Intel SC5300BRP Configuration guide

Intel® Server Chassis
SC5300 5U Kit
Technical Product Specification
C67699-002
Revision 1.31
January, 2006
Enterprise Platforms and Services Marketing

Intel® Server Chassis SC5300 5U Kit TPS Introduction
Revision 1.31 1
Revision History
Date Revision Number Modifications
June 18, 2004 1.0 Initial Release
June 25, 2004 1.1 Format Updates
July 20 , 2004 1.1.1 Format updates
Jan 5, 2005 1.2 SATA and SCSI backplane updates Incorporated T.H.
Comments. Added BRP Added Errata/Inte
g
ration A
pp
endix
Jan 16, 2006 1.3 SATA backplane updates – added SAS compatibility
Jan 16, 2006 1.31 Modified Sections 1.3 and 1.4
Disclaimers
Information in this document is provided in connection with Intel®products. No license, express or
implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except
as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability
whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel
products including liability or warranties relating to fitness for a particular purpose, merchantability, or
infringement of any patent, copyright or other intellectual property right. Intel products are not intended for
use in medical, life saving, or life sustaining applications. Intel may make changes to specifications and
product descriptions at any time, without notice.
Designers must not rely on the absence or characteristics of any features or instructions marked
"reserved" or "undefined." Intel reserves these for future definition and shall have no responsibility
whatsoever for conflicts or incompatibilities arising from future changes to them.
The Intel® Server Chassis SC5300 may contain design defects or errors known as errata which may
cause the product to deviate from published specifications. Current characterized errata are available on
request.
Intel Corporation server baseboards contain a number of high-density VLSI and power delivery
components that need adequate airflow to cool. Intel’s own chassis are designed and tested to meet the
intended thermal requirements of these components when the fully integrated system is used together. It
is the responsibility of the system integrator that chooses not to use Intel developed server building
blocks to consult vendor datasheets and operating parameters to determine the amount of air flow
required for their specific application and environmental conditions. Intel Corporation can not be held
responsible if components fail or the server board does not operate correctly when used outside any of
their published operating or non-operating limits.
Intel, Pentium, Itanium, and Xeon are trademarks or registered trademarks of Intel Corporation.
*Other brands and names may be claimed as the property of others.
Copyright © Intel Corporation 2004-2005.

Introduction Intel® Server Chassis SC5300 5U Kit TPS
2 Revision 1.31
Table of Contents
1. Introduction ...........................................................................................................12
1.1 Intel®Server Chassis SC5300 Design Features........................................12
1.2 Intel®Server Chassis SC5300BASE Summary .........................................14
1.3 Intel®Server Chassis SC5300BRP Summary............................................15
1.4 Intel®Server Chassis SC5300LX Summary............................................... 15
2. Chassis Features...................................................................................................17
2.1 Chassis Dimensions and Weight ...............................................................17
2.2 System Colors............................................................................................ 17
2.2.1 Pedestal and Rack Mount Features...........................................................17
2.3 Security......................................................................................................18
2.4 I/O Panel....................................................................................................18
2.5 Standard and Optional Hot Swap Drive Bays ............................................19
2.6 5.25-inch Half-height Peripheral Bays........................................................19
2.7 Chassis Views............................................................................................20
3. Chassis Power Subsystem...................................................................................22
3.1 600-W Power Supply ................................................................................. 22
3.1.1 Mechanical Outline ....................................................................................22
3.1.2 Output Wire Harness .................................................................................23
3.1.3 600-W Power Supply Airflow and Temperature Rise................................28
3.1.4 AC Specifications.......................................................................................28
3.1.5 600-W DC Output Specifications .............................................................. 30
3.1.6 600-W Protection Circuits .........................................................................31
3.1.7 600-W Power Supply Control and Indicator Functions............................... 32

