Invacare®Kirilos/Atlante
Kirilos,AtlanteElectric,AtlanteHydraulic
enMobilePatientLift
UserManual...................................3
frLève-personnemobile
Manueld'utilisation............................29
itSollevatoremobile
Manualed’uso.................................57
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsaved
forfuturereference.

©2020InvacareCorporation
Allrightsreserved.Republication,duplicationormodicationinwholeorinpartisprohibitedwithoutpriorwritten
permissionfromInvacare.Trademarksareidentiedby™and®.AlltrademarksareownedbyorlicensedtoInvacare
Corporationoritssubsidiariesunlessotherwisenoted.
–
Tousdroitsréservés.Larepublication,laduplicationoulamodicationdetoutoupartieduprésentdocumentest
interditesansl'accordécritpréalabled'Invacare.Lesmarquescommercialessontidentiéespar™et®.Toutes
lesmarquescommercialessontdétenuesparoucédéessouslicenceàInvacareCorporationousesliales,sauf
stipulationcontraire.
–
Tuttiidirittiriservati.Èproibitalariproduzione,laduplicazioneolamodicaparzialeocompleta,salvoprevia
autorizzazionescrittadapartediInvacare.Imarchisonocontrassegnatida™e®.Tuttiimarchisonodiproprietào
licenzadiInvacareCorporationodisueafliate,salvoindicazionecontraria.

Contents
ThismanualMUSTbegiventotheuseroftheproduct.
BEFOREusingthisproduct,thismanualMUSTbereadandsaved
forfuturereference.
1General.........................................4
1.1Introduction..................................4
1.1.1SymbolsinthisDocument.....................4
1.2ServiceLife...................................4
1.2.1Additionalinformation........................4
1.3LimitationofLiability............................4
1.4WarrantyInformation...........................4
1.5Compliance...................................4
1.5.1Product-specicstandards.....................4
2Safety..........................................5
2.1Generalsafetyinformation.......................5
2.1.1Pinchpoints................................5
2.2SafetyInformationonAccessories..................6
2.3Safetyinformationonelectromagneticinterference.....6
2.4Labelsandsymbolsontheproduct.................6
2.4.1Identicationlabel...........................6
2.4.2OtherLabelsandSymbols.....................7
3ProductOverview.................................8
3.1Intendeduse..................................8
3.2Mainpartsofthelift............................8
3.3Accessories...................................8
4Setup...........................................9
4.1GeneralSafetyInformation.......................9
4.2Scopeofdelivery..............................9
4.3AssemblingtheLift.............................9
4.4DisassemblingtheLift...........................10
5Usage..........................................11
5.1Generalsafetyinformation.......................11
5.2Locking/Unlockingtherearcastors.................11
5.3Raising/LoweringanElectricLift...................11
5.4Raising/LoweringaHydraulicLift...................11
5.5Closing/OpeningLegs...........................11
5.5.1Closing/Openinglegsmanually..................12
5.6Emergencyfunctions............................12
5.6.1PerforminganEmergencyStop..................12
5.6.2ActivatinganEmergencyLowering...............12
5.7Chargingthebattery............................12
6PatientTransfer...................................14
6.1Generalsafetyinformation.......................14
6.2Preparingtolift................................14
6.2.1Attachingtheslingtothelift...................15
6.3Transferringapatientfromabed..................15
6.4Transferringapatienttoabed....................16
6.5Transferringapatientfromawheelchair.............16
6.6Transferringapatienttoawheelchair...............17
6.7Transferringapatienttoandfromacommode........17
6.8Liftingapatientfromtheoor....................18
7Maintenance.....................................19
7.1Generalmaintenanceinformation..................19
7.2DailyInspections...............................19
7.3CleaningandDisinfection........................19
7.3.1Generalsafetyinformation.....................19
7.3.2CleaningIntervals............................19
7.3.3Cleaninginstructions.........................19
7.3.4DisinfectionInstructions.......................19
7.4Serviceinterval................................20
7.4.1Safetyinspectionchecklist.....................20
7.5LubricatingtheLift.............................20
7.6Checkingandtighteningbolts.....................20
7.7MaintainingtheHydraulicPump...................21
8AfterUse........................................22
8.1TransportandStorage...........................22
8.2Disposal.....................................22
8.3Reconditioning................................22
9Troubleshooting...................................23
9.1Identifyingandrepairingfaults....................23
10TechnicalData...................................24
10.1Dimensionsandweight.........................24
10.2Electricalsystem..............................24
10.3Hydraulicsystem..............................25
10.4Environmentalconditions........................25
10.5Materials....................................25
11Electromagneticcompatibility(EMC)..................26
11.1GeneralEMCinformation.......................26
11.2Electromagneticemission........................26
11.3ElectromagneticImmunity.......................26
11.4TestspecicationsforimmunitytoRFwireless
communicationsequipment......................27

