Inter-m SYSTEM-2240G User manual

Operation Manual
MULTI P.A COMBINATION
SYSTEM-2240G
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 1

Cont nts
Cont nts
W lcom
Warning.........................................................................................................................................1
Unpa king......................................................................................................................................1
Installation
Environment....................................................................................................................................2
Important Safety Instru tions.............................................................................................................2
F atur s............................................................................................................................................3
A essories.....................................................................................................................................3
Op ration ........................................................................................................................................3
Front Pan l ......................................................................................................................................4
R ar Pan l .....................................................................................................................................10
How to Us CD / MP3 Play r ....................................................................................................12
Op rating th Cass tt D ck......................................................................................................15
Cass tt Maint nanc ..................................................................................................................16
Application of Th Ant nna........................................................................................................18
Conn cting th Sp ak rs ............................................................................................................19
Applications ..................................................................................................................................20
Block Diagrams.............................................................................................................................21
Sp cifications ................................................................................................................................22
S rvic
Pro edures....................................................................................................................................23
S hemati .....................................................................................................................................23
Parts List .......................................................................................................................................23
Variations and Options ...............................................................................................................23
Warranty .......................................................................................................................................23
MULTI P.A COMBINATION
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 2

MULTI P.A COMBINATION
1
SYSTEM-2240G
Welco e
Welco e
A p rsonal w lcom to you from th manag m nt and mploy s of Int r-M
All of the o-workers here at Inter-M are dedi ated to providing ex ellent produ ts with inherently good value,
and we are delighted you have pur hased one of our produ ts.
We sin erely trust this produ t will provide years of satisfa tory servi e, but if anything is not to your omplete
satisfa tion, we will endeavor to make things right.
Wel ome to Inter-M, and thank you for be oming part of our worldwide extended family!
* It can b h at d up if you us this product in clos d box or ill-v ntilat d plac .
ISK OF ELECT IC SHOCK
DO NOT OPEN
CAUTION
CAUTION: TO EDUCE THE ISK OF ELECT IC SHOCK.
DO NOT EMOVE COVE (O BACK).
NO USE -SE VICEABLE PA TS INSIDE.
EFE SE VICING TO QUALIFIED SE VICE PE SONNEL.
ATTENTION : ISQUE DE CHOC ELECT IQUE
NE PAS QUV I
WARNING
To prevent fire or shock hazard, do not
expose the unit to rain or moisture.
*WA NING FO YOU P OTECTION PLEASE EAD THE FOLLOWING-WATE AND MOISTU E: Unit should not be used near water(e.g.
near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, etc). Care should be taken so than objects do
not fall and liquids are not spilled into the enclosure through openings.
*Do not install this equipment in a confined space such as a book case or similar unit.
*Warning : To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture and objects filled with liquids, such as vases,
should not be placed on this apparatus.
*This apparatus shall be connected to a mains socket outlet with a protective earthing connection.
*
To completely disconnect this apparatus from the AC mains, disconnect the power supply cord plug from the AC receptacle.
* The mains plug of the power supply cord shall remain readily accessible.
CAUTION
*These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric shock, do not perform any servicing
other than that contained in the operating instructions unless you are qualified to do so.
NOTE
*This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC ules. These limits are
designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
This symbol is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock to
persons.
This symbol is intended to alert the user to the
presence of important operation and maintenance
(servicing) instructions in the literature accompanying
the appliance.
Caution: To prevent electric shock do not use this (polarized) plug with
an extension cord, receptacle or other outlet unless the blades
can be fully inserted to prevent blade exposure.
Attentions: Pour prévenir les chocs électriques ne pas utiliser cette
fiche polarisée avec un prolongateur, une prise de courant
on une autre sortie de courant, sauf si les lames peuvent
étre insérées à fond sans en laisser aucune partie à
découvert.
Pour deconnecter completement l’appareil du reseau
d’alimentation. deconnecter le cordon d’alimentation de la
prise murale.
La prise du reseau d’alimentation doit demeurer aisement
accessible.
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 3

