Interacoustics AD629 User manual

D-0004558-H - 2016/11
Instructions for Use – Part 1
AD629
Diagnostic Audiometer
EN Instructions for Use
DE Gebrauchsanweisung
FR Instructions d’utilisation
SV Bruksanvisning
FI Käyttöohjeet

Instructions for Use - EN
Diagnostic Audiometer AD629

Table of Contents
1INTRODUCTION...........................................................................................................................1
1.1 About this manual ...............................................................................................................1
1.2 Intended use........................................................................................................................1
1.3 Product description .............................................................................................................2
1.4 Warning...............................................................................................................................2
2UNPACKING AND INSTALLATION ............................................................................................3
2.1 Unpacking and Inspection...................................................................................................3
2.2 Marking................................................................................................................................ 4
2.3 General warnings and precautions .....................................................................................4
3GETTING STARTED - SETUP AND INSTALLATION.................................................................7
3.1 Back panel external connections – standard accessories..................................................8
3.2 PC-Interface........................................................................................................................8
3.3 Patient communication and monitoring...............................................................................9
Talk Forward.............................................................................................................9
Talk Back ................................................................................................................9
Assistant monitor ......................................................................................................9
Monitoring ................................................................................................................9
3.4 Operating instructions .......................................................................................................10
3.5 Tests screens and function key descriptions ....................................................................14
Tone test ..............................................................................................................15
Stenger Test ...........................................................................................................15
ABLB - Fowler test..................................................................................................16
Tone in noise test (Langenbeck Test) ....................................................................16
Weber ..............................................................................................................17
Speech test.............................................................................................................17
3.6 Setup ................................................................................................................................26
Instrument setup .....................................................................................................27
Common settings....................................................................................................27
Tone setting............................................................................................................29
Speech settings ......................................................................................................30
Auto settings ...........................................................................................................31
Sessions and clients...............................................................................................31
3.7 Printing..............................................................................................................................33
3.8 AD629 stand alone unit, print logo update........................................................................33
3.9 Diagnostic suite.................................................................................................................35
Instrument setup .....................................................................................................35
SYNC mode............................................................................................................36
The SYNC tab.........................................................................................................36
Client upload...........................................................................................................36
Session download...................................................................................................37
3.10 Hybrid (online/PC-controlled) mode..................................................................................38
4MAINTENANCE..........................................................................................................................39
4.1 General maintenance procedures.....................................................................................39
4.2 How to clean Interacoustics products ...............................................................................40
4.3 Concerning repair..............................................................................................................40
4.4 Warranty............................................................................................................................41
5GENERAL TECHNICAL SPECIFICATIONS..............................................................................43
5.1 Reference equivalent threshold values for transducers....................................................46
5.2 Maximum hearing level settings provided at each test frequency....................................46
5.3 Pin assignments................................................................................................................46
5.4 Electromagnetic compatibility (EMC)................................................................................46

AD629 Instructions for Use - EN Page 1
1Introduction
1.1 About this manual
This manual is valid for the AD629. These products are manufactured by:
Interacoustics A/S
Audiometer Alle 1
5500 Middelfart
Denmark
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
Web: www.interacoustics.com
1.2 Intended use
The AD629 audiometer is designed to be a device for diagnosing hearing loss. Output and specificity of this
type of device are based on the test characteristics defined by the user, and may vary depending on
environmental and operating conditions. The diagnosing of hearing loss using this kind of diagnostic
audiometer depends on the interaction with the patient. However, for patients not responding well
possibilities of various tests allow the tester to have at least some evaluative result. Thus, a “normal hearing”
result should not allow for ignoring other contra indications in this case. A full audiologic evaluation should be
administered if concerns about hearing sensitivity persist.
The AD629 audiometer is intended to be used by an audiologist, hearing healthcare professional or trained
technician in an extremely quiet environment according to the ISO standard 8253-1. This instrument is
intended for all patient groups regarding sex, age and health.Careful handling of the instrument whenever in
contact with a patient should be of high priority. Calm and stable positioning while testing is preferred for
optimal accuracy.