Intel® Server Chassis SC5300 5U Kit TPS Introduction
Revision 1.31 3
3.1.8 Mean Time Between Failures (MTBF) ....................................................... 32
3.2 730-W Power Supply ................................................................................. 32
3.2.1 730W Power Supply Mechanical Outline...................................................33
3.2.2 Output Wire Harness ................................................................................34
3.2.3 Airflow Requirements and Temperature Rise ............................................34
3.2.4 AC Specifications.......................................................................................34
3.2.5 730-W DC Specifications..........................................................................35
3.2.6 730-W Protection Circuits ..........................................................................37
3.2.7 730-W Power Supply Control and Indicator Functions............................... 38
3.2.8 730-W Mean Time Between Failure (MTBF)..............................................38
3.2.9 Redundant (1+1) Hot Swap Mode..............................................................38
3.3 730-W Power Distribution Board................................................................38
3.3.1 Power Distribution Mechanical Overview...................................................39
3.3.2 Temperature Operational Limits................................................................41
3.3.3 Electrical Specification...............................................................................41
3.3.4 Protection Circuits......................................................................................46
3.3.5 Control and Indicator Functions.................................................................46
3.4 SMBus Monitoring Interface.......................................................................47
3.4.1 Mean Time Between Failures (MTBF) ....................................................... 48
4. System Cooling.....................................................................................................49
4.1 Fan Configuration ......................................................................................49
4.1.1 Processor Passive Heat Sink Cooling Solution..........................................49
4.1.2 Base Cooling Solution................................................................................50
4.1.2 Redundant Cooling Solution ......................................................................50
4.2 Fan Control................................................................................................52

Introduction Intel® Server Chassis SC5300 5U Kit TPS
4 Revision 1.31
4.3 FAN Header Connector Descriptions.........................................................52
5. Hard Disk Drive Bays............................................................................................53
5.1 Server Chassis SC5300 4HDD and 6HDD SCSI HSBP Overview ............ 53
5.1.1 SCSI Enclosure Management Controller ...................................................53
5.1.2 SCSI Interface............................................................................................54
5.1.3 External Memory Device............................................................................54
5.1.4 Hot Swap Power Controller........................................................................54
5.1.5 SCSI Drive Connectors..............................................................................54
5.1.6 Power Connectors .....................................................................................55
5.1.7 SCA2 SCSI Connector...............................................................................55
5.1.8 68-Pin SCSI Connector..............................................................................56
5.1.9 IPMB (I2C) Header ....................................................................................58
5.1.10 Power Budget ............................................................................................58
5.1.11 Hard Drive Activity and Fault LED..............................................................58
5.1.12 SCSI Backplane Status LEDs....................................................................59
5.1.13 SCSI Hot Swap Drive Bay Upgrade Kits....................................................61
5.2 SATA/SAS Hot Swap Backplane...............................................................61
5.2.1 Enclosure Management Controller.............................................................63
5.2.2 SATA/SAS Interface ..................................................................................63
5.2.3 I2C Serial Bus Interface..............................................................................63
5.2.4 General Purpose Input/Output (GPIO).......................................................65
5.2.5 External Memory Device............................................................................67
5.2.6 LEDs..........................................................................................................67
5.2.7 SATA/SAS Drive Connectors.....................................................................67
5.2.8 Power Connectors .....................................................................................68

Intel® Server Chassis SC5300 5U Kit TPS Introduction
Revision 1.31 5
5.2.9 Clock Generation and Distribution .............................................................68
5.2.10 7-Pin SATA/SAS Connector – Drive0-Drive5.............................................69
5.2.11 IPMB Header - IPMB .................................................................................69
5.2.12 SATA/SAS Host I2C Header - I2C_1..........................................................70
5.2.13 Power Budget ............................................................................................70
5.2.14 Board Layout..............................................................................................70
5.2.15 Connector Specifications ...........................................................................71
5.2.16 SATA/SAS Hot Swap Drive Cage Upgrade Kit.......................................... 72
6. Front Panel ............................................................................................................73
6.1 Front Panel Board Layout.......................................................................... 73
6.1.1 Front Panel Connectors.............................................................................73
6.1.2 Front panel JP2 Header (17x2) Pin-out. ....................................................74
6.1.3 I2C Connectors at J1 and J2 (Not Installed) Pin-out...................................75
6.1.4 Front Panel Controls and Indicators...........................................................75
6.2 Chassis Interconnect .................................................................................78
6.3 Chassis Internal Cables.............................................................................79
6.3.1 Front Panel Cable...................................................................................... 79
6.3.2 USB Cable and Connectors.......................................................................80
6.3.3 Hot Swap Fan Cables and Connectors......................................................80
6.3.4 SCSI Cable................................................................................................82
6.3.5 Serial Cable ...............................................................................................83
6.3.6 SATA Cable...............................................................................................83
6.3.7 IPMB cable for 6-Drive Bays (4-pin)...........................................................84
6.3.8 I2C Cable for 6-Drive Bays (3-pin).............................................................. 84
7. System-Compatible Server Boards .....................................................................85

