involight LEDMH90S User manual

USER MANUAL
LEDMH S90

. 1 .
TABLE OF CONTENTS
Maintenance---------------------------------------------------- 1
Statement------------------------------------------------------- 1
Attention Item ------------------------------------------------- 2
Product introduction ------------------------------------------ 2
------------------------------------------- 3
10 Control Channel ------------------------------------------- 7
------------------------------------------10
------------------------------------------------14
15 Control Channel
That Control Display
Fault conditions
Maintenance
1. Please keep the light in dryness and avoiding use in wet place.
2. Using intermittently can be extended the life.
3. Attention to clean the fan and lens usually in order to get the ventilating effects and
lighting effects better.
4. Please do not wipe the crust using organic menstruum for avoid to damage the product.
Statement
The product has well capability and intact packing when leave factory. All of the user should
comply with above warning item and manual, any misuse cause of the damages are not
included in our guarantee, and also can not be responsible for any malfunction & problem
owing to ignore the manual.
Please forgive that we will not be notice for technical change.

. 2 .
Attention Item
1. For guarantee the life of product, please don't put it on the wet place and also not
use it in the place over 40 degree.
2. Please don't lay the product on the unfixable or shakable place.
3. Ask for the professional to maintain the product in order to avoid the danger of
get an electric shock.
4. Power supply should not be changed over ±10% while the light is using, it will
be decreased the life of lamp if the power is too high, but it will be influenced the
luminosity if the power is too low.
5. Please look round the manual for ensure the product can be used normally.
Product introduction
Power supply: AC100-240V, 60/50Hz
Power consumption: 200W
Fiting lamp: 120W
DMX-control-channels: 15 or 10
Colour-wheel 1: 7 single filter + White + Rainbow-effect
Gobo-wheel 1: 8 staic gobo (with gobo shake) + open + Rainbow-effect
Gobo-wheel 2: 7 rotating gobo + open + Rainbow-effect
Shuttle: Flash rate: 0-20Hz
Effect wheel: 3-face prism ( controllable rotating speed, adjustable positive &
negative)
Focus: motorized focus
Dimmer: 0~100% mechanic dimmer
Iris： 0~100% mechanic adjustable
Maximum PAN-movement: 540°, self-correcting
Maximum TILT-movement: 270°, self-correcting
8bit / 16bit PAN/TILT movement resolution
Master/Slave ativated by sound at pre-programmed function.

. 3 .
0~255
0~255
0~255
0~255
0~255
15 Control Channel
Accept DMX512 control channel, detail as follow:
Channel DMX-value Feature
1 PAN
2 TILT
3 PAN 16bit
4 TILT 16bit
5 X/Y Speed
540°
PAN spinner
270°
TILT spinner
PAN / TILT controllable speed with decreasing
6 Color
Wheel
White
Blue
Yellow
Pink
Green
Red
Light Blue
Orange red
White
From White To Blue
From Blue To Yellow
From Yellow To Pink
From Pink To Green
From Green To Red
From Red To Light Blue
From Light Blue To Orange red
Positive rainbow effect with increasing speed
Negative rainbow effect with increasing speed
0~7
8~15
16~23
24~31
32~39
40~47
48~55
56~63
64~66
67~78
79~92
93~107
108~120
121~136
137~152
153~170
171~212
213~255
7 GOBO
Wheel
0~9 10~19 20~29 30~39
40~49 50~59 60~69 70~79

. 4 .
Channel DMX-value Feature
Gobo 2 Shake with increasing speed
Gobo 3 Shake with increasing speed
Gobo 4 Shake with increasing speed
Gobo 5 Shake with increasing speed
Gobo 6 Shake with increasing speed
Gobo 7 Shake with increasing speed
Positive rainbow effect with increasing speed
Negative rainbow effect with increasing speed
Gobo 1 Shake with increasing speed
7 GOBO
Wheel
Static Gobo 2 Shake with increasing speed
Static Gobo 3 Shake with increasing speed
Static Gobo 4 Shake with increasing speed
Static Gobo 5 Shake with increasing speed
Static Gobo 6 Shake with increasing speed
Static Gobo 7 Shake with increasing speed
Static Gobo 8 Shake with increasing speed
Positive rainbow effect with increasing speed
Negative rainbow effect with increasing speed
Static Gobo 1 Shake with increasing speed
9 Static
GOBO
Wheel
100~119
120~139
140~159
160~179
180~199
200~219
220~237
238~255
80~99
92~107
108~123
124~139
140~155
156~171
172~187
188~203
204~219
220~237
238~255
0~9 10~19 20~29 30~39 40~49
50~59 60~69 70~79 90~91
8 GOBO
Rotation
Stop
Gobo rotate index
Positive rainbow effect with increasing speed
Negative rainbow effect with increasing speed
0~10
11~127
128~191
192~255
80~89

