Invacare 5310IVC User manual

Invacare®HomecareBeds
5411IVC,5410IVC,5311IVC,5310IVC,5307IVC,
5411LowIVC,5410LowIVC
enUserManual
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,readthismanualandsaveforfuturereference.

©2017Invacare®Corporation
Allrightsreserved.Republication,duplicationormodicationinwholeorinpartisprohibited
withoutpriorwrittenpermissionfromInvacare.Trademarksareidentiedby™and®.Alltrademarks
areownedbyorlicensedtoInvacareCorporationoritssubsidiariesunlessotherwisenoted.
MakingLife’sExperiencesPossibleisaregisteredtrademarkintheU.S.A.

Contents
1General.........................................4
1.1Symbols.....................................4
1.2IntendedUse.................................4
2Overview........................................5
2.1LabelLocations................................5
2.2TechnicalSpecications..........................5
2.3AccessoriesandAccessoryWeight..................7
2.4OperatingConditions............................7
3Safety..........................................8
3.1GeneralGuidelines.............................8
3.2OperatingInformation...........................16
3.3ServicingDouble-InsulatedProducts.................17
3.4Disposal.....................................17
4Set-up
..........................................18
4.1Receiving....................................18
4.2Unpacking....................................18
4.3Inspecting....................................20
4.4AssemblingtheHeadandFootSpringSections........21
4.5AssemblingtheSpringFabric......................22
4.6AdjustingandReconnectingtheHeadSectionPull
Tube.......................................22
4.7InstallingtheCasters............................23
4.8AssemblingtheUniversalBedEnds.................24
4.9InstallingLowBedEnds..........................25
4.9.1InstallingtheCastersontotheLowBedEnds.......25
4.10Assembling/Installing/RemovingDriveShaft..........26
4.11InspectingtheBed............................27
4.11.1Installing/RemovingCableLock.................29
4.11.2InstallingtheManualCrankforHi/LoFunction.....29
4.11.3Installing/RemovingthePendant................30
4.12StoringtheBed...............................30
5Operation.......................................31
5.1BedOperationandComponentOverview............31
5.2OperatingFullElectricBed.......................33
5.3OperatingtheSemi-ElectricBed....................34
5.3.1UsingtheEmergencyCrank....................35
5.4OperatingtheManualBed.......................36
5.5OptionalBedRails..............................36
6Maintenance.....................................38
6.1ServiceLife...................................38
6.2WearandTearItems............................38
6.3CleaningtheBed...............................39
6.4MaintenanceandCleaningChecklist................41
7Troubleshooting...................................43
7.1TroubleshootingMechanical......................43
7.2TroubleshootingElectrical........................44
8Warranty........................................46
8.1LimitedWarranty..............................46

Invacare®HomecareBeds
1General
1.1Symbols
Signalwordsareusedinthismanualandapplytohazards
orunsafepracticeswhichcouldresultinpersonalinjuryor
propertydamage.Refertothetablebelowfordenitionsof
thesignalwords.
DANGER!
–Dangerindicatesanimminentlyhazardous
situationwhich,ifnotavoided,willresultin
deathorseriousinjury.
WARNING!
–Warningindicatesapotentiallyhazardous
situationwhich,ifnotavoided,couldresultin
deathorseriousinjury.
CAUTION!
–Cautionindicatesapotentiallyhazardous
situationwhich,ifnotavoided,mayresultin
propertydamage.
Givesusefultips,recommendationsandinformation
forefcient,trouble-freeuse.
1.2IntendedUse
Thebedisintendedtobeusedasamattresssupport
system.Thebedallowsforarticulationoftheheadandfoot
sectionstoprovidedifferentpositionsforthepatient.It
isintendedtobeusedinhomecareandlongtermcare
facilities.
41114836-H-05