AD629 Instructions for Use - EN Page 2
1.3 Product description
The AD629 is a 2 channel clinical audiometer offering air, bone, speech and free field line output. It
offers a wide range of clinical test features such as high frequency, SISI, etc.
1.4 Warning
Throughout this manual, the following meaning of warnings, cautions and notices are used:
Included parts
DD45 Audiometric headset
B71 Bone conductor
APS3 Patient response button
Goose neck microphone
Power cable
Operation manual CD
Multilingual CE instructions for use
Optional parts
Diagnostic Suite software
OtoAccess database
21925 Amplivox audiocups, noise reducing headset
Carrying case (Standard or Trolly Style)
EARTone3A/5A Audiometric insert phones
IP30 Audiometric insert phones
HDA300 Audiometric headset with double mono 6.3mm jack
TDH39 Audiometric headset
CIR33 Insert earphone set for masking or monitoring
DD450 Audiometric headset
Talk back microphone
Sound field speakers SP90 (with external power amp)
AP12 Power Amplifier 2x12 Watt
AP70 Power Amplifier 2x70 Watt
WARNING indicates a hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION, used with the safety alert symbol, indicates a hazardous situation
which, if not avoided, could result in minor or moderate injury.
NOTICE NOTICE is used to address practices not related to personal injury.

AD629 Instructions for Use - EN Page 3
2Unpacking and installation
2.1 Unpacking and Inspection
Check box and contents for damage
When the instrument is received please check the shipping box for rough handling and damage. If the box is
damaged it should be kept until the contents of the shipment have been checked mechanically and
electrically. If the instrument is faulty please contact your local distributor. Keep the shipping material for the
carrier’s inspection and insurance claim.
Keep carton for future shipment
The AD629 comes in its own shipping carton, which is specially designed for the AD629. Please keep this
carton. It will be needed if the instrument has to be returned for service.
If service is required please contact your local distributor.
Reporting Imperfections
Inspect before connection
Prior to connecting the product it should once more be inspected for damage. All of the cabinet and the
accessories should be checked visually for scratches and missing parts.
Report immediately any faults
Any missing part or malfunction should be reported immediately to the supplier of the instrument together with
the invoice, serial number, and a detailed report of the problem. Together with his manual you will find a "Return
Report" where you can describe the problem.
Please use "Return Report"
Please realise that if the service engineer does not know what problem to look for, he may not find it, so
using the Return Report will be of great help to us and is your best guarantee that the correction of the
problem will be to your satisfaction.
Storage
If you need to store the AD629 for a period, please ensure it is stored uder the conditions specified in the
section for technical specifications:

AD629 Instructions for Use - EN Page 4
2.2 Marking
The following marking can be found on the instrument:
Symbol
Explanation
Type B applied parts.
Patient applied parts that are not conductive and can be immediately
released from the patient.
Follow the instruction manual
WEEE (EU-directive)
This symbol indicates that when the end-user wishes to discard this product,
it must be sent to separate collection facilities for recovery and recycling.
0123
The CE-mark indicates that Interacoustics A/S meets the
requirements of Annex II of the Medical Device Directive
93/42/EEC. TÜV Product Service, Identification No. 0123,
has approved the quality system.
Year of manufacture
Do not re-use
Parts like ear-tips and similar are for single use only
Display Port Connection – HDMI type
2.3 General warnings and precautions
External equipment intended for connection to signal input, signal output or other connectors shall comply
with relevant IEC standard (e.g. IEC 60950 for IT equipment). In these situations an optical isolator is
recommended to fulfill the requirements. Equipment not complying with IEC 60601-1 shall be kept outside
the patient environment, as defined in the standard (usually 1.5 meter). If in doubt, contact qualified medical
technician or your local representative.