. 5 .
Channel DMX-value Feature
10 Shutter
Close
Open
Open
Strobe effect with increasing speed
Pulse strobe
Random Shutter
0~7
8~22
23~85
86~100
101~165
166~180
181~245
246~255
Open
Open
0~255
0~255
11 Dimmer
12 Focus
0~100% mechanic dimmer
Motorized focus, zoom out to zoom in
Reset Gobo rotation
Reset Gobo 2
Reset Focus
Reset Prism
Disabled blackout while pan/tilt/ movinggobo wheel
Disabled blackout while pan/tilt/ movingcolor wheel
Disabled blackout while / movingpan/tilt/color wheel gobo wheel
Reset tilt
Color Wheel 1 disk reset
14
function
Channel
Reserved
Blackout while pan/tilt moving
Blackout while wheel movingcolor
Reset pan
Blackout while wheel movinggobo
Gobo disk reset
Disabled blackout while / movingcolor wheel gobo wheel
Reserved
0~9
10~14
15~19
20~24
25~29
30~34
35~39
40~44
45~49
50~54
55~59
60~64
65~69
70~74
75~79
80~84
85~89
13 Prism
0~7
8~15
16~127
128~239
White
Stop, static prism effect
240~255 Stop, static prism effect
Rotation prism effect Positive rainbow
Rotation prism effect Negative rainbow

. 6 .
Channel DMX-value Feature
140~149
150~159
160~169
170~179
180~189
190~199
200~209
210~219
220~229
230~239
240~249
250~255
15 Effect
50~59
60~69
70~79
80~89
90~99
100~109
110~119
120~129
130~139
Effect 5
Effect 6
Effect 7
Effect 8
Effect 9
Effect 10
Effect 11
Effect 12
Effect 13
Effect 14
Effect 15
Effect 16
Effect 17
Effect 18
Effect 19
Effect 20
Effect 21
Effect 22
Effect 23
Effect 24
Effect 25
Reserved
Run random pnogramme
Sound control
100~129
130~192
193~255
0~9
10~19
20~29
30~39
40~49
Reserved
Effect 1
Effect 2
Effect 3
Effect 4
14
function
Channel
All channel reset
90~99

. 7 .
0~255
0~255
10 Control Channel
Accept DMX512 control channel, detail as follow:
Channel DMX-value Feature
1 PAN
2 TILT
540°
270°
3 Color
Wheel
White
Blue
Yellow
Pink
Green
Red
Light Blue
orange red
White
From White To Blue
From Blue To Yellow
From Yellow To Pink
From Pink To Green
From Green To Red
From Red To Light Blue
From Light Blue To orange red
Positive rainbow effect with increasing speed
Negative rainbow effect with increasing speed
0~7
8~15
16~23
24~31
32~39
40~47
48~55
56~63
64~66
67~78
79~92
93~107
108~120
121~136
137~152
153~170
171~212
213~255
4 GOBO
Wheel
0~9 10~19 20~29 30~39
40~49 50~59 60~69 70~79
Gobo 1 Shake with increasing speed
Gobo 2 Shake with increasing speed
80~99
100~119
Gobo 3 Shake with increasing speed
120~139

. 8 .
Channel DMX-value Feature
4 GOBO
Wheel
Gobo 4 Shake with increasing speed
Gobo 5 Shake with increasing speed
Gobo 6 Shake with increasing speed
Gobo 7 Shake with increasing speed
Positive rainbow effect with increasing speed
Negative rainbow effect with increasing speed
140~159
160~179
180~199
200~219
220~237
238~255
Static Gobo 2 Shake with increasing speed
Static Gobo 3 Shake with increasing speed
Static Gobo 4 Shake with increasing speed
Static Gobo 5 Shake with increasing speed
Static Gobo 6 Shake with increasing speed
Static Gobo 7 Shake with increasing speed
Static Gobo 8 Shake with increasing speed
Positive rainbow effect with increasing speed
Negative rainbow effect with increasing speed
Static Gobo 1 Shake with increasing speed
6 Static
GOBO
Wheel
92~107
108~123
124~139
140~155
156~171
172~187
188~203
204~219
220~237
238~255
0~9 10~19 20~29 30~39 40~49
50~59 60~69 70~79 90~91
5 GOBO
Rotation
Gobo rotate index
Positive and Negative Rotation with increasing speed
Positive Rotation with increasing speed
Negative Rotation with increasing speed
0~10
11~127
128~191
192~255
7 Shutter
Close
Open
Strobe effect with increasing speed
Pulse strobe
0~7
8~22
23~85
86~100
101~165
166~180
Open
Open
80~89

. 9 .
Channel DMX-value Feature
Open
Random Shutter
181~245
246~255
7 Shutter
0~255
0~255
8 Dimmer
9 Focus
0~100% mechanic dimmer
Motorized focus, zoom out to zoom in
10 Prism
0~7
8~15
16~127
128~239
White
Stop, static prism effect
240~255 Stop, static prism effect
Rotation prism effect Positive rainbow
Rotation prism effect Negative rainbow