Introduction Intel® Server Chassis SC5300 5U Kit TPS
6 Revision 1.31
8. Upgrade Accessories............................................................................................86
8.1 AXX6SCSIDB and AXX4SCSIDB Hot Swap SCSI Drive Bays.................. 86
8.2 SATA/SAS Hot Swap Drive Bay Upgrade Accessory AXX6SASDB.......... 86
8.3 External SCSI Adapter Cable AXXEXTSCSICBL ...................................... 86
8.4 Rack Conversion Kit ARIGRACK...............................................................86
9. Reliability, Serviceability, and Availability..........................................................87
9.1 MTBF.........................................................................................................87
9.2 Serviceability..............................................................................................87
10. Environmental Limits............................................................................................89
10.1 System Office Environment........................................................................89
10.2 System Environmental Testing ..................................................................89
11. Product Regulatory Compliance..........................................................................90
11.1 Product Safety Compliance........................................................................90
11.2 Product EMC Compliance..........................................................................90
11.3 Product Regulatory Compliance Markings.................................................90
11.4 Electromagnetic Compatibility Notices....................................................... 91
11.4.1 USA ...........................................................................................................91
11.4.2 FCC Verification Statement........................................................................92
11.4.3 ICES-003 (Canada) ...................................................................................92
11.4.4 Europe (CE Declaration of Conformity)...................................................... 92
11.4.5 Japan EMC Compatibility...........................................................................92
11.4.6 BSMI (Taiwan)...........................................................................................93
Appendix A: Intel® Server Chassis SC5300 Spares and Accessories..................94
Appendix B: Intel® Server Chassis SC5200, SC5250-E, SC5275-E and SC5300
Common Spares & Accessories Components .........................................................98

Intel® Server Chassis SC5300 5U Kit TPS Introduction
Revision 1.31 7
Appendix C: Errata and Integration Notes...............................................................99
Reference Documents ..............................................................................................100

Introduction Intel® Server Chassis SC5300 5U Kit TPS
8 Revision 1.31
List of Figures
Figure 1. ATX* 2.03 I/O Aperture.................................................................................18
Figure 2. Tool-less Rails Mounting 5.25-inch CDROM Drive ........................................ 19
Figure 3. Intel® Server Chassis SC5300BASE Components.......................................20
Figure 4. Intel® Server Chassis SC5300LX Components............................................ 20
Figure 5. Rack Configuration with Sub-bezel and Right Side Panel Removed ............21
Figure 6. Output Cable Harness for 600-W and 700-W Power Supplies......................25
Figure 7. 730-W Power Supply Mechanical Drawings................................................. 33
Figure 8. Enclosure Mechanical Dimensions ...............................................................39
Figure 9. Mechanical Dimensions Power Distribution Board........................................40
Figure 10. CPU and PCI Air Ducts...............................................................................49
Figure 11. Fixed Fan Mounting ....................................................................................50
Figure 12. Hot Swap Fans and Connectors .................................................................51
Figure 13. Redundant Chassis Airflow Characteristics................................................. 51
Figure 14. 4-HDD Hot Swap Drive Bay, Front/Rear Isometric View............................. 60
Figure 15. 6-HDD Hot Swap Drive Bay, Front/Rear Isometric View.............................. 60
Figure 16. Drive Carrier with Air Baffle Installed...........................................................61
Figure 17. Intel® Server Chassis SC5300 6-HDD SATA/SAS Hot Swap Backplane
Block Diagram.........................................................................................................62
Figure 18. Intel® Server Chassis SC5300 6-HDD SATA/SAS Hot Swap Backplane I2C
Bus Connection Diagram ........................................................................................64
Figure 19. Intel® Server Chassis SC5300 6-HDD SATA/SAS Hot Swap Backplane
Board Layout...........................................................................................................71
Figure 20. Front Panel Primary Side............................................................................ 73
Figure 21. Front Panel Secondary Side .......................................................................73
Figure 22. Front Panel Controls and Indicators............................................................76
Figure 23. Chassis Interconnect SCSI Diagram...........................................................78
Figure 24. Chassis Panel Cable...................................................................................79
Figure 25. USB Cable Drawing .................................................................................... 80
Figure 26. USB Connector...........................................................................................80
Figure 27. 120-mm Hot Swap Fan Cable......................................................................81
Figure 28. Hot Swap Fan 6-pin Cable Connector.........................................................81