Overview
2Overview
2.1LabelLocations
AVERTISSEMENT
1118366
A
Close cover
when not in use otherwise
personal injury may occur.
Fermer le couvercle
avant d'utiliser,
sans quoi des
blessures
peuvent
survenir.
AVERTISSEMENT
WARNING
P/N 1117179 Rev B
CAUTION
1. Unplug product before washing.
2. Make sure all electrical parts (motors,
junction box and pendant) are not
damaged and that all connection
ports are plugged.
3. Disinfect and wash all components.
4. DO NOT power wash or steam clean.
Use household water pressure.
5. Rinse thoroughly with water
(maximum temperature 110°).
6. Dry all components before storing.
CLEANING INSTRUCTIONS
See Owner's Manual
P/N 1116654
Undersideofbedshown.
WarningLabel1117179RevBlocatedonthegearbox
(notshown).
A=Pendantcord
2.2TechnicalSpecications
FullElectric5410IVC,5411IVC
SHIPPINGWEIGHT176.5lbs(80.1kg)
WEIGHTCAPACITY
OCCUPANT350lbs(159kg)
SAFEWORKINGLOAD450lbs(204kg)
OVERALLLENGTH88in(223.4cm)
OVERALLWIDTH36in(91.4cm)
SPLITSPRINGTOENDS
HEAD43in(109.2cm)
FOOT45in(114.3cm)
ADJUSTMENTRANGE
DECK15in(38cm)±2into23
in(58.3cm)±2in
BEDEND26¼in(66.7cm)to33¾
in(85.7cm)
COMPONENTSHeadSpring,UniversalBed
Ends,FootSpringThree
Motors
1114836-H-055

Invacare®HomecareBeds
Semi-ElectricSingleCrankHi/Lo5310IVC,5311IVC
SHIPPINGWEIGHT172lbs(78.0kg)
WEIGHTCAPACITY
OCCUPANT350lbs(159kg)
SAFEWORKINGLOAD450lbs(204kg)
OVERALLLENGTH88in(223.4cm)
OVERALLWIDTH36in(91.4cm)
SPLITSPRINGSTOENDS
HEAD43in(109.2cm)
FOOT45in(114.3cm)
ADJUSTMENTRANGE
DECK15in(38cm)±2into23
in(58.3cm)±2in
BEDEND26¼in(66.7cm)to33¾
in(85.7cm)
COMPONENTSHeadSpring,Universal
BedEnds,FootSpringTwo
Motors
ManualSingleCrank-Hi/Lo5307IVC
SHIPPINGWEIGHT161.5lbs(73.3kg)
WEIGHTCAPACITY
OCCUPANT350lbs(159kg)
SAFEWORKINGLOAD450lbs(204kg)
OVERALLLENGTH88in(223.4cm)
OVERALLWIDTH36in(91.4cm)
SPLITSPRINGSTOENDS
HEAD43in(109.2cm)
FOOT45in(114.3cm)
ADJUSTMENTRANGE
DECK15in(38cm)±2into23
in(58.3cm)±2in
BEDEND26¼in(66.7cm)to33¾
in(85.7cm)
COMPONENTSHeadSpring,UniversalBed
Ends,FootSpringTwoCrank
61114836-H-05

Overview
2.3AccessoriesandAccessoryWeight
WARNING!
RiskofInjuryorDamage
Toavoidinjuryordamagefrommisuse:
–DONOTinstalltheaccessorieswithoutreading
andunderstandingalloftheinstructionsinthe
instructionsheetthataccompaniesthem.
Accessoriesaresubjecttochange.ContactDealer
orInvacareforcurrentlist
DESCRIPTIONMODELNUMBERWEIGHT
662928lbs(12.7kg) BEDRAIL,FULL
6629P28lbs(12.7kg)
BEDRAIL,HALF
LENGTH
6630DS24lbs(10.9kg)
ASSISTRAIL663224lbs(10.9kg)
7740A30lbs(13.6kg) TRAPEZE
7714P23lbs(10.4kg)
MATTRESS518020lbs(9.1kg)
518426lbs(11.8kg)
518530lbs(13.6kg)
5185XL30lbs(13.6kg)
Accessoriesaresubjecttochange.ContactDealer
orInvacareforcurrentlist
DESCRIPTIONMODELNUMBERWEIGHT
SolaceSeries,
SoftformSeries
23–31lbs
(10.4–14.1kg)
variesdepending
onmodel
MATTRESS
microAirSeries17–56lbs
(7.7–25.4kg)
variesdepending
onmodel
BEDEXTENDER,
CENTER
51438lbs(3.6kg)
BEDEXTENDER,
HEADEND
5143A19lbs(8.6kg)
2.4OperatingConditions
RECOMMENDED
STORAGEANDSHIPPING
TEMPERATURE
-22°Fto158°F(-30°Cto70°C)
upto93%relativehumidity,
noncondensing
RECOMMENDED
OPERATING
TEMPERATURE
41°Fto104°F(5°Cto40°C)
15%to93%relativehumidity,
noncondensing
RECOMMENDED
ATMOSPHERICPRESSURE700hpato1060hpa
1114836-H-057

