Innova XTIRPA IN-8002 Instruction Manual

MU8002-002ANG Rev1 2016 P. 1
INSTRUCTION AND SAFETY MANUAL
XTIRPA™ 1067mm (42") PORTABLE MANHOLE
GUARD SYSTEM FOR PPE
UNIVERSAL RESCUE SYSTEM
IN-8002
TO BE READ AND UNDERSTOOD BY USER PRIOR TO EACH USE
INNOVA Public Ulity Products Inc.., 1040 BOUL. INDUSTRIEL, GRANBY, QUEBEC, CANADA
Tel [phone] Fax [phone] www.xrpa.ca
™
Numéro:

MU8002-002ANG Rev1 2016 P. 1
INTRODUCTION
WARNING
The XTIRPA System is part of a personal protection equipment system for fall protection, work
positioning, or rescue, for use in confined spaces.
The user must read, understand and follow the manufacturer’s instructions for each component or part of
the complete XTIRPA System. These instructions must be provided to the user of the XTIRPA Sys-
tem. The user must read and understand these instructions before using the XTIRPA System. The
manufacturer’s instructions must be followed for proper use and maintenance of this product. Alterations
or misuse of the XTIRPA System or of any component or part thereof or failure to follow instructions
may result in serious injury or death, for which the manufacturer disclaims all warranties and liabilities
whatsoever, user, owner and purchaser of the XTIRPA System waiving all claims, rights and recourses
against the manufacturer and derived therefrom.
The XTIRPA  System was designed for persons needing a personal protection equipment system for
fall protection, work positioning, or rescue, for use in confined spaces. The XTIRPA System is in-
tended to act as a support structure or anchorage for these uses. Due to its conception and the use of an
advanced composite, the XTIRPA System is one of the lightest and most ergonomic systems of its
kind on the market. The XTIRPA System is in compliance with ANSI, OSHA, CE and CSA stand-
ards. The equipment has been tested in accordance with applicable requirements of the standard EN
795:2012 Type B.
IMPORTANT: The buyer must complete and r etur n the limited war r anty r egistr ation for m.
Always keep this Instruction and safety manual available to any worker needing to use the XTIRPA
System.
Before each use, the user must read, understand and follow the manufacturer’s instruction and safety
manual.
Keep instructional and safety labels apposed on the XTIRPA System and components and parts thereof
clean and legible at all times. Clean or replace if required. New labels can be obtained upon demand.
Establish a regular training program on the XTIRPA System for new & experienced workers, as fur-
ther recommended in this Inspection and safety manual. Establish a detailed inspection program for the
XTIRPA System and document findings, as further recommended in this Instruction and safety manu-
al. Always inspect the XTIRPA System before each use and at least once a year by a competent per-
son.
The XTIRPA System and its components and parts have labels indicating the maximum capacity of
each. Exceeding said maximum capacity may result not only in damages to the XTIRPA System or
components or parts thereof but also in serious injury or death, for which the manufacturer disclaims all
warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA System waiving all
claims, rights and recourses against the manufacturer derived therefrom.
The XTIRPA Universal Safety system IN-8002, including components IN-2108, 1067mm (42") Porta-
ble Manhole Guard for Fall Protection & Retrieval and IN-2210, Davit Arm for Fall Protection and Re-
trieval Including Secondary Block, conforms to document number MU8002-002ANG Rev1 2016.
APAVE SUDEUROPE SAS (Headquarters: 8 rue Jean-Jacques Vernazza—Z.A.C. Saumaty-Séon - CS
60193 - 13322 MARSEILLE CEDEX 16) is the notified body involved in the initial production and certi-
fication control phase.

