International Concepts VERONA S-1702 User manual

ITEM NO.: S-1702
REVISED MAY 17, 2018
Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No.
: 24 IN VERONA STOOL
: S-1702

ITEM NO.: S-1702
REVISED MAY 17, 2018
Printed in Vietnam
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly
and constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to
assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: S-1702
REVISED MAY 17, 2018
Printed in Vietnam
- 3 -
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Chair Back
1
B
Seat Frame
1
C
Seat
1
D
Front Leg
(L-R)
2
E
Side Stretcher
(L-R)
2
F
Front
stretcher
1
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Short Bolt
(M6 x 40mm)
3
2
Medium Bolt
(M6 x 60mm)
4
3
Long Bolt
(M6 x 80mm)
4
4
Long Screw
(M4 x 50mm)
6
5
Short Screw
(M4 x 35mm)
4
6
Lock Washer
(6.5 x11mm)
11
7
Flat Washer
(6.5 x19mm)
11
8
Allen Key
(M4 x 30mm x 110mm)
1

ITEM NO.: S-1702
REVISED MAY 17, 2018
Printed in Vietnam
- 4 -
STEP 1
Attach seat frame (B) to the back (A) with bolts (1) and (3), and washers (6) and (7) as shown below.
Tighten with Allen key (8).
Note: DO NOT tighten any of the bolts, until the stool is assembled, then put on a flat level surface to
make sure the stool is level and then tighten the bolts.
STEP 2
Attach front legs (D) to the seat frame with bolts (2), and washers (6) and (7) as shown below. Tighten
with Allen key (8).
Attach front stretcher (F) between front legs, and then attach side stretchers (E) to front and back
legs with screws (4) as shown below. Tighten with a screwdriver.

ITEM NO.: S-1702
REVISED MAY 17, 2018
Printed in Vietnam
- 5 -
STEP 3
Attach the seat (C) to top of the seat frame (B) with screws (5) as shown below. Tighten with a screwdriver.