AD629 Instructions for Use - EN Page 5
This instrument does not incorporate any separation devices at connections for PC’s, printers, active
speakers etc. (Medical Electrical System)
When the instrument is connected to a PC and other items of equipment of a medical electrical system
assure that the total leakage current cannot exceed the safety limits and that separations have the dielectric
strength, creepage clearances and air clearances required fulfilling the requirements of IEC/ES 60601-1.
When the instrument is connected to a PC and other similar items be aware of not touching the PC and
patient simultaneously
To avoid the risk of electric shock, this equipment must only be connected to supply mains with protective
earth.Do not use any additional multiple socket-outlet or extension cord.
This instrument contains a coin-type lithium battery. The cell can only be changed by service personnel.
Batteries may explode or cause burns, if disassembled, crushed or exposed to fire or high temperatures. Do
not short-circuit.
No modification of this equipment is allowed without Interacoustics’ authorization.
Interacoustics will make available on request circuit diagrams, component part lists, descriptions, calibration
instructions, or other information that will assist service personnel to repair those parts of this audiometer that
are designated by the Interacoustics as repairable by service personnel
Never insert or in any way use the insert headset without a new clean non defect test tip. Always make sure
that foam or ear-tip is mounted correctly. Ear tips and foam are single use.
The instrument is not intended to be used in environments exposed to fluid spills.
It is recommended that the disposable foam ear tips supplied with the optional EarTone5A insert transducers
are replaced after each patient tested. Disposable plugs also insure that sanitary conditions exist for each of
your patients, and that periodic cleaning of a headband or cushion is no longer required.
•The black tubing protruding the foam ear tip is attached to the sound tube nipple of the insert
transducer.
•Roll the foam tip into the smallest possible diameter.
•Insert into the ear canal of the patient.
•Hold the foam tip until expanded and a seal is achieved.
•After testing the patient the foam tip including the black tubing is detached from the sound tube
nipple.
•The insert transducer should be examined prior to attaching a new foam tip.
The instrument is not intended to be used in oxygen rich environments or use in conjunction with flammable
agents
NOTICE
To prevent system faults take appropriate precautions to avoid PC viruses and similar.
Use only transducers calibrated with actual instrument. To identify a valid calibration, the serial number for
the instrument will be marked on the transducer.
Although the instrument fulfils the relevant EMC requirements precautions should be taken to avoid
unnecessary exposure to electromagnetic fields, e.g. from mobile phones etc. If the device is used adjacent
to other equipment it must be observed that no mutual disturbance appears.Please also refer to EMC
concideration in the appendix.

AD629 Instructions for Use - EN Page 6
Within the European Union it is illegal to dispose electric and electronic waste as unsorted
municipal waste. Electric and electronic waste may contain hazardous substances and therefore
has to be collected separately. Such products will be marked with the crossed-out wheeled bin
shown below. The cooperation of the user is important in order to ensure a high level of reuse and
recycling of electric and electronic waste. Failing to recycle such waste products in an appropriate
way may endanger the environment and consequently the health of human beings.
To prevent system faults take appropriate precautions to avoid PC viruses and similar.

AD629 Instructions for Use - EN Page 7
3Getting started - setup and installation
The following shows an overview of the AD629:
The top left part of the AD629 (display holder) contains monitor speaker.
The left side of the instrument contains two mini jack connectors for a microphone and a headphone – or
a headset. This is used for talkback headphone/speaker (TB) and talk forward microphone (TF).
A goose neck microphone can be plugged into the top part of the instrument just above the Talk Forward
button. This can be used for talk forward. When not plugged in the goose neck microphone can be placed
underneath the display. Please refer to the section about patient communication for more details.
The upper right side of the instrument holds the on/off switch of the instrument.
Make sure that the audiometer is placed so that the patient cannot see/hear of the clinician uses the
instrument
Back Panel - connectors
Microphone
and
Headphone
(Headset)
mini jacks
Power
on/off
Front Panel
display &
buttons/dials
Talk
forward
mic.
Monitors
peaker

AD629 Instructions for Use - EN Page 8
3.1 Back panel external connections – standard accessories
The back panel contains all the rest of the main connectors (sockets):
Special notes:
•In addition to the standard DD45 headset, four other air conduction transducers may be used
(they all connect to specific outputs on the AD629):
•HDA300: High Frequency requires a HF headset
•CIR33 for insert masking: Insert phone CIR33 for insert masking has a limited sound
quality, making it only adequate for masking noise presentation.
•EAR-Tone 3A or 5A general purpose insert phone: Insert headphone EAR-Tone 3A or
5A are high quality transducers that may be used instead of the DD45/TDH39. It
improves cross hearing from the normal approximately 40dB of the TDH39 to
approximately 70dB. Masking as well as avoiding over-masking is thus easier with this
type of headphone.
•IP30 insert phone is the standard insert phone with same properties as EAR-Tone 3A
•The LAN connection is currently not used for any application (only internally in production)
•Mic 2: Please refer to the section about Patient Communication (Talk Forward and Talk Back)
•CD-input: It is required that any attached CD-player has a linear frequency response in order to
comply with the requirements of IEC 60645-2
•USB connections is used for:
•PC connection to Diagnostic Suite (the large USB connector)
•Direct print
•PC-keyboard (for entering client names)
3.2 PC-Interface
Please refer to the Diagnostic Suite operation manual regarding hybrid mode (on-line and PC-operated
mode) as well as patient/session data transfer.
4 USB A
connectors for
printer , mouse
keyboard and
memory stick
Standard
Headphones
DD45/TDH39/
HDA300
Bone
conducto
r B71
Patient
Respons
e Switch
For Talk Back
Mic.
USB B
Connector for
PC
connection
Power
connector
LAN (for
future
use)
Free Field 1
and 2
(external
amplification)
Insert
Phone
EarTone
3A / IP30
Insert
maskin
g
Extra Talk
forward
mic., e.g.
for table
mic.
External
CD /
MP3
input

