Intel®4-Processor Server System
S7000FC4UR
Configuration Guide
Intel Value and Enterprise Servers
Rev 1.7
A reference guide to assist customers in ordering components to configure
S7000FC4UR
4-Processor 4U SAS 2.5” and 3.5” Server
Revisions/Additions in blue font
S7000FC4UR Configuration Guide Page 1 of 12

1/7/2009 S7000FC4UR Configuration Guide Page 2 of 12
1. Table of Contents
1. Table of Contents..................................................................................................................2
2. Revision History....................................................................................................................3
3. Important Notes ....................................................................................................................3
4. Base System SKU Contents ................................................................................................4
5. Value and Enterprise System SKU Comparsion................................................................5
6. Production System Configuration Options........................................................................7
7. Base System Part Configurator...........................................................................................8
8. Complete Product Production Ordering Code Listings....................................................9
8.1 Table 1: Base System Codes...................................................................................9
8.2 Table 2: System Accessory Codes ..........................................................................9
8.3 Table 3: System Field Replaceable Units (FRUs) and Spare Part Codes.............11
9. Processor Codes Reference..............................................................................................12
9.1 Tray Processor Codes Reference..........................................................................12
9.2 Boxed Processor Codes Reference (does not include Heatsink) ..........................12

1/7/2009 S7000FC4UR Configuration Guide Page 3 of 12
2. Revision History
Date Rev Modification
Aug 29, 2006 0.1 NPI Draft
Dec 1, 2006 0.2 Alpha MM#s Added
Jan 15, 2006 0.3 Added Beta Placeholders
Feb 25, 2007 0.6 Updated Production and Beta SKU information
Mar 25, 2007 0.9 Updated Production Placeholders and Silver SKU information
April 20, 2007 0.95 Updated Production MM#s and Added Spares SKUs
June 22, 2007 0.98 Updated Production MM #s, added spares and Value vs. Enterprise pages
July 15, 2007 1.0 Promoted to rev 1.0 status, removed Pre-Production Order Codes, Improved description of
FFCCABLEKIT, added Boxed Processor Reference codes
July 30, 2007 1.1 Updated Config table with corrections
Sept 1, 2007 1.2 Revised with Corrections
April 21, 2008 1.3 Updated MM#s
Sept 1, 2008 1.4 Updated MM#s
Sept 12, 2008 1.5 Updated MM#s, and added Dunnington Boxed and Tray Processor Reference Codes
Dec 1, 2008 1.6 Updated MM#s
Jan 7, 2009 1.7 Added new SFC4URX 3.5” SKU and new spare Hot Swap Backplane; updated MM#
3. Important Notes
1. Each S7000FC4UR server system can accommodate up to four memory boards. System SKUs include one memory board
in the base configuration.
2. Product code SFC4URE comes preconfigured with redundant cooling and power.
3. Product code SFC4UR comes preconfigured with 1 power supply and an empty second power supply bay and 2 of 4 rear
fan modules. Additional accessories may be ordered for redundant power and cooling configuration requirements.
4. Systems will not ship with processors, hard drives, or memory. These parts must be obtained separately.
5. Heat sinks are not included with any server systems.
6. Processor thermal blanks must be ordered separately (if no processor is installed).
7. The S7000FC4UR memory board supports FBD 533 or 667 registered DIMMs.
8. The Intel factory will package board orders into single order packaging and ship to fill customer orders. Each board MM is a
self-contained shipping package of one board.
9. Power cords are not shipped with the system and must be obtained from local suppliers.
10. All parts listed below are fully RoHS compliant.
11. The SFC4URX 3.5” SKU requires a Host Bus Adapter (HBA) or RAID Adapter for operation. The SAS Riser AFCSASRISER
is not used with this SKU. Please refer to the Intel® Server System S7000FC4UR Tested Hardware and Operating System
List or consult your Intel support representative.

