolpanel:
lwiththe‘Stopalarms’shortcut
lbyaccessingmaintenancemode
lbypre-setdisarmscenarios
lwiththeeventsassociatedwiththecausesofshutdown
lThealarmconditionclears
lThemaximumalarmtimeexpires
Ifanalarmconditionexceedsthemaximumsoundersignallingtime,thesignallingwillbeinterrupted.
3.3 Faults and tampers
TheSTATUSandPRGLEDswillsignalfaultortamperconditionsonthesounder/flasheronlywhensetup
todosoduringtheprogrammingphase.
NoteThis type of activation prevents the control panel from activating the LEDs.
Thissignallingconsistsofaseriesofflashes.Ifseveralconditionsaredetectedsimultaneously,bothLEDs
arecapableofsignallingtheeventsconsecutively.
LEDs Number of blinks Event
STATUS
1
Fault
Lowbattery
2 Lossofcommunicationwiththecontrolpanel
PRG 1 Tamper Opencasingtamper
Dislodgementtamper
Faultsignallingwillstopautomaticallywhenthecauseofthefaultclears.
8Installation and programming manual- 102

Air2-Smarty/W| © 2021 Inim Electronics S.r.l. 9
4. Installation of Air2-Smarty/W

1. Chooseasuitablemountingplacement.
The  sounder/flasher  must  be  installed  high  up  on  a  flat  surface/wall.
Ferromagneticmaterialswhicharelocatedinthevicinityofthemountingpositioncaninfluencethemagne-
ticfieldandcanresultinthereducedoperatingcapacityofthedevice.
2. Removethecoverbyfirstunscrewingthescrewthenliftingthecatchonthebase(Description of
parts, [K]).
3. Usingthewallplugs,attachthebasetothewall.
4. Insertthetamper-protectionscrewintoitslocation(Description of parts, [O]).
5. ConnectthebatterytotheconnectoronthePCB(Description of parts, [C])andplaceitinitshousing.
TheSTATUSLEDwillalternate5flashesand5secondpauses(waitingtobeenrolled).
6. Enrollthedevice.
TheSTATUSLEDwillalternate3flashesand3secondpauses(waitingforthedislodgement/Opentamper
devicetoclose).
7. Closethecoverbypositioningthepininitslocationonthebase,thenturnituntilthecatchclicksclo-
sed.
TheSTATUSLEDwillflashwithafrequencyofoneflashpersecondfor15seconds.
TheSTATUSLEDwillstopflashingandthesounder/flasherwillbereadytooperate.

4. Installation of Air2-Smarty/W
4.1 Enrolling a wireless device
TheenrollingprocessallowsyoutoassociateanINIMwirelessdevicewiththeAir2-BS200transceiverthat
connectstotheanti-intrusioncontrolpanel.
Thisprocedurevariesdependingonthecontrolpanelinuseandtheprogrammingsoftwareorapplication:
1. Accessthecontrol-panelprogrammingsection.
2. Selectthedevicetobeenrolledinaccordancewithitstype:
laninputterminal,foradetector(motiondetector,magneticcontact,etc.)
lanoutputterminal,foranoutputdeviceconnectedtoaterminaloftheAir2-MC300magnetic
contact
lakeypad
lasounder/flasher
lakey,foraremotecontroldevice,selectingastheassociatedreadertheonesimulatedbythe
transceiver
3. Setthedeviceas‘Wireless’.
4. Startthelearningphasefromthecontrolpanel.
5. PresstheENROLLbuttononthewirelessdevice.
Via Prime/STUDIO software application
Oncethesolutionforthesystemtobedesignedhasbeenopened,clickonthe
System Layout buttononthemenuontheleft.Theninthesectionontherightclick
ontheAdd device on BUSbutton.
Awindowopenswhereyoucanselectthedevicestobeconfiguredandaddthemtotheconfiguration.

Inthesectionontheleftyoucanincreasethenumberusingthebuttoncorresponding
totheselecteddevicetype.
Toremoveadevicefromthestructure,workthroughtheAdddeviceprocedure,but
insteaddeselectthedeviceyouwanttoremove
Alternatively,youcanaccesstheprogrammingsectionbyclickingontherelevantbuttononthemenuonthe
left,andfromthelistthatappearsclickontheDeletebuttonthatcorrespondstothelineofthedevicetobe
removed.
Byclicking-onSoundersinthemenuontheleft,itwillbepossibletoselectthesinglesounderfromthe‘Pro-
gramming-ConfiguredSounders’section.
Thecheckboxnexttothatofthesounder/flasherdescriptionallowstheselectionofthesounder/flasher
type:
lHardwiredsounder/flasher
lIndoorwirelesssounder/flasher
lOutdoorwirelesssounder/flasher
If‘wireless’isselectedasthesounder/flashertype,theprogrammingsectionwillprovidetheLearn button
thatinitializestheenrollingprocess.
Via keypadEnrollingofwirelessdevicesispossiblebyenablingthemenuoptionsintheinstallermenusection:
Type in Code (Installer), PROGRAMMING Sounders/Flashers, Enable/Disable
