involight MovingBeam410Q User manual

MovingBeam410Q
Manual

DMX LED Moving Head, 4-in-1 10W RGBW
User Manual
Please read the manual before operation
A. SPECIFICATION
1. Power input: AC 100V-240V, 60Hz/50Hz
2. Wattage: 70W
3. LEDs: 4-in-1 10W RGBW
4. Beam angle: 1.8 degrees
5. Selectable:1,22, 26 DMX channels
6. Operation mode: LCD display
7. Working temperature: -10℃~40℃
8. IP rate: IP20
9. Weight: 6.8 kg
10.Size: 555*95*210mm
11.Power linking: 7pcs@110V, 13pcs@240V,
12.Lumen:
R
2439lux@2m
G
4843lux@2m
B
178lux@2m
W
980lux@2m
A
6948lux@2m
B. OPERATION
There are many types of lighting effects for this fixture, there are five working modes.
Auto running
Build-in program
Sound-active mode
DMX mode
Slave mode

C. FUNCTION DESCRIPTION
LCD Menu struture chart
1. Auto running
When the display shows “AUTO”, the light will run as the program which had been set. Press
“SETUP” button to enter into the optional menu. Press “UP” and DOWN” to choose the optional
which need to set the parameter as below: Led, Pan or Tilt.
1) LED function
When choose “Led”, and press “SETUP” enter to LED auto running parameter setting. The
option with black marks is selected.
You could choose “Auto”, “Color”or “Dimmer”.
When choose “Auto”, press “SETUP” button enter to setup menu.

Press “UP” and “DOWN” to select the parameter. When choose “Speed”, press “SETUP”to
choose the speed menu of the auto running.
Press “UP” and “DOWN” to adjust the auto running speed from 01-20.
When choose “Freq.”, press “SETUP” to set the flash speed.
Press “UP” and “DOWN” to adjust the flash speed 00-20Hz
When choose “Color”, press the “SETUP” to set the parameter. Choose “Static”and press
“SETUP”again to enter color program. Press “UP”and “DOWN”to choose relative color.
When choose “Dimmer”, press the “SETUP” to set the parameter. When choose “RED”,
“GREEN”, “BLUE”or “WHITE”, press “SETUP”to enter relative gray level: 0-255. When
choose “Freq. ”, press “UP”and “DOWN”to set the flash speed 00-20Hz.
2) Pan function
When choose “Pan”, press “SETUP” enter the function choose menu.
Pan has 4 modes, p-Auto, p-Manul, p-CW and p-CCW.
When choose “p-Auto”, pan enters to build-in program.
When choose “p-Manul”, pan stops in setting location. Press “SETUP”enters to set pan
location. Press “UP”and “DOWN”to adjust the location: 0—540 degrees.
When choose "p-CW", Pan turns with clockwise direction (from the LED light). Press
“SETUP”, enter to set Pan speed setting. Press “UP”and “DOWN”to adjust the speed: 1-16.
When choose "p-CCW", Pan turns with anti-clockwise direction (from the LED light). Press
“SETUP”, enter to set Pan speed setting. Press “UP”and “DOWN”to adjust the speed: 1-16.
3) Tilt function
When choose “Tilt”, press “SETUP” enter the function choose menu.
Pan has 2 modes, t-Auto and p-Manul.
②When choose “t-Auto”, Tilt enters to build-in program.
When choose “t-Manul”, Tilt stops in setting location. Press “SETUP”enters to set tilt location.
Press “UP”and “DOWN”to adjust the location: 0—200 degrees.
2. Build-in program
When display shows ”SHOW”, it enter to the build-in program
Press “SETUP” to enter the build-in programs. There are 9 programs inside. Press “UP” and
“DOWN” to choose the built-in program from Show1 –Show9 (the built-in program is pre-set and