Invacare®Kirilos/Atlante
1General
1.1Introduction
Thisusermanualcontainsimportantinformationaboutthe
handlingoftheproduct.Toensuresafetywhenusingthe
product,readtheusermanualcarefullyandfollowthe
safetyinstructions.
Notethattheremaybesectionsinthisdocument,whichare
notrelevanttoyourproduct,sincethisdocumentapplies
toallavailablemodels(onthedateofprinting).Ifnot
otherwisestated,eachsectioninthisdocumentreferstoall
modelsoftheproduct.
Themodelsandcongurationsavailableinyourcountrycan
befoundinthecountry-specicsalesdocuments.
Invacarereservestherighttoalterproductspecications
withoutfurthernotice.
Beforereadingthisdocument,makesureyouhavethe
latestversion.YoundthelatestversionasaPDFonthe
Invacarewebsite.
Ifyoundthatthefontsizeintheprinteddocumentis
difculttoread,youcandownloadthePDFversionfromthe
website.ThePDFcanthenbescaledonscreentoafont
sizethatismorecomfortableforyou.
Formoreinformationabouttheproduct,forexampleproduct
safetynoticesandproductrecalls,contactyourInvacare
distributor.Seeaddressesattheendofthisdocument.
Incaseofaseriousincidentwiththeproduct,youshould
informthemanufacturerandthecompetentauthorityin
yourcountry.
1.1.1SymbolsinthisDocument
Symbolsandsignalwordsareusedinthisdocumentand
applytohazardsorunsafepracticeswhichcouldresultin
personalinjuryorpropertydamage.Seetheinformation
belowfordenitionsofthesignalwords.
WARNING
Indicatesahazardoussituationthatcouldresult
inseriousinjuryordeathifitisnotavoided.
CAUTION
Indicatesahazardoussituationthatcouldresult
inminororslightinjuryifitisnotavoided.
IMPORTANT
Indicatesahazardoussituationthatcouldresult
indamagetopropertyifitisnotavoided.
TipsandRecommendations
Givesusefultips,recommendationsand
informationforefcient,trouble-freeuse.
1.2ServiceLife
Theexpectedservicelifeofthisproductiseightyearswhen
useddailyandinaccordancewiththesafetyinstructions,
maintenanceintervalsandcorrectuse,statedinthismanual.
Theeffectiveservicelifecanvaryaccordingtofrequencyand
intensityofuse.
1.2.1Additionalinformation
Theexpectedservicelifeisbasedonanestimatedaverage
of4liftingcyclesperday.
1.3LimitationofLiability
Invacareacceptsnoliabilityfordamagearisingfrom:
•Non-compliancewiththeusermanual
•Incorrectuse
•Naturalwearandtear
•Incorrectassemblyorset-upbythepurchaserorathird
party
•Technicalmodications
•Unauthorisedmodicationsand/oruseofunsuitable
spareparts
1.4WarrantyInformation
Weprovideamanufacturer’swarrantyfortheproduct
inaccordancewithourGeneralTermsandConditionsof
Businessintherespectivecountries.
Warrantyclaimscanonlybemadethroughtheprovider
fromwhomtheproductwasobtained.
1.5Compliance
Qualityisfundamentaltothecompany’soperation,working
withinthedisciplinesofISO13485.
ThisproductfeaturestheCEmark,incompliancewiththe
MedicalDeviceRegulation2017/745ClassI.Thelaunchdate
ofthisproductisstatedintheCEdeclarationofconformity.
Wearecontinuouslyworkingtowardsensuringthatthe
company’simpactontheenvironment,locallyandglobally,
isreducedtoaminimum.
WeonlyuseREACHcompliantmaterialsandcomponents.
WecomplywiththecurrentenvironmentallegislationsWEEE
andRoHS.
1.5.1Product-specicstandards
TheproducthasbeentestedandconformstoISO10535
(Hoistsforthetransferofdisabledpersons)andallrelated
standards.
Forfurtherinformationaboutlocalstandardsandregulations,
contactyourlocalInvacarerepresentative.Seeaddresses
attheendofthisdocument.
41551341-F

Safety
2Safety
2.1Generalsafetyinformation
Thissectionofthemanualcontainsgeneralsafety
informationaboutyourproduct.Forspecicsafety
information,refertotheappropriatesectionofthemanual
andprocedureswithinthatsection.
WARNING!
Riskofinjuryordamage
–Donotusethisproductoranyavailableoptional
equipmentwithoutrstcompletelyreading
andunderstandingtheseinstructionsandany
additionalinstructionalmaterialsuchasuser
manualsorinstructionsheetssuppliedwith
thisproductoroptionalequipment.Ifyouare
unabletounderstandthewarnings,cautionsor
instructions,contactahealthcareprofessional,
Invacareproviderorqualiedtechnicianbefore
attemptingtousethisproduct.
–Donotmakeanyunauthorizedalterationsor
modicationstotheproduct.
WARNING!
Themaximumsafeworkingloadmustnotbe
exceeded
–Donotexceedthemaximumsafeworkingload
ofthisproductorusedaccessorieslikeslings,
spreaderbarsetc.Seedocumentationorthe
labelingforthestatedmaximumsafeworking
load.
–Thecomponentwiththelowestloadlimit
determinesthemaximumsafeworkingloadof
theentiresystem.
WARNING!
Riskofinjuryordamage
Improperuseofthisproductmaycauseinjury
ordamage.
–Donotattemptanytransferwithoutapproval
ofthepatient’shealthcareprofessional.
–Readtheinstructionsinthisusermanualand
observetrainedpersonnelperformingtransfer
procedures.Thenpracticetransfersunder
supervisionandwithacapablepersonacting
asapatient.
–Specialcaremustbetakenwithpeoplewith
disabilitieswhocannotcooperatewhilebeing
transferred.
–Donotusetheliftasatransportdevice.It
isintendedtotransferanindividualfromone
restingsurfacetoanother.
WARNING!
Riskofinjuryordamage
Inappropriatehandlingofcablescancause
electricalshockandproductfailure.
–Donotkink,shearorotherwisedamagethe
cablesoftheproduct.
–Makesurethatnocablesarejammedor
damaged,whentheproductisused.
–Makesurethewiringiscorrectandconnections
areproper.
–Donotuseunauthorizedequipment.
WARNING!
Riskofinjuryordamage
Excessivemoisturewilldamagetheproductand
maycauseelectricalshock.
– The patient lift can be used in a bath or shower
area but must NOT be used under the shower.
The patient must be transferred to a shower
chair or use other means for showering.
– If the patient lift is used in a moisture
environment, ensure that the patient lift is
wiped clean of any moisture after use.
– Do not plug or unplug the power cable in a
moisture environment or with wet hands.
– Do not store the product in a damp area or
damp condition.
– Periodically inspect all components of the
product for signs of corrosion or damage.
Replace parts that are corroded or damaged.
– See 10.4 Environmental conditions, page 25.
WARNING!
Riskofinjuryordamage
Ignitionsourcescancauseburnsorre.
–Patienttransfermustbeperformedwitha
safetyspacebetweentheliftandpossible
ignitionsources(heater,stove,replace,etc.)
–Thepatientandassistantsmustnotsmoke
duringtransfer.
–Theslingmustnotbeplacedoverheatsources
(heater,stove,replace,etc.)
WARNING!
Riskofinjuryordamage
Toavoidinjuryordamagewhenoperatingthe
product:
–Closesupervisionisnecessarywhentheproduct
isusednearchildrenorpets.
–Donotletchildrenplaywiththeproduct.
CAUTION!
Riskofinjuryordamage
Theproductcangethotwhenexposedtosunlight
orotherheatsources.
–Donotexposetheproducttodirectsunlightfor
prolongedperiods.
–Keeptheproductawayfromheatsources.
IMPORTANT!
Accumulationoflint,dustandotherdirtcan
impairtheproduct.
–Keeptheproductclean.
2.1.1Pinchpoints
1551341-F5