MULTI P.A COMBINATION
2SYSTEM-2240G
Unpacking
Please take a few minutes to read this manual to familiarize yourself with the important information regarding
installation, produ t features, and operation.
As with most ele troni devi es, we strongly re ommend you retain the original pa kaging. In the unlikely event
the produ t must be returned for servi ing, the original pa kaging (or reasonable equivalent) is required.
Installation
Unpacking
Please take a few minutes to read this manual to familiarize yourself with the important information regarding
installation, produ t features, and operation.
As with most ele troni devi es, we strongly re ommend you retain the original pa kaging. In the unlikely event
the produ t must be returned for servi ing, the original pa kaging (or reasonable equivalent) is required.
Installation
Environ ent
Never pla e this produ t in an environment whi h ould alter its performan e or redu e its servi e life. Su h
environments usually in lude high levels of heat, dust, moisture, and vibration.
I portant Safety Instructions
1. Read these instru tions.
2. Keep these instru tions.
3. Heed all warnings.
4. Follow all instru tions.
5. Do not use this apparatus near water.
6. Clean only with dry loth.
7. Do not blo k any ventilation openings. Install in a ordan e with the manufa turer’s instru tions.
8. Do not install near any heat sour es su h as radiators, heat registers, stoves, or other apparatus (in luding
amplifiers) that produ e heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet, onsult an ele tri ian
for repla ement of the obsolete outlet.
10. Prote t the power ord from being walked on or pin hed parti ularly at plugs,
onvenien e re epta les, and the point where they exit from the apparatus.
11. Only use atta hments/a essories spe ified by the manufa turer.
12. Use only with the art, stand, tripod, bra ket, or table spe ified by the manufa turer, or sold with the apparatus.
When a art is used, use aution when moving the art/apparatus ombination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods of time.
14. Refer all servi ing to qualified servi e personnel. Servi ing is required when the apparatus has been damaged
in any way, su h as power-supply ord or plug is damaged, liquid has been spilled or obje ts have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been
dropped.
S3125A
S3125A
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 4

MULTI P.A COMBINATION
3
SYSTEM-2240G
Features
Features
- SPEAKER SELECTOR
Eleven-speaker sele tor swit hes allow you to sele t up to 10 speakers in any ombination.
- SEVEN-BAND EQUALIZER AND SPECTRUM ANALYZER
Seven-band graphi equalizer with full spe trum analyzer gives you unlimited tonal ontrol, allowing you to
shape your sound to meet your environment.
- TUNER MEMORY
Digital quartz tuner with 30 available memory lo ations (18 FM, 12 AM) provides instant a ess to your favorite
stations.
- 1CD/MP3
The produ t has a built-in CDP than an play ba k the CD stored in a MP3 file format to enable onvenient
use.(Support playba k of CD in CD/MP3 format.)
- SIDE PANEL MONITOR SPEAKER
Side-mounted monitor speaker with three-position swit h allows you to monitor the system’s output.
- ANNOUNCEMENT CHIME
Convenient four-tone hime for use with announ ements.
- RECORD FUNCTION
The system has a re ord fun tion whi h is allowing you to reate another master tape.
Accessories
One deta hable AC power ord is provided for use with this produ t.
Operation
Operation
Make ertain that speakers and input sour es are properly onne ted before swit hing on.
Keep volume levels turned down and graphi equalizer set to 0dB position before swit hing on.
When the power swit h is pressed, this unit starts operation with tuner display.
NOTE: The system’s operation is delayed by approximately three se onds after pressing the power swit h. This is
due to the built-in prote tion ir uitry, designed to prote t the speakers and other system omponents.
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 5

