Goodrive300-21 integrated machine for air compressor Preface
i
Preface
Goodrive300-21 series dual inverter integrated machine for air compressor (hereafter referred to as
GD300-21 air compressor integrated machine) is especially developed for
synchronous/asynchronous twin screw air compressor. It can be used in combination with HMI touch
screen to drive and control the twin screw air compressor.
GD300-21 air compressor integrated machine is capable of providing dual inverter output of master
and fan for the air compressor as well as offering +24V power to the touch screen. It supports control
of solenoid valve and receiving of temperature and pressure signal. In respect of function, it is a
perfect replacement for the original dual inverter electrical control cabinet of air compressor but with a
much smaller size and simpler installation and commissioning procedures.
Given the application scenarios and actual demands of air compressor, GD300-21 air compressor
integrated machine can realize fast start-up and stable operation of air compressor through dual PID
and unique weak magnetic design. It adopts independent air duct, heavy load and high power factor
design to effectively cope with challenging grid conditions and application environment. In addition, it
can realize IOT application by installing optional parts and accessories.
Read through this manual carefully before installation to ensure correct installation and operation of
GD300-21 air compressor integrated machine, thus giving full play to its excellent functions and
performance.
If the end user is a military unit or the product is used for weapon manufacturing, please comply with
relevant export control regulations in the Foreign Trade Law of the People's Republic of China, and
complete necessary formalities.
The manual is subject to change without prior notice.

Goodrive300-21 integrated machine for air compressor Contents
ii
Contents
Preface............................................................................................................................................i
Contents.........................................................................................................................................ii
1 Product overview........................................................................................................................1
1.1 Product specifications .........................................................................................................1
1.2 Product nameplate..............................................................................................................2
1.3 Model instruction.................................................................................................................3
1.4 Product ratings....................................................................................................................3
2 Installation guidance ..................................................................................................................5
2.1 Wiring and terminal instruction of main circuit......................................................................5
2.1.1 Wiring diagram of the main circuit..............................................................................5
2.1.2 Terminal diagram of the main circuit ..........................................................................5
2.2 Wiring and terminal instruction of control circuit...................................................................7
2.2.1 Control circuit layout diagram....................................................................................7
2.2.2 Wiring diagram of control circuit.................................................................................9
2.2.3 User terminal instruction of control circuit...................................................................9
3 Instruction for panel display .................................................................................................... 11
4 Commissioning guidelines.......................................................................................................12
4.1 Wiring diagram of integrated machine system ...................................................................12
4.2 Recommended wiring process ..........................................................................................12
4.3 Function commissioning procedure...................................................................................15
5 Function description.................................................................................................................23
5.1 Function code instruction ..................................................................................................23
5.2 Air compressor control logic ..............................................................................................61
5.3 PID commissioning ...........................................................................................................63
5.3.1 General procedures for PID parameter setup ..........................................................64
5.3.2 How to fine-tune PID...............................................................................................65
5.4 Running logic of blower oil pump.......................................................................................69
6 Troubleshooting........................................................................................................................70
6.1 Faults and countermeasures for integrated machine..........................................................70
6.2 Faults and countermeasures for air compressor device.....................................................74
Appendix A Product dimension ..................................................................................................77
A.1 Wall-mounting dimensions................................................................................................77
A.2 Floor-mounting dimensions (with top cover)......................................................................78
A.3 Floor-mounting dimension (without top cover)...................................................................79
A.4 Product weight and packaging dimension .........................................................................79
Appendix B Optional parts..........................................................................................................81
B.1 Contactor component .......................................................................................................81
B.1.1 Unpacking inspection..............................................................................................81