Invacare®Kirilos/Atlante
WARNING!
RiskofInjury
Pinchpointsarepresentinseverallocationson
theliftandngerscouldbepinched.
–Alwayskeephandsandngersclearofmoving
parts.
2.2SafetyInformationonAccessories
CAUTION!
RiskofInjury
Non-originalorincorrectaccessoriesmayaffect
thefunctionandsafetyofthisproduct.
–Duetoregionaldifferences,refertoyour
localInvacarewebsiteorcatalogforavailable
accessoriesorcontactyourInvacareprovider.
–Seethemanualdeliveredwiththeaccessory
forfurtherinformationandinstructions.
–Useonlyoriginalaccessoriesfortheproduct
inuse.Undercertaincircumstances,theuse
slingsfromothermanufacturersispossible.See
additionalinformationinthissection.
CAUTION!
CompatibilityofSlingswithAttachmentSystem
Invacareusesacommonattachmentsystem
basedonhooksandloops.Loopsontheslings
areattachedtohooksonspreaderbars(coat
hangerstyle).Therefore,suitableslingsofother
manufacturerscanbeusedonthisliftaswell.
–Useonlyslingswithloopattachmentsthatare
suitableforspreaderbars(coathangerstyle)
withhooks.
–Donotuseslingsdesignedfor"Keyholeor
ClipAttachmentSystems"or"TiltingFrame
Systems".
Toselecttheappropriatesling,ariskassessmentmustbe
performedbyahealthcareprofessional.Theriskassessment
mustconsider:
•Thepatient’sweight,size,physicalabilityandmedical
condition.
•Thetypeoftransferandtheenvironment.
•Thecompatibilitytotheotherliftingequipmentused.
2.3Safetyinformationon
electromagneticinterference
WARNING!
Riskofmalfunctionduetoelectromagnetic
interference
Electromagneticinterferencebetweenthis
productandotherelectricalequipmentcanoccur
anddisturbtheelectricaladjustmentfunctions
ofthisproduct.Toprevent,reduceoreliminate
suchelectromagneticinterference:
–Onlyuseoriginalcables,accessoriesandspare
parts,tonotincreaseelectromagneticemission
orreduceelectromagneticimmunityofthis
product.
–Donotuseportableradiofrequency(RF)
communicationsequipmentcloserthan30cm
toanypartofthisproduct(includingcables).
–Donotusethisproductnearactive
high-frequencysurgicalequipmentandthe
RFshieldedroomofasystemformagnetic
resonanceimaging,wheretheintensityof
electromagneticdisturbancesishigh.
–Ifdisturbancesoccur,increasethedistance
betweenthisproductandtheotherequipment
orswitchitoff.
–Refertothedetailedinformationandfollow
theguidanceinchapter11Electromagnetic
compatibility(EMC),page26.
WARNING!
Riskofmalfunction
Electromagneticinterferencemaycauseimproper
operation.
–Donotusethisproductadjacenttoorstacked
withotherelectricalequipment.Ifsuchuseis
necessarythisproductandtheotherequipment
mustbecloselyobservedtoverifythatthey
areoperatingnormally.
2.4Labelsandsymbolsontheproduct
2.4.1Identicationlabel
Theidenticationlabelcontainsthemainproduct
information,includingtechnicaldata.
Product Name
YYYY-MM
= xxx kg
Invacare Portugal, Lda
Rua Estrada Velha 949
4465-784 Leça do Balio, Portugal
XXXXXX XXXXX_XX
XXXXXXXXXXXXX
Xxxxxxx xxxxx xxx
Xxxxxxx xxxxx xxx
Xxxxxxx xxxxx xxx
Xxxxxxx xxxxx xxx
Xxxxxxx xxxxx xxx
ISO 10535
Serialnumber
Referencenumber
Manufacturer
61551341-F

Safety
Dateofmanufacture
Max.safeworkingload
ClassIIequipment
(KirilosandAtlanteElectriconly)
TypeBappliedpart
(KirilosandAtlanteElectriconly)
WEEEconform
(KirilosandAtlanteElectriconly)
Readusermanual
(AtlanteHydrauliconly)
EuropeanConformity
Medicaldevice
Abbreviationsfortechnicaldata:
•Iin=IncomingCurrent
•Uin=IncomingVoltage
•Int.=Intermittence
•AC=AlternatingCurrent
•Max=maximum
•min=minute
Formoreinformationabouttechnicaldata,see10Technical
Data,page24.
2.4.2OtherLabelsandSymbols
(KirilosandAtlanteElectriconly)
Readtheusermanualbeforeusingthisproductandfollow
allinstructionsforsafetyanduse.
XX° C
XX° C
XX° C
XX° C
XX%
XX% XXX hPa
XXX hPa =XXX kg
Totalweightoftheproductwiththe
maximumsafeworkingloadapplied
Temperaturelimit
Humiditylimitation
Atmosphericpressurelimitation
Transportandstorageconditions
Operationconditions
Donotapplyanysideforcestotheactuator(e.g.by
usingitasapushbar)asthismightresultindamageand
malfunction.
Donotremovethislabelandmanipulatetheunderlying
screwasthismightimpairthesafetyoftheproduct
Thewarrantyoftheproductisvoidedifthislabelis
removedorbroken
1551341-F7

Invacare®Kirilos/Atlante
3ProductOverview
3.1Intendeduse
Themobilepatientliftisatransferdeviceandisintendedto
transferandpositionanindividualfromonerestingsurface
toanother.Forexample:
•Betweenthebedandawheelchair
•Toandfromthetoilet
•Loweringandraisingpatientsto/fromtheoor
Themaximumsafeworkingloadisstatedin10Technical
Data,page24
Themobilepatientliftisdesignedtobeusedindoorsona
levelsurface,inhospitals,nursingfacilitiesanddomestic
areas.Themobilepatientliftcanbeturned(rotated)in
placefortransferswithlimitedoorspace.
Ahealthcareprofessionalorprivatepersonwhohasreceived
propertrainingistheintendedoperatorofthisproduct.
Indications
Themobilepatientliftisindicatedforcompletelyorpartially
immobilepatients,whocannotbetransferredwithother
typesofliftsortransferaids.
Allpositionchangesarepossiblewithoutassistanceofthe
patient.
Therearenoknowncontraindicationsforthisproduct.
3.2Mainpartsofthelift
ABase
BLeg
CCastor
DRearcastorwithbrake
EBoom
FMast
GSpreaderbar
HHookforsling
IActuator(KirilosandAtlanteElectriconly)
JControlunitwithbattery(KirilosandAtlanteElectric
only)
KEmergencyStop(KirilosandAtlanteElectriconly)
LPushbar
MHandcontrol(KirilosandAtlanteElectriconly)
NLegspreaderhandle
OHydraulicpump–replacesactuatorIforAtlante
Hydraulic
PManualemergencyloweringdevice(Kirilosand
AtlanteElectriconly)
3.3Accessories
Duetoregionaldifferences,refertoyourlocal
Invacarewebsiteorcatalogfordetailsaboutavailable
accessoriesorcontactyourInvacareprovider.
Slingmodelswithloopattachments,suitableforspreader
bars(coathangerstyle)withhooks:
•Fullbodysupportslings-withoutheadsupport
•Fullbodysupportslings-withheadsupport
•Slingsfordress/toileting-withorwithoutheadsupport
•Slingsforamputee
81551341-F