can’t be reset).
3. Sound-active Mode
When display shows “SOUND”, enter the sound-active mode.
Press “SETUP” enters the menu of adjusting the sound sensitivity. Press “UP” and “DOWN” to
adjust the sensitive value from 0-31.
4. DMX Mode
When display shows “DMX”, enter the DMX mode.
Press “SETUP” enters to the main menu: “Address”and “Channel”. Press the “UP”or “DOWN”
to choose the option.
When choose “Address”, press the “SETUP” enters to the address menu, set the DMX address
1-512 through “UP” and “DOWN”.
When choose “Channel”,press “SETUP” enter to set the DMX channel through “UP” and
“DOWN”.
There are three channels: 1-ch, 22-ch, and 26-ch (choose 22-ch to restore factory settings)
This product has automatic identification functions. Once receive DMX signal, the fixture will
enter the DMX mode. Once the signal disappears, the fixture will return the previous mode.
When LCD shows “DMX IN”, it means it enter the DMX mode.
DMX Mode 1: 1-ch
1-ch
Channel
Number
Function
1
0--29
LED close
30-44
Built-in program Show1
45-59
Built-in program Show2
60-74
Built-in program Show3
75-89
Built-in program Show4
90-104
Built-in program Show5
105-119
Built-in program Show6
120-134
Built-in program Show7
135-149
Built-in program Show8
150-164
Built-in program Show9
165-194
LED close
195-255
Sound active, the sensitivity will be higher when the
value is larger.
DMX Mode 2: 22-ch

22-ch
Channel
Number
Function
1
0-255
Pan 0-540°
2
0-255
Pan fine turning
3
0-255
Tilt 0-200°
4
0-255
Tilt fine turning
5
0-255
Pan/Tilt Speed
The speed is lower when the No. is larger.
6
0-129
No function
130-192
The speed is from fast to low when pan moves
forward.
193-255
The speed is from low to fast when pan moves
forward.
7
0-255
LED1 R 0-100%
8
0-255
LED1 G 0-100%
9
0-255
LED1 B 0-100%
10
0-255
LED1 W 0-100%
11
0-255
LED2 R 0-100%
12
0-255
LED2 G 0-100%
13
0-255
LED2 B 0-100%
14
0-255
LED2 W 0-100%
15
0-255
LED3 R 0-100%
16
0-255
LED3 G 0-100%
17
0-255
LED3 B 0-100%
18
0-255
LED3 W 0-100%
19
0-255
LED4 R 0-100%
20
0-255
LED4 G 0-100%
21
0-255
LED4 B 0-100%
22
0-255
LED4 W 0-100%
DMX Mode 3: 26-ch
26-ch
Cha
nnel
Number
Function
1
0-255
Pan 0-540°
2
0-255
Pan fine turning
3
0-255
Tilt 0-200°
4
0-255
Tilt fine turning
5
0-255
Pan/Tilt Speed
The speed is lower when the No. is larger.
0-129
No function

6
130-192
The speed is from fast to low when pan moves
forward.
193-255
The speed is from low to fast when pan moves
forward.
7
0-255
LED Master Dimming
8
0-255
LED1 R 0-100%
9
0-255
LED1 G 0-100%
10
0-255
LED1 B 0-100%
11
0-255
LED1 W 0-100%
12
0-255
LED2 R 0-100%
13
0-255
LED2 G 0-100%
14
0-255
LED2 B 0-100%
15
0-255
LED2 W 0-100%
16
0-255
LED3 R 0-100%
17
0-255
LED3 G 0-100%
18
0-255
LED3 B 0-100%
19
0-255
LED3 W 0-100%
20
0-255
LED4 R 0-100%
21
0-255
LED4 G 0-100%
22
0-255
LED4 B 0-100%
23
0-255
LED4 W 0-100%
24
0-9
No function
10-19
LED auto running, motor position controlled by
CH1-CH6
20-29
Built-in program Show1
30-39
Built-in program Show2
40-49
Built-in program Show3
50-59
Built-in program Show4
60-69
Built-in program Show5
70-79
Built-in program Show6
80-89
Built-in program Show7
90-99
Built-in program Show8
100-109
Built-in program Show9
110-129
No function
130-255
Sound active, the sensitivity will be higher when the
value is larger.
25
0-255
Led speed only for the LED auto running mode
26
0-14
LED no strobe
15-255
LED strobe it will be faster with larger value (It has
no use under built-in program mode)

