Our outdoor DMX LED twins ’ magiflood offers many possibilities to achieve the effects which
you want. It is for DJs, bands, nightclubs and other performers who want a complete LED wash
light system. Please read the manual before operation.
A.
A.
A.
A. SPECIFICATION
SPECIFICATION
SPECIFICATION
SPECIFICATION
1. Size: 41.2*34.4*33.5cm
2. Weight: 8.8kg
3. Power input: AC 110V/240V , 60HZ/50HZ
4. Power consumption: 120W
5. LEDS: 36*tri-3W LEDS;
6. Beam angle: 45 degree
7. IP rate: IP66
8. Very powerful static colors effects
9. Perfect color mixing & wall wash effects for the buildings
10. Built-in programs, auto run, DMX mode, M/S, static colors
11. DMX channels: 5CH, 8CH, 9CH
12. Safety eye available
B.OPERATION:
B.OPERATION:
B.OPERATION:
B.OPERATION:
After power on, Press “ MODE ” button to activate the main menu: Built-in programs mode, Auto
running mode, DMX mode, Slave mode, static color mode.
“ SETUP ” is to set the relative specification for current mode.
“ UP ” is to add the value of current specification.
“ DOWN ” is to decrease the value of current specification.
Built-in programs-- running one of built-in programs
Auto run — running built-in programs one after another in continuous loop.
DMX mode--controlled by DMX controller
Slave mode — the projectors in this mode will be synchronously run with the projectors in master
mode
Static color mode-- to have static color effects from this function.
1.
1.
1.
1. Built-in
Built-in
Built-in
Built-in program
program
program
program
Press the “ MODE ” ,enter the menu to choose the program “ Pr. ××” 。
Press the “ UP ” or “ DOWN ” ,choose the effect program Pr.01~Pr.09 。
When the LED display shows Pr.01- Pr.09, the first time to press “ SETUP ” , it will show “ SP.XX ” ，
press “ UP ” or “ DOWN ” to set up the running speed for the program from SP01~SP100(FL) ；the
second time to press “ SETUP ” ,it will show “ FSxx ” ，press “ UP ” or “ DOWN ” to set up flash speed
from FS00~FS99.
2.
2.
2.
2. Auto
Auto
Auto
Auto R
R
R
R unning
unning
unning
unning
Press “ MODE ” to enter the auto running “ AUTO ” ,the fixture will run the built-in programs from
Pr.01~Pr.09.The user can set up the running speed and flash speed under built in program. Then it
will auto run the effects in order.

2
3.
3.
3.
3. DMX
DMX
DMX
DMX M
M
M
M ode
ode
ode
ode
Press the “ MODE ” ,enter the DMX mode “ d. ×××” 。
Press the “ UP ” or “ DOWN ” ,set up the DMX address d.001 — d.512 。
Press the “ SETUP ” ,enter the menu to set up DMX mode X-ch 。
Press the “ UP ” or “ DOWN ” ,set up the DMX mode,5-ch ，8-ch ，9-ch
DMX mode 1 ：5-ch
CHANNEL VALUE FUNCTION
CH1 0-255 Master dimmer
CH2 0-255 RED
CH3 0-255
GREEN
CH4 0-255
BLUE
CH5 0-255
Strobe
DMX mode2 ：8-ch
CHANNEL VALUE FUNCTION
CH1 0-255 Master dimmer
CH2 0-255 RED1
CH3 0-255
GREEN1
CH4 0-255
BLUE1
CH5 0-255
RED2
CH6 0-255
GREEN2
CH7 0-255
BLUE2
CH8 0-255
Strobe
DMX mode3 ：9-ch
CH1 CH2 CH3 CH4 CH5 CH6 CH7 CH8 CH9
0-255
MASTER
DIMMER
0-255
RED
0-255
GREEN
0-255
BLUE
0
0
NO
USE
0-255
STROBE
0-127
function1NO
USE
NO
USE
NO
USE
1-255
TABLE
TABLE
TABLE
TABLE
1
1
1
1
NO
USE
1-255
TABLE
TABLE
TABLE
TABLE
2
2
2
2
0-255
SPEED
0-255
RED
1
0-255
GREEN
1
0-255
BLUE
1
0-255
RED 2
0-255
GREEN
2
0-255
BLUE 2
128-255
function2
TABLE
TABLE
TABLE
TABLE 1
1
1
1

3
4.
4.
4.
4. Slave
Slave
Slave
Slave M
M
M
M ode
ode
ode
ode
Press the “ MODE ” ,enter the slave mode “ SLA V ” .
5.
5.
5.
5. Static
Static
Static
Static color
color
color
color of
of
of
of single
single
single
single section
section
section
section control
control
control
control
Press “ MODE ” button, enter static color of single section control mode “ COL1 ”
Press setup until it shows “ 1.xxx ” （the red color of fixture 1 ） 、 “ 2.xxx ” (the green color of fixture
1) 、“ 3.xxx ” (the blue color of fixture 1) 、“ 4.xxx ” (the red color of fixture 2) 、“ 5.xxx ” (the green color
of fixture 2) 、“ 6.xxx ” (the blue color of fixture 2)
Press “ up ” or “ down ” to adjust brightness.
6.
6.
6.
6. Static
Static
Static
Static color
color
color
color of
of
of
of whole
whole
whole
whole unit
unit
unit
unit control
control
control
control
Press MODE button ,enter static color of whole unit control mode “ COL2 ”
Press setup button, it will show “ r.xxx ” 、“ g.xxx ” 、“ b.xxx ”
Press “ up ” or “ down ” to adjust brightness.
CH5
DMX value FUNCTION
1-22 R
23-45 G
46-68 B
69-91 cyan
92-114 Y
115-137 orange
138-160 pink
161-183 purple
184-206 deongaree
207-229 Pale green
230-252 white
253-255 WW
TABLE
TABLE
TABLE
TABLE 2
2
2
2
CH6
DMX value
FUNCTIO
N
1-15 R
16-31 G
32-47 B
48-63 Y
64-79 cyan
80-95 purple
96-111 white
112-127 Pr01
128-143 Pr02
144-159 Pr03
160-175 Pr04
176-191 Pr05
192-207 Pr06
208-223 Pr07
224-239 Pr08
240-255 Pr09

4
Notice:
Notice:
Notice:
Notice:
A. 4 buttons without any press within 20 seconds, the LED display will be turn off .Meanwhile, all
the buttons will self lock if someone press any button by mistake. Press “ mode ” + “ down ” over
one second to clear lock. Then the LED display will be resume the original condition and all the
buttons will be work in normal.
B. It is of thermal self-protection. If it is full on last a long time, the system will adjust the power
consumption in order to reduce the heat. Please make sure around is well ventilated when the unit
is full on.
C. It will show the version, such as V1.0 ，when turn on the system. Two seconds later, it will run
normally with the setup mode.