. 10 .
That Control Display
1、Top menu, present the current operation:
2. Press the <MODE/ESC> button repeatedly until you reach the desired
menu function.Press the <ENTER> button to select the menu function
currently displayed, or to enable menu option. To return to the previous op
tion or menu without changing the value.Press the <MODE/ESC> button.
DMX Address: 001
DMX Signal
DMX mode: select channel 1 - channel 512
1 . DMX Address <
2 . R u n
D M X A d d r e s s
Address:001
Current mode
Current position designation
DMX Mode
Press the <DOWN> buttons to navigate
the digit,Press the <UP> buttons to navigate
the value
Press the <DOWN> buttons to navigate the digit,
Press the <UP> buttons to navigate the value.
2-Run
3-Pan
< 2-Run
Select: Fast
2-Run
Select: Slow
2-Run
Select: Sound
2-Run
Select: Slave
built-in program
auto quick running
built-in program
auto slow running
built-in program
sound control
built-in program
slave running state
Use the <UP>,<DOWN>,
and <ENTER> button to
scroll through these
menu items

. 11 .
3-Pan
Select: Normal
3-Pan
Select: Reverse
Pan mode
Positive
Pan mode
Negative
3-Pan <
4-Tilt
7-Tilt Angle <
8-Channel
7-Tilt Angle
Select: 270
7-Tilt Angle
Select: 180
7-Tilt Angle
Select: 90
Tilt 270°(For built-in program only)
Tilt 180°(For built-in program only)
Tilt 90°(For built-in program only)
6-Pan Angle
Select: 360
6-Pan Angle
Select: 180
6-Pan Angle
Select: 540
Pan 540°(For built-in program only)
Pan 360°(For built-in program only)
Pan 180°(For built-in program only)
6-Pan Angle <
7-Tilt Angle
5-Display
Select: 30 Close
5-Display
Select: Bright
The Background lighting will turn
off affter 30 seconds if no buttons
are pushed
The Background lighting long-light
5-Display <
6-Pan Angle
4-Tilt
Select: Normal
4-Tilt
Select: Reverse
Tilt mode
Positive
Tilt mode
Negative
4-Tilt <
5-Display

. 12 .
8-Channel
Select: Basic
8-Channel
Select: Advance
Basic / Advanced mode
Basic mode
Basic / Advanced mode
Advance mode
8-Channel <
9-Temp. Disp
T1 T2 T3
50 50 50
independent temperature of each LED
temperature
9-Temp. Disp <
10-Reset System
10-Reset System
Select: OK
10-Reset System
Select: NO
whole machine reset seletion
whole machine reset
whole machine reset seletion
no reset
10-Reset System <
11-Load set
3、Service Functions. Press <MODE/ESC> at least 10 second,
goes into motor start bit adjustment.
Init Motor Set
Password:0000
Press the <DOWN> buttons to navigate the digit,
Press the <UP> buttons to navigate the value
1-Pan Init <
2-Tilt Init
1-Pan Init
Set: 128
1、moto vernier regulation manual. Manufacturing code:2323. enter code
and press "enter" enter the follow operation interface:
Motor start bit adjustment
for Pan
<ENTER>
2-Tilt Init <
3-Color Init
2-Tilt Init
Set: 128
Motor start bit adjustment
for Tilt
<ENTER>
1 -Load set
Select: OK
1
1 -Load set
Select: NO
1
load original state seletion
load original data
load original state seletion
unload
1 -Load set <
1-DMX Address
1

. 13 .
5-Grota Init <
6-Gobo 2 Init
5-Grota Init
Set: 128
Motor start bit adjustment
for Grota
<ENTER>
3-Color Init <
4-Gobo 1 Init
4-Gobo 1 Init <
5-Grota Init
3-Color Init
Set: 128
4-Gobo 1 Init
Set: 128
Motor start bit adjustment
for Color wheel
Motor start bit adjustment
for Gobo wheel 1
<ENTER>
<ENTER>
8-Prism Init
9-Lamp Init
< 8-Prism Init
Set: 128
Motor start bit adjustment
for Prism
<ENTER>
6-Gobo 2 Init
7-Focus Init
<
7-Focus Init
8-Prism Init
<
6-Gobo 2 Init
Set: 128
7-Focus Init
Set: 128
Motor start bit adjustment
for Gobo wheel 2
Motor start bit adjustment
for focus
<ENTER>
<ENTER>
9-Lamp Init
1-Pan Init
< 9-Lamp Init
Set: 128
initial lamp brightness
modification
<ENTER>
1-Prism Half < 1-Prism Half
Set: 000
Prism motor half-step
modification
<ENTER>
After entering into the interface above, pressing the <MODE/ESC>
button can be back to the present running state or if no operating within 60s,
it will exit automatically.
2、Password is 2322, enter the password and press <ENTER>, goes into
the item:
2-Focus Half < 2-Focus Half
Set: 000
focus motor half-step
modification
<ENTER>

. 14 .
Lamp Hot：When the LED reach 90℃, it is protected by the system and turn
off automatically, and display will show "Lamp Hot".
Open：Under the condition that the temperature resistance of the LED is not
connected or already damaged, the display will be "open".
Short：Under the condition that the temperature resistance of the LED is short
circuited, the display will be "Short".
Fault conditions

LEDMH S90
