International Concepts BROOKLYN 3 DRAWER NIGHTSTAND BD-8003 User manual

ITEM NO.: BD-8003
REVISED DEC 07, 2016
Printed in Vietnam
- 1 -
WARNING!
Serious or fatal injuries can occur from furniture tip over. Use tip over restraint (steel
band included) to secure this product to the wall.
Description
Item No.
: BROOKLYN 3 DRAWER NIGHTSTAND
: BD-8003
ASSEMBLY INSTRUCTIONS

ITEM NO.: BD-8003
REVISED DEC 07, 2016
Printed in Vietnam
- 2 -
Thank you for purchasing this quality product. This product has been designed for easy assembly and
constructed for durability. All parts were checked prior to packaging to insure quality. Prior to
beginning assembly, however, make sure all parts and hardware are included and free of obvious
defect. If a part is missing or defective, please contact the store where purchased. If hardware is
missing, or you need help with assembly, please call toll free 888-944-8396.
IMPORTANT NOTE:
-Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the
parts from being scratched.
-Remove all wrapping material, including staples & packing straps before you start to assemble.
-DO NOT tighten all screws and bolts until completely assembled.
-Keep all hardware parts out of reach of children.
WARNING:
Long exposure to rubber or soft plastic may cause a chemical reaction and damage the finish
of your product. Protect the surface of the product with cloth if you are using any product
with rubber feet or base.
BEFORE ASSEMBLY
ASSEMBLY TOOLS REQUIRED
NOT INCLUDED

ITEM NO.: BD-8003
REVISED DEC 07, 2016
Printed in Vietnam
- 3 -
PART LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have the following parts:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Top
1
B
Side panel
(L-R)
2
C
Bottom panel
1
D
Back panel
2
E
Back rail
1
F
Drawer front
3
G
Drawer side
(L-R)
6
H
Drawer back
3
I
Drawer
bottom
3
J
Support bar
3

ITEM NO.: BD-8003
REVISED DEC 07, 2016
Printed in Vietnam
- 4 -
HARDWARE LIST
When unpacking, please be careful not to discard any parts with the packaging. Before continuing,
please make sure you have all of the following hardware:
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Allen key
(M4x30mmx110mm)
1
2
Bolt
(M6x30mm)
8
3
Spring washer
(6.5x11mm)
8
4
Flat washer
(6.5x13mm)
8
5
Long screw
(M4x35mm)
40
6
Pan head screw
(M4x30mm)
6
7
Wooden knob
(30x30mm)
6
8
Medium screw
(M4x30mm)
6
9
Steel band
2
10
Short screw
(M3x15mm)
4
NOTE: WARNING LABEL (INCLUDED)

ITEM NO.: BD-8003
REVISED DEC 07, 2016
Printed in Vietnam
- 5 -
STEP 1
Attach top (A), and center panel (E) and bottom panel (C) to side panel (B) with bolts (2), and washers
(3) and (4) as shown below. Tighten with Allen key (1).
Slide back panels (D) into the grooves as shown below
STEP 2
Attach bottom panel (C) and top (A) to the other side panel (B) with bolts (2), and washers (3) and (4)
as shown below. Tighten with Allen key (1).

ITEM NO.: BD-8003
REVISED DEC 07, 2016
Printed in Vietnam
- 6 -
STEP 3
Attach back rail (E) to side panels (B) with screws (5) as shown below .Tighten with a screwdriver.
Attach drawer sides (G) to drawer front (F) with screws (5) as shown below. Tighten with a screwdriver.
Insert drawer bottom (I) into the grooves at bottom of drawer sides (G) and drawer font (F) as shown
below.
STEP 4

ITEM NO.: BD-8003
REVISED DEC 07, 2016
Printed in Vietnam
- 7 -
STEP 5
Attach drawer back (H) to drawer sides (G) with screws (5) as shown below. Tighten with a screwdriver.
STEP 6
Attach support bars (J) to bottom of drawers with screws (8) as shown below. Tighten with a screwdriver.

ITEM NO.: BD-8003
REVISED DEC 07, 2016
Printed in Vietnam
- 8 -
Attach knobs (7) to front of drawers with screws (6) as shown below. Tighten with a screwdriver.
Carefully put the drawers into the unit.
Attach steel bands (9) to the unit with screws (10) as shown below.
(to secure the product to the wall and reduce the risk of tipping over).
Important!
Properly attach steel bands (9) to the wall in an area of drywall or plaster with a wood stud:
Mark the attachment point(s) with a pencil at the appropriate height positioned over the wood stud(s)
in the wall.
Drill 1/8-inch (3mm) diameter hole(s) into the wood stud(s) located in the wall, where you marked
with the pencil.
Properly attach steel bands to the wall with screws (5) and tighten screw(s) firmly into the wall.
STEP 7
STEP 8