Setup
4Setup
4.1GeneralSafetyInformation
WARNING!
RiskofInjuryorDamage
Damagedpartsmayaffectthesafetyofthe
product.
–Checkallpartsforshippingdamagebeforeuse.
–Incaseofdamage,donotusetheequipment
andcontactyourInvacareproviderforfurther
instructions.
WARNING!
RiskofInjuryorDamage
Improperassemblymaycauseinjuryordamage.
–Assemblymustbeperformedonlybyaqualied
technician.
–UseonlyInvacarepartsintheassemblyofthis
patientlift.
–Aftereachassembly,checkthatallttings
areproperlytightenedandallpartshavethe
correctfunction
–Donotovertightenthemountinghardware.
Thismaydamagethemountingbrackets.
Ifthereareanyissuesorquestionsduringassembly,
contactyourInvacareprovider.
4.2Scopeofdelivery
Theitemslistedinthetableareincludedinyourpackage.
AMastassemblyincludingboom,
spreaderbarandactuatororhydraulic
pump(1piece)
BBattery(1piece,KirilosandAtlante
Electriconly)
CHandcontrol(1piece,Kirilosand
AtlanteElectriconly)
DLegspreaderhandle(1piece)
EBasewithlegs(1piece)
F-notshownCableforcharging(1piece,Kirilosand
AtlanteElectriconly)
G-notshownSling(1piece)
H-notshownUserManual(1piece)
4.3AssemblingtheLift
WARNING!
–Checkallpartsforvisibledefectsordamage
beforeassembly.Incaseofanydamage,donot
usetheproductandcontactInvacare.
–Makesuretheemergencystopisactivated
beforeassemblyordisassembly.
–Takecarewhenliftingcomponentsduring
assembly.Somepartsareheavy.Always
remembertoadoptthecorrectliftingposition.
Performunpackingandassemblyoperationatoorlevel.
Assemblingthemasttothebase
1.PutthebaseAonalevelsurfaceandlocktherear
castorsB.
2.LoosenthemastknobC,butleaveitscrewedintothe
baseA.
3.InsertthetubeofthemastDintotheholeofthebase
A.
4.WhilesupportingthemastassemblyD,tightenthe
mastknobC.
5.PlacethelegspreaderhandleEontoitssupportF
andpushthespringpin,tolockthehandleEonits
supportF.
Installingtheactuatororhydraulicpumptothe
boom
2x17mmwrench
1551341-F9

Invacare®Kirilos/Atlante
1.LoosenthenutAandremoveboltBfromtheboom
mountingbracketC.
2.PlacetheactuatorDorhydraulicpumpEintheboom
mountingbracketCandaligntheholes.
3.ReinstalltheboltBandtightenthenutA.
Wiring
(KirilosandAtlanteElectriconly)
1.PlugthehandcontrolcableonsocketAandmotor
cableonsocketBonthecontrolunit.
2.PlacethebatteryConthecontrolunit.Pushthetopof
thebatteryagainstthemountingbracketuntilthereis
anaudibleclick.
4.4DisassemblingtheLift
1.Putthebaseonalevelsurfacesothatallcastorsmake
contactwiththeoor.
2.Locktherearcastors.
3.Reversetherelevantstepsoftheassemblingprocedure
foryourmodel.
101551341-F

Usage
5Usage
5.1Generalsafetyinformation
WARNING!
Riskofinjuryordamage
Beforeusingtheliftwithapatient,refertothe
followingsafetyinformationandinstructions:
–2Safety,page5
–6PatientTransfer,page14
5.2Locking/Unlockingtherearcastors
WARNING!
RiskofInjuryorDamage
Theliftcouldtipandendangerthepatientand
assistants.
–Invacarerecommendsthattherearcastors
beleftunlockedduringliftingproceduresto
allowthepatientlifttostabilizeitselfwhenthe
patientisinitiallyliftedfromachair,bedorany
stationaryobject.
–Invacarerecommendslockingtherearcastors
oftheliftonlywhenpositioningorremoving
theslingfromaroundthepatient.
•Tolockthecastor,pushdownpedalAwiththefoot.
•Tounlockthecastor,pushuppedalAwiththefoot.
5.3Raising/LoweringanElectricLift
Thehandcontrolisusedtoraiseorlowerthelift.
1.Toraisethelift—Press
andholdtheUPAbutton
toraisetheboomandthe
patient.
2.Tolowerthelift—Press
andholdtheDOWNB
buttontolowertheboom
andthepatient.
Releasethebuttontostopraisingorloweringthelift.
5.4Raising/LoweringaHydraulicLift
Thepumphandleandcontrolvalveareusedtoraiseor
lowerthehydrauliclift.
RefertothesafetyinformationintheIntroductionof
theUsagesectionbeforeperformingthisprocedure.
Therearetwocontrolsonthepumpassembly:
•ThecontrolvalveA
•ThepumphandleB
Toraisethelift:
1.TurnthecontrolvalveAclockwisetotheCLOSED
position.
2.MovethepumphandleBupanddowntoelevatethe
boomC.
Tolowerthelift:
1.TurnthecontrolvalveAcounterclockwisetotheOPEN
position.
2.TheweightofthepatientintheslingDwillcausethe
boomtodescend.
3.Ifthereisnopatientinthesling,pulldownonthe
boomC.
Therateofdescentoftheboomiscontrolledbythe
amountthatthecontrolvalveisopen.
Asafetygateispartofthehydraulicsystem
thatcontrolsthemaximumdescentoftheboom
regardlessofhowfarthecontrolvalveisopened.
5.5Closing/OpeningLegs
WARNING!
RiskofInjury
Theliftcouldtipandendangerthepatientand
assistants.
–Thelegsoftheliftmustbeinthemaximum
openpositionforoptimumstabilityandsafety.
Ifitisnecessarytoclosethelegsoftheliftto
maneuvertheliftunderabed,closethelegsof
theliftonlyaslongasittakestopositionthe
liftoverthepatientandliftthepatientoffthe
surfaceofthebed.Whenthelegsofthelift
arenolongerunderthebed,returnthelegsof
thelifttothemaximumopenposition.
1551341-F11