MU8002-002ANG Rev1 2016 P. 2
DESCRIPTION & INTERPRETATION OF
MARKING SYMBOLS
This symbol is used to alert the user to a potential hazard. The safety of the worker is in
jeopardy. It is imperative to follow the manufacturer’s recommendations.
This symbol asks the user to read and understand the manual for this product before
use.
This symbol specifies that the system should be used by a single user.
-1-
APPLICATION
The XTIRPA System, and its many components and parts (including davit arm and manhole guard),
are intended to be used as part of a personal protection equipment system for fall protection, work posi-
tioning, personnel handling, materials handling, or rescue, for use in confined spaces. The XTIRPA
System is intended to act as a support structure or anchor for these uses.
-2-
RESTRICTIONS
a) CAPACITY: The maximum working load for this product is 420 lbs(190 kg).
According to (ANSI, OSHA, CSA).
According to EC (EN 795: 2012), use an EN-360 and/or EN-363 fall protection system
or an EN-1496 recovery system.
b) The manufacturer attests that anchoring devices have been tested accordingly to the present European
standard and, unless otherwise stipulated, equipment is to be used by only one person using a shock ab-
sorber in accordance with regulation EN 355.
c) PRECAUTIONS: Take the necessary precautions to limit injuries to the user and risks of damaging
the XTIRPA System.
d) Use of the XTIRPA System in areas where environmental hazards exist may require additional pre-
cautions to limit the possibility of injury to the user or damage to the XTIRPA System. Hazards may
include, but are not limited to: high heat, fire, flame, smoke, fumes, caustic chemicals, corrosive environ-
ments, high voltage power lines, sudden changes of pressure, explosive or toxic gases or substances, wa-
ter or risks of flooding, risks of wall, ceiling or floor collapsing, moving machinery and sharp edges.
e) Install and secure all signaling and other precautionary and security measures, including but not lim-
ited to, notifying users, bystanders and vehicle operators circulating near the XTIRPA System of the
presence of the XTIRPA System and its workers, before starting work.

MU8002-002ANG Rev1 2016 P. 3
f) Wear all appropriate, certified and recommended security equipment such as, but not limited to, hard
hat, protective eyewear, leather gloves, protective clothing, work boots, harness in accordance with EN
361, flashlight and respiratory device if needed.
WARNING: Equipment shall not be used beyond its limits, or in any other applications for which
the equipment was not designed for.
WARNING: A war ning should specify that the equipment shall not be used by a person that has
not been trained or is not competent to use the equipment safely.
g) Always work in teams of at least two (2) people: 1 attendant and 1 confined space worker (the person
attached to the lifeline cable or rope). These people must be qualified and trained on the XTIRPA Sys-
tem. They must have read and understood this Instruction and safety manual before using the XTIRPA
System. One person works in the confined space (the user attached to the lifeline cable or rope) and the
other (attendant) pays out the line and reels it in, keeps contact with the person inside and remains availa-
ble in case of any emergency. The attendant makes sure, at all times, that the user who is tying his life-
line cable or rope to his EN 361-compliant harness is in the right position. The attendant also assures that
the XTIRPA System is well in place and that no load imbalance is possible.
IMPORTANT: Dur ing installation of the system, it is important to ensur e stability thr oughout.
h) Use only a certified full body harness in accordance with EN 361 and certified lifeline cables and
ropes for any user of the XTIRPA System, with appropriate specifications designed and recommended
for use in specialized work conditions such as those for which the XTIRPA System is intended to be
used as per this Instruction and safety manual. For the installation of lifeline cables and ropes on the cer-
tified 12kn anchor points of the davit arm, see section 6 paragraph 5 and 6.
IMPORTANT: When used as PPE, the system must be fitted with a device limiting the dynamic
forces exerted on the user to a maximum of 6kN (1320 LbF).
i) Plan your work program before starting. Have the required equipment, procedures and people, which
must be qualified and trained on the XTIRPA System and who must have read and understood this
Instruction and safety manual before using the XTIRPA System, available to do the job.
j) Keep all instructional and safety labels on the XTIRPA System and its components and parts clean
and legible at all times. Clean or replace if required. New labels can be obtained upon demand.
IMPORTANT: If the markings on the anchoring device are not legible after installation, it is r ec-
ommended that supplementary markings next to the anchoring device be made.
WARNING: All modifications of the equipment or all additions to the equipment shall not be per -
formed without the authorization of the manufacturer, and all repairs shall be done as indicated by the
operating mode of the manufacturer.
WARNING: It is established and agreed that the equipment (system) is reserved for the use of only
one person.
k) Do not exceed 420lbs (190kg) (CSI, ANSI, OSHA) as the maximum work load of the system.
l) Follow all applicable laws, regulations and standards for work in, entry in and exit from confined spac-
es.

