INVENTOR PFVI32-09WF User manual

MODELS/ΜΟΝΤΕΛΑ:
PFVI32-09WF/PFVO32-09
PFVI32-12WF/PFVO32-12
PFVI32-18WF/PFVO32-18
PFVI32-24WF/PFVO32-24
REMOTE CONTROLLER
AIR CONDITIONING SYSTEMS
• USER’S MANUAL
• ΕΓΧΕΙΡΙΔΙΟ ΧΡΗΣΗΣ
• MANUAL UTILIZATORULUI
ENGLISH | ΕΛΛΗΝΙΚΑ | ROMANA

2
Contents
Attention.....................................................................................................1
Function buttons .......................................................................................2
Remote controller (closed cover) ....................................................2
Remote controller (open cover).......................................................4
Use of Remote Control .............................................................................9
Insert/replace batteries............................................................................9
Automatic operation mode (AUTO) ................................................9
Cooling/Heating operation mode....................................................9
Fan operation Mode ........................................................................10
Dry operation mode ........................................................................10

1
1. Before any command from the remote controller, point the remote
controller’s signal transmitter towards the receiver of the air
conditioner.
2. The remote controller can operate in range of up to 8 meters from the
unit.
3. Please ensure that there are no obstacles between the remote
controller and unit.
4. Do not hit, drop or throw the remote controller.
5. Do not leave the remote controller under direct sunlight, or near
heating sources.
6. Please ensure that you use two AAA batteries of the same type.
7. Do not use rechargeable batteries.
8. Do not mix used batteries with new.
9. Always remove the batteries from the remote controller before long-
term without use.
10. If there is no sound of received command from the remote controller
/ unit and there is no indication of communication between remote
controller and unit, please replace the batteries with two new of same
type.
11. If the remote controller’s display resets when a button is pressed,
please replace the batteries with two new of same type.
12. Always properly discard used batteries.
Note:
All the pictures in the manual are for explanatory purposes only.
The actual shape of the unit you purchased may be slightly dierent
(depending on the model).
Cooling-only units do not have the function of E-heating or electric
heating. If selected on the remote controller, the unit will not start
that operation. Please don’t turn the remote controller to such
buttons.
Attention

2
Function buttons
Signal transmitter
Remote controller (closed cover)
Note:
You can operate the buttons on the cover only when the cover is closed.

3
1. “ON/OFF” button
Press the ON/OFF button to start or stop the unit.
By turning o the unit, functions of Timer and Sleep are deactivated as
well.
2. “SPEED” button
Press the SPEED button to select the fan speed.
Fan speed setting will change as follows:
3. / buttons
Press the button to increase the setting temperature by 1°C.
Press the button to decrease the setting temperature by 1°C.
The temperature can be changed quickly by pressing the button
continuously.
Setting temperature range is 16oC ~ 32oC.
4. “COOL” button
Press the COOL button, the mode of operation is shifted to cooling.
5. “HEAT” button
Press the HEAT button, the mode of operation is shifted to heating.
Note: cooling only unit has no heating function
6. “SWING” buttons (SWING and SWING )
Press the buttons to activate the corresponding swing function (up/
down or left/right). To deactivate the corresponding swing function,
press the button again.
Up/down (left/right) has memory function per operation mode and will
remain if you stop and start the unit.
When selecting the Swing setting for the current operation mode, the
other modes’ swing settings will not be aected.
Function buttons

4
Function buttons
Signal transmitter
Remote controller (open cover)
Open it from
left to right

5
1. “ON/OFF” button
Press the ON/OFF button to start or stop the unit.
By turning o the unit, functions of Timer and Sleep are deactivated as
well.
2. “MODE” button
Press the MODE button to select the operation mode
The operation mode will change as below:
Note: cooling-only units have no heating function
3. “SPEED” button
Press the SPEED button to select the fan speed.
Fan speed setting will change as follows:
4. “TURBO” button
Press the TURBO button to activate the turbo function for the fan
speed of the unit. The TURBO indication on the remote controller will
light. Press again to deactivate the turbo function.
Turbo function can only be set during cooling or heating modes of
operation.
5. “SILENCE” button
Press the SILENCE button to activate the silent function.
The SILENCE (SILE) indication on the remote controller will light. Press
again to deactivate the silent function.
6. “TIMER” button
While the unit is operating, you can press the TIMER button to set the
TIMER OFF function. The TIMER OFF function allows you to set the
amount of timer after which the unit will automatically turn o.
While the unit is deactivated, you can press the TIMER button to set
Buttons description

