Insportline IN 12568Handy J1 User manual

USER MANUAL –EN
IN 12568 Mini Self-Balance Car Windrunner Handy J1

2
CONTENTS
INTRODUCTION..................................................................................................................................... 4
DOCUMENT OVERVIEW ....................................................................................................................... 4
Document overview ............................................................................................................................. 4
User manual......................................................................................................................................... 4
Document related instructions ............................................................................................................. 4
PRODUCT INTRODUCTION.................................................................................................................. 4
The description of Mini Self-Balance car............................................................................................. 4
Record the serial number of Mini Self-Balance car ............................................................................. 5
How to run the Mini Self-Balance car .................................................................................................. 5
INSTALLATION....................................................................................................................................... 6
Check whether the parts are complete................................................................................................ 6
To assemble the machine.................................................................................................................... 6
CONTROLLER AND INFORMATION DISPLAY DEVICE ...................................................................... 7
Remote................................................................................................................................................. 7
Pedal sensor........................................................................................................................................ 8
Display ................................................................................................................................................. 8
THE INSTRUCTIONS OF BATTERY...................................................................................................... 8
Battery running low .............................................................................................................................. 8
Charging steps..................................................................................................................................... 9
Temperature too high or too low.......................................................................................................... 9
The battery specification...................................................................................................................... 9
Matters needing attention when shipping the battery........................................................................ 10
Safe to use car ...................................................................................................................................... 10
Weight limit of users........................................................................................................................... 10
Maximum range ................................................................................................................................. 10
Speed limit ......................................................................................................................................... 11
Warning.............................................................................................................................................. 11
LEARNING TO DRIVE .......................................................................................................................... 11
Open the car ...................................................................................................................................... 11
Secure parking................................................................................................................................... 12
Driving steps ...................................................................................................................................... 12
Driving practice .................................................................................................................................. 12
DRIVING SAFETY INSTRUCTION....................................................................................................... 13
MAINTENANCE .................................................................................................................................... 14
Handling............................................................................................................................................. 14
The maintenance of the wheels......................................................................................................... 14
Cleaning............................................................................................................................................. 14

3
Storage............................................................................................................................................... 14
PARAMETERS...................................................................................................................................... 15
FAULT HANDLING................................................................................................................................ 15
TERMS AND CONDITIONS OF WARRANTY, WARRANTY CLAIMS................................................. 15

4
INTRODUCTION
Thank you for your choosing and buying the Mini Self-Balance car.
This is automatic balancing electric balance car.
This product manual is designed to help you assemble, use and maintain this vehicle.
It’s very important to understand Mini Self-Balance car driving safety.
You can check the product manual and video to learn safe driving.
This product manual informs the customer all the operating instructions and matters needing attention,
If the user is not acting according to the operation manual or in violation of the waning content and cause
an accident, the company shall not be held legally responsible.
DOCUMENT OVERVIEW
Document overview
Account security information and warning information, to ensure that every user can enjoy
fun to Mini Self-Balance car and safe driving
Introduces the various components of Mini Self-Balance car
Discuss the steps to assemble the Mini Self-Balance car
Driving security considerations
Provide detailed driving method and skill
User manual
The best way to ensure a perfect experience with the Mini Self-Balance car is to read this manual
carefully. You will learn how to control this new vehicle. Keep it safe after reading in case you may need
it later.
Document related instructions
The following instructions apply to the whole product manuals:
PRODUCT INTRODUCTION
The description of Mini Self-Balance car
The operation of Mini Self-Balance car relies of the basic principle of “dynamic stability”, namely the
auto-balance ability of the car. When car is in balance mode, you can control the speed and direction to
make it to your destination.

5
Record the serial number of Mini Self-Balance car
Coding is unique, so store your code to use later. The code is very important to track the quality of
products, insurance claims, and loss of claim.
Access code
To obtain location: warranty card, body of car
Coding is made up 16 Numbers and letters
Record and save the code
How to run the Mini Self-Balance car
This car including car body, motor and circuit system, etc. Motor installed in the car body two side, power
supply, control circuit, drive systematic and sensor and control switch installed on the car body. Between
the wheel and the body rotation, Speed sensor and Angle sensor. Angle and Angle information wheel
and the wheel and the body rotation. Speed sensor and angle sensor, Angle information wheel and the
car body, transmitted to the control center, control of the motor torque and speed, in order to balance
formula one. Brake apparatus and throttle lever are not required for driving. When the driver leans
forward, the car advances; when the driver stands upright, the car stops. It is controlled by dynamic
equilibrium principle. When the body moves, the center of gravity constantly changes accordingly to
achieve balance.

6
The steering rod controls the wheels and rotates the car to the left or to the right. 1800and 3600
rotations can be realized. At the same time, it supports the body to help keep balance.
Car´s built-in inertia dynamic stabilization system can keep the direction of the level before and
after, but does not guarantee stability of the left and right. During steering operation, follow the
steering rod, body tilt, overcome to centrifugal force, increase security.
INSTALLATION
This part is to look at the content of the components and installation guide.
Check whether the parts are complete
1. Main body 6. Remote (2 pcs)
2. Steering lever 7. Product manuals
3. Steering lever handle 8. Warranty car
4. Charger 9. Certificate
5. Toolkit
To assemble the machine
Step 1: Put the shift lever handle in the direction shown by the graphic steering rod assembly, pay
attention to the positive and negative direction.
Step 2: According to the direction of graphic inserted the steering stem component body steering rod,
pay attention to the positive and negative direction.