MU8002-002ANG Rev1 2016 P. 4
m) A person who has not read this instruction and safety manual, has not been trained in using the XTIR-
PA System and does not understand all operation, safety, maintenance, servicing and storage instruc-
tions contained in this Instruction and safety manual and in any other recommendations provided by the
manufacturer or its certified trainers is not qualified to operate the XTIRPA System and does it at their
sole risk, therefore waiving any and all claims, rights and recourses against the Manufacturer and derived
there from.
n) Make sure to conform to relative demands regarding anchoring devices. (E.g.: floor adapter, wall
adapter etc.) Or ensure that the chosen structure that will be used has an anchoring point, and keep in
mind minimal required resistance, equivalency and position.
o) The maximum force that can be applied by the system to the structure is a vertical force of 22kN
(5000 lbf) according to CSA, ANSI, and OSHA; or 12kN according to EN362, EN795 EC from the an-
chor when the system is placed.
p) A rescue plan shall be put in place in order to account for all likely emergencies that could occur
while working.
WARNING: The anti-toppling device A2108-18 must be used while the manhole guard is being used
in V configuration. See illustrations 4 and 5 in Section 5 of the manual.
WARNING: Anchor ing devices must be installed only by competent persons or or ganizations.
WARNING: The system must be appropr iately checked, for example, by calculations or tests.
WARNING: The use of a base, str uctur al anchor or fastener , if one exists, must be taken into ac-
count when calculating the amount of force supported by the anchor during strength and integrity test-
ing.
WARNING: Any modification or addition to the equipment cannot be done without the pr ior
written consent of the manufacturer, and any repairs must be undertaken in accordance with the manu-
facturer’s procedures.
WARNING: This equipment (system) is reser ved for the use of one per son at a time.
WARNING: It is impor tant to place the XTIRPA™ System on a hard and level surface. Do not
use the XTIRPA™ System on a soft surface, including, but not limited to, sand, grass, gravel and
rocks. If you have any questions about the use or maintenance or whether the XTIRPA™ System
is appropriate for your job, please contact the Manufacturer PSP INNOVA INC.
WARNING: For safety r easons, make sur e when using the anti-drop system that you have enough
space under the user, so as to avoid injury. If a fall occurs, there should be enough space to avoid a colli-
sion with the ground or any obstacle. See the diagram in Section 8 for calculating this distance.
4