MULTI P.A COMBINATION
4SYSTEM-2240G
Front Panel
Front Panel
1. SPEAKER SELECTOR
These swit hes are used to individually sele t audio output to any ombination of up to 10 speakers.
2. POWER SWITCH
Pressing this button swit hes the unit on, as indi ated by the Power LED. Pressing the button again will swit h
the unit off.
3. SPECTRUM ANALYZER
The seven multi-segment LED meters indi ate the level of ea h asso iated frequen y band.
4. GRAPHIC EQUALIZER
Ea h slider ontrols the ut (de reased gain) or boost (in reased gain) for its asso iated frequen y band. The
middle position indi ates flat response (no ut or boost). Moving the slider upwards in reases that
frequen y’s gain, while moving it down de reases the level of that frequen y.
5. MONITOR SWITCH
This swit h ontrols the relative volume of the side-mounted monitor speaker.
REC MUTE
TAPE DIRECTION
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 6

MULTI P.A COMBINATION
5
SYSTEM-2240G
6. MASTER VOLUME
This knob provides ontinuous ontrol of the overall system output volume.
7. CHIME BUTTON
Pressing this swit h a tivates the hime ir uitry.
8. MIC 1 INPUT
High-impedan e input ja k for Mi 1. (Note: Mi inputs 2-5 are lo ated on the rear panel.)
9. MIC INPUT LEVEL CONTROLS
Controls the individual levels of mi inputs 1 through 5.
10. CD VOLUME
Controls the level of the CD playba k output.
11. TUNER VOLUME
Controls the level of the AM/FM tuner output.
12. DECK VOLUME
Controls the level of Cassette De ks A and B output. Can also be used to ontrol the re ord level when
dubbing from de k A to de k B.
13. AUX VOLUME
Controls the level of Aux 1 and Aux 2 inputs.
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 7

MULTI P.A COMBINATION
6SYSTEM-2240G
1. CD/MP3 SECTION
1. DISC TRAY
The 1p of CD/MP3 dis is inserted or eje ted at dis tray. Only use the size of 12 m dis .
2. STOP BUTTON
Depressing this button stops playba k of the CD/MP3 dis .
3. PLAY/PAUSE
Depressing this button will pause CD/MP3 Playba k. Depressing a se ond time will resume play.
4. SCAN
Depressing this button will play the first 10 se onds of ea h song in sequen e. Depressing again will resume normal play.
5. REPT (REPEAT)
Depress this button on e to repeat the urrently playing song. Depress and hold for more than one se ond, to
repeat all the songs in the urrent MP3 dire tory. Depress again to repeat all songs on the dis . Depress
again to release Repeat fun tion.
6. RAND (RANDOM)
Depress this button to play the songs on the dis in a random order. Depress again to release Random fun tion.
7. LCD DISPLAY
This LCD display indi ates the status of the CD unit.
8. EJECT
Depress this button to eje t dis .
9. TRACK (REVERSE/FORWARD)
Depress this button to listen to the previous/next song on the dis .
10. DIRECTORY (REVERSE/FORWARD)
This fun tion is available only for MP3 dis s. It allows for movement between file dire tories on an MP3 dis .
Depress this button to move to the previous/next dire tory.
F1
F1
MP3 PLAYER STOP PLAY
PAUSE
SCAN REPT RAND
EJECT TRACK DIRECTORY
CD / MP3
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 8

MULTI P.A COMBINATION
7
SYSTEM-2240G
2. TUNER SECTION
1. TUNING FREQUENCY DISPLAY
You an onfirm the frequen y of tuner through this display.
2. BAND SELECT BUTTON
These swit h is for sele ting AM or FM, when using the tuner.
3. ADDRESS SELECT BUTTON
These swit hes sele t six memory address banks for the storage of broad asting frequen ies. Ea h of these
banks an be hold five broad asting frequen ies at designated memory address areas, i.e., F1, F2, F3, A1
and A2. Therefore a total of thirty broad asting frequen ies an be stored.
4. UP/DOWN BUTTON
When the swit h is momentarily pressed on e, the AM/FM frequen y will adjust with a single UP/DOWN ount.
When the swit h is pressed ontinuously, the frequen y is ontinuously fast UP/DOWN ounted.
5. MEMORY BUTTON
This is for memorizing the broad asting frequen y.
1. Sele t the memory area AM or FM with the BAND swit h (2).
2. Sele t the frequen y that you want to memorize with the UP/DOWN swit h (4).
3. Press the MEMORY swit h (5), then sele t the desired address with ADDRESS swit h (3).
4. The present status of the tuner will be memorized in the sele ted address.
6. POWER SWITCH
Pressing this swit h to ON, will light and supply the power to this unit.
F1
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 9