1/7/2009 S7000FC4UR Configuration Guide Page 4 of 12
4. Base System SKU Contents
System Part Description
SFC4URE
Enterprise
SKU
Production
SFC4UR
Value
SKU
Production
SFC4URX
3.5”
SKU
Production
1/2" DVD-ROM Drive 1 0 0
Base Chassis 1 1 1
Baseboard 1 1 1
Bezel 0 0 0
Button Control Panel 1 1 1
Button panel cable 1 1 1
Drive Power Cable (Tape Backup and DVD-ROM) 1 1 1
Fan Power Cable 1 1 1
Front Fan Module 2 2 2
Front Panel Cable (SAS to Front Panel) 1 1 1
Front Panel IO board 1 1 1
Integrated RAID activation key 0 0 0
Integrated RAID Battery 0 0 0
Integrated RAID Memory 0 0 0
Intel LCD Control Panel 0 0 0
Intel Remote Management Module 0 0 0
IO Riser 1 0 0
Memory Board (8 Slots per board) with 8 DIMM fillers 1 1 1
Memory Board Filler Baffles NA NA NA
Power Supply Filler Panel NA NA NA
Power Supply Modules (15Amp, 110/220V) 2 1 1
Processor Heatsinks 0 0 0
Processor Thermal Dummy 0 0 0
Rack Faceplate Assembly 1 1 1
Rack Handles (Pair) 1 1 1
Rear Fan Module 4 2 2
Sample Safety Label 1 1 1
SAS Riser to backplane cable 2 0 0
SAS Riser with Integrated RAID capability (Intel) 1 0 0
SAS/SATA 4U Backplane Board 1 1 1
SAS/SATA HDD Carrier (Black) 2.5” 8 8 NA
SAS/SATA HDD Carrier (Black) 3.5” NA NA 5
SATA Optical drive cable 1 1 1
SATA to IDE converter board 1 1 1
System Packaging (with Intel labeling) 1 1 1
System Serial # Label 1 1 1

5. Value and Enterprise System SKU Comparsion
1/7/2009 S7000FC4UR Configuration Guide Page 5 of 12

1/7/2009 S7000FC4UR Configuration Guide Page 6 of 12

6. Production System Configuration Options
Processor
Heatsink
OR
Processor
Blank
Mandatory Accessories
Optional Accessories
SFC4UR
Value 4U Server
Up to 3 additional
memory boards. ROMB Key
and Batter
y
Redundant
Power Supply
Bezel
SAS Expansion
Module Redundant Fans
Remote Management
Module 2 (RMM2) Rack Rails and
CMA
DVD-ROM
Drive
Included in SFC4URE
OR
SFC4URE
Enterprise 4U Server
I/O
Module
OR
SFC4URX 3.5”
4U Server
1/7/2009 S7000FC4UR Configuration Guide Page 7 of 12

1/7/2009 S7000FC4UR Configuration Guide Page 8 of 12
7. Base System Part Configurator
Mandatory Accessories
Feature Product
Processor heat sink
AFCPROCHS
Processor
Heat Sinks and Blanks
(All 4 sockets must have Processor + Heatsink
OR
Processor Blank)
Processor blank
AFCPROCBLANK
Optional Accessories
Feature Product
LCD Control Panel LCD control panel
AXXLCPMOD2
Memory board 8 DIMM memory board
BFCMEM
RAID Solutions Intel® SAS 2.5” RAID Activation Key
AXXRAKSAS2
(only used with SAS Module above)
Intel® RAID Smart Battery
AXXRSBBU4
(only used with SAS Module and Activation Key above)
Rack rails
AXXRAIL3U7U
Rack Mount Solutions Cable Management Arm
AXXCMA3U7U
Front Bezel 4U Front bezel for rack mount
AHW4URBEZEL
Intel® Remote Server
Management Module (RMM2) RMM requires Network IO Module (FFCIORISER) to connect
AXXRMM2
(only used with IO Module above)
Below Accessories are included in Enterprise System SKU (SRFC4URE)
SAS Module Enables SAS Storage Capability with Intel Integrated RAID
AFCSASRISER
Integrated Network IO Module Dual Channel NIC Module, with connector for RMM2
FFCIORISER
Redundant Rear Fans Additional Cooling Reliability to Server (+2 fans per Server)
FFC4UBKFAN
Redundant Power Supply Additional Power Reliability to Server (+1 per Server)
AFC4UPWR
Optical DVD Media Drive DVD-ROM drive
AFCDVD