Intel® Server Chassis SC5300 5U Kit TPS Introduction
Revision 1.31 9
Figure 29. 90-mm Hot Swap 5-pin Cable Connector....................................................81
Figure 30. Hot Swap 8-pin (8 CM) Fan Cable Connectors........................................... 81
Figure 31. 8-pin (12 CM) Fan Connector......................................................................82
Figure 32. SCSI Cable 4-Drive Bay..............................................................................82
Figure 33. SCSI Cable 6-Drive Bay..............................................................................83
Figure 34. Serial Cable.................................................................................................83
Figure 35. SATA Cable ................................................................................................83
Figure 36. SATA Cable Connector...............................................................................83
Figure 37. I2C 4-pin Cable............................................................................................84
Figure 38. I2C 6-Pin Cable ...........................................................................................84
Figure 39. External SCSI Adapter Cable Detail............................................................ 86

Introduction Intel® Server Chassis SC5300 5U Kit TPS
10 Revision 1.31
List of Tables
Table 1. Intel® Server Chassis SC5300BASE, SC5300BRP, and SC5300LX Features12
Table 2. Product Matrix................................................................................................15
Table 3. Chassis Dimensions and Weights..................................................................17
Table 4. System Color Code........................................................................................17
Table 5. 600-W and 730-W Power Supply Cable Lengths..........................................24
Table 6. Baseboard Power Connector P1 Pin-out........................................................26
Table 7. Processor Power Connector P2.....................................................................26
Table 8. Power Signal Connector P13 ........................................................................27
Table 9. Peripheral Power Connectors......................................................................... 27
Table 10. Floppy Power Connector P6.........................................................................28
Table 11. PCI Express Connector................................................................................28
Table 12. AC Input Ratings.......................................................................................... 29
Table 13. Maximum System Load Ratings...................................................................30
Table 14. Light System Load Ratings...........................................................................30
Table 15. AC Input Rating............................................................................................34
Table 16. Edge Finger Pin-out .....................................................................................35
Table 17. 730-W Load Ratings..................................................................................... 36
Table 18. Voltage Regulation Limits.............................................................................37
Table 19. Thermal Requirements.................................................................................41
Table 20. Cable Lengths..............................................................................................41
Table 21. P1 Baseboard Power Connector..................................................................42
Table 22. P2 Processor Power Connector...................................................................43
Table 23. P3-P5, P7-P12 Peripheral Power Connectors.............................................. 43
Table 24. P6 Floppy Power Connector.........................................................................43
Table 25. Power Signal Connector...............................................................................44
Table 26. +12V Outputs Load Ratings.........................................................................44
Table 27. DC/DC Converters Load Ratings .................................................................45
Table 28. Voltage Regulation Limits.............................................................................45
Table 29. Power Connector Pin-out .............................................................................55
Table 30. SCA2 SCSI Connector Pin-out.....................................................................55

Intel® Server Chassis SC5300 5U Kit TPS Introduction
Revision 1.31 11
Table 31. 68-pin SCSI Connector Pin-out....................................................................57
Table 32. IPMB Header Pin-out ...................................................................................58
Table 33. Hot Swap Backplane Worst-case Power Budget..........................................58
Table 34. Hard Drive Activity LED................................................................................ 59
Table 35. SCSI Backplane LED ...................................................................................59
Table 36. I2C Bus Addressing ......................................................................................64
Table 37. I2C Bus Loading ...........................................................................................64
Table 38. GEM424* Controller GPIO Assignment........................................................ 65
Table 39. LED Function................................................................................................67
Table 40. SATA Host I2C Header Pin-out..................................................................... 70
Table 41. Front Panel Connector Designations............................................................ 74
Table 42. Front Panel JP2 Pin-out Descriptions........................................................... 74
Table 43. Front Panel J1 and J2 I2C Pin-out................................................................75
Table 44. Intel® Server Chassis SC5300 System Cables............................................ 79
Table 45. USB Connector Pin-out................................................................................80
Table 46. MTBF Calculations.......................................................................................87
Table 47. Maximum Maintenance Procedure Times.................................................... 87
Table 48. System Office Environment Summary..........................................................89