Goodrive300-21 integrated machine for air compressor Contents
iii
B.1.2 Electrical wiring.......................................................................................................81
B.1.3 Fuse pedestal installation........................................................................................82
B.1.4 Dimension of contactor component.........................................................................83
B.2 IoT module .......................................................................................................................84
B.2.1 Product overview....................................................................................................84
B.2.2 Specifications .........................................................................................................88
B.2.3 Operation guide......................................................................................................89
B.2.4 Ordering information...............................................................................................89
B.3 Drip-proof top cover..........................................................................................................89
B.3.1 Installation of drip-proof top cover ...........................................................................90
B.4 Floor installation pedestal .................................................................................................91
B.4.1 Package list............................................................................................................91
B.4.2 Installation diagram of the pedestal.........................................................................91
B.4.3 Installation diagram of optional pedestal..................................................................92
B.4.4 Floor wiring process................................................................................................93
B.5 TC070A touch screen .......................................................................................................93
B.5.1 Product specifications.............................................................................................93
B.5.2 Connection terminals ..............................................................................................95
B.5.3 Wiring description...................................................................................................96
B.5.4 Cable description....................................................................................................97
B.5.5 Installation dimensions and description ...................................................................98
Appendix C Communication protocol ......................................................................................100
C.1 Application of Modbus.....................................................................................................100
C.1.1 RS485..................................................................................................................100
C.2 RTU command codes and communication data..............................................................100
C.2.1 Command code 03H, reading N words (continuously up to 16 words) ...................100
C.2.2 Command code 06H, writing a word .....................................................................100
C.2.3 Command code 08H, diagnosis............................................................................101
C.2.4 Command code 10H, continuous writing...............................................................101
C.2.5 Data address definition.........................................................................................101
C.2.6 Error messages....................................................................................................105
Appendix D Common EMC problems and solution..................................................................107
D.1 Interference problems of meter switch and sensors.........................................................107
D.2 Interference on RS485 communication...........................................................................107
D.3 Failure to stop and indicator shimmering due to motor cable coupling.............................108
D.4 Leakage current and interference on RCD......................................................................109
D.5 Live device chassis......................................................................................................... 110

Goodrive300-21 integrated machine for air compressor Product overview
-1-
1 Product overview
GD300-21 air compressor integrated machine is capable of providing dual inverter output of master
and fan for the air compressor as well as offering +24V power to the touch screen. It supports control
of solenoid valve and receiving of temperature and pressure signal. In respect of function, it is a
perfect replacement for the original dual inverter electrical control cabinet of air compressor but with a
much smaller size and simpler installation and debugging procedures.
1.1 Product specifications
Category
Function
Specifications
Power input
Input voltage of inverter
(V)
3PH 220V(-15%)–240V(+10%)
3PH 380V(-15%)–440V(+10%)
Rated input current (A)
See 1.4 Product ratings.
Rated input frequency (Hz)
50Hz or 60Hz; Allowed range: 47–63Hz
Efficiency
> 97%
Power factor
0.9
Power output
of main
inverter
Output voltage (V)
Equal to the input voltage, with the deviation less than
5%.
Rated output current (A)
See 1.4 Product ratings.
Rating output power (kW)
See 1.4 Product ratings.
Output frequency (Hz)
0–400Hz
Power output
of fan inverter
Output voltage (V)
Equal to the input voltage, with the deviation less than
5%.
Rated output current (A)
See 1.4 Product ratings.
Rating output power (kW)
See 1.4 Product ratings.
Output frequency (Hz)
0–50Hz
Other power
output
+24VDC power
24W
220VAC/110VAC
30W
Running
control
performance
Control mode
Open loop vector, space voltage vector
Speed ratio
Asynchronous motor (AM): 1:200 (Sensorless vector
control), synchronous motor (SM): 1:20 (Sensorless
vector control)
Speed control accuracy
±0.2% (Sensorless vector control)
Speed fluctuation
±0.3% (SVC)
Torque response
<20ms (Sensorless vector control)
Starting torque
For AMs: 0.25Hz150% (Sensorless vector control)
For SMs: 2.5Hz150% (Sensorless vector control)
Overload capacity
Master inverter: 150%/1m
Fan inverter: 120%/1m

Goodrive300-21 integrated machine for air compressor Product overview
-2-
Category
Function
Specifications
Specialized function
Sleep and wake-up function, constant pressure
control, constant temperature control, accessory
maintenance and phase sequence inspection
Analog input of pressure
Two 4–20mA/0–1.6MPa inputs
Analog input of
temperature
Two temperature analog inputs; resolution rate: 1°C,
range: -20°C–150°C
Digital input
Three regular inputs; max. frequency: 1kHz
Digital output
One Y terminal output, two relay outputs (NO)
250VAC/3A
Fault protection
More than 30 protection functions, such as protection
against overcurrent, overvoltage, undervoltage,
overtemperature, phase loss, and overload
Communication 485
One 485 communication (two terminal interfaces)
Other
Installation method
Supports wall-mounting and floor-mounting
Temperature of running
environment
-10°C –+50°C; Derating is required if the ambient
temperature exceeds 40°C. Derate 1% for each
additional 1°C.
Ingress protection (IP)
rating
IP20
Cooling method
Forced air cooling
DC reactor
Standard
EMC filter
Optional external filters can be used to meet the
IEC61800-3 C2 requirements.
Note: When the voltage of the integrated machine is above 440VAC, the power frequency
transformer inside the integrated machine needs to be customized as needed.
1.2 Product nameplate
IP20
Model:GD300-21-022G-4
Power(Output):22kW(motor) 1kW(fan)
Input:AC 3PH 380V(-15%)-440V(+10%) 45A 47Hz-63Hz
Output:AC 3PH 0V-Uinput 45A 0Hz-400Hz(motor)
AC 3PH 0V-Uinput 3A 0Hz-50Hz(fan)
S/N: MADE IN CHINA
Shenzhen INVT Electric Co.,Ltd
Figure 1-1 Product nameplate