Invacare®HomecareBeds
3Safety
3.1GeneralGuidelines
DANGER!
RiskOfDeath,Injury,OrDamage
Improperuseofthisproductmaycauseinjury
ordamage.
–Ifyouareunabletounderstandthewarnings,
cautionsorinstructions,contactahealthcare
professional,dealerortechnicalpersonnel
beforeattemptingtousethisequipment.
–Donotusethisproductoranyavailable
optionalequipmentwithoutrstcompletely
readingandunderstandingtheseinstructions
andanyadditionalinstructionalmaterialsuch
asusermanuals,servicemanualsorinstruction
sheetssuppliedwiththisproductoroptional
equipment.
Continueduseoftheproductwithdamagedparts
couldleadtotheproductmalfunctioning,causing
injurytotheuserand/orcaregiver.
–CheckALLproductcomponentsandcartonfor
damage,andtestcomponentsbeforeuse.DO
NOTuseproductifcomponentsaredamaged
orifproductisnotworkingproperly.Contacta
qualiedtechnicianorInvacareforrepair.
DANGER!
RiskofDeath,InjuryorDamage
Toavoidinjuryorproductdamage:
–Set-upandAssemblyinstructionsMUSTbe
performedbyqualiedtechniciansonly.
“QualiedTechnicianOnly”sectionsaremarked
accordingly.
THEINFORMATIONCONTAINEDINTHISDOCUMENT
ISSUBJECTTOCHANGEWITHOUTNOTICE.
DANGER!
RiskOfDeath,Injury,OrDamage
Lightedcigarettescancauseareorotherrelated
hazardsresultingindeath,injury,ordamage.
–Donotsmokewhileusingthisproduct.
–Donotallowotherstosmokenearthisproduct.
DANGER!
RiskOfDeath,Injury,OrDamage
Bedaccessoriesdesignedbyothermanufacturers
haveNOTbeentestedbyInvacare.Useof
NON-Invacarebedaccessoriesmayresultininjury
ordeath.
–UseONLYInvacarerails,mattresses,bed
extendersandotheraccessorieswithInvacare
bedproducts.
81114836-H-05

Safety
DANGER!
RiskofDeath,InjuryorDamage
Improperassemblymaycauseinjuryordamage.
Useofincorrectorimproperparts,including
replacement(service)parts,maycauseinjuryor
damage.
–ReplacementpartsMUSTmatchoriginal
Invacareparts.
DANGER!
RiskofInjuryorDeath
Toreducetheriskofelectricalshock:
–Alwaysunplugtheproductfromtheelectrical
outletbeforecleaning.
DANGER!
RiskOfDeath,Injury,OrDamage
Toreducetheriskofshock:
–Unplugfromtheoutletbeforeservicing.
–Closesupervisionisnecessarywhenthe
productisusedby,ornearchildrenand/or
disabledpersons.
–Usethisproductonlyforitsintendeduse
asdescribedintheseinstructions.DONOT
useattachmentsnotrecommendedbythe
manufacturer.
–Ifliquidisspilledinoraroundtheproduct,
unplugbeforecleaning.Cleanupthespill
andallowtheproductortheareaaroundthe
producttodrythoroughlybeforeusingthe
controlsagain.
DANGER!
RiskOfDeath,Injury,OrDamage
Toavoidshock,productdamageandpersonal
injury:
–DONOTuseoutdoors.
–Connectthisproducttoaproperlygrounded
outletonly.RefertoOperation.
–DONOTplacevideoequipmentsuchas
televisionsorcomputermonitorsonproduct.
OperatingInformation
DANGER!
RiskOfDeath,Injury,OrDamage
Toavoidinjuryordamagewhenoperating
product:
–Afteranyadjustments,repairorserviceand
beforeuse,makesureallattachinghardware
istightenedsecurely.
–Closesupervisionisnecessarywhenthe
productisusednearchildrenorpetsORwhen
thisproductisoperatedbyornearpeople
withphysical/mentaldisabilities.Physically
challengedindividualswhocannotprevent
themselvesfromrolling/climbingoutofthe
productmayrequirealternativesafemeansof
restraint.
–Theproductisnotdesignedtobeusedasa
patienttransport.Whentransportingapatient,
useanapprovedpatienttransport.Otherwise,
injuryordamagemayresult.
1114836-H-059