7
Step 3: Open the part at the back of the switch, start the machine.
WARNING: Before you do maintenance or install parts, ensure that the device is not charging.
CONTROLLER AND INFORMATION DISPLAY DEVICE
Remote
The remote is a remote control device, maximum remote control distance is 10 meters, within this range,
the car can be remote controlled.
A: The power. In vehicle mode, press A key to system shutdown and into shutdown mode.
B: The power button. After power on, press the B key to start the car, can be operated in this
car.
C: The alarm key.

8
D: drag line mode. The system boot mode, press the D key, with the hand pull handle can
control the vehicle
Pedal sensor
Under the MATS the device has four sensors, on the state of the flat on floor MATS. This car will
automatically adjust its equilibrium.
When you drive this car, you must ensure that the floor mat isn’t trampled, please don’t
trample the floor.
Please don’t carry items on the floor mat, or car will start, increases the risk of collision,
resulting in personal injury or damage to the car itself.
Display
Display in this car between two feet, in is used to display car run information.
Display screen can display the power of the vehicle and the vehicle running speed.
THE INSTRUCTIONS OF BATTERY
Describe the car charging methods, how to maintain the battery, matters needing attention, and the
battery specifications.
For others and your security, prolonging the life of the battery and enhance battery performance,
please according to the following the operation of the battery.
Battery running low
When you find that power is less than 10%, you must stop driving, electricity shortages, car don´t have
enough energy to your normal driving, the system will automatically slow down, and automatically shut
down and it cannot be started after shutdown. If you continue to drive such car, it is easy to fall down
injured, also can affect the battery life.
Do not use the battery on the following situations, 1. Emit some smell or serious fever 2. Leak
out of the material
Only professional´s disassembly and maintenance of batteries
Don´t touch any material leaked battery.
Children and animals are far away from the battery. Be sure to pull out the charger before install
batteries or driving, under the condition of charging it is dangerous to do anything.
You can only use the charger provided by the company.

9
To use the battery in local laws permit.
Charging steps
Open the car charging port.
To ensure the charging port is dry.
Charging link of a head of inserted to the car to first, then put the charger on the power
supply (100V to 240 V, 60 Hz)
When the two lights on the charger are red, the normal charging, otherwise please check
whether the circuit connection is good.
When the batterycharger, one of the red lights turn green, suggests that electricity has been
full of, please stop charging at this time. Charging for a long time will affect the service life
of batteries.
Charging must be turned off, please do not boot when charging, otherwise it will damage
the battery.
please use the standard plug used in the local
Please in accordance with the provisions, recharged, storage battery otherwise it will damage
the battery, he battery life. Charging time is about 1.5 hours, charging time is too long will
shorten battery life.
Keep clean, dry charging environment. The charging port can´t charge when it´s wet.
Temperature too high or too low
If you want to car reached the highest efficiency, the temperature of the battery must be marked
in the temperature range of batteries specification. If in driving battery temperature too high or
too low, the system will be safety warnings.
Before charging and charge process temperature must be within the recommended value. Close
to the recommended temperature, the charging efficiency is the highest, if extreme cold or heat
the charging time will be lengthened or machine can´t fully charged.
The battery specification

10
Matters needing attention when shipping the battery
Lithium battery is considered to be dangerous goods, need to get the local law allows during
transportation.
If you need to car for air freight, or need other ways to transport lithium battery, please contact
our company or company designated agents.
Safe to use car
Driving operations in balance car driving differs a lot from that of traditional car since it is not
equipped with a traditional brake, accelerator and gear system. Careful reading of the following
guidance or training by professionals is required for the first-time driving of balance car.
The best way to ensure a perfect experience with the two-wheel balance car is to read this
manual carefully. You will learn how to control this new vehicle. Keep is safe after reading in
case you may need it any time. Every time before driving, please to check whether there is
damage to the car tires, if there´s any loose for parts, if you have any abnormal situation, please
contact the agent for repair.
The Guarantee Card attached to the car shall, in this manual, describe the guarantee clauses on
your new two-wheel balance car term by term. Please read this User´s Manual carefully to
understand your rights and obligations.
Correct installation of the parts before using car, to prevent damage to the car in use process.
Does not use car made any endanger one´s personal or property safety.
Please don´t use modified formula one parts, this will affect the performance of car even damage
of car, can produce serious harm to personal
Weight limit of users
Limit the weight of the drivers have following two reasons
Ensure the safety of the driver.
Hypercharge has damaged in the car
The maximum weight limit: 120 Kg
The minimum weight limit: 25 Kg
Over weight can lead to fall.
Maximum range
Maximum range related to many factors, such as fowling
The road: drive in smooth and flat surface can increase the range and instead will reduce the
distance
Speed and driving habits: keep medium speed increases range, frequent stops, acceleration,
deceleration, will reduce to distance.
The weight of the drives affects the distance.