MU8002-002ANG Rev1 2016 P. 5
-3-
XTIRPA SYSTEM REQUIREMENTS
IMPORTANT: If you have questions about the use, care or suitability of the XTIRPA System for your
application, please contact the Manufacturer INNOVA Public Utility Products Inc.
IMPORTANT: Record the product identification information from the ID label in the maintenance and
inspection log of this Instruction and safety manual.
IMPORTANT: Record purchasing date and also date of first use on the maintenance and inspection log
sheet included in this safety instruction manual.
a) The XTIRPA System is intended to be used as part of a personal protection equipment system for
fall protection, work positioning, personnel handling, materials handling, or rescue, for use in confined
spaces. The XTIRPA System is intended to act as a support structure or anchor for these uses.
The XTIRPA System must be used only with adapters, anchors, connectors (EN 362), and other com-
ponents, parts or subsystems that have been certified, approved and recommended by the Manufacturer.
WARNING: This system should never be used to transport persons and material at the same time.
b) Substitutions or replacements made with non-approved adapters, anchors, connectors (EN 362), other
components, parts or subsystems may be incompatible, may jeopardize the safety and reliability of the
complete XTIRPA System and may result in serious injury or death, for which the Manufacturer dis-
claims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA System
waiving all claims, rights and recourses against the Manufacturer derived therefrom.
IMPORTANT: It is imperative to keep the pulling angle at a maximum of twenty-two degrees (22°)
from the lifeline cable or rope, as to avoid any frontward load unbalance of the manhole guard and cause
it to topple over (see illustration A).
WARNING: The anti-toppling device A2108-18 must be used while the manhole guard is being used in
V configuration. See illustrations 4 and 5 in Section 5 of the manual.
c) Connectors (EN 362) (hooks, carabiners, D-rings) must be able to support a weight of at least 5000 lbs
(2273 Kg). (CSI, ANSI, OSHA).
d) The manhole guard’s integrated mast must be positioned at the highest point of the area to be barricad-
ed.
e) When attaching the EN 361-compliant safety harness with the lifeline cable or rope, it is imperative, in
order to avoid the manhole guard toppling over, that the user tie himself to the front of the XTIRPA
System.
f) Always open the manhole guard to its full capacity before installing davit arm.
g) Make sure the lifeline cable or rope is positioned directly over the work area. Use only certified life-
line cable or rope, in perfect working condition, with appropriate specifications, including maximum lev-
erage capabilities, for the intended use of the XTIRPA System.

MU8002-002ANG Rev1 2016 P. 6
h) Owners must make sure that, before each use, all users of the XTIRPA System have read, under-
stood and follow the Manufacturer’s Instructions and safety manual.
i) Owners must also make sure that all users have successfully been trained in using the XTIRPA Sys-
tem, before allowing them to use the XTIRPA System, and at least annually thereafter.
j) A person who has not read the Instruction and safety manual, has not been trained in using the XTIR-
PA System and does not understand all operation and safety instructions, is not qualified to operate the
XTIRPA System. An untrained user exposes himself and others to possible serious injury or death,
for which the Manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser
of the XTIRPA System waiving all claims, rights and recourses against the Manufacturer derived
therefrom.
k) Refer to and follow applicable ANSI, OSHA, CSA, CE or other standards and local regulations.
Comply with all requirements of your local regulations for your applications.
WARNING: It is possible that a hazar d may occur while using multiple components, as one of
them could affect the safety function of the system, if the safety function of one component can be af-
fected by that of another component.
WARNING: It is essential for the safety of the user , if the pr oduct is r esold to a destination out-
side the first country, that the reseller supplies the instruction manual, maintenance instruction log sheet
for the periodic inspections and all associated repair instructions written in the native language of the
country in which the product will be used. It is also required to supply all specific additional information
for the equipment.
WARNING: Any per sons with a medical condition which could cause a hazard to the user dur ing
normal operation and in emergency situations should avoid using the system.
l) See other important operation instruction and safety information contained hereafter in this Instruction
and safety manual.
WARNING: If the system has been used to stop a fall, it should not be used again until a compe-
tent person has, in writing, authorized its reuse.
WARNING: The safety of the user is in dir ect relation to the quality of maintenance and integr ity
of the equipment.
m) It is imperative to supply all information in sufficient quantity to assure that different equipment arti-
cles are compatible when assembled as system.
n) Life expectancy of the XTIRPA System and its components will be determined based on the con-
clusions of periodic and monthly inspections which will determine whether or not the product may re-
main in service.