Invacare®HomecareBeds
DANGER!
RiskOfInjuryOrDamage
Toavoidinjuryordamagewhenoperating/moving
bed:
–ALWAYSensurethattheindividualutilizingthe
bedispositionedproperlywithintheconnes
ofthebed.DONOTletanyextremities
protrudeoverthesideorbetweenthebed
railswhenperformingthesefunctions.
–Beawareofpotentialpinchpointswhen
operatingbed,railsorotheraccessories.
–Makesureheadandfootsprings/sectionsare
connectedsecurelytothebedendsbeforeuse.
–Thebedisequippedwithlockingcasters.
Beforeusingthebed,testthewheellocksto
ensurecasterslockcorrectly.Whentransferring
intooroutofthebed,ALWAYSlockthecasters.
Evenwithcastersproperlylocked,some
ooringsurfaces(suchastileorwood,)will
allowthebedtomoveundersomeconditions.
Usingthebedonthesetypesofsurfaces
MUSTbeevaluatedbythecareprovider .DO
NOTtransferoccupantifbedisnotstable.
Otherwise,injuryand/ordamagemayoccur .
–DONOTmoveproductwithlockingcastersin
LOCKEDposition.
DANGER!
RiskOfDeath,Injury,OrDamage
Toavoidpinching,crushandcollapsehazards
frombeddeckcontactwithobjectsunderthe
bed:
–DONOTplaceanyobjectsorletanyindividual
underneaththebedorinbetweentheraised
bedframecomponentsatanytime.
Toavoidriskofdeathorinjuryfromchokingor
ingestionofsmallpartsormaterials:
–Closelysupervisechildren,pets,orindividuals
withphysical/mentaldisabilities.
RefertotheBedRailEntrapmentRiskNotication
Guideatwww.invacare.comforadditionalsafety
information.
101114836-H-05

Safety
DANGER!
RiskOfDeath,Injury,OrDamage
Patiententrapmentfromtheuseofbedside
railsmaycauseinjuryordeath.Toavoidpatient
entrapment:
–TheInvacaremattressMUSTtrmlyagainst
thebedframeANDbedsiderailstoprevent
patiententrapment.Followthemanufacturer’s
instructions.Monitorpatientfrequently.Read
andunderstandtheUserManualpriortousing
theInvacarebedandbedrails.Usermanuals
areavailableatwww.invacare.comoryour
dealer.
–Afteranyadjustments,repairorserviceand
beforeuse,makesureallattachinghardware
istightenedsecurely.
DANGER!
RiskOfDeath,Injury,OrDamage
Conditionssuchasrestlessness,mental
deteriorationanddementiaorseizuredisorders
(uncontrolledbodymovement),sleeping
problems,andincontinencecansignicantly
impactapatient'sriskofentrapment.Pediatric
patientsorpatientswithsmallbodysizemayalso
haveanincreasedriskofentrapment.
–Monitorpatientswiththeseconditions
frequently.
–Placethemattressdeckintheatposition
whenleftunattended.
WARNING!
RiskOfInjuryOrAdverseHealthConsequences
Fallhazardexistsduetobedheight.
–Alwaysleavebedinlowestheightwhen
unattended.
ReplacementParts/Accessories
DANGER!
RiskOfDeath,Injury,OrDamage
Toavoidrehazardsandtubingentanglement:
–Usemaskedornasaltypeoxygenadministering
equipmentonlyinconjunctionwiththe
manual/electricbed.Theuseofanyothertype
ofoxygenadministeringequipmentcanresult
inarehazard.
–Whenusingnasalormaskedtypeoxygen
administeringequipment,theoxygenorair
tubingMUSTberoutedandsecuredproperly
toensurethatthetubingdoesnotbecome
entangledand/orseveredduringnormal
operationofmanual/electricbed.
–DonotusethisbedinActiveTreatment“Ether
Environments.”
DANGER!
RiskOfDeath,Injury,OrDamage
Toavoidrehazards,injuryordamage:
–DONOTuseproductwithammablegases.
Explosionmayoccur .
1114836-H-0511