Introduction Intel® Server Chassis SC5300 5U Kit TPS
12 Revision 1.31
1. Introduction
This specification details the feature set of the Intel®Server Chassis SC5300, an entry-level
server chassis designed for Intel®server board products. The Server Chassis SC5300 series of
products are low cost, quick to integrate, and allow utilization of multiple platforms and
configurations. The Server Chassis SC5300 series comes in three configurations: 600-W
SC53000BASE, 730-W SC5300BRP, and 730-W SC5300LX. The configurations are
distinguishable from one another based primarily on power supply and cooling features.
1.1 Intel®Server Chassis SC5300 Design Features
The Intel®Server Chassis SC5300 series makes extensive use of tool-less hardware features
and, dependent upon configuration and upgrade features, provides redundant cooling and
redundant power supply capability. The following table lists the features for the SC5300BASE,
SC5300BRP, and SC5300LX configurations.
Table 1. Intel® Server Chassis SC5300BASE, SC5300BRP, and SC5300LX Features
Intel® Server Chassis
SC5300BASE Intel® Server Chassis SC5300BRP Intel® Server Chassis SC5300LX
Power
Delivery Includes one (1) fixed
600-W power factor
corrected (PFC) Intel
validated power supply
unit (PSU) with an
integrated cooling fan,
upgradeable to a
redundant (1+1) 730-W
PFC PSU
Includes (1 of 2) redundant
730-W PFC module Intel
validated PSU. Each power
module includes an
integrated cooling fan.
Each redundant power
module includes one (1)
AC line input.
Includes (1 of 2) redundant
730-W PFC module Intel
validated PSU. Each power
module includes an
integrated cooling fan.
Each redundant power
module includes one (1)
AC line input.
System
Cooling Two fixed, non-redundant
chassis fans: one (1) 120-
mm and one (1) 92-mm.
Upgradeable to redundant
cooling with optional
accessory kit. Both fans
are tool-less.
Two fixed, non-redundant
chassis fans: one (1) 120-
mm and one (1) 9-mm.
Upgradeable to redundant
cooling with optional
accessory kit. Both fans
are tool-less
Four tool-less, hot
swappable and redundant
chassis fans with handle-
mounted diagnostic failure
LEDs: two (2) 120-mm and
two (2) 92-mm.
Peripheral
Bays Three (3) tool-less, multi-
mount 5.25-inch
peripheral bays
Three (3) tool-less, multi-
mount 5.25-inch peripheral
bays
Three (3) tool-less, multi-
mount 5.25-inch peripheral
bays