AD629 Instructions for Use - EN Page 9
3.3 Patient communication and monitoring
Talk Forward
Talk Forward is activated by the “Talk Forward” button (21). AD629 contains three microphone
connectors which will work in the following priority (depending on which one(s) is connected):
•Priority 1: The mini jack in the left side of the instrument – can be used with a headset together with
the headphone connector. This has the first priority.
•Priority 2: The swan neck microphone (1) of the AD629 is located above the “Talk Forward” (21)
button. If no mic. is connected to the priority 1 mic., this with be used.
The image below will be shown while the talk forward (21) is active (by hold the button down) where the
calibration (gain) level and intensity level for patient communication can be adjusted. To change the
calibration level the clinician would adjust the HL dB dial (41) to the appropriate level. To adjust the
Intensity level the dial in channel 2 (43) would be used.
Talk Back
The operator may use Talk Back (28) in one of the following ways:
•If no headphone is connected to the Talk Back (left side connector), the voice is wired through
the Talk Back speakers next to the display (2).
•If a headphone/headset is connected to the instrument, talk back will come through this instead.
To adjust the TB level, hold down the TB button and use left/right totary wheels to adjust the level.
Assistant monitor
There is always a direct connection through the goose neck microphone to the assistant wearing a
headset connected to the “Assistant Monitor” output.
Monitoring
Monitoring of channel 1, 2 or both channels together is available by selecting the “Monitor” button (27)
once, twice or three times. Selecting it a fourth time will switch off the monitoring function again. To adjust
the monitor levels, hold down the monitor button and use left/right totary wheels to adjust the level.
Selecting desired way of listening:
The monitor signal will be available through the monitor headset if connected, the internal monitor
speaker.

AD629 Instructions for Use - EN Page 10
3.4 Operating instructions
The figure below shows the outline of the front plate of the AD629 including buttons, dials and display:
The following table describes the functions of the various buttons and dials.
Name(s)/Function(s)
Description
1
Microphone
For live voice speech and talk forward instruction to the patient in
the test cabin.
2
Talk back Speaker
For speech feedback from the patient in the test cabin.
3
Color Display Screen
For displaying the different test screens. Will be further explained
in the sections describing the individual tests.
4
Tone and Response
Indicator
Indication light seen when a tone is presented to the patient.
Indication light seen when the patient activates the patient signal
using the patient response.
5
Channel 1
Indicates intensity level for channel 1, e.g.:
(21)
(4)
(3)
(5)
(15)
(16)
(7
(8
(9
(10)
(11)
(12)
(13)
(14
(17)
(18)
(19)
(20)
(22)
(23)
(24)
(25)
(26)
(27)
(28)
(29)
(30)
(31)
(32)
(33)
(34)
(35)
(36)
(37)
(38)
(39)
(40)
(41)
(43)
(42)
(2)
(6)
(1)

AD629 Instructions for Use - EN Page 11
6
Masking / Channel 2
Indicates masking or Intensity level for channel 2, e.g.:
7-14
Function Keys
These keys are context sensitive and depend on the selected test
screen. Will be further explained in the sections describing the
individual tests
.
15
Shift
The shift function will enable the clinician to activate the sub
functions written in italic underneath the buttons.
16
Temp Setup
Allows the clinician to make temporary changes in certain settings
within each test. To save the changes as default (for the next
session) press “Shift (15)” and then (14). Choose
between the different settings using the right rotary wheel (43).
Change the individual settings using the left rotary wheel (41).
17
Setup /
Tests
The common setting menu can be accessed for more specific tests
and changes to general settings can be made. This is also where
the special tests are accessed: Auto tests (HW, Békésy), MHA,
SISI. To save the changes as default (for the next session) press
“Shift (15)” and then (14). Choose between the
different settings using the right rotary wheel (43). Change the
individual settings using the left rotary wheel (41).
18
Delete /
del curve
Delete points during testing delete. Delete the entire test curve of a
graph by holding “Shift (15)” together with this button.
19
Save Session/
New Session
Saving a session after testing or alternatively add a new session by
holding the “Shift (15)” together with this button. (A new session will
recall the default settings saved in 16 and 17)
20
Print
Allows results to be printed directly after testing (via a supported
USB printer).
21
Talk Forward
Instruction to the patient directly through his headphones via the
microphone can be given. The intensity changes by turning the
“HL dB” (41) while holding the “Talk Forward” button.
22
Tone / Warble
Pure tones or warble tones can be chosen as stimuli by activating
this button once or twice. The stimuli chosen will be shown on the
display, e.g.:
23
Wavefile
Enables one to perform speech testing using loaded wavefiles, i.e.
pre-recorded speech material. Please see setup under Temp
Setup (15). Requires installation of speech material.
24
Mic
For live speech testing through the microphone (1). The VU meter
can be seen on the display screen. Adjust the microphone gain by
holding down the Mic button for one second.