5. Master/slave Mode
When the LCD displays shows “SLAVE”, it enters the M/S mode.
D. SETTING
In the setting menu, press “SETUP”button enter to select the menu. There are 9 options, you may
select through “UP”and “DOWN”button.
1) BLTime: to set the LCD light time
2) Adjust: to set the motor restoration
3) Reset: to restore factory setting
4) Power: the voltage of power supply
5) Error: system self inspection
6) Lamp: LED information
7) Use: Time for use
8) Sensor: sensor setting
9) About: fixture information
a. When choose “BL Time”, press “SETUP”button to adjust the time: 5s, 10s, 20s, 30s, ON
through “UP”and “DOWN”button.
b. When choose “Adjust”, press “SETUP”button to select Pan, Tilt through “UP”and “DOWN”
button.
Pan: press “UP”and “DOWN”button to adjust “Pan”position until the pan is parallel with the
base. Press “SETUP”button, the display shows “Adjust Y/N”. Press “SETUP”button to adjust the
pan. Press “MODE”button back to the menu.
Tilt: press “UP”and “DOWN”button to adjust “Pan”position until the light is parallel with the
base. Press “SETUP”button, the display shows “Adjust Y/N”. Press “SETUP”button to adjust the
pan. Press “MODE”button back to the menu.
This function does not work when the fixture is under DMX mode or fail on position restoration.
c. When choose “Reset”, press “SETUP’button to enter to factory resetting mode. Press “SETUP”
button again, LCD shows “Factory Reset”. Press “MODE”button back to the menu.
d. When choose “Power”, press “SETUP”button enter to check the information of power supply.
“Main”means the voltage of main board; “LED”means the voltage of LED driver.
e. When choose “Error”, press “SETUP”button enter to self-inspection. LCD shows “000000”
means approved. If not, press “SETUP”button to check the mistake.
f. When choose “Lamp”, press “SETUP”button to show the LEDs information

g. When choose “Use”, press “SETUP”button to show the usage time of fixture. Press “SETUP”
button to choose “Clear Y/N”. If not, press “MODE”back to the menu
H. When choose “Sensor”, press “SETUP”button to enter the menu:
P-Hall
It is about the pan sensor state. Press “SETUP”button to check it. LCD shows “Hall OK”means
the pan sensor runs well. If LCD shows “LCD not good”means something wrong with the sensor.
T-Hall
It is about the tilt sensor state. Press “SETUP”button to check it. LCD shows “Hall OK”means
the pan sensor runs well. If LCD shows “LCD not good”means something wrong with the sensor.
P-Rast
It is about pan coding state and setting. Press “SETUP”button to enter to the menu: p-sets, p-state
When choose “p-sets”, could open or close the pan coding through “UP”and “DOWN”button.
When you close the pan coding, pan could not restore the position.
When choose “p-state”, press “SETUP”button to check the pan coding state. “Current”is the
adjust times. “History”is the total amount of the adjust times. Press “SETUP”button, LCD shows
“Clear Y/N?”, the data are cleared. Press “MODE”button back to the menu.
T-Rast
Same as pan coding setting.
I. When choose “About”, press “SETUP”button enter to refer the product information (includes
item number, version number, motor driver and LED driver information) through “UP”and
“DOWN”button.
E. FACTORY RESTORATION
1) In the setting menu, you may refer to the detail operation
2) Press “MODE”and “SETUP”button in the same time for a while, power on the fixture, LCD
shows “Factory Reset…”. Then release the buttons and recover the factory setting.