Intel® Server Chassis SC5300 5U Kit TPS Introduction
Revision 1.31 13
Intel® Server Chassis
SC5300BASE Intel® Server Chassis SC5300BRP Intel® Server Chassis SC5300LX
Drive Bays
(6+4) Bay
Layout
Includes one (1) tool-less
fixed drive bay for up to
six (6) fixed IDE or SCSI
drives.
Optional hot-swap / tool-
less drive bays available:
six-drive SCSI, six-drive
SATA/SAS, 4-drive SCSI.
A four-drive tool-less fixed
drive bay is also available
as an accessory
The SC5300BASE
configuration supports up
to six drives.
Includes one (1) tool-less
fixed drive bay for up to six
(6) fixed IDE or SCSI
drives.
Optional hot-swap / tool-
less drive bays available:
six-drive SCSI, six-drive
SATA/SAS, four-drive
SCSI.
A (4) drive tool-less fixed
drive bay is also available
as an accessory
The SC5300BRP
configuration supports up
to 10 drives
Includes one (1) tool-less
fixed drive bay for up to six
(6) fixed IDE or SCSI
drives.
Optional hot-swap / tool-
less drive bays available:
six-drive SCSI, six-drive
SATA/SAS, four-drive
SCSI.
A (4) drive tool-less fixed
drive bay is also available
The SC5300LX
configuration supports up
to 10 drives
PCI Slots Seven full-length PCI slots Seven full-length PCI slots Seven full-length PCI slots.
Optional hot plug PCI kit is
available for the Intel®
Server Board SE7520AF2.
Form Factor 5U Tower, convertible to
rack mount 5U Tower, convertible to rack mount 5U Tower, convertible to rack mount
Front Panel LEDs for NIC1, NIC2,
System ID, HDD activity /
failure and system status.
Power Switch - ID switch,
Reset, Power, Sleep, NMI
Optical side cover
intrusion switch and
connection for bezel
intrusion switch
Integrated temperature
sensor for fan speed
management
LEDs for NIC1, NIC2,
System ID, HDD activity /
failure and system status.
Power Switch - ID switch,
Reset, Power, Sleep, NMI
Optical side cover intrusion
switch and connection for
bezel intrusion switch
Integrated temperature
sensor for fan speed
management
LEDs for NIC1, NIC2,
System ID, HDD activity /
failure and system status.
Power Switch - ID switch,
Reset, Power, Sleep, NMI
Optical side cover intrusion
switch and connection for
bezel intrusion switch
Integrated temperature
sensor for fan speed
management
External Two (2) front USB and
one (1) optional front or
rear mounted serial port
Two (2) front USB and one
(1) optional front or rear
mounted serial port
Two (2) front USB and one
(1) optional front or rear
mounted serial port
Color Black Black Black
Construction 1.0 mm, zinc plated sheet
metal, meets Intel
Cosmetic Spec # C25432
1.0 mm, zinc plated sheet
metal, meets Intel
Cosmetic Spec # C25432
1.0 mm, zinc plated sheet
metal, meets Intel
Cosmetic Spec # C25432
Chassis ABS Fire retardant, non-
brominated
PC-ABS
Fire retardant, non-
brominated
PC-ABS
Fire retardant, non-
brominated
PC-ABS

Introduction Intel® Server Chassis SC5300 5U Kit TPS
14 Revision 1.31
Intel® Server Chassis
SC5300BASE Intel® Server Chassis SC5300BRP Intel® Server Chassis SC5300LX
Dimensions
(Rack) 17.5-inch x 8.6-inch x
26.2-inch 17.5-inch x 8.6-inch x 26.2-inch 17.5-inch x 8.6-inch x 26.2-inch
Dimensions
(Pedestal) 17.5-inch x 8.6-inch x
26.9-inch 17.5-inch x 8.6-inch x 26.9-inch 17.5-inch x 8.6-inch x 26.9-inch
Weight 34.6 kg 36.2 kg 36.2 kg
Optional
Accessories Rack Conversion Kit
Rack Cable Management
Arm
Intel® Management
Module
Slim-line CD and Floppy
Carrier
Redundant Power Supply
Kit
Six (6) Drive Hot-swap
SCSI Backplane
Six (6) Drive Hot-swap
SATA.SAS backplane
Four (4) Drive Hot-swap
SCSI Backplane
Redundant Cooling
Upgrade Kit
10-pack Branding /
Customization Panels
Four (4) Drive Fixed Drive
Bay
Unpainted Rack Top
Cover
Rack Conversion Kit
Rack Cable Management
Arm
Intel® Management
Module
Slim-line CD and Floppy
Carrier
Redundant Power Supply
Kit
Six (6) Drive Hot-swap
SCSI Backplane
Six (6) Drive Hot-swap
SATA/SAS Backplane
Four (4) Drive Hot-swap
SCSI Backplane
Redundant Cooling
Upgrade Kit
10-pack Branding /
Customization Panels
Four (4) Drive Fixed Drive
Bay
Unpainted Rack Top Cover
Rack Conversion Kit
Rack Cable Management
Arm
Intel® Management
Module
Slim-line CD and Floppy
Carrier
Redundant Power Supply
Kit
Six (6) Drive Hot-swap
SCSI Backplane
Six (6) Drive Hot-swap
SATA/SAS Backplane
Four (4) Drive Hot-swap
SCSI Backplane
Redundant Cooling
Upgrade Kit
10-pack Branding /
Customization Panels
Four (4) Drive Fixed Drive
Bay
Unpainted Rack Top Cover
Hot-plug PCI Kit
1.2 Intel®Server Chassis SC5300BASE Summary
The Intel® Server Chassis SC5300BASE is designed to address the entry-level market. It
includes a fixed single 600-W Power Factor Correction (PFC) non-redundant power supply,
which supports up to six hard drives. Two tachometer output fans are mounted in front of the
server board. Optional four- and six-drive SCSI hot swap drive bay kits provide upgrades to
allow support for 6 hot swap SCSI drives. An optional six-drive hot swap SATA/SAS drive bay
is also available. Three 5.25-inch half-height peripheral bays are available for installation of a
floppy drive, CD-ROM drive and/or other accessories. Standard chassis configuration is
pedestal. A rack mount conversion kit is available.