Invacare®HomecareBeds
WARNING!
RiskOfInjuryOrDamage
Toavoidinjuryordamagefrommisuseor
entrapment:
–Readandunderstandtheinstructionsorlabel
providedwithmattress.
–Ifyoudonotunderstandtheinstructionsorif
instructionsaremissing,contactthemattress
manufacturer.
DANGER!
RiskOfDeath,Injury,OrDamage
Toavoidentrapment,productdamage,and/or
personalinjury:
–Invacarerecommendsthatthemattressbe
centeredonthebedframe.Otherwise,
individualsmaybecometrappedbetweenthe
bedrailandthebedframe.
–ALWAYStesttomakesurethatthesiderails
areproperlyandsecurelyinplacebeforeusing.
Otherwise,injuryordamagemayoccur .
DANGER!
RiskOfInjuryOrAdverseHealthConsequences
FallhazardexistsduetouseofNon-Invacare
mattresses.Non-Invacaremattressesare
potentiallyincompatiblewithInvacarebeds.
–Toavoidinjury,ensurethatonlyInvacare
mattressesareusedwithInvacarebedsatall
times.
DANGER!
RiskofDeathorInjury
Anincreasedriskofpatiententrapmentmay
occurovertimeduetomattresscompression.
–Periodicallymonitorgapsbetweenthebed,
mattress,and/orbedrail.Wheregapsoccur,
patiententrapmentispossibleandthemattress
shouldbereplaced.
121114836-H-05

Safety
DANGER!
RiskOfDeath,Injury,OrDamage
Toavoidentrapment,productdamage,and/or
personalinjury:
–Whenusedwithamanual/electricbed,the
bedrailsDONOTfallunderanyweight
limitations.Bedrailscanbedeformedor
brokenifexcessivesidepressureisexerted
onthebedrails.Thesebedrailsareusedfor
thepurposeofpreventinganindividualfrom
inadvertentlyrollingoutofbed.Thebedrails
arenotintendednormaybeusedforrestraint
purposes.Ifanindividualiscapableofinjuring
himself/herself,aphysicianorahealthcare
professionalshouldbeconsultedforalternative
meansofsaferestraint.
–Afterraising/loweringthehead/footendofthe
electricbed,checkthedistancebetweenthe
bottomofthebedrailandthemattress.If
thereisexcessivedistancebetweenthebottom
ofthebedrailandthemattressinwhich
individualsmaybecomeentangled,adjustthe
heightofthebedrail(ifapplicable),orprovide
alternativemeansofpatientprotection.
–DONOTusethesiderailsaspushhandlesfor
movingtheelectricbed.
–Replacementmattressesandbedsiderails
withdimensionsdifferentfromtheoriginal
equipmentsuppliedorspeciedbythebed
framemanufacturerarenotinterchangeable.
Variationsinbedsideraildesign,widthand
thicknessorrmnessofthemattresscould
cause/contributetoentrapment.
DANGER!
RiskofDeath,InjuryorDamage
Toavoidinjuryordamagefrommisuseor
entrapment:
–Properpatientassessmentandmonitoring,and
propermaintenanceanduseofequipment
isrequiredtoreducetheriskofentrapment.
Variationsinbedraildimensionsandmattress
thickness,sizeordensitycouldincreasethe
riskofentrapment.VisittheFDAwebsite
athttp://www.fda.govtolearnaboutthe
risksofentrapment.Review“AGuidetoBed
Safety”,publishedbytheHospitalBedSafety
Workgroup.Usethelinklocatedundereach
bedrailproductentrytoaccessthisbedsafety
guide.
–Refertotheusermanualsforbedsandrailsfor
additionalproductandsafetyinformation.
–Patiententrapmentfromtheuseofbed
siderailsmaycauseinjuryordeath.The
InvacaremattressMUSTtrmlyagainstthe
bedframeANDbedsiderailstoprevent
patiententrapment.Followthemanufacturer’s
instructions.Monitorpatientfrequently.Read
andunderstandtheUserManualpriortousing
thisequipment.Invacaremanualsareavailable
atwww.invacare.comoryourdealer .
–Anincreasedriskofpatiententrapmentmay
occurovertimeduetomattresscompression.
Periodicallymonitorgapsbetweenthebed,
mattress,and/orbedrail.Wheregapsoccur,
patiententrapmentispossibleandthemattress
shouldbereplaced.
1114836-H-0513