Invacare®Kirilos/Atlante
5.5.1Closing/Openinglegsmanually
A
1.Toopenthelegs,pullthelegspreaderhandleAoffand
thentotheleftuntilitlocksinthenotchofthebracket.
2.Toclosethelegs,pushthelegspreaderhandleAoff
andthentotherightuntilitlocksinthenotchofthe
bracket.
TheshifterhandleMUSTlockintoitsmountingslot
tolockthelegsinthefullclosedposition.
WARNING!
RiskofInjury
Theliftcouldtipandendangerthepatientand
assistants.
–IfthelegspreaderhandleisNOTpositioned
completelyintoitsmountingslot,DONOTuse
thepatientliftuntilthelegspreaderhandle
isproperlyseatedandthelegsofthepatient
liftarelockedinplace.
5.6Emergencyfunctions
5.6.1PerforminganEmergencyStop
(KirilosandAtlanteElectriconly)
1.PresstheredemergencybuttonAonthecontrolunit
tostoptheboomandpatientfromraisingorlowering.
2.Toreset,rotatetheemergencybuttonclockwise.
5.6.2ActivatinganEmergencyLowering
ActivatinganEmergencyLoweringontheControl
Unit
(KirilosandAtlanteElectriconly)
Ifthehandcontrolfails,theboomcanbeloweredbyusing
thecircularswitchforemergencyrelease.Useasharp
object,suchasapenciltopressthebutton.
1.LowertheboombypressingandholdingbuttonAat
thefrontofthecontrolunit.
2.Stoploweringtheboombyreleasingthebutton.
ActivatingaMechanicalEmergencyLowering
(KirilosandAtlanteElectriconly)
Iftheemergencyloweringonthecontrolunitisnotworking,
amechanicalemergencyloweringisavailableasaback-up.
Thismayhappenincaseofpartialortotalpowerfailure,or
ifthebatteryrunsdownduringuse.
WARNING!
RiskofInjuryorDamage
Repeatedmechanicalemergencyloweringleads
toahighincreaseoftheloweringspeed.
–Onlyusethemechanicalemergencylowering
asaback-upwhentheemergencyloweringon
thecontrolunitisnotworking.
–Donotusethemechanicalemergencylowering
repeatedlyinclosesuccession.
–Alwayslowerthepatientontoasupporting
surfacelikeabedorachair.
–Afteramechanicalemergencyloweringwas
required,theliftmustbecheckedtoresolve
themalfunctionofthecontrolunit.
1.LocatetheemergencyreleaseknobAatthetopofthe
actuatorpiston.
2.RotatetheemergencyreleaseknobAclockwise.
Theboomwilllowerslowlywithoutadditional
downwardforceontheboom.
ActivatinganEmergencyLoweringonthe
HydraulicPump
(AtlanteHydrauliconly)
1.TurnthecontrolvalveAcounterclockwisetotheOPEN
position.
5.7Chargingthebattery
(KirilosandAtlanteElectriconly)
121551341-F

Usage
IMPORTANT!
–Makesuretheemergencystopisnotactivated
whilechargingthebattery.
–Makesurethatchargingtakesplaceinaroom
withgoodairventilation.
–Electricalfunctionsarenotworkingwhenthe
liftisconnectedtopowersupply.
–Donotattempttousetheliftifthebattery
housingisdamaged.
–Replaceadamagedbatteryhousingbefore
furtheruse.
–Donotmovetheliftwithoutunpluggingfrom
thepoweroutlet.
Itisrecommendedtochargethebatterydailytoensure
optimaluseoftheliftandprolongthelifeofthebattery.
Furthermore,itisrecommendedtochargethebattery
beforerstuse.
Controlunit
Thecontrolunitisequippedwithasoundsignal.Abeep
indicatesthatthebatteryhaslowcapacity,butloweringthe
patientisstillpossible.Itisrecommendedtochargethe
batteriesassoonasthesoundsignalisheard.
1.PlugthecableforchargingCintoapoweroutlet.
Thebatterywillchargeinapproximately4
hours.Thechargerstopsautomaticallywhenthe
batteriesarefullycharged.
TherightyellowchargediodeAwillcontinuous
lightduringchargingandswitchoffwhenfully
charged.
TheleftgreendiodeBwilllightcontinuously
whilethecontrolunitisconnectedtothemains,
andlightsupwhenanybuttononthehand
controlispressed.
2.Disconnectthepowercordfromthepoweroutletafter
thebatteryhasbeenfullycharged.
1551341-F13