Intel® Server Chassis SC5300 5U Kit TPS Introduction
Revision 1.31 15
1.3 Intel®Server Chassis SC5300BRP Summary
The Intel®Server Chassis SC5300BRP supports the redundant power capability of the
SC5300LX configuration and the fixed fan features of the SC5300BASE configuration. The
SC5300BRP configuration includes a single 730-W PFC power supply module. Two
tachometer output fans are mounted in front of the server board. When populating the server
chassis with a single power supply, the power supply must be populated in the first power
supply bay. A second 730-W module may be added to provide redundant power supply.
Optional four- and six-drive SCSI hot swap drive bay kits provide upgrades to allow support for
up to 10 hot swap SCSI drives. An optional six-drive hot swap SATA/SAS drive bay is also
available. Three 5.25-inch half-height peripheral bays are available for installations of a floppy
drive, CD-ROM drive and/or other accessories.
1.4 Intel®Server Chassis SC5300LX Summary
The Intel® Server Chassis SC5300LX supports redundant power and includes redundant fan
features. The SC5300LX configuration includes a single 730-W PFC power supply module.
When populating the server chassis with a single power supply, the power supply must be
populated in the first power supply bay. A second 730-W module may be added to provide
redundant power supply. Four LED hot swap tachometer output fans provide redundant
cooling. Optional four- and six-drive SCSI hot swap drive bay kits provide upgrades to allow
support for up to 10 hot swap SCSI drives. An optional six-drive hot swap SATA/SAS drive bay
is also available. Three 5.25-inch half-height peripheral bays are available for installation of a
floppy drive, CD-ROM drive and/or other accessories. The standard chassis configuration is
pedestal. A rack mount conversion kit is available.
Table 2. Product Matrix
Product Code Intel®
Server
Board
Optional
Hot Swap
SCSI/SAT
A/SAS
Drives
Standard
Fixed Hard
Drive Bays
Power Supply and
Required Power
Cord Configuration
Hot
Swap
Fans
Pedestal/
Rack
SC5300BASE
Fixed 600-W
SE7520AF2
SE7520BD2
SE7525SP2
SE7525GP2
6-SCSI
6-
SATA/SAS
4-SCSI
6-drive bay
4-drive bay
optional
accessory
is available
Fixed 600-W PFC
Requires one power
cord
No Pedestal is
Standard.
Rack
Conversion
Kit is an
accessory.
SC5300BRP
Hot Swap
Redundant
730-W
SE7520AF2
SE7520BD2
6-SCSI
6-
SATA/SAS
4-SCSI
6-drive bay
4-drive bay
optional
accessory
is available
One 730-W PFC
module installed.
Second power
module is optional.
Requires one power
cord per module.
No Pedestal is
Standard.
Rack
Conversion
Kit is an
accessory.
SC5300LX
Hot Swap
SE7520AF2
SE7520BD2
6-SCSI or
6- 6-drive bay
4-drive bay
One 730-W PFC
module installed. Yes Pedestal is Standard.

Introduction Intel® Server Chassis SC5300 5U Kit TPS
16 Revision 1.31
Redundant
730-W SATA/SAS
4-SCSI
optional
accessory
is available
Second power
module is optional.
Requires one power
cord per module.
Rack
Conversion
Kit is an
accessory.

