Innova XTIRPA IN-8016 Instruction Manual

MU8016-012ENG rev02
INSTRUCTION AND SAFETY MANUAL
XTIRPA DAVIT ARM AND MAST SYSTEM FOR PPE
UNIVERSAL RESCUE SYSTEM
IN-8016
INNOVA Public Utility Products Inc.
1040 Boulevard Industriel, Granby, Québec, Canada
Tel [phone] Fax [phone] www.xtirpa.com
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE

MU8016-012ENG rev02 3
INTRODUCTION
WARNING
The XTIRPA system is part of a personal protection equipment system for fall protection,
work positioning, or rescue, for use in conned spaces.
The user must read, understand and follow the manufacturer’s instructions for each com-
ponent or part of the complete XTIRPA system. These instructions must be provided to the
user of the XTIRPA system. The user must read and understand these instructions before
using the XTIRPA system. The manufacturer’s instructions must be followed for proper
use and maintenance of this product. Alterations or misuse of the XTIRPA system or of
any component or part thereof or failure to follow instructions may result in serious injury
or death, for which the manufacturer disclaims all warranties and liabilities whatsoever,
user, owner and purchaser of the XTIRPA system waiving all claims, rights and recourses
against the manufacturer and derived therefrom.
The XTIRPA system was designed for persons needing a personal protection equipment system
for fall protection, work positioning, or rescue, for use in conned spaces. The XTIRPA system is
intended to act as a support structure or anchor for these uses. Due to its design and the use of
an advanced composite, the XTIRPA system is one of the lightest and most ergonomic systems
of its kind on the market. The XTIRPA system is in compliance with ANSI, OSHA, CSA and CE
standards. The equipment has been tested in conformance with applicable requirements of the
EN 795:2012 Type A and TS16415 : 2013 standard.
IMPORTANT: The buyer must complete and return the limited warranty registration form.
Always keep this instruction and safety manual available to any worker needing to use the XTIR-
PA system.
Before each use, the user must read, understand and follow the manufacturer’s instruction and
safety manual.
Keep instructional and safety labels a󰀩xed to the XTIRPA system and its components and parts
clean and legible at all times. Clean or replace if required. New labels can be obtained upon
demand.
Establish a regular training program on the XTIRPA system for new & experienced workers, as
further recommended in this instruction and safety manual. Establish a detailed inspection pro-
gram for the XTIRPA system and document ndings, as further recommended in this instruction
and safety manual. Always inspect the XTIRPA system before each use and at least once a year.
The XTIRPA system and its components and parts have labels indicating the maximum capac-
ity of each. Exceeding said maximum capacity may result not only in damages to the XTIRPA
system or its components or parts but also in serious injury or death, for which the manufacturer
disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA
system waiving all claims, rights and recourses against the manufacturer derived therefrom.
The XTIRPA Universal Safety system, IN-8016 including various adapter options, mast exten-
sion, conforms to document number MU8016-012ENG rev02.
APAVE SUDEUROPE SAS (Headquarters: 8 rue Jean-Jacques Vernazza—Z.A.C. Sau-
maty-Séon - CS 60193 - 13322 MARSEILLE CEDEX 16) is the notied body involved in the

MU8016-012ENG rev024
initial production and certication control phase.
DESCRIPTION & INTERPRETATION OF
MARKING SYMBOLS
This symbol is used to alert the user to a potential hazard. The safety of the worker
is in jeopardy. It is imperative to follow the manufacturer’s recommendations.
This symbol asks the user to read and understand the manual for this product
before use.
This symbol species that the system can be used simultaneously by a maximum
of 2 users.
Anchorage hardware must be qualied and experienced personnel. The installer
This symbol species that the system should be used by a single user.
Periodic inspections of hardware must be done. In the occurrence of a fall or the
safety of the equipment is in doubt, equipment must be immediately removed from
service and inspected by qualied personnel before reuse.
Maximum permissible arresting force (MAF) .
The positioning pins must always be in place when manoeuvering personnel. Oth-
erwise, serious injuries may occur.
Adaptors are designed to function only with the XTIRPA equipment or approved
by the manufacturer.
-1-
APPLICATION
The XTIRPA system, and its many components and parts (including davit arm, manhole guard,
movable adapter, permanent adapter, integrated mast and side entry cart), are intended to be
used as part of a personal protection equipment system for fall protection, work positioning, per-
sonnel handling, materials handling, or rescue, for use in conned spaces. The XTIRPA system
is intended to act as a support structure or anchor for these uses.

MU8016-012ENG rev02 5
-2-
RESTRICTIONS
a) CAPACITY: The maximum working load (CMT) of this product is 360lbs (164kg). According
to EN 795: 2012 and TS16415: 2013, use an EN-360 fall protection system and / or EN-363
or EN-1496 recovery system.
b) The manufacturer certies that the anchoring devices have been tested in accordance with
this European standard (EN 795: 2012 Type A and TS16415: 2013) and that, unless indicat-
ed otherwise, they are suitable for use by a single person, by anchor point, with an energy
absorber in accordance with EN 355.
c) PRECAUTIONS: Take the necessary precautions to limit injuries to the user and risks of
damaging the XTIRPA system.
d) Use of the XTIRPA system in areas where environmental hazards exist may require addition-
al precautions to limit the possibility of injury to the user or damage to the XTIRPA system.
Hazards may include, but are not limited to: high heat, re, ame, smoke, fumes, caustic
chemicals, corrosive environments, high voltage power lines, sudden changes of pressure,
explosive or toxic gases or substances, water or risks of ooding, risks of wall, ceiling or oor
collapsing, moving machinery and sharp edges.
e) Install and secure all signaling and other precautionary and security measures, including but
not limited to, notifying users, bystanders and vehicle operators circulating near the XTIRPA
system of the presence of the XTIRPA system and its workers, before starting work.
f) Wear all appropriate certied and recommended security equipment such as, but not limited
to, hard hat, protective eyewear, leather gloves, protective clothing, work boots, harness in
accordance with EN 361, ashlight and respiratory device if needed.
WARNING: Equipment shall not be used past its capacity, or in any other applications for
which the equipment was not designed.
WARNING: The equipment should only be used by trained and competent persons in
order for this product to be used safely.
g) Always work in teams of at least two (2) people: 1 attendant and 1 conned space work-
er (the person attached to the lifeline cable or rope). These people must be qualied and
trained on the XTIRPA system. They must have read and understood this instruction and
safety manual before using the XTIRPA system. One person works in the conned space
(the user attached to the lifeline cable or rope) and the other (attendant) pays out the line and
reels it in, keeps in contact with the person inside and remains available in case of any emer-
gency. The attendant makes sure, at all times, that the user who is tying his lifeline cable or
rope to his EN 361-compliant harness is in the right position. The attendant also assures that
the XTIRPA system is well in place and that no load imbalance is possible.
IMPORTANT: During installation of the system, it is important to ensure stability through-
out.