8. Complete Product Production Ordering Code Listings
The following table lists all of the product codes applicable to the Fox Cove platform (sorted by category). Following
the table are individual document sections which provide additional product descriptions for each product code.
8.1 Table 1: Base System Codes
Image MM /
UPC Product Code Description of Product Qty Per Min Order
899977 SFC4UR Intel® Server System S7000FC4UR. Base
Customizable (Value SKU) 1 1
899982 SFC4URE Intel® Server System S7000FC4UR. (Enterprise SKU) 1 1
900851 SFC4URX Intel® Server System S7000FC4UR. (3.5” SKU) 1 1
8.2 Table 2: System Accessory Codes
1/7/2009 S7000FC4UR Configuration Guide Page 9 of 12
Image MM /
UPC Product Code Description of Product Qty Per Min Order
899976 BFCMEM S7000FC4UR Memory board, 8 DIMM slots, FBD-
533/667. Single-Pack. 1 1
891016 AFC4UPWR Power supply module. 4U. 15Amp, 110/220V. 1 1
891013 AFCPROCHS
Intel® CEK processor heat sink.
1 1
861922 AHW4URBEZEL Bezel for front of S7000FC4UR. 1 1
891014 AFCPROCBLANK
Intel® CEK processor blank. One required for every
empty processor slot to maintain proper airflow for
cooling. 1 1
881379 AXXBCPMOD2 Button Control Panel Module. 1 1
879578 AXXLCPMOD2 Intel® Local Control Panel
862119 AXXCMA3U7U Rack cable management arm. 3U-7U chassis. Does
not include the rack rails. Supports S7000FC4UR. 1 1
881844 AXXRAIL3U7U Rack rails for 3U-7U chassis. Does not include the
cable management arm. Tool-less J-hook design.
Supports S7000FC4UR. 1 1
892106 AFCSASRISER SAS Controller Module with Integrated RAID for
S7000FC4UR. Includes interconnect cables: 2X SAS
cables and SES cable. 1 1
891290 AXXRAKSAS2 Intel® SAS RAID Activation Key. 1 5

1/7/2009 S7000FC4UR Configuration Guide Page 10 of 12
899346 AXXRSBBU4 Intel® RAID Smart Battery. 1 5
894383 AXXRMM2 Intel® Remote Management Module. 1 1
881681 FXX25HDDCAR Intel® 2.5" SAS Hard Drive Carrier. 10 1
880265 FXX10DVCARBLK Intel® 3.5" SAS Hard Drive Carrier. 10 1
891932 AFCDVD Slim Line DVD Spare 1 1
891570 FFC4UBKFAN Rear System fans for the S7000FC4UR. 2 1

Table 3: System Field Replaceable Units (FRUs) and Spare Part Codes
Image MM /
UPC Product Code Description of Product Qty Per Min Order
899975 BFCBASE Intel® Server Base board for S7000FC4UR 1 1
BRD 881385 FHW4UFRTPNL Control Panel IO Board for S7000FC4UR. 1 1
Spare 891614 FFC4UPLAS Processor (Top/Bottom) Air Ducts, PCI Divider
assembly, PCI Card hold down latch assemblies (25
green, 25 blue) for S7000FC4UR. 1 1
Spare 891583 FFCINTRU Cable: Intrusion switch for S7000FC4UR. 1 1
891440 FFCIORISER
Dual channel NIC and RMM attach IO Riser for
S7000FC4UR. 1 1
898557 FFCSASRISER SAS Controller Module with Integrated RAID for
S7000FC4UR. 1 1
Spare 885051 FHW4U2SASBP SAS 2.5” 4U backplane for S7000FC4UR. 1 1
Spare 876328 FHW4U3SASBP SAS 3.5” 4U backplane for S7000FC4UR. 1 1
881380 FHW4UFAN Front System fan for the S7000FC4UR. 1 1
Spare 881390 FHW4UPDB Power distribution board for SR4850HW4. 1 1
Spare 891572 FFC4UINTSATA Cable: Baseboard x4 SATA Port to SAS HDD
backplane. (7 pin) 1 1
Spare 870273 FHWSATAIDE SATA to IDE conversion board. 1 1
Spare 891600 FFCCABLEKIT S7000FC4UR System Cables Bundle
(Includes all of the Cables Below) 1 1
FFC4UBBSATA Cable: Baseboard x1 SATA Port to Optical Media
Drive. (7 pin) 1 1
FFC4UCP Cable: Front panel control to front panel I/O 1 1
FFC4UFPBPSAS Cable: Front panel I/O to HDD Backplane for
S7000FC4UR. (34 pin) 1 1
FFC4UFPSATA Cable: Front panel IO to Baseboard for S7000FC4UR.
(100 pin) 1 1
FFC4UFRTFANPWR Cable: Front Fan Power cable 1 1
FFC4UINTSAS Cable: Internal SAS Riser to 2.5" Backplane. 2 1
Cable: 5.25" Peripheral bay to SAS HDD Backplane
for S7000FC4UR. (4 pin power) 1
Cable: SES SAS Module Riser to SAS backplane LED
Fault cable (3 pin) 1
1/7/2009 S7000FC4UR Configuration Guide Page 11 of 12