Invacare®Kirilos/Atlante
6PatientTransfer
6.1Generalsafetyinformation
WARNING!
RiskofInjuryorDamage
Improperuseofthisproductmaycauseinjury
ordamage.
–Beforetransferringtoastationaryobject
(wheelchair,bed,commodeorothersurface)
checkthattheweightcapacitycanwithstand
thepatient’sweight.
–Ifapplicablethewheelorcastorlocksofthe
stationaryobject(wheelchair,bedetc.)mustbe
inalockedpositionbeforeloweringthepatient
ontoorliftingthepatientoff.
WARNING!
RiskofInjuryorDamage
Improperuseofthisproductmaycauseinjury
ordamage.
–Usethepushbarsonthemastatalltimesto
pushorpullthelift.
–Avoidusingtheliftonanincline.Invacare
recommendsthattheproductonlybeusedon
aatsurface.
–Duringtransfer,withthepatientsuspendedin
aslingattachedtothelift,DONOTrollliftover
unevensurfacesthatcouldcausethelifttotip
over.
WARNING!
RiskofInjuryorDamage
Damagetopartsofthelift(handcontrol,castors,
etc.)causedbyimpactwiththeoor,wallsor
otherstationaryobjectsmaycausedamageto
theproductandleadtoinjury.
–DONOTallowpartsofthelifttoimpactthe
oor,wallsorotherstationaryobjects.
–ALWAYSstorethehandcontrolproperlywhen
notinuse.
WARNING!
RiskofInjury
Thespreaderbarcanmovesuddenlyandcause
injury.
–Whenpositioninglift,beawareoftheposition
ofthespreaderbarandthepatient.
WARNING!
RiskofEntrapmentorStrangulation
Thehandcontrolcordcancauseinjuryif
improperlypositionedandsecured.
–ALWAYSbeawareofthelocationofthehand
controlcordinrelationtothepatientand
caregivers.
–DONOTallowthehandcontrolcordtobecome
entangledaroundthepatientandcaregivers.
–Thehandcontrolmustbesecuredproperly.
ALWAYSstorethehandcontrolproperlywhen
notinuse.
WARNING!
RiskofEntrapmentorStrangulation
Itemsinthepatient’ssurroundingscancause
entrapmentstrangulationduringlifting.Toavoid
entrapmentorstrangulation:
–Beforelifting,checkthatthepatientis
completelyfreeofhis/hersurroundings.
WARNING!
RiskofEntrapment
Thereisariskofentrapmentbetweenthe
spreaderbarhooksandthesling.
–Usecautionwhenlifting.
–NEVERputhandsorngersonornearthe
hookswhenlifting.
–Ensurethepatient’shandsandngersareaway
fromthehooksbeforelifting.
IMPORTANT!
Alltransferproceduresdescribedinthefollowing
canbeperformedbyone(1)assistant.However,
Invacarerecommendsthattheproceduresare
performedbytwo(2)assistantswhenever
possible.
6.2Preparingtolift
WARNING!
RiskofInjury
Duringtransfersandliftoperation,theboomcan
impactthepatientorcaregiversandcauseinjury.
–ALWAYSbeawareofthepositionoftheboom
duringtransfers.
–Ensuretheboomispositionedinawaythatit
cannotimpactthepatientorbystanders.
–ALWAYSbeawareofyourbodypositionin
relationtotheboomduringtransfers.
1.
2.
Before proceeding, review the information and observe
all warnings indicated in 2 Safety, page 5 and 6
Patient Transfer, page 14.
Position the patient onto the sling. Refer to your sling
user manual.
3.Unlocktherearcastors.See5Usage,page11.
4.Openthelegsofthelift.See5Usage,page11.
5.Usethepushbarstomovethepatientliftintoposition.
WARNING!
–Whenusingtheliftinconjunctionwith
bedsorwheelchairs,beawareofthe
positionoftheliftinrelationshiptothose
otherdevicessothattheliftdoesnot
becomeentangled.
–Beforepositioningthelegsofthepatient
liftunderabed,makesurethatthearea
isclearofanyobstructions.
6. Lower the patient lift for easy attachment of the
sling.
7. Lock the rear castors. See 5 Usage, page 11
8. Attach the sling. See 6.2.1 Attaching the sling to the
lift, page 15.
141551341-F

PatientTransfer
6.2.1Attachingtheslingtothelift
WARNING!
RiskofInjury
Usageofwrongordamagedslingscancausethe
patienttofallorcauseinjurytoassistants.
–UseanInvacareapprovedslingthatis
recommendedbytheindividual’sdoctor,nurse
ormedicalassistantforthecomfortandsafety
oftheindividualbeinglifted.
–Invacareslingsandpatientliftaccessoriesare
specicallydesignedtobeusedinconjunction
withInvacarepatientlifts.
–Aftereachlaundering(inaccordancewith
instructionsonthesling),inspectsling(s)for
wear,tear,andloosestitching.
–Bleached,torn,cut,frayed,ordamagedslings
areunsafeandcouldresultininjury.Discard
immediately.
–Donotalterslings.
WARNING!
RiskofInjury
Improperlyattachedoradjustedslingscancause
thepatienttofallorcauseinjurytoassistants.
–Besuretochecktheslingattachmentseach
timetheslingisremovedandreplaced,to
ensurethatitisproperlyattachedbeforethe
patientisremovedfromastationaryobject
(bed,chairorcommode).
–Donotuseanykindofplasticbackincontinence
padorseatingcushionbetweenpatientand
slingmaterialthatmaycausethepatientto
slideoutoftheslingduringtransfer.
–Makesurethatthereissufcientheadsupport
whenliftingapatient.
–Positionthepatientintheslingasdirectedby
theinstructionsprovidedwiththesling.
–Adjustmentsforpatientsafetyandcomfort
shouldbemadebeforemovingthepatient.
Thestrapsoftheslingmaybeequippedwithcolorcoded
loopsprovidingdifferentlengthstoplacethepatientinto
differentpositions.Shorterstrapsattheshoulderswill
produceamoreverticallift,whichwillassistwithpositioning
intoachairorwheelchair.Bylengtheningthestrapsatthe
shoulders,amorereclinedpositioncanbeachievedwhich
ismoresuitableforachairtobedtransfer.Alwaysmatch
theloopcolorsofthecorrespondingstrapsoneachsideof
theslingforanevenliftofthepatient.
1.PlacethedesiredloopofstrapAoverhookConthe
spreaderbarD.
2.PulldownthestrapAuntiltheloopisfullyseatedat
thebottomofhookC.
3.RepeatthestepsforeachoftheremainingstrapsA
oftheslingB.
6.3Transferringapatientfromabed
1.Preparetolift.See6.2Preparingtolift,page14.
2.Attachtheslingtothelift.SeeAttachingtheslingto
thelift.
3.Unlocktherearcastors.
4.
Lowerthebedtothelowestposition.
5.
Liftthepatienthighenoughtoclearthestationary
objectwiththeirweightfullysupportedbythelift.
TheboomwillstayinpositionuntiltheDOWN
buttonispressed.
6.
Beforemovingthepatient,checkagaintomakesure
thattheslingisproperlyattachedtothehooksofthe
spreaderbar.SeeAttachingtheslingtothelift.Ifany
attachmentsarenotproperlyinplace,lowerthepatient
backontothestationaryobjectandcorrecttheproblem.
7.
Usingthepushbars,movetheliftawayfromthe
stationaryobject.
1551341-F15

