IOTA I-4PT-A User manual

IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. CAUTION – To prevent electrical shock, do not mate unit connector until installation is complete and A.C.
power is supplied to the unit.
2. CAUTION – This fixture provides more than one power supply output source. To reduce the risk of electrical
shock, disconnect both normal and emergency sources by turning off the A.C. branch circuit and by discon-
necting the unit connector.
3. CAUTION – This is a sealed unit. The integral, high temperature Ni-Cad battery is not replaceable. Replace
the entire unit when necessary and dispose of the nickel-cadmium battery properly.
4. DO NOT USE OUTDOORS. The I-4PT-A is for use with grounded, UL Listed, damp location rated, indoor
fixtures. Not for use in heated air outlets or hazardous locations.
5. The I-4PT-A requires an unswitched A.C. power source of 120 to 277 volts.
6. When the I-4PT-A is installed on the same branch circuit, refer to Illustration 2, Figures A and B for input wir-
ing. When installed on a separate branch circuit, refer to Illustration 2, Figures C and D for input wiring. Per
NEC, the I-4PT-A and A.C. ballast must be on the same panel board.
7. Do not mount near gas or electric heaters.
8. The I-4PT-A should be mounted in locations and at heights where it will not readily be subjected to tampering
by unauthorized personnel.
9. The I-4PT-A will operate one 13W through 42W 4-pin LED CFL replacement lamp for 90 minutes. Contact
Customer Service for additional lamp usage.
10. The I-4PT-A is compatible with most electronic A.C. ballasts (including multiple lamps) as follows:
Electronic ballasts – one lamp emergency operation.
11. The I-4PT-A meets CA T20 Battery Charger Efficiency Standards and is certified in the CA Title 20
Modernized Appliance Efficiency Database System (MAEDBS) as a Small Battery Charger.
12. Suitable for use in damp locations.
13. For use in 0° C minimum, 55° C maximum ambient temperatures.
14. The use of accessory equipment or lamps not recommended by the manufacturer may cause an unsafe
condition, will void warranty, and will result in non-compliance with UL specifications.
15. Do not use this equipment for other than intended use.
16. Install in accordance with the National Electrical Code and local regulations.
17. Installation and servicing should be performed by qualified personnel.
18. Lighting fixture manufacturers, electricians and end users need to ensure product system compatibility before
final installation.
SAVE THESE INSTRUCTIONS
INSTRUCTION MANUAL
I-4PT-A
EMERGENCY LIGHTING EQUIPMENT
FOR 13W - 42W 4-PIN
LED REPLACEMENT LAMPS
P.O. BOX 11846 TUCSON, AZ 85734
[phone] • FAX [phone]
www.iotaengineering.com
MEETS CA T20
BATTERY CHARGER
EFFICIENCY STANDARDS

Page 2
INSTALLATION INSTRUCTIONS
CAUTION: Before installing, make certain the A.C. power is off and the I-4PT-A unit connector is disconnected.
1. LAMPS OPERATED
The I-4PT-A will operate one 13W - 42W LED CFL replacement lamp in emergency mode. Contact IOTA Custom-
er Service for a list of lamps that are qualified for operation in emergency mode.
2. MOUNTING THE I-4PT-A
When used with ceiling mounted downlight fixtures, the I-4PT-A should be mounted on the fixture above the ceil-
ing. The flex conduit marked “A” should be wired into the ballast/lamp compartment or to an electrical junction box
on the fixture which allows access to the ballast/lamp connections. Refer to Illustration 1 for typical mounting.
When battery packs are remote mounted, consult Customer Service for the maximum allowable distance between
the battery pack and the lamp.
3. MOUNTING THE THREADED BODY TEST SWITCH (TBTS)
Cut a single gang switch box into the ceiling tile adjacent to the fixture within reach of the I-4PT-A flex
marked “B”. After mounting the switch box, connect flex “B” to the box and route all leads inside the box. Refer to
Illustration 1 for typical mounting.
