Innova IN-8012 Instruction Manual

MU8012-012ENG rev05
INSTRUCTION AND SAFETY MANUAL FOR
T-SHAPED UNIVERSAL BASE SYSTEM FOR XTIRPA
VEHICLES AND COUNTERBALANCED TRUCKS
UNIVERSAL RESCUE SYSTEM
IN-8012
INNOVA Public Utility Products Inc.
1040 Boulevard Industriel, Granby, Québec, Canada
Tel [phone] Fax [phone] www.xtirpa.com
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE

Produced at: GRANBY, Québec Canada, March 27th 2020
____________________________________________________
Michael Parker
Quality Manager
EC DECLARATION OF CONFORMITY (English)
Manufacturer established in the community:
Produits de Services Publics INNOVA inc.,
1040, boul. Industriel, Granby, Québec, Canada J2J 1A4
Declares that the following PPE product:
IN-8012 XTIRPATM Universal T-base system for 102mm (4") mast for PPE
is in conformity with the provisions of the regulation (EU) 2016/425 and complies to the standard:
Personal fall Protection Equipment type B and E EN 795: 2012
is identical to the PPE product which was submitted to the EC Certificate of Conformity no: 2754/1363/160/04/20/1
368
and 2754/1363/160/04/20/1369 delivered by:
ALIENOR CERTIFICATION (2754)
21 rue Albert Einstein
ZA du SANITAL
86100 CHÂTELLERAULT- France
is submitted to the article 19c (module C2) of the regulation (EU) 2016/425, under the supervision of the notified body:
ALIENOR CERTIFICATION (2754)
21 rue Albert Einstein
ZA du SANITAL
86100 CHÂTELLERAULT- France

MU8012-012ENG rev05 3
INTRODUCTION
WARNING
The XTIRPA system is part of a personal protection equipment system for fall protection,
work positioning, personnel handling, materials handling, or rescue, for use in conned
spaces.
The user must read, understand and follow the Manufacturer’s instructions for each com-
ponent or part of the complete XTIRPA system. These instructions must be provided to the
user of the XTIRPA system. The user must read and understand these instructions before
using the XTIRPA system. The manufacturer’s instructions must be followed for proper
use and maintenance of this product. Alterations or misuse of the XTIRPA system or of
any component or part thereof or failure to follow instructions may result in serious injury
or death, for which the manufacturer disclaims all warranties and liabilities whatsoever,
user, owner and purchaser of the XTIRPA system waiving all claims, rights and recourses
against the manufacturer and derived therefrom.
The XTIRPA System was designed for persons needing a personal protection equipment sys-
tem for fall protection, work positioning, personnel handling, materials handling, or rescue, for
use in conned spaces. The XTIRPA System is intended to act as a support structure or anchor
for these uses. Due to its design and the use of an advanced composite, the XTIRPA System is
one of the lightest and most ergonomic systems of its kind on the market. The XTIRPA System
is in compliance with ANSI, OSHA, CSST and CE standards. The equipment has been tested in
accordance with applicable requirements of the standard EN 795:2012 Type A, Type B as well
as Type E and TS16415: 2013.
IMPORTANT: The buyer must complete and return the limited warranty registration form.
Always keep this instruction and safety manual available to any worker needing to use the XTIR-
PA system.
Before each use, the user must read, understand and follow the manufacturer’s instruction and
safety manual.
Keep instructional and safety labels a󰀩xed to the XTIRPA system and its components and parts
clean and legible at all times. Clean or replace if required. New labels can be obtained upon
demand.
Establish a regular training program on the XTIRPA system for new & experienced workers, as
further recommended in this instruction and safety manual. Establish a detailed inspection pro-
gram for the XTIRPA system and document ndings, as further recommended in this instruction
and safety manual. Always inspect the XTIRPA system before each use and at least once a year
by a competent person.
The XTIRPA system and its components and parts have labels indicating the maximum capac-
ity of each. Exceeding said maximum capacity may result not only in damages to the XTIRPA
system or its components or parts but also in serious injury or death, for which the manufacturer
disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA
system waiving all claims, rights and recourses against the manufacturer derived therefrom.
The XTIRPA IN-8012 universal safety system, including the following components: IN-2240

