Description
Item No.
:
MAINE LADDERBACK W/WOOD SEAT
: C-2170
ASSEMBLY
INSTRUCTIONS

ITEM : C-2170
REVISED DEC 19, 2011
Printed in Vietnam
- 2 -
BEFORE ASSEMBLY
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. Please take the time to read and follow the assembly instructions carefully.
Be sure to check all packing material carefully for small parts which may have come loose inside the carton
during shipment. Please separate, identify, and count all parts and metal hardware. Compare with part list to be
sure all parts are present.
If hardware is missing or you have difficulty assembling this product, please call Toll Free: 1-888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Q
ty
Sketch
NO
Description
Q
ty
Ske
tch
A Back 1 B Seat Frame 1
C Seat 1 D Front Leg (L-R) 2
E Side Stretcher 2
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM : C-2170
REVISED DEC 19, 2011
Printed in Vietnam
- 3 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Short bolt
(M6x40mm)
3 2
Medium bolt
(M6x60mm)
4
3
Long bolt
(M6x80mm)
4 4
Lock Washer
(M6.5x11mm)
11
5
Flat Washer
(M6.5x19mm)
11 6
Allen Key
(4mm)
1
7
Screw
(M4x35mm)
8
STEP 2
STEP 1
Attach seat frame (B) to the back (A) with bolts (1) and (3), washers (5) and (4). Tighten with the Allen
key (6) as shown below.
Note: DO NOT fully tighten any of the bolts, until the chair is assembled, then put on a flat level
surface to make sure the chair is level and then tighten the bolts.

ITEM : C-2170
REVISED DEC 19, 2011
Printed in Vietnam
- 4 -
STEP 2
Attach front legs (D) to the seat frame with bolts (2), washers (5) and (4). Tighten with Allen key (6).
Attach side stretchers (E) to front and back legs with screws (7). Tighten with a screwdriver.
STEP 3
Attach seat (C) to top of the seat frame (from Step 2) with screws (7). Tighten with the screw driver