MULTI P.A COMBINATION
8SYSTEM-2240G
3. CASSETTE DECK SECTION
1. EJECT BUTTON
Pressing this button opens and loses the adja ent assette door.
2. RECORD LEVEL LED
Three-segment LED meters indi ate the re ord input level of the sele ted sour e.
3. DISPLAY (TAPE DIRECTION)
The urrent tape operation dire tion is shown on the display.
4. RECORDING MUTE LED
During the re ording mute for four se onds, the led light on the display panel will blink tree times.
5. RECORDING MUTE BUTTON
During re ording, press the REC MUTE button on the front panel to re ord about four se onds of silen e and
then pause re ording. If you want to re ord more than four se onds of silen e, press and hold the REC MUTE
button to reate a silen e of longer than four se onds.
.
6. PLAY DIRECTION SWITCH (DECK B ONLY)
a. : Single-side PLAY or REC (tape stops when rea hing the end).
b. : Side A to Side B to STOP, Side B to STOP (tape stops when end of side B is rea hed).
. : Continuous Auto-Reverse (tape will ontinuously swit h from Side A to Side B and ba k during
playba k). When in REC mode, tape will stop when end of Side B is rea hed.
REC MUTE
TAPE DIRECTION
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 10

MULTI P.A COMBINATION
9
SYSTEM-2240G
7. FAST FORWARD SWITCH ( ▶▶ )
Pressing this swit h a tivates Fast Forward mode. Use this button during playba k for forward AMS
operation (see page 15).
8. FORWARD PLAY SWITCH (
▶ )
Pressing this swit h a tivates Forward Play mode. The “ ▶ ” indi ator lights, and the tape plays in a forward
dire tion.
9. STOP SWITCH (■)
Press this swit h to stop the tape.
10. REVERSE PLAY SWITCH ( ◀ )
Pressing this swit h a tivates Reverse Play mode. The “ ◀ ” indi ator lights, and the tape plays in a reverse
dire tion.
11. REWIND SWITCH ( ◀◀ )
Pressing this swit h a tivates Fast Rewind mode. Use this button during playba k for reverse AMS operation
(see page 15).
12. PAUSE SWITCH ( II)
Pressing this swit h in PLAY or REC mode will pause the tape, this is shown as follows: “PAU” and it will blink
on the display.
13. REC SWITCH (●)
Pressing this swit h will pla e the unit in Re ord Pause mode. Pressing PLAY subsequent to pressing the REC
swit h will begin re ording.
14. NORMAL SPEED DUB SWITCH
Pressing this swit h will a tivate normal-speed dubbing mode.
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 11

MULTI P.A COMBINATION
10 SYSTEM-2240G
Rear Panel
Rear Panel
1. IMPEDANCE SELECTOR
Sele ts between high impedan e (100V/25V) operation for standard appli ations and low impedan e (70V)
operation for distributed systems.
2. SPEAKER OUTPUT TERMINAL STRIP
Conne t up to 10 individual speakers to this strip. Make ertain that the total impedan e load is less than the
rated impedan e, as shown below.
※USA/CANADA & Asso iated : 25V/2.6Ω or 70V/21Ω
3. CIRCUIT BREAKER
In the event of an AC power overload, the ir uit breaker will trip, interrupting the AC power sour e and
prote ting the unit from ex ess urrent. Push the ir uit breaker in to reset.
4. AC INLET
Conne t the supplied standard AC input able here.
ANTENNA
AM
(300 )FM
(75 )
MODEL Low Imp. Out High Imp. Out
Impedan e SYSTEM-2240G 4Ω21Ω41Ω2.6Ω
Voltage SYSTEM-2240G 31V 70V 100V 25V
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 12