MU8002-002ANG Rev1 2016 P. 7
-4-
MAINTENANCE, SERVICING, STORAGE
a) Before each use, the user must read and understand the Manufacturer’s Instruction and safety manual.
Ensure that the markings are visible at all times.
b) Before each use, carefully inspect the XTIRPA System and all components and parts thereof. Any
defective parts or components could result in serious injury or death.
c) ANSI, OSHA, CSA and CE require a regular inspection program for all confined space entry/retrieval
equipment and to maintain documented results of these inspections. Use the maintenance and inspection
logs included in this Instruction and safety manual to document the results.
d) It is recommended that the anchoring device be marked with the most recent or next inspection date.
e) Remove the XTIRPA System from service if a problem or an unsafe or defective condition is found
during the inspection. Return to an authorized service center or the manufacturer for service.
f) Replacement components and parts and additional maintenance and servicing procedures must be
completed by an authorized service center which has been approved by the manufacturer, or by the man-
ufacturer itself.
g) If leveling screwing pads do not move freely, they must be lubricated with a light machine oil.
h) Establish a monthly inspection which should be done by a competent person (person who is familiar,
has been trained and has read and fully understands this Instruction and safety manual), other than the
user.
WARNING: A per iodic inspection should be per for med at least once ever y twelve months.
i) Periodically clean the exterior of the davit arm and base, using water and mild detergent. Clean labels
as required.
j) Store the XTIRPA System in a clean and dry environment, out of direct sunlight. Avoid areas with
chemical or toxic vapors, substances or environments. Do not immerse or leave in direct contact with
water, as corrosion and rust may occur. Inspect the XTIRPA System after any period of extended stor-
age and at least once a month.
k) The XTIRPA System and its components was designed for 10 years of continuous service. The life
expectancy of the XTIRPA System and its components will be determined after periodic and monthly
inspections that will determine whether or not the product may remain in service.
l) All components and parts of the XTIRPA System should be stored in separate bags to facilitate
transport and handling.

MU8002-002ANG Rev1 2016 P. 8
WARRANTY
The XTIRPA System offered by the Manufacturer, INNOVA Public Utility Products Inc., is warranted
against manufacturing defects in workmanship and materials for a period of two (2) years from the date
of shipment of the product, which warranty only covers the original purchaser of the XTIRPA System.
The Manufacturer will promptly repair or replace all components or parts found to be defective, the Man-
ufacturer reserving the right to elect to have any alleged defective part returned to its plant for inspection
before making a repair or replacement.
Only components or parts found to be defective by the Manufacturer, at its sole discretion and upon any
inspection requested and performed by the Manufacturer, will either be repaired or replaced by the Man-
ufacturer, at its sole choice.
All claims must be forwarded in writing to the Manufacturer, immediately upon discovery by owner, and
must be accompanied by a copy of the proof of purchase of the original purchaser. The Manufacturer
will issue a claims number and give specific instructions to be followed as to claim procedures and return
of the defective part, if so requested by the Manufacturer. Owner will collaborate with the Manufacturer
and its representatives to allow inspection of any alleged defective part. All shipping costs to return de-
fective components and parts to the Manufacturer’s plant are payable by owner. The cost of reshipping
replacement components or parts being covered, payable by the Manufacturer.
This warranty does not cover equipment damages resulting from any other cause than a manufacturing
defect in workmanship or materials, including, without limitation, damages resulting from abuse, lack of
maintenance, improper handling or storage, voluntary damages, vandalism, accidental damages or dam-
ages resulting from impact or collision, damage in transit, damages caused by fire, explosion, chemical,
toxic or corrosive vapors, substances or environments, water, normal corrosion and rust, storms, hail, and
other acts of God, war or insurrection, acts of terrorism or other damage beyond the control of the Manu-
facturer. This warranty applies only to the original purchaser and is the only one applicable to the XTIR-
PA System, and is in lieu of all other warranties, expressed or implied. Without limiting the generality
of the foregoing, the Manufacturer will not be liable nor responsible for any other cost, damages or
claims whatsoever, including for any special, incidental, indirect, or consequential damages whatsoever
such as, but not limited to, damages for loss of profits or expected revenues, for business interruption, for
personal injury, for failure to meet any duty including of good faith or of reasonable care, for negligence,
and for any other pecuniary or other loss whatsoever, arising out of or in any way related to the use of or
inability to use the XTIRPA System, even in the event of the fault, tort (including negligence), strict
liability, breach of contract or breach of warranty, even if the Manufacturer has been advised of the pos-
sibility of such damages. The Manufacturer hereby disclaims all other warranties and conditions, either
express, implied or statutory, including, but not limited to, any implied warranties or conditions of mer-
chantability, of fitness for a particular purpose or application, and of lack of negligence or lack of work-
manlike effort.
IMPORTANT: The buyer must fill out and return the Limited Warranty registration form for each prod-
uct.