MU8012-012ENG rev054
(Mast for fall protection and retrieval); IN-2313 (102mm (4’’) Mast for Davit-Arm IN-2237 1524mm
(60’’) height); IN-2426 (Mast for davit arm 30’’ to 48’’ 500mm (19.7) high); IN-2237 (Extendable
davit arm for fall protection and retrieval); IN-2305 (T-shaped universal base for 102mm (4”)
mast); A2305-40 (2438mm (96”) extension tube for counterbalanced truck); A2305-07 (Coun-
terbalanced truck); IN-2525 (Fall arrest counterweight cart), a2305-90 (counterweight sup-
port), A2305-12 (Anchor adaptor for T-shaped universal base); A2305-20 (63.5-51mm(2.5-2”)
coupling reducer for T-shaped base extension); A2305-25 (T-shaped base union for 1829mm
(72”) extension); A2305-29 (90-degree extension); A2305-16 (1829mm (72”) extension for
63.5mm(2.5”) T-shaped base coupling); A2305-55 (Adaptor for vehicle coupling); A2305-65
(Ballast support assembly); IN-2517 (Hitch adapter for Europeam Vehicle), complies with docu-
ment number MU8012-012ENG rev04.
Aienor certication (CE2754), ZA du SANITAL, 21 rue Albert Einstein, 86100 CHÂTELLERAULT
France is the notied body in charge of module B certication and module C2 production control.
DESCRIPTION & INTERPRETATION OF
MARKING SYMBOLS
This symbol is used to alert the user to a potential hazard. The safety of the worker
is in jeopardy. It is imperative to follow the manufacturer’s recommendations.
This symbol asks the user to read and understand the manual for this product
before use.
This symbol species that the system can be used simultaneously by a maximum
of 3 users.
Anchorage hardware must be qualied and experienced personnel. The installer
must follow the anchorage hardware manufacturers recommendations at all times.
Periodic inspections of hardware must be done. In the occurrence of a fall or the
safety of the equipment is in doubt, equipment must be immediately removed from
service and inspected by qualied personnel before reuse.
Maximum permissible arresting force (MAF) .
The positioning pins must always be in place when manoeuvering personnel. Oth-
erwise, serious injuries may occur.
Adaptors are designed to function only with the XTIRPA equipment or approved
by the manufacturer.
-1-

MU8012-012ENG rev05 5
APPLICATION
The XTIRPA system, and its many components and parts (including davit arm, manhole guard,
removable adapter, permanent adapter, integrated mast and side entry cart), are intended to be
used as part of a personal protection equipment system for fall protection, work positioning, per-
sonnel handling, materials handling, or rescue, for use in conned spaces. The XTIRPA system
is intended to act as a support structure or anchor for these uses.
-2-
RESTRICTIONS
a) CAPACITY: The maximum working load (CMT) of this product is 360lbs (164kg). According
to CE (EN 795: 2012 and TS16415: 2013), use an EN-360 fall arrest system and / or EN-363
or EN-1496 recovery system.
b) The manufacturer attests that anchoring devices have been tested accordingly to the current
European standard (EN 795:2012 Type A, Type B and Type E and et TS16415 : 2013) and,
except otherwise stipulated, they are to be used by a single person per anchor point, using
a shock absorber in accordance with regulation EN 355.
c) PRECAUTIONS: Take the necessary precautions to limit injuries to the user and risks of
damaging the XTIRPA system.
d) Use of the XTIRPA system in areas where environmental hazards exist may require addition-
al precautions to limit the possibility of injury to the user or damage to the XTIRPA system.
Hazards may include, but are not limited to: high heat, re, ame, smoke, fumes, caustic
chemicals, corrosive environments, high voltage power lines, sudden changes of pressure,
explosive or toxic gases or substances, water or risks of ooding, risks of wall, ceiling or oor
collapsing, moving machinery and sharp edges.
WARNING: The system should be used on a surface that does not contain contamination
such as: oil, grease, or other products that could make the system unstable.
WARNING: The a2305-65 equipment should not be used when it freezes or there is a
risk of frost.
e) Install and secure all signaling and other precautionary and security measures, including but
not limited to, notifying users, bystanders and vehicle operators circulating near the XTIRPA
system of the presence of the XTIRPA system and its workers, before starting work.
f) Wear all appropriate certied and recommended security equipment such as, but not limited
to, hard hat, protective eyewear, leather gloves, protective clothing, work boots, harness in
accordance with EN 361, ashlight and respiratory device if needed.
WARNING: Equipment shall not be used past its capacity, or in any other applications for
which the equipment was not designed.