MULTI P.A COMBINATION
11
SYSTEM-2240G
5. REMOTE CHIME CONNECTOR
Conne t a remote hime sour e here.
6. CHIME VOLUME CONTROL
Adjusts the output level of the ele troni hime.
7. MIC MUTE SELECTOR
When this swit h is in the MIC ALL position, signal from the CHIME or from any Mi Input will mute all other
audio signals.
When this swit h is in the MIC 1/2 position, signal from the CHIME or from Mi Input 1 or 2 will mute all
other audio signals.
When this swit h is in the OFF position, the MUTE fun tion is disabled. Signal from the CHIME or any Mi
Input will have no effe t.
8. MIC INPUTS 2 - 5
Conne t Mi inputs 2 through 5 here. Input sensitivity and impedan e is 1mV/20kW.
9. AUX INPUTS
Conne t an external sour e (CD player, video, mixer, et .) to these inputs.
10. PREAMP OUTPUT
This output provides line level output signal for onne tion to an external amplifier.
11. ANTENNA TERMINALS
Conne t external antenna here.
FM: 75Ω oaxial able antenna.
AM: 300Ω loop antenna.
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 13

MULTI P.A COMBINATION
12 SYSTEM-2240G
How to Use CD / MP3 Player
How to Use CD / MP3 Player
Pow r ON/OFF
- When there does not exist a dis upon power-on:
1. If power is applied to CDP, message is displayed, keeping a standby status.
2. Push the CD softly until the tray pulls on the CD.
3. While the unit reads CD, message is displayed.
4. For MP3 CD, message is displayed.
5. After the unit sear hes the musi information on a CD (for about 10 se onds), message is
displayed, keeping a standby status.
6. Press the swit h to start operation. Then playba k is started from the first song on a CD.
- When there exists a dis upon power-on:
1. While the unit reads CD, message is displayed.
2. For MP3 CD, message is displayed.
3. After the unit sear hes the musi information on a CD, message is displayed, keeping a standby
status.
4. Press the swit h to start operation. Then playba k is started from the first song on a CD.
- LCD DISPLAY OFF
1. If press STOP swit h in ase of NO DISC was registered in LCD DISPLAY window, LED power turns off.
2. Please press any key in ase of turns on LCD DISPLAY power again or push the CD to DISC TRAY.
Functions
- PLAY Fun tion
1. Insert a CD, and press swit h after CD information is displayed.
2. When MP3 CD is played, is displayed on the left top of LCD display.
- PAUSE Fun tion
1. If you stop playing at the urrent position temporarily, press swit h.
2. While this pause fun tion is a tive, message is displayed.
3. If you press swit h on e more, the pause fun tion is released and the unit starts playing from
the urrent position.
4. While the pause fun tion is a tive, you an move between dire tories or tra ks. If, however, you make
su h movement, the pause fun tion is released, and the unit starts playing automati ally.
- SCAN Fun tion
1. You an use this fun tion to sear h a desired song by hearing the first part of ea h tra k.
2. If you press swit h in the ourse of playing, the unit plays the beginning part of ea h subsequent
tra k for 10 se onds.
3. If you press swit h in a stop status, message is displayed, and then if you press PLAY/
PAUSE swit h, the unit plays the beginning part of ea h tra k for 10 se onds from the first tra k of
a CD.
4. While the tra k is performing a sear h fun tion, message is displayed.
5. If you find a desired tra k, press swit h on e more to stop sear hing and start playing.
6. In ase of MP3, if you long-press swit h for more than 1 se ond, message is display-
ed, and the unit plays the beginning part of ea h file in the dire tory for 10 se onds.
EADING CD OM
S -- PAUSE
D -- INT NO.
D -- INT NO.
INT O
S -- CDP-- -- --
PLAY/PAUSE
MP3
PLAY/PAUSE
PLAY/PAUSE
PLAY/PAUSE
SCAN
STOP
SCAN
SCAN
SCAN
CD STOP
S -- CDP-- -- --
EADING CD OM
NO DISC
NO DISC
CD STOP
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 14