Illustration 1 Downlight Fixture
FLEX “A”
JUNCTION
BOX
CEILING
TILE
A.C. BALLAST &
LAMP SOCKET COMPARTMENT
FLEX “B”
SWITCH BOX
TEST SWITCH
CHARGE LIGHT
I-4PT-A
TBTS
ENSURE WIRING IS IN ACCORDANCE WITH THE NATIONAL ELECTRICAL CODE AND LOCAL REGULATIONS.
4. WIRING
A. When the I-4PT-A is installed on the same branch circuit, refer to Illustration 2, Figures A and B for
input wiring. When installed on separate branch circuits, refer to Illustration 2, Figures C and D for input wiring.
Per NEC, the I-4PT-A and A.C. ballast must be on the same panel board.
B. The I-4PT-A requires an unswitched A.C. power source of 120 to 277 volts; therefore, when
used with switched fixtures, the I-4PT-A input must be wired ahead of the switch. Refer to Illustration 2
for switched and unswitched fixture wiring diagrams.
C. Refer to the wiring diagrams on the back page for the proper wiring. For wiring diagrams of ballasts not shown,
consult our Customer Service.
5. LABELS
Attach the appropriate labels adjacent to the TBTS. Annotate Re-lamping label for lamp manufacturer and part
number. The Caution and the Re-lamping labels must be on the fixture in a readily visible location to anyone at-
tempting to service the fixture.
6. COMPLETING INSTALLATION
When the installation is complete, switch the A.C. power on and join the I-4PT-A unit connector.

Page 3
OPERATION
General – This unit is primarily designed to be used with compact fluorescent lamp downlight fixtures. It will wire in
conjunction with the existing A.C. ballast(s) and LED CFL Replacement lamp(s) to provide the emergency function. It can
also be wired for emergency only operation. The TBTS light is offered for installation in a standard single gang switch box
adjacent to the fixture.
Normal Mode – A.C. power is present. The A.C. ballast operates the LED CFL Replacement lamp(s) as intended. The
I-4PT-A is in the standby charging mode. The TBTS will be lit providing a visual indication that the battery is being
charged.
Emergency Mode – The A.C. power fails. The I-4PT-A senses the A.C. power failure and automatically switches to the
Emergency Mode. One lamp is illuminated, at reduced output, for a minimum of 90 minutes. When the A.C. power is
restored, the I-4PT-A switches the system back to the Normal Mode and resumes battery charging. See page 1 of the
Instruction Manual.
TESTING & MAINTENANCE
Pressing the TBTS turns off the light on the TBTS and forces the unit into emergency mode, interrupting power to the
designated A.C. ballast. The emergency lamp is now being lit by the I-4PT-A unit. After releasing the TBTS, the fixture
returns to normal operation after a momentary delay.
Initial Testing – Allow the unit to charge approximately 1 hour, then conduct a short discharge test by depressing the
TBTS. The TBTS will go out and the LED CFL Replacement lamp will be illuminated. Allow a 24 hour charge before
conducting a one hour test.
The I-4PT-A is a maintenance free unit, however, periodic inspection and testing is required. NFPA 101, Life Safety
Code, outlines the following schedule:
Monthly – Insure that the TBTS light is illuminated. Conduct a 30 second discharge test by depressing the TBTS. One
lamp should operate at reduced output.
Annually – Insure that the TBTS light is illuminated. Conduct a full 1½ hour discharge test. The unit should operate as
intended for the duration of the test.
“Written records of testing shall be kept by the owner for inspection by the authority having jurisdiction.”
SERVICING SHOULD BE PERFORMED BY QUALIFIED PERSONNEL.
Consult Customer Service or visit www.iotaengineering.com for current warranty information.