Invacare®HomecareBeds
Electrical
WARNING!
RiskOfDeath,Injury,OrDamage
Shockhazardsandriskofreexistduetouseof
improperextensioncordanduseofthreeprong
adapters.
–Toavoidinjuryorproductdamage,whenusing
anextensioncord,useonlyaULapproved
threeprongextensioncordhavingatleast16
AWG(AmericanWireGauge)wireandthe
sameorhigherelectricalratingastheproduct
beingconnected.
Toreducetheriskofelectricshock,thisfurnishing
hasapolarizedplug(onebladeiswiderthan
theother).Thisplugwilltinapolarizedoutlet
onlyoneway.
–Iftheplugdoesnottfullyintheoutlet,
reversetheplug.Ifitstilldoesnott,contacta
qualiedelectriciantoinstalltheproperoutlet.
–DONOTchangethepluginanyway.
WARNING!
RiskOfInjuryOrDamage
Toavoidproductdamageandpersonalinjury:
–Disconnectpendantwhennotinuseandstore
outofreachofchildren.
GroundingInformation
WARNING!
RiskOfInjuryorDamage
Toavoidinjuryordamagefromimproper
groundingorusingdamagedparts:
–DONOToperatetheproductifthecordor
outletisdamaged.
–DONOToperatetheproductifanymotorhas
malfunctionedorisdamagedinanymanner .
RadioFrequencyInterference
UseofportableandmobileRFcommunications
equipmentcanaffectmedicalelectricalequipment
WARNING!
RiskofProductDamage
ElectronicequipmentmaybeinuencedbyRadio
FrequencyInterference(RFI).
–Cautionshouldbeexercisedwithregardtothe
useofportablecommunicationsequipmentin
theareaaroundsuchequipment.
–IfRFIcauseserraticbehavior,unplugthe
productimmediately.Leaveunpluggedwhile
transmissionisinprogress.
141114836-H-05

Safety
WARNING!
RiskOfProductDamage
Theuseofaccessories,transducers,cords
andcablesotherthanthosespeciedbythe
manufacturer,mayresultinincreasedemissions
ordecreasedimmunityofthisbed
–Thisproductshouldnotbeusedadjacentto
orstackedwithotherequipmentandthat
ifadjacentorstackeduseisnecessary,this
productshouldbeobservedtoverifynormal
operationinthecongurationinwhichitwill
beused.
WeightLimitations
DANGER!
RiskOfDeath,Injury,OrDamage
Toavoidbedcollapseandresultinginjuryor
damage:
–Theweightlimitoftheoccupantofthebed
CANNOTexceed350lbs(159kg).TheTOTAL
weightlimitofthebed(includingaccessories,
mattress,occupantandanyotherobjects
positionedonthebed)cannotexceed450lbs
(204kg)(SafeWorkingLoad).
–NEVERpermitmorethanonepersononthe
bedatanytime.
–Bodyweightshouldbeevenlydistributedover
thesurfaceofthebed.DONOTlay,sitorlean
insuchawaythatyourentirebodyweightis
placedonlyonraisedheadorfootsectionsof
thebed.Thisincludeswhenrepositioningor
transferringinoroutofbed.
1114836-H-0515