MU8002-002ANG Rev1 2016 P. 9
-5-
XTIRPA SYSTEM DESCRIPTION
WARNING
The XTIRPA System is part of a personal fall arrest, work positioning, personnel handling, material
handling or rescue system for use in confined spaces. The XTIRPA System is intended to act as a sup-
port structure or anchor for these uses. The user must read, understand and follow the manufacturer’s
instructions for each component or part of the complete XTIRPA System. These instructions must be
provided to the user of the XTIRPA System. The user must read and understand these instructions be-
fore using the XTIRPA System. The Manufacturer’s instructions must be followed for proper use and
maintenance of the XTIRPA System. Alterations or misuse of the XTIRPA System or failure to fol-
low instructions may result in serious injury or death, for which the Manufacturer disclaims all warran-
ties and liabilities whatsoever, user, owner and purchaser of the XTIRPA System waiving all claims,
rights and recourses against the Manufacturer and derived therefrom.
DESCRIPTIONS
1067mm (42") PORTABLE MANHOLE GUARD WITH INTEGRATED MAST: IN-2108 (see
illustration 1)
610mm (24") DAVIT ARM W/SECONDARY BLOCK: IN-2210 (see illustration 1)
1067mm (42") XTIRPA PORTABLE MANHOLE GUARD SYSTEM FOR PPE: IN-8002 (see il-
lustration 3)
1067mm (42") XTIRPA PORTABLE MANHOLE GUARD SYSTEM FOR PPE: IN-8002 V posi-
tion (see illustration 4)
ANTI-TOPPLING DEVICE FOR 1067mm (42") MANHOLE GUARD: A2108-18 (see illustr ation
5)
Illustration 1: IN-2108
Illustration 2: IN-2210
Illustration 3: IN-8002
Illustration 5: A2108-18
Illustration 4: IN-8002 in “V”

MU8002-002ANG Rev1 2016 P. 10
-6-
OPERATION, ASSEMBLY AND USE
XTIRPA SYSTEM
WARNING: The XTIRPA System is part of a personal fall arrest, work positioning, personnel han-
dling, material handling or rescue system for use in confined spaces. The XTIRPA System is intended
to act as a support structure or anchor for these uses. The user must read, understand and follow the Man-
ufacturer’s instructions for each component or part of the complete XTIRPA System.
WARNING: These instr uctions must be provided to the user of the XTIRPA System. The Manu-
facturer’s instructions must be followed for proper use and maintenance of the XTIRPA System. Al-
terations or misuse of the XTIRPA System or failure to follow instructions may result in serious injury
or death, for which the Manufacturer disclaims all warranties and liabilities whatsoever, the user, owner
and purchaser of the XTIRPA System waiving all claims, rights and recourses against the Manufactur-
er and derived therefrom.
IMPORTANT : If you have questions on the use, care or suitability of the XTIRPA System for
your application, please contact the Manufacturer INNOVA Public Utility Products Inc.
IMPORTANT : Record the pr oduct identification infor mation fr om the ID label of the XTIRPA
System in the maintenance and inspection log of this Instruction and safety manual.
OPERATION AND INSTALLATION OF DAVIT ARM AND MAST SYSTEM
1. Make sure that all components
and parts are in good working condition
and that they all work correctly.
2. A) Undo the rubber draw latch and
open the manhole guard to its maximum
capacity. B) If necessary, adjust the legs
to level the system. C) Close and lock the
door using locking mechanism.
IMPORTANT: Always open the manhole guar d to its full capacity befor e installing davit ar m.