Invacare®Kirilos/Atlante
8.
Usingthehandlesonthesling,turnthepatientsothat
he/shefacestheassistantoperatingthepatientlift.
9.
Lowerthepatientsothathis/herfeetrestonthebase
ofthelift,straddlingthemast.
Thelowercenterofgravityprovidesstability
makingthepatientfeelmoresecureandthelift
easiertomove.
10.
Movethepatientliftwithbothhandsrmlyonthe
pushbars.
11.Proceedwiththetransfertoanotherrestingsurfaceor
stationaryobject.
6.4Transferringapatienttoabed
1.Performthefollowingstepsinadditiontothoserequired
toliftthepatientofanotherrestingsurfaceorstationary
object
2.
Raiseorlowerthelifttopositionthepatientoverthe
stationarysurface.Besuretoraiseorlowerthepatient
enoughtoclearthesidesofthestationaryobject.
3.
Lowerthepatientontothestationarysurface.
4.Ensurethepatientisfullysupportedbythesurfaceto
whichyouaretransferring.
5.Locktherearcastors.
6.Raisethebedtoagoodworkingheight(usuallyhip
heightofcaregivers).
7.
Detachtheslingfromthespreaderbar.
8.Unlocktherearcastors.
9.
Movetheliftawayfromthearea.
6.5Transferringapatientfroma
wheelchair
1.Engagetheparkingbrakesofthewheelchairtoprevent
movementofthewheelchair.
2.Preparetolift.See6.2Preparingtolift,page14.
3.Ensurethewheelchairisplacedbetweentheopened
legsoftheliftwiththepatientfacingthemast.
4.Attachtheslingtothelift.SeeAttachingtheslingto
thelift.
5.Unlocktherearcastors.
6.
Raisetheboomuntilthereistensiononthestraps
oftheslingandmakesurethattheslingisproperly
attachedtothehooksofthespreaderbar.SeeAttaching
theslingtothelift.Ifanyattachmentsarenotproperly
inplace,lowerthepatientbackontothewheelchair
andcorrecttheproblem.
161551341-F

PatientTransfer
7.
Liftthepatienthighenoughtoclearthewheelchair
surfacewiththeirweightfullysupportedbythelift.
8.Usingthepushbars,movetheliftawayfromthe
wheelchair.
9.Proceedwiththetransfertoanotherrestingsurfaceor
stationaryobject.
6.6Transferringapatienttoawheelchair
WARNING!
RiskofInjury
–Beforetransferring,checkthatthewheelchair
weightcapacitycanwithstandthepatient’s
weight.
–ThewheelchairwheellocksMUSTbeina
lockedpositionbeforeloweringthepatientinto
thewheelchairfortransport.
1.Performthefollowingstepsinadditiontothoserequired
toliftthepatientofanotherrestingsurfaceorstationary
object
2.Engagetheparkingbrakesofthewheelchairtoprevent
movementofthewheelchair.
3.Positionthepatientovertheseatwiththeirbackagainst
thebackofthechair.
4.
Begintolowerthepatientandusethegrabhandle
(onselectedmodels)orsidesoftheslingtoguidethe
patient’shipsasfarbackaspossibleintotheseatfor
properpositioning.Thiswillmaintainagoodcenterof
balanceandpreventthechairfromtippingforward.
6.7Transferringapatienttoandfrom
acommode
TheInvacarepatientliftisNOTintendedasa
transportdevice.IfthebathroomfacilitiesareNOT
nearthebedorifthepatientliftcannotbeeasily
maneuveredtowardsthecommode,thenthepatient
MUSTbetransferredtoawheelchairandtransported
tothebathroomfacilitiesbeforeusingthepatientlift
againtopositionthepatientonastandardcommode.
Theslingswithcommodeopeningsaredesignedto
beusedwitheitheracommodechairorstandard
commode.
Beforetransferringthepatient,thepatientliftshould
beguidedtothebathroomfacilitiestocheckthatit
canbeeasilymaneuveredtowardsthecommode.
1.Performthefollowingstepsinadditiontothoserequired
toliftthepatientofanotherrestingsurfaceorstationary
object
2.
Elevatethepatienthighenoughtoclearthecommode
chairarmsandhavetheirweightsupportedbythe
patientlift.See5Usage,page11
3.
Positiontheliftsothelegsareoutsideofthecommode
legsandthepushbarsoftheliftareoppositeofthe
commodeandguidethepatientoverthecommode.
4.
Lowerthepatientontothecommode,leavingthe
slingattachedtothespreaderbarhooks.Invacare
recommendsthattheslingremainsconnectedtothe
spreaderbarhooksduringthepatient’suseofeither
thecommodechairorstandardcommode.
1551341-F17

Invacare®Kirilos/Atlante
5.
Whencomplete,recheckforcorrectslingattachment.
6.Raisethepatientoffofthecommode.
7.
Whenthepatientisclearofthecommodesurface,use
thepushbarstomovetheliftawayfromthecommode.
8.Proceedwiththetransfertoanotherrestingsurfaceor
stationaryobject.
6.8Liftingapatientfromtheoor
WARNING!
RiskofInjury
Theliftcaninjureapatientwhoisontheooror
anassistantworkingontheoor.
–Alwaystakecarewhenmovingpartsofthelift
closetoapersonontheoor.
1.Determineifthepatienthassufferedanyinjuriesfrom
afall.Ifnomedicalattentionisneeded,proceedwith
thetransfer.
2.
PositiontheslingAunderthepatient.Refertothesling
usermanualformoreinformationaboutpositioning
slings.
3.
Havethepatientbendhis/herkneesandraisehis/her
headoffoftheoorsupportingthepatient’sheadwith
apillowB.
4.Unlocktherearcastors.See5Usage,page11
5.Openthelegsofthelift.See5Usage,page11
6.
Positiontheliftwithonelegunderthepatient’sbent
kneesandtheotherlegunderthepatient’shead.Keep
theslingstrapsinsideofthelegsofthelift.
7.
Lowertheboomsothespreaderbarisdirectlyoverthe
patient’schest.
8.
Attachthesling.SeeAttachingtheslingtothelift.
9.Raisetheboomtoliftthepatientofftheoor.
10.Proceedwiththetransfertoanotherrestingsurfaceor
stationaryobject.
181551341-F