MU8012-012ENG rev056
WARNING: The equipment should only be used by trained and competent persons to
ensure safe use of this product.
g) Always work in teams of at least two (2) people: 1 attendant and 1 conned space work-
er (the person attached to the lifeline cable or rope). These people must be qualied and
trained on the XTIRPA system. They must have read and understood this instruction and
safety manual before using the XTIRPA system. One person works in the conned space
(the user attached to the lifeline cable or rope) and the other (attendant) pays out the line
and reels it in, keeps in contact with the person inside and remains available in case of any
emergency. The attendant makes sure, at all times, that the user who is tying his lifeline ca-
ble or rope to his harness is in the right position. The attendant also assures that the XTIRPA
system is well in place and that no load imbalance is possible.
IMPORTANT: During installation of the system, it is important to ensure stability through-
out.
h) Use only a certied full body harness in accordance with EN 361 and lifeline cables and
ropes for any user of the XTIRPA System, with appropriate specications designed and rec-
ommended for use in specialized work conditions such as those for which the XTIRPA Sys-
tem is intended to be used as per this instruction and safety manual. For the installation of
lifeline cables and ropes on the certied 14kn anchor points of the davit arm, see section 6.
IMPORTANT: When used as PPE, the system must be tted with a device limiting the
dynamic forces exerted on the user to a maximum of 6kN (1320 LbF).
i) Plan your work program before starting. Have the required equipment, procedures and peo-
ple, which must be qualied and trained on the XTIRPA system and who must have read and
understood this instruction and safety manual before using the XTIRPA system, available
to do the job.
j) Keep all instructional and safety labels a󰀩xed on the XTIRPA system and its components
and parts clean and legible at all times. Clean or replace if required. New labels can be
obtained upon demand.
IMPORTANT: If the markings on the anchoring device are not legible after installation,
it is recommended that supplementary markings next to the anchoring device be made.
WARNING: No modications or additions to the equipment shall be performed without the
authorization of the manufacturer, and all repairs shall be done as indicated by the operat-
ing procedure of the manufacturer.
WARNING: It is established and agreed that the equipment (system) is reserved for the
use of three persons maximum.
k) Do not exceed 360 lbs (164 kg) per anchor, the maximum workload (CMT) of the system.

MU8012-012ENG rev05 7
l) Follow all applicable laws, regulations and standards for work, entry and exit in conned
spaces.
m) A person who has not read this instruction and safety manual, has not been trained in using
the XTIRPA system and does not understand all operation, safety, maintenance, servicing
and storage instructions contained in this instruction and safety manual and in any other
recommendations provided by the manufacturer or its certied trainers is not qualied to op-
erate the XTIRPA system and does it at their sole risk, therefore waiving any and all claims,
rights and recourses against the manufacturer and derived therefrom.
n) Make sure to conform to relative demands regarding anchoring devices (E.g.: oor adapter,
wall adapter, etc.) or ensure that the chosen structure that will be used has an anchoring
point, and keep in mind minimal required resistance, equivalency and position.
WARNING: Anchoring devices must be installed only by competent persons or organiza-
tions.
o) The maximum force applied by the system on the structure is a vertical force of 14kN accord-
ing to EN362, EN795: 2012 CE and TS16415: 2013 on the anchorage to which the system
is hooked.
WARNING: The system must be appropriately checked, for example, by calculations or
tests.
WARNING: The use of a base, structural anchor or fastener, if one exists, must be taken
into account when calculating the amount of force supported by the anchor during strength
and integrity testing.
p) A rescue plan shall be put in place in order to account for all likely emergencies that could
occur while working.
WARNING: Any modication or addition to the equipment cannot be done without the prior
written consent of the manufacturer, and any repairs must be undertaken in accordance
with the manufacturer’s procedures.
WARNING: It is established and agreed that the equipment (system) is reserved for the
use of three persons maximum.
WARNING: It is important to place the XTIRPA system on a hard and level surface. Do not
use the XTIRPA system on a soft surface, including, but not limited to, sand, grass, gravel
and rocks. If you have any questions about use or maintenance or whether the XTIRPA
system is appropriate for your job, please contact the Manufacturer PSP INNOVA INC.

MU8012-012ENG rev058
WARNING: For safety reasons, make sure when using the anti-drop system that you have
enough space under the user, so as to avoid injury. If a fall occurs, there should be enough
space to avoid a collision with the ground or any obstacle. See the diagram in Section 8
for calculating this distance.

