INNOBIZ musilia User manual

EN
ESSENTIAL OIL DIFFUSER WITH INTEGRATED BLUETOOTH
Instructions for use
1

- Before you use the devices, read carefully and
keep the operating instructions described below.
Always make sure that you properly handle the
devices. Throughout this instruction manual,
the term «device» refers to the diffuser and its
accessories.
- If you notice a burning smell or the product
shows other signs of signicant malfunction,
immediately disconnect the power cord from
the electrical outlet. Wait until the burning smell
dissipates, then contact your retailer.
- If the device falls, disconnect the power cord
from the electrical outlet.
- Maintain the essential oil diffuser with an appro-
priate cleaner available at your retailer.
- Do not try to disassemble or modify the devices.
You will be exposed to hazards and your parts and
EN
Instructions for safe use
2

labour warranty would become invalid.
- Do not bend, twist or pull the power cord, this
may damage it and cause a re or electrical
shock hazard.
- Do not place heavy objects on the devices.
- Do not obstruct the diffuser output of your
device.
- Do not use the devices in areas that are smoky,
humid, dusty, or subject to strong vibrations.
- Do not expose the devices to high temperatures.
- Keep the devices out of the reach of children.
- Do not use the devices near an open ame.
- Do not use the devices in a humid atmosphere.
Do not immerse the devices in water.
- Carefully observe the precautions for use provi-
ded with the bottles of essential oils.
- Do not overll the essential oil diffuser. They
could stain the furniture on which they are placed.
3

- Maintain the essential oil diffuser with an appro-
priate cleaner available at your retailer.
- Do not place the diffuser on an inclined or
unstable piece of furniture. It could fall, break and
cause injury.
- This device can be used by children 8 years
of age and older and by persons with limited
physical, sensory or mental abilities or without
experience or knowledge of the device, if they are
properly supervised or if the instructions relating
to the safe use of the device were given to them
and the associated risks were understood.
- Children must not play with this device.
- Cleaning and maintenance must not be perfor-
med by unsupervised children.
- Only use substances recommended for diffusion
in the device. Using other substances may cause
a toxic hazard or risk of re.
- The device may only be used with the power
4

adapter provided.
- Unplug the device before handling or mainte-
nance. Make sure that it has been emptied of any
liquid or substance for diffusion.
- The device must only be powered using very low
voltage for safety reasons, which corresponds to
the device marking.
- If the power cable is damaged, it must be
replaced with a cable or special kit available from
the manufacturer or after sales support.
- Unplug the device whilst lling or cleaning.
- Do not put too much water. Observe the maxi-
mum lling level indicated by the mark on the
device. In case of surplus, empty the excess and
immediately wipe with a soft cloth the plastic
parts that may have been in contact with the
water and essential oil.
- Use a cloth dampened with water and white
vinegar to clean and descale your device. Then
5

dry it with a soft clean cloth.
- When using the device, pay attention to the
emission of hot water vapour.
The crossed-out wheelie bin symbol affixed to the product or its
accessories indicates that they are classified as electrical and elec-
tronic equipment.
As such, the European regulations require it is collected separately
from other waste:
- by distributors, if an equivalent product is purchased,
-using the locally-available collection facilities (waste reception centre,
separate collection, etc.).
In this way, you will be helping to reuse and recycle Waste Electrical
and Electronic Equipment that could have potentially harmful effects
on the environment and on human health.
This appliance satisfies the European Community requirements
concerning safety, hygiene, the environment and consumer protection.
6

What is aromatherapy ?
Aromatherapy is the use of aromatic essential oils for your well-
being. Essential oils are extracted from the bark of trees, ower
petals, roots, stems and the fruit of unique medicinal plants to
offer you all their benets.
Quick start:
Simply ll the tank of your diffuser with tap water and add a few
drops of 100% pure and natural essential oil. Press the diffuse
button and instantly transform your environment by bringing the
serenity of nature directly into your home or ofce.
How do ultrasonic essential oil diffusers work?
This essential oil diffuser uses a silent ultrasonic technology to
create vibrations in the water. Without generating heat, these
vibrations create a mist of ne particles of water and essential
oil, which diffuse into the air, thus making you enjoy the natural
benets and pleasant scent of the oils.
EN
What is aromatherapy ?
7

1. Mist outlet
2. Lid
3. Maximum water level
4. Ceramic Disc
5. Water tank
6. Air outlet
7. Bluetooth button
8. Diffuse button
9. Air inlet
10. Connecting the USB cable
11. USB cable
EN
Description of items
8

EN
Use
Water
essential oil
1. Remove the lid.
2. Add about 70 ml of tap water to the tank.
3. NOTE: Do not exceed the maximum water line.
4. Add 5 to 10 drops of essential oil to the tank.
5. Replace the cover.
6. Connect the USB cable under the diffuser and to a USB
socket, or the supplied adapter.
7. Follow the diffuse button and Bluetooth®instructions.
9

EN
Use
DIFFUSE BUTTON
1st push: Continuous diffusion/ colour light
Add the drawings from the changing original instructions.
2nd push: Continuous diffusion without light.
3rd push: Intermittent diffusion (15 sec. ON/ 15sec. OFF) and
changing light colour.
4th push: Intermittent diffusion without light.
5th push: Shutdown.
Diffusion will stop automatically when the tank is empty.
When the tank is full (70ml), the diffuser will be able to diffuse
for about 4 hours streaming and
about 8 hours in intermittent
diffusion.
NOTE: Do not lean it, move it, or
try to empty or ll the device while
it is plugged in.
BLUETOOTH BUTTON
Turn on the Bluetooth®app on your device.
Press and hold the Musilia Bluetooth®button for two seconds.
The blue LED light will ash.
Select the name of the Bluetooth connection “HUMMINGBIRD“
on your device to connect to it.
To turn off the Bluetooth®function, press and hold the Musilia
Bluetooth®softkey for ve seconds.
10

EN
Maintenance
Specications
To ensure the proper operation of the diffuser, it is recommended
to clean it when changing the oil, or every three days.
Unplug the diffuser from the mains before cleaning.
Use a damp cloth to clean the outside of the unit.
Use a cotton swab or rag to clean the water tank.
Prevent water from entering the air outlet.
Do not use aggressive detergents, solvents or abrasives to clean
the diffuser.
Use the diffuser on a dry, level surface.
Model: USB Bluetooth®
Capacity: 70 ML
Voltage: DC 5V
Speaker output: 3 Watts/ 4 Ohms
Frequency response: 160 HZ-18K HZ
11

EN
Repairs
Malfunctions Possible origins Solutions
The diffuser is not
connected. Plug in the diffuser and turn it on.
There is not
enough water. Rell the tank.
Do not use demine-
ralised water Use tap water
There is too much
water (water level
above the maxi-
mum red mark).
Empty the surplus
water.
The ceramic disc
may be dirty.
Clean the ceramic
disc with white vi-
negar and a cotton
swab, also clean
the tank.
The lid is not
closed properly. Close the lid properly.
The air inlet
is clogged or
congested.
Make sure the air
inlet is clean and
free.
The air outlet
is clogged or
congested.
Ensure the air
outlet is clean and
free.
The diffuser is not
working, there is
no mist or less
steam than usual
12

Malfunctions Possible origins Solutions
No Bluetooth
connection
Your device does
not work with the
diffuser.
Check that your
device’s Bluetooth
is activated and
that it is clearly vi-
sible. Ensure that
the diffuser is not
already linked to
another device.
Select the name
of the Bluetoo-
th connection
“HUMMINGBIRD»
on your device to
connect to it.
13