MU8002-002ANG Rev1 2016 P. 11
5. A) Install the lifeline cable or rope or winch on mounting bracket
made to accept the hoisting device, and lock with pin attached to the SRL or
winch bracket.
6. A) Pass the lifeline cable or rope into the pulley
located at the top end of the davit arm. Make sure that
the lifeline cable or rope is well in place.
7. A) If a material positioning winch is required, use the
bottom mounting bracket located under the davit arm. Install
winch to mounting bracket and lock with pin attached to
winch.
B) Remove the small pulley locking pin. Position
cable over pulley and re-install pulley using locking pin.
WARNING: It is strictly pr ohibited to use the material /positioning winch as a fall ar r est, when
the winch is positioned on the bottom mounting bracket located under the davit arm.
WARNING: Only adaptors and br ackets that ar e appr oved, certified and recommended by the
manufacturer are to be used with the XTIRPA System.
3. A) Remove both handle pins
from their locations.
B) Install the receptacle of the
davit arm on the integrated mast
of the manhole guard.
4. A) Lock all with the first handle pin.
B) Install the inferior leg of the davit arm
between the eyelets of the manhole guard and
lock with the second handle pin.
C) If necessary, install the anti-toppling
device A2108-18 through the eyelets on each
side of the manhole guard and lock with the pin.

MU8002-002ANG Rev1 2016 P. 12
8. A) Remove locking pin located in the
mid section of the davit arm.
B) Extend the inner mast to full exten-
sion. Replace locking pin to secure the davit
arm.
IMPORTANT: Make sure the lifeline cable or rope is positioned directly over the work area. Use
only certified lifeline cable or rope, in perfect working condition, with appropriate specifications, in-
cluding maximum leverage capabilities, for the intended use of the XTIRPA System.
WARNING: It is imper ative to position the XTIRPA System on a hard and level surface. Do not
use the XTIRPA System on soft ground, such as but not limited to, sand, grass, gravel and
rocks. If you have questions on the use, care or suitability of the XTIRPA System for your appli-
cation, please contact Manufacturer.
IMPORTANT: An EN 361-compliant fall protection harness is the only body support device allowed
to be used for fall protection.
IMPORTANT: It is imperative to keep the pulling angle at a maximum of twenty-two degrees
(22°) from the lifeline cable or rope, as to avoid any frontward load unbalance of the manhole guard and
cause it to topple over (see illustration A).
22º maximum angle
9. A) When attaching the safety harness with the lifeline cable or rope,
it is imperative, in order to avoid the manhole guard toppling over, that the
user tie himself at the front of the XTIRPA System.
WARNING: The integr ated mast on the manhole guar d must be positioned at the highest point of
the area to be barricaded.
IMPORTANT: When attaching the EN 361-compliant safety harness with the lifeline cable or rope, it
is imperative, in order to avoid the manhole guard toppling over, that the user tie himself at the front of
the XTIRPA System, where the door opens.
WARNING: The Manufacturer ’s Instr uction and safety manual must be followed for pr oper use
and maintenance of this product. Alterations or misuse of this product or failure to follow instructions
may result in serious injury or death, for which the Manufacturer disclaims all warranties and liabilities
whatsoever, user, owner and purchaser of the XTIRPA System waiving all claims, rights and recours-
es against the Manufacturer derived therefrom.