MU8012-012ENG rev05 9
-3-
XTIRPA SYSTEM REQUIREMENTS
IMPORTANT: If you have questions on the use, care or suitability of the XTIRPA system
for your application, please contact the manufacturer INNOVA Public Utility Products Inc.
IMPORTANT: Record the product identication information from the ID label in the main-
tenance and inspection log of this instruction and safety manual.
IMPORTANT: Record purchasing date and also date of rst use on the maintenance and
inspection log sheet included in this safety instruction manual.
IMPORTANT: In the event that a handling/positioning hoist is required, this option is of-
fered to you with the addition of an adaptor located at the bottom of the davit arm. Installa-
tion steps 10, 11 and 12 for the lifeline/hoist will need to be repeated. If you have questions
regarding the use, maintenance or appropriateness of the XTIRPA system for your appli-
cation, please contact the manufacturer PSP INNOVA INC.
a) The XTIRPA system is intended to be used as part of a personal protection equipment sys-
tem for fall protection, work positioning, personnel handling, materials handling, or rescue,
for use in conned spaces. The XTIRPA system is intended to act as a support structure
or anchor for these uses. The XTIRPA system must be used only with adapters, anchors,
connectors (EN 362), and other components, parts or subsystems that have been certied,
approved and recommended by the manufacturer.
WARNING: This system should never be used to transport persons and material at the
same time.
b) Substitutions or replacements made with non-approved adapters, anchors, connectors (EN
362), other components, parts or subsystems may be incompatible, may jeopardize the safe-
ty and reliability of the complete XTIRPA system and may result in serious injury or death,
for which the manufacturer disclaims all warranties and liabilities whatsoever, user, owner
and purchaser of the XTIRPA system waiving all claims, rights and recourses against the
manufacturer derived therefrom.
c) Connectors (EN 362) (hooks, carabiners, D-rings) must comply with EN362.
d) Make sure the lifeline cable or rope is positioned directly over the work area. Use only cer-
tied lifeline cable or rope, in perfect working condition, with appropriate specications, in-
cluding maximum leverage capabilities, for the intended use of the XTIRPA system.
e) Owners must make sure that, before each use, all users of the XTIRPA system have read,
understood and follow the Manufacturer’s Instructions and safety manual.
f) Owners must also make sure that all users have successfully been trained in using the XTIR-
PA system, before allowing them to use the XTIRPA system, and at least annually thereafter.

MU8012-012ENG rev0510
IMPORTANT: When used, the expandable coupling system for XTIRPA vehicles and
counterbalanced trucks must be lifted using the adjustable supporting legs. The transport
wheels must not be in contact with the ground.
g) A person who has not read the Instruction and safety manual, has not been trained in using
the XTIRPA system and does not understand all operation and safety instructions, is not
qualied to operate the XTIRPA system. An untrained user exposes himself and others to
possible serious injury or death, for which the manufacturer disclaims all warranties and
liabilities whatsoever, user, owner and purchaser of the XTIRPA system waiving all claims,
rights and recourses against the manufacturer derived therefrom.
h) Refer to and follow all EN standards or other local standards and regulations. Observe all the
requirements of your local regulations for your applications.
i) See other important operation instruction and safety information contained hereafter in this
instruction and safety manual.
j) It is imperative to supply all information in su󰀩cient quantity to assure that di󰀨erent equip-
ment articles are compatible when assembled as a system.
WARNING: It is possible that a hazard may occur while using multiple components, as
one of them could a󰀨ect the safety function of the system, if the safety function of one
component can be a󰀨ected by that of another component.
WARNING: It is essential for the safety of the user, if the product is resold to a destination
outside the rst country, that the reseller supplies the instruction manual, maintenance
instruction log sheet for the periodic inspections and all associated repair instructions
written in the native language of the country in which the product will be used. It is also
required to supply all specic additional information for the equipment.
WARNING: Any persons with a medical condition which could cause a hazard to the user
during normal operation and in emergency situations should avoid using the system.
k) Life expectancy of the XTIRPA system and its components will be determined based on the
conclusions of periodic and monthly inspections which will determine whether or not the
product may remain in service.
WARNING: It is likely that a danger may arise when using several articles in which the
security function of one of the articles is a󰀨ected by the security function of another article
or interferes with it.