1/7/2009 S7000FC4UR Configuration Guide Page 12 of 12
9. Processor Codes Reference
9.1 Tray Processor Codes Reference
Category Product Code Description
Tray Processor 80565KH0778M 2.93 GHz / 2X4M Quad-Core Intel® Xeon® processor X7350 (Tigerton 130W)
Tray Processor 80565JH0368M 1.86 GHz / 2X4M Quad-Core Intel® Xeon® processor L7345 (Tigerton 50W)
Tray Processor 80565QH0568M 2.40 GHz / 2X4M Quad-Core Intel® Xeon® processor E7340 (Tigerton 80W)
Tray Processor 80565QH0566M 2.40 GHz / 2X3M Quad-Core Intel® Xeon® processor E7330 (Tigerton 80W)
Tray Processor 80565QH0464M 2.13 GHz / 2X2M Quad-Core Intel® Xeon® processor E7320 (Tigerton 80W)
Tray Processor 80565QH0254M 1.60 GHz / 2X2M Quad-Core Intel® Xeon® processor E7310 (Tigerton 80W)
Tray Processor 80564QH0778M 2.93 GHz / 2X4M Dual-Core Intel® Xeon® processor E7220 (Tigerton 80W)
Tray Processor 80564QH0568M 2.40 GHz / 2X4M Dual-Core Intel® Xeon® processor E7210 (Tigerton 80W)
Category Product Code Description
Tray Processor 80582KH067007 2.66 GHz / 16M Six-Core Intel® Xeon® Processor X7460 (Dunnington 130W)
Tray Processor 80582JH046003 2.13 GHz / 12M Six-Core Intel® Xeon® Processor L7455 (Dunnington 65W)
Tray Processor 80583JH046003 2.13 GHz / 12M Quad-Core Intel® Xeon® Processor L7445 (Dunnington 50W)
Tray Processor 80582QH056003 2.40 GHz / 12M Six-Core Intel® Xeon® Processor E7450 (Dunnington 90W)
Tray Processor 80583QH056007 2.40 GHz / 16M Quad-Core Intel® Xeon® Processor E7440 (Dunnington 90W)
Tray Processor 80583QH046003 2.13 GHz / 12M Quad-Core Intel® Xeon® Processor E7430 (Dunnington 90W)
Tray Processor 80583QH0468M 2.40 GHz / 8M Quad-Core Intel® Xeon® Processor E7420 (Dunnington 90W)
9.2 Boxed Processor Codes Reference (does not include Heatsink)
Category Product Code Description
Boxed Processor BX80565X7350 2.93 GHz / 2X4M Quad-Core Intel® Xeon® processor X7350 (Tigerton 130W)
Boxed Processor BX80565E7340 2.40 GHz / 2X4M Quad-Core Intel® Xeon® processor E7340 (Tigerton 80W)
Boxed Processor BX80565E7330 2.40 GHz / 2X3M Quad-Core Intel® Xeon® processor E7330 (Tigerton 80W)
Boxed Processor BX80565E7320 2.13 GHz / 2X2M Quad-Core Intel® Xeon® processor E7320 (Tigerton 80W)
Boxed Processor BX80565E7310 1.60 GHz / 2X2M Quad-Core Intel® Xeon® processor E7310 (Tigerton 80W)
Category Product Code Description
Boxed Processor BX80582X7460 2.66 GHz / 16M Six-Core Intel® Xeon® Processor X7460 (Dunnington 130W)
Boxed Processor BX80582E7450 2.40 GHz / 12M Six-Core Intel® Xeon® Processor E7450 (Dunnington 90W)
Boxed Processor BX80583E7440 2.40 GHz / 16M Quad-Core Intel® Xeon® Processor E7440 (Dunnington 90W)
Boxed Processor BX80583E7420 2.40 GHz / 8M Quad-Core Intel® Xeon® Processor E7420 (Dunnington 90W)

Mouser Electronics
Authorized Distributor
Click to View Pricing, Inventory, Delivery & Lifecycle Information:
Intel:
FFCSASRISER