Goodrive300-21 integrated machine for air compressor Product overview
-3-
Note: The preceding are standard product nameplate examples. The CE/TUV/IP20 marking on the
top right will be marked according to actual certification conditions.
1.3 Model instruction
A model designation code contains product information. You can find the model designation code on
the inverter nameplate and simplified nameplate.
GD300-21 –022 G - 4
① ② ③ ④
Figure 1-2 Product model
Field
Sign
Description
Content
Product series
abbreviation
①
Product series
abbreviation
GD300-21: GD300-21 series dual inverter integrated
machine for air compressor
Rated power
②
Power class
022: 22kW
Load type
③
Load type
G: Constant torque load
Voltage class
④
Voltage class
2: AC 3PH 220V (-15%)–240V (+10%)
4: AC 3PH 380V (-15%)–440V (+10%)
1.4 Product ratings
Model
Rated input current
of the integrated
machine (A)
Main motor inverter
Fan inverter
Rating
output
power (kW)
Rated
output
current (A)
Rating
output
power (kW)
Rated
output
current (A)
GD300-21-7R5G-2
35
7.5
30
1
4.2
GD300-21-011G-2
48
11
42
1
4.2
GD300-21-015G-2
60
15
55
1
4.2
GD300-21-018G-2
75
18.5
70
1
4.2
GD300-21-022G-2
90
22
80
1.5
7.5
GD300-21-030G-2
120
30
110
1.5
7.5
GD300-21-037G-2
145
37
130
1.5
7.5
GD300-21-045G-2
175
45
160
3
11
GD300-21-015G-4
33
15
32
1
3
GD300-21-018G-4
38
18.5
38
1
3
GD300-21-022G-4
45
22
45
1
3
GD300-21-030G-4
60
30
60
1.5
3.7
GD300-21-037G-4
75
37
75
1.5
3.7
GD300-21-045G-4
93
45
92
3
6.8
GD300-21-055G-4
112
55
115
3
6.8

Goodrive300-21 integrated machine for air compressor Product overview
-4-
Model
Rated input current
of the integrated
machine (A)
Main motor inverter
Fan inverter
Rating
output
power (kW)
Rated
output
current (A)
Rating
output
power (kW)
Rated
output
current (A)
GD300-21-075G-4
146
75
150
3
6.8
GD300-21-090G-4
175
90
180
4
9.5
Note:
The rated input current of 15–90kW integrated machine is the actual result gained under 380V
input voltage.
The rated output current is the output current when the output voltage is 380V.

Goodrive300-21 integrated machine for air compressor Installation guidance
-5-
2 Installation guidance
2.1 Wiring and terminal instruction of main circuit
2.1.1 Wiring diagram of the main circuit
R
S
T
U1
V1
W1
U2
V2
W2
Goodrive300-21
Master
Fan
Figure 2-1 Wiring diagram of the main circuit
2.1.2 Terminal diagram of the main circuit
The terminal layout of 15–22kW, 30kW–37kW and 45–90kW main circuit slightly differs from each
other. In below figure, 15–22kW and 45–90kW models are taken as examples for terminal layout.
Figure 2-2AC380V 15–22kW