6
the TIMER ON function. The TIMER ON function allows you to set the
amount of timer after which the unit will automatically turn on.
After pressing this key once, the indications H and [ON or OFF
depending of setting] will start ashing on the remote controller’s
display. While the indicators are ashing, press buttons to adjust the
desired time (setting time range is from 0.5 to 24hr). Press the TIMER
button once again to complete the setting (the indications on the
controller’s display will stop ashing.
If no button is pressed for 10s while timer indicators are ashing, the
timer setting will quit.
You can deactivate a set timer setting by pressing TIMER button once.
7. “HEALTH” button
Press the HEALTH button to activate or deactivate the health function
(activates/deactivates the unit’s ionizer).
8. “SLEEP” button
Press the SLEEP button to activate or deactivate the sleep function
When selecting the Swing setting for the current operation mode, the
other modes’ swing settings will not be aected.
When sleep mode is activated, the unit will operate in sleep mode for
10 hours, after which it will continue the last set operation.
If TIMER OFF function has been also set, the unit will turn o
automatically according to set timer.
Note: if you press MODE or ON/OFF button, the sleep function will
deactivate.
9. “iFEEL” button
Press the iFEEL button to activate the iFEEL function. The display
will show the actual room temperature while the function is active
and the unit will operate according to the temperature reading near
the remote controller (requires the transmitter to point towards the
display). When function is deactivated, the display will show the setting
temperature. This function cannot be set while the unit operates at
FAN mode.
Buttons description

7
Buttons description
10. “DISPLAY” button
Press the DISPLAY button once to turn o the unit’s display. If
you press again, the display will ash for 5s then show ambient
temperature and setting temperature.
11. “iCLEAN” button
When the unit is deactivated, press the iCLEAN button to start the
iCLEAN function.
The iCLEAN function will start the unit under specic settings in order
to remove dust and remaining moisture from the evaporator. This
operation should be used often to prevent appearance of mold and
smells from residue buildup inside the unit.
After starting the iCLEAN function, you can press iCLEAN button or
ON/OFF button to quit it.
Note: This function does not substitute proper and regular cleaning
and maintenance of the unit.
12. “ELE.H” button (only for hot pump type).
While the unit is operating in heating mode, press the ELE.H button to
activate the supplementary electric heating.
13. “Anti-FUNGUS” button
The Anti-FUNGUS function can help prevent appearance of mold and
smells from residue buildup inside the unit.
To enable the activation of Anti-FUNGUS function, turn o the unit
and remote controller, point the controller to the unit’s display and
press and hold the Anti-FUNGUS button. The unit will beep 5 times
followed by another 5 beeps, indicating that you can use the Anti-
FUNGUS function. To disable the function, repeat the process above
(the unit will beep 5 times followed by another 3 beeps).
To activate/deactivate the Anti-FUNGUS function, press the Anti-
FUNGUS button once. This function can only be set while the unit
operates under cooling, dry and auto (cooling and dry) modes. The
function will force the unit to operate for 3 minutes under heating
mode (Fan mode for cooling-only units) with low fan speed.
Note: When this function is active, it is suggested to allow the
operation to complete.

8
Function buttons
14. “SPOT SWING” button
By pressing the SPOT SWING button, the horizontal louvers will swing
automatically.
Press it again to deactivate it.
15. “ECO” button
Press the ECO button to activate the economic operation of the unit.
While ECO function is activated, the unit will operate under specic
settings for optimal power consumption. The ECO function will
automatically deactivate after 8 hours.
You can press the ECO button again to manually deactivate the ECO
function.
If TIMER OFF function has been also set, the unit will turn o
automatically according to set timer.
Note: ECO function can only be activated under cooling operation
mode.
16. “iFavor” button
The iFavor button is a shortcut button. You can use the iFavor
function to save and quickly return to preferred settings of mode, fan
speed, set temperature and swing.
To save the preferred settings, while the unit is operating, select the
settings you want (mode, fan speed, set temperature, swing), then
press and hold the iFavor button for 3 seconds. The display will ash 3
times when the settings are saved.
The iFavor function can only have one saved setting at any time, if you
repeat the process above, the new settings will overwrite the previously
saved ones.
To activate the saved iFavor settings, while the unit is operating, press
once the iFavor button.