Invacare®HomecareBeds
3.2OperatingInformation
DANGER!
RiskofDeath,InjuryorDamage
Toavoidelectricaldamage,productdamage,
shockand/orpersonalinjury:
–DONOTunplugpowercordfromjunctionbox.
–Whenproductisnottobeusedforan
extendedperiod,unplugelectricbedfromthe
walloutlet.
–Keepallproductcomponentsandaccessories
aminimumof12inchesawayfromhotor
heatedsurfaces.
DANGER!
RiskOfDeath,Injury,OrDamage
Toavoidproductdamageand/orpersonalinjury
fromfallorentrapment.
–Invacarerecommendstheuseofmattress
keepers.
DANGER!
RiskOfInjuryOrAdverseHealthConsequences
Fallhazardexistsduetoincorrectinstallationof
bedrails.
–Toavoidinjury,ensurethattheInvacare
bedrailsareinstalledcorrectlyandsecurely
attachedtothebedwhileenteringorexiting.
FallhazardexistsduetouseofNon-Invacare
bedrails.Non-Invacarebedrailsarepotentially
incompatiblewithInvacarebeds.
–Toavoidinjury,ensurethatonlyInvacarebed
railsareusedwithInvacarebedsatalltimes.
FallhazardexistsduetouseofNon-Invacare
mattresses.Non-Invacaremattressesare
potentiallyincompatiblewithInvacarebeds.
–Toavoidinjury,ensurethatonlyInvacare
mattressesareusedwithInvacarebedsatall
times.
161114836-H-05

Safety
DANGER!
RiskofDeath,InjuryorDamage
Toavoidseriousinjuryorproductdamage
fromtripping,entanglementand/orpinched,or
severedcords:
–Ensureallcord(s)areroutedandsecured
properly.
–Keepallmovingparts,includingthemain
frame,mattressdeck,andalldriveshafts,free
ofobstruction(i.e.blankets/sheets,tubing,
wiring,cords,etc.)duringoperationofthe
product.
–Donotrolltheproductoverthepoweror
pendantcord.
WARNING!
RiskofInjuryorDamage
Theemergencycrankwillturnwhenmotorison
andcouldcausepersonalinjuryordamageto
thebed.
–ALWAYSremovetheemergencycrankbefore
performingelectronicfunctions.
WARNING!
RiskofInjuryorDamage
Duetoapoweroutageoranelectronic
malfunction,anemergencycrankisprovided.
–DONOTusetheemergencycranktoraisethe
bed.Personalinjuryordamagetothecrank
mayoccur .
3.3ServicingDouble-InsulatedProducts
Protectiontotheuseragainstelectricalshockhazardis
providedbyusingdoubleinsulatedconstruction.Servicing
adouble-insulatedproductrequiresextremecareand
knowledgeofthesystem,andistobedoneonlybyqualied
servicepersonnel.Replacementpartsforadouble-insulated
productmustbeidenticaltothepartstheyreplace.A
double-insulatedproductismarkedwiththewords“DOUBLE
INSULATION”or“DOUBLEINSULATED”orthedouble
insulatedsymbol.
3.4Disposal
Followlocalgoverningordinancesandrecyclingplans
regardingdisposaloftheproductorcomponentsnormally
usedinoperation.Theproductdoesnotgeneratewaste
orresidueinoperation.Anyaccessoriesnotpartofthe
productMUSTbehandledinaccordancewiththeindividual
productmarkingfordisposal.
Thisproducthasbeensuppliedfromanenvironmentally
awaremanufacturerthatcomplieswiththeWasteElectrical
andElectronicEquipment(WEEE)Directive2012/19/EC.
Thisproductmaycontainsubstancesthatcouldbeharmful
totheenvironmentifdisposedofinplaces(landlls)that
arenotappropriateaccordingtolegislation.
Pleasebeenvironmentallyresponsibleandrecyclethis
productthroughyourrecyclingfacilityatitsendoflife.
1114836-H-0517