AD629 Instructions for Use - EN Page 12
25
1 CD 2
By pressing this function once or twice it is possible to have
recorded speech in either channel 1 or channel 2 separately.
Adjust the gain of CD 1 and 2 by holding down the CD button for
one second.
26
Ext Range
Extended Range: Usually the maximum output is e.g. 100dB but if
a higher output e.g. 120 dB is needed then “Ext Range” can be
activated when reaching a certain level.
27
Ch 1 Monitor 2
With the activation of this button, presentation to the patient from
e.g. CD can be heard through the built in monitor of the AD629 or
monitor headset in both channel 1 or 2. Adjust the gain by holding
down the button for one second.
28
Talk Back
Talk back, when active allows the clinician to hear comments or
responses from the patient through the AD629 or monitor
headset. Adjust the gain by holding down the button for one
second.
29
Right / Insert
For selecting the right ear during testing. Insert phones for the
right ear can be activated by pressing twice.
30
Left / Insert
For selecting the left ear during testing. Insert phones for the left
ear can be activated by pressing twice.
31
R Bone L
For bone conduction testing.
•First push: selects the right ear for testing.
•Second push: selects the left ear for testing.
32
1 FF 2
Pressing “1 FF 2” will select free field speaker as output for Channel
1.
•First push: Free Field speaker 1
•Second push: Free Field speaker 2
33
Man / Rev
Manual / Reverse tone presentation modes:
•First push: Manual tone presentation each time “Tone
Switch” (42) is activated.
•Second push: The reverse function-
continuous tone
presentation which will be interrupted each time “Tone
Switch” (42) is activated.

AD629 Instructions for Use - EN Page 13
34
Single / Multi
Pulsing modes:
•First push: the tone presented will have a pre-set length
when “Tone Switch” is activated. (Set up in the
“Setup/Tests” (17)).
•Second push: the tone will be pulsing continuously.
•Third push: returns back to normal mode.
35
Mask On/Off
Masking channel on/off:
•First push: turns masking on
•Second push: turns masking off
36
Sync
This allows the masking attenuator to the tone attenuator to be
activated. This option is used for e.g. synchronous masking.
37
Store
Use this function to store test thresholds / results.
38
No Resp
Use this function if the patient has shown no response to stimuli.
39
Down / Incorrect
Used to decrease the frequency level.
The AD629 has an incorporated automatic speech score counter.
Therefore as a second function you can use this button as an
“Incorrect” button when performing speech tests. For automatic
speech score counting while testing speech push this button after
each word not heard correctly by the patient.
40
Up / Correct
Used to increase the frequency level.
The AD629 has an incorporated automatic speech score counter.
Therefore as a second function you can use this button as a
“Correct” button when performing speech tests. For automatic
speech score counting while testing speech push this button after
each word heard correctly by the patient.
41
HL db Channel 1
This allows for the adjusting of the intensity in channel 1 shown at
(5) in the display.
42
Tone Switch / Enter
Used for tone presentation where the “Tone” light (4) will show.
Can also be used as “Enter” (selection) button.
43
Masking Channel 2
Adjust the intensity level in channel 2 or masking levels when
masking is used. Shown at (6) in the display.

AD629 Instructions for Use - EN Page 14
3.5 Tests screens and function key descriptions
The following tests are available from the Test (20) button. Use rotary wheels (57)/(58) to select the
individual test screen:
•Tone
•Stenger
•ABLB – Fowler
•Tone in noise – Langenbeck
•Weber
•Speech
•Auto – Hughson Westlake
•Auto – Békésy
•QuickSIN – Quick speech in noise
•SISI – Short increment sensitivity index
•MHA – Master Hearing Aid
•HLS – Hearing Loss Simulater
The (optional) HF (High Frequency) / HFz (High Frequency Zoom) test features are activated from the
Tone Screen – i.e. as extentions to the Tone audiogram test screen.
Please note that the tests available in this list depend on the test licenses installed on the instrument. This
may also vary from country to country.