MU8002-002ANG Rev1 2016 P. 13
WARNING: The XTIRPA System must be used only with adapters, anchors, connectors (EN 362),
other components, parts or subsystems that have been certified, approved and recommended by the Man-
ufacturer. Substitutions or replacements made with non-approved adapters, anchors, connectors (EN
362), other components, parts or subsystems may be incompatible, may jeopardize the safety and relia-
bility of the complete XTIRPA System and may result in serious injury or death, for which the Manu-
facturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA
System waiving all claims, rights and recourses against the Manufacturer derived therefrom. The con-
nectors (EN 362) (hooks, carabiners, D-rings) must be able to support a load of at least 5,000 lbf. (22kN)
in accordance with ANSI, CSA, and OSHA and 12kN in accordance with EN-795:2012.
WARNING: For all fall pr otection devices, it is essential, for safety pur poses, that anchor ing de-
vice is always positioned correctly and that the task to be performed should be done in a manner to re-
duce risk of fall and height of fall. The anchoring point and fall protection device must be placed direct-
ly over the user’s position.
WARNING: The entire system must be immediately removed from service: if the safety of the system
is in doubt or the system has stopped a fall. It is imperative not to use the system until a competent per-
son has authorized (in writing) the reuse of the system.
WARNING: With the use of a fall pr otection device, it is essential for safety pur poses, to verify
the free space required under the user at the work site before each use to avoid and prevent falls, in case
of collision with ground or any other obstacle that could be in the path of the fall.

MU8002-002ANG Rev1 2016 P. 14
-7-
THE FOLLOWING INSTRUCTIONAL AND SAFETY SIGNS
MUST BE KEPT CLEAN AND LEGIBLE AT ALL TIMES
Product No. Manufacturer
WARNING LABEL IN-2210
WARNING LABEL IN-2210
WARNING LABEL IN-2210
SERIAL NUMBER LABEL
Product serial number
Product number
Date of manufacture
Batch number
EC ACCREDITATION LABEL
Notified body Number
Accredited Standard Number
European comformity
Standard Product Type

MU8002-002ANG Rev1 2016 P. 15
-8-
Calculation diagram

™Registration Limited Warranty Form
This warranty applies only to the original purchaser and is the only one applicable to the Xtirpa System, and is in lieu of all other warranties, expressed or immplied.
The purchaser has to complete and return to INNOVA Public Utility Products Inc., all information within thirty days of purchase. Otherwise limited warranty will be void, if the product is not registered.
Register Now: Mail or fax this registration form or visit our web site and register online.
Mail: INNOVA Public Utility Products Inc., 1040, boul. Industriel, Granby J2J 1A4
Fax: [phone]
Web site: WWW.XTIRPA.COM
PRODUCT
Model number: Purchasing Date:
Serial number: Manufacturing Date:
CUSTOMER / USER INFORMATION
Company: Phone:
Street Address: Fax:
City: E-Mail
State:
Zip: Do you wish to be on Innova's mailing list
Name: for new product literature:
Yes □
Position: No □
*Any failure to follow the Manufacturer's instructions contained in the Instruction and safety manual, including with regard to the inspection and maintenance of the
XTIRPA TM system and of components and parts there of, will cause warranty to become null and void and may result in serious injuryor death of the user, for which the
Manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA TM system waiving all claims, rights and recourses
against Manufacturer and derived there from.
Manufactured by: INNOVA Public Utility Products Inc.
1040 boul. Industriel, Granby, Québec, Canada J2J 1A4 Tél: [phone] Fax: [phone]

™MAINTENANCE AND INSPECTION LOG
PRODUCT: ______________________ Purchasing Date: ____________________
Model number: _________________ Serial number: ______________________ Manufacturing Date: ____________________
i
ns
p
ection:
____________________
Date of 1st use: ____________________
Inspection date: LABELS CORROSION STRUCTURAL
DAMAGE WELDING PINS & HARDWARE OTHER (SPECIFY) CORRECTIVE ACTION TAKEN (IF REQUIRED) INSPECTED BY:
COMMENTS:
*Any failure to follow the Manufacturer's instructions contained in the Instruction and safety manual, including with regard to the inspection and maintenance of the
XTIRPATM system and of components and parts there of, will cause warranty to become null and void and may result in serious injury or death of the user, for which the
Manufacturer disclaims all warranties and liabilities whatsoever, user, owner and purchaser of the XTIRPA TM system waiving all claims, rights and recourses
against Manufacturer and derived there from.
Manufactured by: INNOVA Public Utility Products Inc.
1040 boul. Industriel, Granby, Québec, Canada J2J 1A4 Tél: [phone] Fax: [phone]