Invacare®HomecareBeds
4Set-up
4.1Receiving
WARNING!
RiskofInjuryorDamage
“QualiedTechnicianOnly”sectionsaremarked
accordingly.
–Set-upandAssemblyinstructionsMUSTbe
performedbyqualiedtechniciansonly.
1.Countcartonsbeforesigningshippingpapers.
2.Designatesomeoneatthefacilitytoreceiveandinspect
allmerchandise.Usethemasterorderacknowledgment
tocheckoffitemsastheyarereceived.
3.Comparethenumberofcartonsshippedwiththe
numberofcartonsactuallyreceivedandnotesuchon
theconsigneecopyofthefreightbill.Makesuretohave
thetruckdriversignthecopyacknowledgingthecount.
4.Ifshortageoccurs,IMMEDIATELYcontactInvacare
CustomerServicedepartmentat(800)333-6900.
4.2Unpacking
DANGER!
RiskofInjuryorDamage
Continueduseoftheproductwithdamagedparts
couldleadtothebedmalfunctioning,causing
injurytotheuserand/orcaregiver.
–CheckALLproductcomponentsandcarton
fordamage,andtestcomponentsbeforeuse.
Incaseofdamageoriftheproductisnot
workingproperly,contactaqualiedtechnician
orInvacareforrepair.
–AnymodicationstotheHomecareBedsare
strictlyprohibited.
WARNING!
RiskofInjuryorDamage
Toavoiddamageorpersonalinjury:
–DONOTplugthepowercordintoapower
sourceuntilassemblyiscomplete.
–DONOTattempttooperatebedcontrolsprior
tocompletionofassembly.
181114836-H-05

Set-up
UnpackingtheBedEnds
1.RemoveanyloosepackingfromthecartonA.
2.BedEndcartonAincludes:
•TwoUniversalBedEndsB
•FourCasters(twolockingandtwonon-locking
casters)C
•OneDriveShaftAssemblyintwopiecesD
•OneHandCrankE
UnpackingFootandHeadSpringSections
A
B
C
D
1.RemoveanyloosepackingAfromthecartonB.
2.FootSpringSectioncartonincludes:
•OneFootSpringC(electricbedsincludependent,
junctionboxwithpowercord,andhead,footand
hi/lo[fullelectriconly]motorswithcables).
•Oneemergencycrankhandle(electricbedsONLY).
3.HeadSpringSectioncartonincludes:
•OneHeadSpringD.
1114836-H-0519

Invacare®HomecareBeds
OptionalLowBedEndKit
Thiskitincludesthefollowing:
•TwoUniversalLowBedEnds.
•FourCasters(twolockingandtwonon-lockingcasters).
•OneDriveShaftAssemblyintwopieces.
HeightRangeisasfollows:
•WithcastersinstalledinpositionA,theheightrange
is9½to20inches.
•WithcastersinstalledinpositionB(outerbedlegs),
theheightrangeis12to23inches.
MeasurementstakenfromoorCtobeddeckD.
4.3Inspecting
DANGER!
RiskOfInjuryOrDamage
Toavoidinjuryordamage,inspectthefollowing
andcontactaqualiedtechnicianorInvacareif
anyofthefollowingissuesarepresent:
–Pendantcoveringiscrackedordamaged.
–Powercordorplughavecutsordamage.
–Motorcableshavecutsordamage.
–Junctionboxorconnectorsaredamaged.
–Emergencycrankismissingordamaged.
DANGER!
RiskOfInjuryOrDamage
Toavoidinjuryordamage:
–Ensurethattheconnectorsarepluggedinto
thejunctionboxandtproperly.
201114836-H-05