MULTI P.A COMBINATION
13
SYSTEM-2240G
- REPEAT Fun tion
1. You an use this fun tion to listen to a song repeatedly.
2. If you want to repeat the song being displayed urrently, press swit h.
3. While this repeat fun tion is a tive, message is displayed.
4. If the above message is displayed, the urrent song is played repeatedly.
5. In ase of MP3, if you long-press swit h for more than 1 se ond, message is displayed,
and the unit plays the files in the dire tory repeatedly.
6. If you press swit h again, message is displayed, and the unit repeats the entire songs
from the beginning to the end.
7. To release the repeat fun tion, press on e more.
- RAND Fun tion (RANDOM)
1. You an use this fun tion to listen to the songs on the urrent dis at random.
2. If you press swit h in the ourse of playing, songs are played at random order.
3. If you press swit h in a stop status, message is displayed. Here, if you press PLAY/
PA USE swit h, songs are played at a random order.
4. While the random fun tion is a tive, message is displayed.
5. If you want to stop the random fun tion, press swit h on e more.
6. In ase of MP3, if you long-press swit h for more than 1 se ond, message is display-
ed, and the unit plays the files in the dire tory at a random order.
- EJECT fun tion (Dis eje tion)
1. You an use this fun tion to pull out a CD.
2. Regardless of the operation status of the player, pressing this swit h eje ts a CD.
- TRACK Fun tion (Forward/Reverse tra king fun tion)
1. You an use this fun tion to listen to a previous or next song in a play or stop status.
2. If you press swit h, the next song is played.
3. If the RANDOM fun tion is a tive, the next random song is played.
4. If you press swit h on e, the unit plays the urrent song again from the beginning.
5. If you press swit h twi e, the unit plays a previous song.
6. If the RANDOM fun tion is a tive, the previous song is not played.
7. If you long-press or swit h for longer than 1 se ond, you an do forward /
ba kward sear h of a relevant song.
- DIRECTORY Fun tion (Movement between dire tories)
1. This is the fun tion used for only MP3 CD.
2. This fun tion is available only when MP3 files are saved to different dire tories in a omputer. If you press
this swit h, you an move to the songs in other dire tory.
4. Tra k number is given in a umulative way ounting the number of tra ks of every dire tory.
5. This dire tory fun tion works at a SCAN, REPEAT and RANDOM status while the unit is in a play or pause
mode, and the dire tory name is displayed. If you move to other dire tory in a STOP mode, a dire tory
name is not displayed but the number of the first song in a new dire tory is displayed.
S -- PT NO.
A -- PT NO.
D -- PT NO.
EPT
EPT
EPT
EPT
T ACK ▶▶|T ACK ▶▶||◀◀T ACK
|◀◀T ACK
|◀◀T ACK
S -- DM NO.
D -- DM NO.
ANDOM
AND
AND
AND
AND
PLAY/PAUSE
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 15

MULTI P.A COMBINATION
14 SYSTEM-2240G
▶Example of movement between tra ks
* When #5 song (# 5 song in dire tory 1) is displayed urrently,
1) if you press , # 13 song (# 1 song in dire tory 2) is displayed.
2) if you press , # 23 song (# 1 song in dire tory 3) is displayed.
DIRECTORY TRACK NUMBER
DIRECTORY 1 : ROCK (12 tra ks) 01 ~ 12
DIRECTORY 2 : POP (10 tra ks) 13 ~ 22
DIRECTORY 2 : METAL (5 tra ks) 23 ~ 27
DI ECTO Y └▶◀┘ DI ECTO Y
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 16

