Service Manual
CUSA EXcel®Ultrasonic Surgical
Aspirator System

ii CUSA EXcel Ultrasonic Surgical System Service Manual
Preface
This manual and the equipment it describes are for use only by qualified medical
professionals trained in the particular technique and surgical procedure to be
performed. It is intended as a guide for servicing the CUSA EXcel®ultrasonic
surgical aspirator only.
Equipment covered in this manual
CUSA EXcel®ultrasonic surgical aspirator with 23 kHz and 36 kHz handpieces.
The CUSA EXcel®Ultrasonic Surgical Aspiration System Service Manual
consists of two parts—the text (part 1 of 2) and a Schematics Supplement (part 2
of 2), which contains the schematics.
Trademark acknowledgements
CUSA EXcel, TissueSelect, MacroTip, MicroTip, PrecisionTip, CEM, and Force
FX are trademarks of Integra LifeSciences Corporation or its subsidiaries.
Ajax®is a registered trademark of the Colgate-Palmolive Company.
Comet®is a registered trademark of Procter & Gamble.
Torque Seal®is a registered trademark of Organic Products Co.
Manufactured by
Integra LifeSciences (Ireland) Limited
IDA Business & Technology Park
Sragh
Tullamore, CO Offaly, Ireland
Distributed by
Integra LifeSciences Corporation
Plainsboro, NJ 08536, USA
800-997-4868
© 2009 Integra LifeSciences. All rights reserved. Contents of this publication
may not be reproduced in any form without the written permission of Integra.
Patent Information
One or more of the following U.S. patents and corresponding foreign patents
cover the CUSA EXcel system
Additional patents pending.
Caution
Federal (USA) law restricts this device to sale by or on the order of a physician.
4634419 4734964 4747820 4827911 4846790
4881761 4921476 4931047 4988334 5015227
5190517 5312329 5421829 5466020 6083191
6214017 6256859 6499358 6602227 6654999
D438952
0086

CUSA EXcel Ultrasonic Surgical System Service Manual iii
About This Manual
The service manual describes the CUSA EXcel ultrasonic surgical aspirator. It
presents the CUSA EXcel as a system that includes a console, handpieces, and
accessories:
• Descriptions of the system, its functions, specifications, and theory of
operation
• Step-by-step instructions on how to unpack, install, maintain, calibrate, and
troubleshoot the system
• Step-by-step instructions on how to replace specific components
• Parts lists, board layouts, and schematics.
Organization
We have organized this guide to introduce the safety issues, the system, and its
functions. After safety and the system, the guide gives instructions for unpacking
the system, then describes its components, technical specifications, and theory of
operation. The next sections tell you how to check out, maintain, troubleshoot,
replace parts, and calibrate the system. A schematics supplement includes printed
circuit board (PCB) layouts and schematics.

iv CUSA EXcel Ultrasonic Surgical System Service Manual
Important
Conventions Used in this Guide
Indicates an operating tip or
maintenance suggestion.
Warning
Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
Caution
Indicates a hazardous situation which, if not avoided, may result in minor or moderate
injury.
Notice
Indicates a hazard which may result in product damage.

CUSA EXcel Ultrasonic Surgical Aspirator System Service Manual v
Table of Contents
Preface 1-ii
About This Manual 1-iii
Organization 1-iii
Conventions Used in this Guide 1-iv
List of Figures 1-xiii
List of Tables 1-xv
Section 1. Service Personnel Safety
Safety Information 1-1