Goodrive300-21 integrated machine for air compressor Installation guidance
-6-
Figure 2-3AC380V 45–90kW
Table 2-1 Terminal instruction
Symbol
Description
UA, UB, UC
Used for input connection of optional contactor components.
R, S, T
3PH AC input terminals, connecting to the grid
U1, V1, W1
3PH AC output terminal, connected to main motor of air compressor
U2, V2, W2
3PH AC output terminal, connected to the fan
Grounding terminal of safety protection, each machine must be
grounded.
Note:
1. Do not use asymmetrical motor cables. Do not use asymmetrically constructed motor cable. If
there is a symmetrically constructed ground conductor in the motor cable in addition to the
conductive shielding layer, ground the ground conductor at the inverter end and motor end.
2. Route the motor cable, input power cable and control cable separately.
3. Before powering on the system, ensure that U1/V1/W1 or U2/V2/W2 are not short-circuited to PE
on the output side. Otherwise, tripping may occur on the power distribution cabinet when the
system is being powered on.

Goodrive300-21 integrated machine for air compressor Installation guidance
-7-
2.2 Wiring and terminal instruction of control circuit
2.2.1 Control circuit layout diagram
TA1
TC1
TA2
TC2
P1+
P1-
P2+
P2-
PTA1 PTB1 PTA2 PTB2
S1 S2 S3 S4 S5 Y1
COM
+24V
GND
485+
485-
Goodrive300-21 control board
34PIN 26PIN
3 1
CN9 CN1 CN2
CN17
CN7
CN8
CN10 CN11 CN12 CN13 CN14
CN15
F1
CN6
J7
J8
COM
+24V
GND
485+
485-
+24V
GND
SW1
+24V
COM J5
485 ON
PE
CGND
PE
CN14-5
GND
ON
J9
J6
VI
I V
PE/CGND
Figure 2-4 Control circuit layout diagram
Table 2-2 Terminal instruction
Symbol
Name
Remarks
CN1
Flat cable interface
Connected to drive board, master control signal wire
CN17
Power interface
Outputs +24V power, can be used to power up external
GPRS.
CN2
Flat cable interface
Connected to drive board, fan control signal wire
CN6
Keypad interface
Reserved interface, connected with keypad
CN14
Touch screen interface
Connected to touch screen, provide +24V power and 485
communication interface
CN13
Digital input terminal
Multi-function input terminal
CN12
Temperature detection
terminal
Connected to PT100 temperature sensor
CN11
Pressure detection
terminal
Connected to pressure sensor
CN10
Relay output terminal
Connected to solenoid valve or contactor coil
F1
Fuse (0.6A/250VAC)
Protection against short circuit of solenoid valve/contactor
coil terminal or overcurrent
CN9
220V/110V voltage input
terminal
Connected to internal power frequency transformer
CN7
220V voltage selection
terminal
Select this terminal with jumpers when users select the
solenoid valve with 220V coil or the contactor.
Note: The default selection is 220V voltage terminal.

Goodrive300-21 integrated machine for air compressor Installation guidance
-8-
Symbol
Name
Remarks
CN8
110V voltage selection
terminal
Select this terminal with jumpers when users select the
solenoid valve with 110V coil or the contactor.
J5
Access terminal for 485
communication terminal
resistor
485 corresponds to access terminal resistor. Does not
connect terminal resistor by default.
J6
Short-circuit terminal of
PE and GND
ON corresponds to short-circuit. No short circuit by default
J7
Jumper terminal
Corresponds to P1+, P1- pressure analog signal selection. I
corresponds to current signal, V to voltage signal. The
default is current input signal.
J8
Jumper terminal
Corresponds to P2+, P2- pressure analog signal selection. I
corresponds to current signal, V to voltage signal. The
default is current input signal.
J9
PE/CGND selection
terminal
485 communication is non-isolation mode. CN14-5 is short
circuited with PE by default.
SW1
DIP switch
Set to +24V terminal by default. See details at Figure 2-5
and Figure 2-6.
●
●
●
COM
+24V
PW
COM
+24V •
•
S1
S2
•
SW1
COM
+24V
PW
COM
+24V •
•
S1
S2
•
●
●
●
+24V
SW1
Figure 2-5 Internal power (NPN mode)
Figure 2-6 External power (PNP mode)
When digital input adopts internal +24V, set the toggle switch according to Figure 2-5 and short circuit
+24V with PW. When digital input adopts external +24V, set the toggle switch according to Figure 2-6
and short circuit COM with PW.