Intel® Server Chassis SC5300 5U Kit TPS Chassis Features
Revision 1.31 17
2. Chassis Features
2.1 Chassis Dimensions and Weight
Shipping weights include packaging.
Complete systems configured with server board, accessories and hard disk drivers will have
varying weights.
Table 3. Chassis Dimensions and Weights
Configuration Pedestal Rack
Height 17 inches (43.2 cm) 8.6 inches (21.8 cm)
Width 8.6 inches (21.8 cm) 16.5 inches (41.9 cm)
Depth 27.9 inches (70.9 cm) 27.4 inches (69.6 cm)
Clearance Front 10 inches (25.4 cm) N/A
Clearance Rear 5 inches (12.7 cm) N/A
Clearance Side 3 inches (7.6 cm) N/A
LX 36.2 kg 36.2 kgWeight
Base 34.6 kg 34.6 kg
2.2 System Colors
The Intel® Server Chassis SC5300 is offered in one color configuration, black.
Table 4. System Color Code
Manufacturer Color Code
GE Black GE701
2.2.1 Pedestal and Rack Mount Features
The standard pedestal front bezel is a molded plastic door covering all drive bays. A key lock is
provided to prevent unauthorized access to the peripheral bays. A molded plastic sub-bezel is
located on the face of the chassis under the front bezel. The sub-bezel houses the front panel
buttons and light pipes for the front panel indicators. Each peripheral bay is covered with a
removable electromagnetic interference (EMI) shield.
Opening the exterior plastic door on the pedestal chassis accesses the hot swap hard drives.
An EMI shield is incorporated into the drive carrier design, eliminating the need for a separate

Chassis Features Intel® Server Chassis SC5300 5U Kit TPS
18 Revision 1.31
shield or door. This adds flexibility to the bezel design by making EMI performance independent
of the cosmetic plastic parts.
Customized bezels for OEM customers can be designed from the standard bezel design. OEM
snap-in branding panels are available.
In the rack mount configuration, the front door is removed and the sub-bezel becomes the front
panel for the rack mount system. The rack mount kit includes the chassis slides, rack handles,
front door hinge cover plate and intrusion switch modification hardware.
2.3 Security
A variety of chassis security options are provided at the system level:
1. A two-position key lock/switch will unlock the front bezel and side cover in the
pedestal configuration only. Rack mount configuration does not have a key lock.
2. For rack mounted systems, a removable padlock loop on the rear of the system
access cover can be used to prevent access to the microprocessors, memory, and
add-in cards. A variety of lock sizes can be accommodated by the 0.270-inch
diameter loop.
3. A Kensington* cable lock mounting hole is provided on the rear chassis I/O panel.
4. An intrusion switch for the side panel and front bezel door are standard. In the rack
mount configuration, only the system cover has an active intrusion switch. Note: See
the appropriate Server Board Technical Product Specification on the
support.intel.com website for a description of BIOS and Intel®Server Management
security features. Intrusion switches are provided allowing server management
software, such as Intel®Server Management (ISM), to detect unauthorized access to
the system cover and pedestal bezel door.
2.4 I/O Panel
All input/output (I/O) connectors are accessible on the rear of the chassis. The SSI E-bay 3.5-
compliant chassis provides an ATX* 2.03-compatible cutout for I/O shield installation. Boxed
server boards provide the required I/O shield for installation in the cutout. The I/O cutout
dimensions are shown in the following figure.
The rear I/O panel conforms to the Advanced Technology Extended (ATX) Specification,
Revision 2.1, and supports seven full-length expansion PCI adaptor cards.
I/O Aperture Baseboard Datum 0,0
5.196 ±0.0106.250 ± 0.008
1.750 ± 0.008
(0.650)
(0.150)
0.100 Min keepout around opening
R 0.039 MAX, TYP
Figure 1. ATX* 2.03 I/O Aperture

Intel® Server Chassis SC5300 5U Kit TPS Chassis Features
Revision 1.31 19
2.5 Standard and Optional Hot Swap Drive Bays
One fixed bay, supporting six cabled drives, ships with the standard chassis. An optional four-
drive bay for cabled (fixed) drives is available. Optional four- and six-drive hot swap bays are
also available and may be installed to replace either the six- or four-drive fixed bays. No tools
are required to replace the fixed drive bays. An optional six drive hot swap SATA/SAS bay is
also available. See the appendix for a full list of accessories.
2.6 5.25-inch Half-height Peripheral Bays
Three 5.25-inch, half-height drive bays are available for installation of a floppy drive, CD-ROM
drive or tape drive. The chassis ships with a 3.5-inch floppy or fixed drive carrier installed in the
top 5.25-inch drive bay and two empty 5.25-inch drive bays. Tool-less mounting rails are
included for all three drive bays and attach without screws.
TP00895
Figure 2. Tool-less Rails Mounting 5.25-inch CDROM Drive