Maintenance
7Maintenance
7.1Generalmaintenanceinformation
CAUTION!
Riskofinjuryordamage
–Donotperformanymaintenanceorservice
procedureswhiletheproductisinuse.
Followthemaintenanceproceduresdescribedinthismanual
tokeepyourproductincontinuousoperation.
7.2DailyInspections
WARNING!
Riskofinjuryordamage
Damagedorwornpartscanaffectthesafetyof
thelift.
–Thepatientliftshouldbecheckedeachtime
itisused.
–Donotusetheliftifdamageisfoundoryou
questionthesafetyofanypartofthelift.
ContactyourInvacareproviderimmediately
andensuretheliftisnotuseduntilrepairsare
made.
DailyInspectionChecklist
qVisuallyinspectthepatientlift.Checkallpartsfor
externaldamageorwear.
qCheckallhardware,attachmentpointsandstressed
parts,suchasslings,hooksandanypivotpointsforsigns
ofwear,cracking,fraying,deformationordeterioration.
qVerifythatthehandcontrolorhydraulicpumpis
functional.
KirilosandAtlanteElectriconly:
qChargethebatteryeverydaytheliftisused.
qChecktheemergencystopfunction.
7.3CleaningandDisinfection
7.3.1Generalsafetyinformation
CAUTION!
Riskofcontamination
–Takeprecautionsforyourselfanduse
appropriateprotectiveequipment.
CAUTION!
Riskofelectricshockandproductdamage
–Switchoffthedeviceanddisconnectfrom
mains,ifapplicable.
–Whencleaningelectroniccomponentsconsider
theirprotectionclassregardingwateringress.
–Makesurethatnowatersplashestotheplug
orthewalloutlet.
–Donottouchthepowersocketwithwethands.
IMPORTANT!
Wronguidsormethodscanharmordamage
theproduct.
–Allcleaningagentsanddisinfectantsusedmust
beeffective,compatiblewithoneanotherand
mustprotectthematerialstheyareusedto
clean.
–Neverusecorrosiveuids(alkalines,acidetc.)
orabrasivecleaningagents.Werecommend
anordinaryhouseholdcleaningagentsuchas
dishwashingliquid,ifnotspeciedotherwisein
thecleaninginstructions.
–Neveruseasolvent(cellulosethinner,acetone
etc.)thatchangesthestructureoftheplastic
ordissolvestheattachedlabels.
–Alwaysmakesurethattheproductiscompletely
driedbeforetakingintouseagain.
Forcleaninganddisinfectioninclinicalorlong-term
careenvironments,followyourin-houseprocedures.
7.3.2CleaningIntervals
IMPORTANT!
Regularcleaninganddisinfectionenhances
smoothoperation,increasestheservicelifeand
preventscontamination.
Cleananddisinfecttheproduct
–regularlywhileitisinuse,
–beforeandafteranyserviceprocedure,
–whenithasbeenincontactwithanybody
uids,
–beforeusingitforanewuser.
7.3.3Cleaninginstructions
IMPORTANT!
–Theproductdoesnottoleratecleaningin
automaticwashingsystems,withhigh-pressure
cleaningequipmentorsteam.
Cleaningthelift
Method:Wipeoffwithawetclothorsoftbrush.
Max.temperature:40°C
Solvent/chemicals:Ordinaryhouseholdcleaningagentand
water.
Drying:Wipedrywithasoftcloth.
Cleaningthesling
Refertothewashinginstructionsontheslingandtothe
slingmanualforcleaningdetails.
7.3.4DisinfectionInstructions
Informationonrecommendeddisinfectants
andmethodscanbefoundonhttps://vah-
online.de/en/for-users.
InDomesticCare
Method:Followtheapplicationnotesfortheused
disinfectantandwipe-disinfectallaccessiblesurfaces.
Disinfectant:Ordinaryhouseholddisinfectant.
1551341-F19

Invacare®Kirilos/Atlante
Drying:Allowtheproducttoair-dry.
InClinicalandLongTermCare
Followyourin-housedisinfectionproceduresandonlyuse
thedisinfectantsandmethodsspeciedtherein.
7.4Serviceinterval
WARNING!
Riskofinjuryordamage
Servicemustbeperformedonlybyaqualied
technician.
–ContactyourInvacareproviderforservice.
Unlessotherwisestatedinlocalrequirements,servicemust
beperformedatleastevery12monthsandaccordingtothe
ServiceInspectionChecklist.Whenperformingannualor
regularservice,allpartsdesignedtocarryloadmustbe,as
aminimum,testedwithmaximumload.Allsafetyfeatures
mustbecheckedaccordingtoISO10535:2006AnnexB.
7.4.1Safetyinspectionchecklist
Apersonwhoissuitablyandproperlyqualiedandwell
acquaintedwiththedesign,useandcareoftheliftshould
performperiodicinspections.
DateofInspection:Initials:
THECASTORBASE
qInspectformissinghardware.
qBaseopens/closeswithease.
qInspectcastorsandaxleboltsfortightness.
qInspectcastorsforsmoothswivelandroll.
qInspectandclearcastorsofdebris.
qInspectpivotjointsforwear.
SLINGSANDHARDWARE
qCheckallslingattachmentseachtimeitisusedto
ensureproperconnectionandpatientsafety.
qInspectslingmaterialforwear.
qInspectstrapsforwear.
qInspectstitching.
THEHYDRAULICPUMP/ELECTRICACTUATORASSEMBLY
qCheckforleakage.
qInspecthardwareonmast,boomandbase.
qCheckforwearordeterioration.Ifdamaged,return
tofactory.
qCycletoensuresmoothquietoperationoftheelectric
actuator.
qCheckforsmoothoperationofthepumphandlefor
hydraulicpumps.
THEBOOM
qCheckallhardwareandhangerbarsupports.
qInspectforbendsordeections.
qInspectboltedjointsofboomforwear.
qInspecttoensurethattheboomiscenteredbetween
thebaselegs.
qCheckthemastpivotbolt.Ensurethattheboltis
tightlysecured.
qInspectpivotjointsforwear.
THEMAST
qMastmustbesecurelyassembledtoboom.
qInspectforbendsordeections.
qInspectpivotjointsforwear.
THESPREADERBAR
qCheckthebolt/hooksforwearordamage.
qCheckslinghooksforwearordeection.
qInspectpivotjointsforwear.
LEGSPREADERHANDLE
qEnsurelegspreaderhandleoperatessmoothly.
CLEANING
qWhenevernecessary.
7.5LubricatingtheLift
WARNING!
RiskofFalling
Hydraulicoilorlubricantontheoorcancausea
fallandinjury.
–Wipeexcesslubricantfromtheliftafter
lubrication.
–Useafacialtissuetowipeexcessoilfrom
aroundthehydraulicpiston.
–Ifexcessoilisleakingfromthehydraulicpump,
contactadealerorqualiedtechnicianfor
service.
Refertothegureforlubricationpoints.Lubricateallpivot
pointswithalightgrease(waterproofautolubricant).Wipe
allexcesslubricantfromliftsurface.
1.SpreaderBar
2.BoomMountingBracket
3.Boom/MastMount
4.MastMountingBracket
7.6Checkingandtighteningbolts
201551341-F