Goodrive300-21 integrated machine for air compressor Installation guidance
-9-
2.2.2 Wiring diagram of control circuit
TA1 TC1 TA2 TC2
P1+ P1- P2+ P2-
PTA1 PTB1 PTA2 PTB2
S1 S2 S3 S4 S5 Y1
COM
Solenoid
valve
+24V
GND
485+ 485-
PE\CGND
GD300-21 control board
+24V
GND
485A+ 485A-
PE
485C+ 485C-
HMIHMI
+24V
GND
485A+ 485A-
PE
485C+ 485C- 485B- 485B+
PE
RS485 joint control
Y1: Fault output signal
Oil gas temp.
Pressure sensor
interface
24V 4-20mA
PT100 temperature
sensor interface Multi-function terminal
Output voltage
220/110VAC
coil Contactor
coil Exhaust
pressure Auxiliary
pressure S1：E-stop signal (NC)
S2-S5: Customized input
Auxiliary
temp.
+24V
GND
13 CN17
COM
485B- 485B+
PE
GD300-21
control board RS485
J1
485+ 485-
+24V
GND
485A-
GND
+5V
485A+
J2
(Optional)
Remote data collection terminal
Figure 2-7 Wiring diagram of control circuit
Note: The solid line represents the recommended wiring diagram which carries the least wiring for
ensuring system operation. The dotted line represents the wiring diagram used when discrepancy
occurred to the configuration of integrated machine.
2.2.3 User terminal instruction of control circuit
Table 2-1 User terminal instruction of control circuit
Category
Symbol
Terminal name
Description
Power supply
+24V
+24V power
supply
Used to externally provide +24V±5% power
supply, max. output current: 1A
Used for powering up GPRS, touch screen
module
GND
+24V power
GND
Reference ground of the +24V power supply
PT100
signal input
PTA1
Temperature
analog signal 1
1. Resolution rate: 1°C
2. Range: -20°C–150°C
3. Detection precision: 3°C
PTB1
PTA2
Temperature
analog signal 2
PTB2
Pressure signal
P1+
Pressure
1. Input range: Current and voltage is optional,

Goodrive300-21 integrated machine for air compressor Installation guidance
-10-
Category
Symbol
Terminal name
Description
input
P1-
analog signal 1
4–20mA/2–10V corresponds to 0–1.6MPa;
P1 is switched by jumper J7 while P2 by J8
2. Input impedance: 20kΩ for voltage input;
500Ω for current input
3. Resolution rate: min. 5mV
4. Error: ±1%, 25°C
P2+
Pressure
analog signal 2
P2-
Digital input
S1
Digital input 1
1. Internal impedance: 3.3kΩ
2. 12–30V voltage input is acceptable
3. Max. input frequency: 1kHz
S2
Digital input 2
S3
Digital input 3
S4
Digital input 4
S5
Digital input 5
COM
Digital
reference GND
Digital output
Y1
Digital output
1. Switch capacity: 50mA/30V
2. Output frequency range: 0–1kHz
Communication
485+, 485-
RS485
communication
RS485 communication terminals, using the
Modbus RTU protocol
PE/CGND
PE/CGND
PE: When select PE by J9, it can be used in
connection terminal of 485 communication
shielded cable;
CGND: When select CGND by J10, it can be
used in connection terminal of 485
communication reference GND or shielded cable.
Solenoid valve
TA1
Solenoid valve
coil
1. Contact capacity: 3A/AC250V, 1A/DC30V
2. Cannot used as high frequency switch output
3. Voltage of power supply: 220V/110V, select
via CN7/CN8
4. Max. output power of internal power
frequency transformer: 30W
TC1
TA2
Contactor coil
TC2
Note: The connection terminal of solenoid valve/contactor cannot be connected to other load. When
the power of solenoid valve and contactor coil exceeds 30W, the power frequency transformer inside
the integrated machine needs to be customized or connected with external 220V power
independently.

Goodrive300-21 integrated machine for air compressor Instruction for panel display
-11-
3 Instruction for panel display
The panel of GD300-21 series air compressor integrated machine carries three LED indicators (fault,
running, power). The position and display state of the indicators are illustrated as below:
Fault
Run
Power
Figure 3-1 Diagram of indicator position
Display state of indicators
State instruction
Power indicator
(green)
ON
Bus voltage is normal
Blinking
Bus voltage is abnormal
Running indicator
(green)
ON
Run
OFF
Stop
Fault indicator
(read)
ON
Fault
OFF
Normal running

