International Concepts HAMPTON OT-70E User manual

ITEM NO.: OT-70E
REVISED SEP 05, 2014 Printed in Vietnam
- 1 -
ASSEMBLY INSTRUCTIONS
Description
Item No. : HAMPTON END TABLE
: OT-70E

ITEM NO.: OT-70E
REVISED SEP 05, 2014 Printed in Vietnam
- 2 -
BEFORE ASSEM
B
LY
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to beginning
assembly, however, make sure all parts and hardware are included and free of obvious defect. If a part is
missing or defective, please contact the store where purchased. If hardware is missing, or you need help with
assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from
being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish of your
table. Protect the surface of the table with cloth if you are using any product with rubber feet or base.
PARTS LIST
When unpacking, please carefully not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following parts:
NO
Description
Q’ty
Sketch
NO
Description
Q’ty
Sketch
A Top 1 C Side Frame
2
B Shelf 1

ITEM NO.: OT-70E
REVISED SEP 05, 2014 Printed in Vietnam
- 3 -
HARDWARE LIST
When unpacking, please carefully not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Q’ty
Sketch
NO
Description
Q’ty
Sketch
1 Bolt
(M6x35mm) 8
2 Flat washer
(6.5x16mm) 8
3 Lock washer
(6.5x11mm) 8
4 Allen Key
(4 x 80mm) 1
STEP 1
Attach side frame (C) to the top (A) with bolt (1), washer (2) and (3) as shown below. Tighten with
Allen key (4).
Attach side frame (C) to the shelf (B) with bolt (1), washer (2) and (3) as shown below. Tighten with
Allen key (4).