MULTI P.A COMBINATION
15
SYSTEM-2240G
Operating the Double Deck
Operating the Double Deck
- CONTINUOUS AUTO-REVERSE
1. Sele t the dire tions swit h for playba k.
2. Pla e the assette tape into the de k B.
3. Press to play a assette tape.
* Caution (DESK B ONLY)
In ase of sele ting the swit h, the dire tion would be hanged.
a. : Single-side PLAY (Tape stops when rea hing the end).
b. : Both side B to STOP (tape stops when end of both side B is rea hed).
. : Continuous Auto-Reverse (tape will ontinuously swit h both side B and ba k during playba k).
- RECORDING
1. Sele t the dire tions swit h to re ord to a assette tape.
2. Pla e the sour e tape into De k A.
3. Insert a blank re ordable tape into De k B (To re ord, over the window with ellophane tape).
4. Press DUB swit h to re ord to a assette tape.
5. Press stop swit h on the De k A or B to stop re ording.
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 17

MULTI P.A COMBINATION
16 SYSTEM-2240G
Cassette Maintenance
Cassette Maintenance
- KEEP THE RECORDING HEADS CLEAN
Tape heads an periodi ally build up a oating of oxide residue from the passage of the tape over them. We
re ommend you lean the heads periodi ally using 99% Isopropyl Al ohol or a spe ially manufa tured tape
head leaner. Use foam appli ators or surgi al otton appli ators and lean in the dire tion of the tape
movement.
Tape head leaner and appli ators may be pur hased from any ele troni s dealer.
Do not use denatured al ohol, as it ontains ex ess impurities whi h an damage the tape heads.
Do not use ommer ial otton swabs, as they an leave fibers whi h an damage the tape heads.
- CARE OF CASSETTE TAPES
Store tapes in their ases to prevent dust and dirt from oming in onta t with the tape surfa e.
Do not tou h the tape surfa e with your fingers.
If the tape has unraveled, insert a pen il or similar obje t into the spro ket and tighten to remove sla k. (See Pi ture 1.)
Wind the tape until it is even and tight with a
pen il.
Tou hing the surfa e of the tape with
your finger will damage sound quality
by transferring skin oils and dirt.
(Pi ture 1)
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 18

MULTI P.A COMBINATION
17
SYSTEM-2240G
- RECORD SAFETY TABS ON CASSETTE TAPES
To disable a tape so it annot be re orded over, lo ate and remove the safety tab opposite the tape opening.
Holding the tape with the opening fa ing down, the tab to the upper left orresponds to the side fa ing you.
(See Pi ture 2.)
*To remove the tap, push it down gently with
a s rewdriver.
* To re ord again, over the window with
ellophane tape.
(Pi ture 2)
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 19

MULTI P.A COMBINATION
18 SYSTEM-2240G
Application of The Antenna
Application of The Antenna
- FM RECEIVING ANTENNA
The ele tri wave of FM broad asting is weakening in hills and valleys, around buildings and in iron-
reinfor ed buildings.
- INSTALLATION OF ANTENNA EXCLUSIVELY FOR FM
Listening to the broad asting, fix the antenna after de iding the lo ation and the dire tion so that the re eption
may be optimized.
- INSTALLATION OF ANTENNA USING THE COAXIAL CABLE
Noisy re eption may o ur in built-up areas and fa tory sites as well as around power ables. This may be the ase
even when an antenna is used ex lusively for FM. In these regions, install the antenna using 75Ω oaxial able.
- INDOOR ANTENNA
In the regions where FM broad asting is heard omparatively well due to the near distan e to the station or
wooden stru ture, you an re eive broad asting of good quality by using T-type antenna.
- AM LEAD ANTENNA
Fix one end of a six to eight metre length of vinyl- oated single able to the AM terminal and the other end to
a high pla e like a wall.
- AM OUTDOOR ANTENNA
Install the vinyl- oated able to an outdoor pla e if the AM re eption is not good enough.
- AM LOOP ANTENNA
Conne ting the feeder of the loop antenna of the terminal of 300Ω.
Listening to the broad asting, fix it after de iding the lo ation and the dire tion so that the re eipt ondition
may be optimum.
ANTENNA
AM
(300 )FM
(75 )
SYSTEM-2240G_MANUAL_127015_FOR_SYSTEM-2240G_E 15. 7. 20. 오전 9:54 페이지 20