Goodrive300-21 integrated machine for air compressor Commissioning guidelines
-12-
4 Commissioning guidelines
4.1 Wiring diagram of integrated machine system
M
TA1 TC1
P1+ P1-
P2+
P2-
PTA1 PTB1
PTA2
PTB2
S1 S2 S3 S4 S5
Y1
COM
Pressure sensor
interface PT100 temp. sensor
interface Multi-function
terminal
Output voltage
220/110VAC
COM
24V 4-20mA
E-stop
signal Internal fault
signal output
Customized
RSTU1 V1 W1
UA UB UC
+24V
GND
485+ 485-
PE\CGND
PE
485A- 485A+
GND
+24V
485C+ 485C-
input
485B+
485B-
PE
PE
485A- 485A+
GND
+24V
485C- 485C+
PE
485- 485+
GND
+24V
GD300-21
GD300-21 HMI HMI
Solenoid valve
coil Contactor coil
(optional)
TA2 TC2
Exhaust
pressure Auxillary
pressure Oil gas temp. Auxillary temp.
GND
+24V
31
CN17
PT100 PT100
AC input power
3
Motor shell grounding
RSTPE
Main motor
M
3
Motor shell grounding
Fan
POWER
MOTOR
METER
U2 V2 W2
RS485 joint control
RS485
Interface for optional parts
+24V
GND
485-
485+
Remote data collection
terminal (optional)
+5V
GND
485A-
485A+
J1 J2
CN15
+24V
GND
485+
485-
Interfaces for
optional
parts
Figure 4-1 Wiring diagram of integrated machine system
Note: The solid line represents the recommended wiring diagram which carries the least wiring for
ensuring system operation. The dotted line represents the wiring diagram used when discrepancy
occurred to the configuration of integrated machine.
4.2 Recommended wiring process
The terminal layout of 15–22kW, 30kW–37kW and 45–90kW slightly differs from each other. 15–
22kW and 45–90kW are taken as examples for wall-mounting wiring.

Goodrive300-21 integrated machine for air compressor Commissioning guidelines
-13-
AC power Main motor
R, S, T, ground wire through hole U1, V1, W1, ground wire through hole
Through-hole of controlling cable
Fan
U2, V2, W2, ground wire through hole
Through-hole of
optional parts cable
Through-hole of
controlling cable
Ventilation hole at the bottom of
integrated machine
Figure 4-2 Bottom view for 15–22kW
Controlling cableControlling
cable
Controlling cable Controlling cable
AC power cable Main motor
cable Fan cable
Data collection
terminal
shielded cable
grounding
Figure 4-3 Front wiring diagram for 15–22kW

Goodrive300-21 integrated machine for air compressor Commissioning guidelines
-14-
AC power
R, S, T through
hole
Main motor
U1, V1, W1 through
hole
Through hole of
controlling cable
Through hole of
optional parts
cable
Through hole of
controlling cable
Fan
U2, V2, W2, ground wire
through hole
Ground wire
through hole
Through hole of
ground wire Ventilation hole at the
bottome of the integrated
machine
Figure 4-4 Bottom view for 45–90kW
Figure 4-5 Front wiring diagram for 45–90kW

Goodrive300-21 integrated machine for air compressor Commissioning guidelines
-15-
Note:
1. There are two controlling cable through holes on the top and at the bottom of the integrated
machine cabinet, users can select which through-hole to use based on wiring condition. It is
recommended that the controlling cable is routed via top through-hole to realize separation
between controlling cable and motor cable and reduce interference. The motor temperature
detection or temperature protection cable which follows the motor power cable can be routed via
bottom through-hole.
2. Refer to B.4.3 Installation diagram of optional pedestal for floor installation layout.
4.3 Function commissioning procedure
It is recommended that GD300-21 air compressor integrated machine adopt touch screen for
displaying and commissioning. The concrete procedures are listed as follows: (if other controllers are
used, contact our technician)
1. Conduct wiring and routing according to “4.1 Wiring diagram of integrated machine system” and
“4.2 Recommended wiring process“; check carefully if the wiring is correct and ensure the
integrated machine and its shell GND is properly connected.
2. After power on, the touch screen HMI interface is shown as follows:
Figure 4-6 Login interface

Goodrive300-21 integrated machine for air compressor Commissioning guidelines
-16-
3. Click "Enter" to enter the working environment interface, as shown in the following figure:
Figure 4-7 Working interface
4. Click "MENU" in above interface and the interface is as follows:
Figure 4-8 Menu interface