Illustration 2
(120-277V) BLK/ORG(120-277V) BLK/ORG
A.C. BALLAST
HOT A.C. LINE
WHITE
BLACK
COMMON
WHT/REDWHT
(+) RED/BLK(+) RED
TBTS
WHITE
A.C. BALLAST
HOT A.C. LINE
WHITE
BLACK
COMMON
WHT/REDWHT
(+) RED/BLK(+) RED
TBTS
BLK/WHT
WHITE
WALL SWITCH
BLK/WHT
No polarity on BLK/WHT Lead. Use either lead for
connection to the AC circuit and ballast
No polarity on BLK/ORG Lead. Use either lead for
connection to the AC circuit and ballast
BLK/WHT
BLK/WHT
I-4PT-A
SEPARATE
BRANCH
CIRCUIT:
B. Unswitched Fixture
C. Switched Fixture D. Unswitched Fixture
A. Switched Fixture
SAME
BRANCH
CIRCUIT:
1
I-4PT-A
A.C. BALLAST
HOT A.C. LINE
WHITE
BLACK
(120-277V) BLK/ORG
COMMON
WHT/REDWHT
(+) RED/BLK(+) RED
TBTS
BLK/WHT
WHITE
WALL SWITCH
BLK/WHT
EM CIRCUIT HOT
A.C. BALLAST
HOT A.C. LINE
WHITE
BLACK
120-277V) BLK/ORG
COMMON
WHT/REDWHT
(+) RED/BLK(+) RED
TBTS
WHITE
BLK/WHT
BLK/WHT
EM CIRCUIT HOT
No polarity on BLK/ORG Lead. Use either lead for
connection to the AC circuit and ballast
No polarity on BLK/ORG Lead. Use either lead for
connection to the AC circuit and ballast
I-4PT-A I-4PT-A
No polarity on
BLK/WHT Lead.
Use either lead for
connection to the
A.C. circuit and
ballast.
1No polarity on
BLK/WHT Lead.
Use either lead for
connection to the
A.C. circuit and
ballast.

Page 4
BLUE
BLUE
RED
RED
BLK/ORG (120-277V)
WHITE
BLK/WHT
BLUE
BLU/WHT
RED
ONE LAMP
A.C.
BALLAST
FLEX A FLEX B
RED/BLK(+)
WHT/RED TBTS
UNIT CONNECTOR
MATE UNIT CONNECTOR AFTER INSTALLATION
IS COMPLETE AND A.C. POWER IS SUPPLIED.
UNSWITCHED
LINE
COMMON
SWITCHED OR
UNSWITCHED
LINE
WHITE
BLACK
LAMP
EMERGENCY
BALLAST
1LRSB_4PT
ONE LAMP RAPID START BALLAST
BLK/WHT
RED/WHT
YELLOW
COMMON
TEST ACCESSORY LEAD - REFER TO INSTALLATION
INSTRUCTIONS FOR PROPER POLARITY WIRING.
NO POLARITY ON BLK/WHT LEADS - USE EITHER LEAD
FOR CONNECTION TO THE AC CIRCUIT AND BALLAST.
ATTENTION: DO NOT MATE UNIT CONNECTOR UNTIL
INSTALLATION IS COMPLETE AND A.C. POWER IS SUPPLIED
1
1
1
2
3
2
3
TYPICAL WIRING DIAGRAMS
Use in conjunction with Rapid Start ballasts and 4 pin LED CFL Replacement lamps only
Rev. 1901
68C42-109
1. ONE LAMP RAPID START BALLAST
2. TWO LAMP RAPID START BALLAST WITH ONE LAMP EMERGENCY OPERATION
BLK/ORG (120-277V)
WHITE
BLK/WHT FLEX A FLEX B
RED/BLK(+)
WHT/RED TBTS
UNIT CONNECTOR
MATE UNIT CONNECTOR AFTER INSTA LLATION
IS COMPLETE AND A.C. POWER IS SUPPLIED.
UNSWITCHED
LINE
COMMON
SWITCHED OR
UNSWITCHED
LINE
WHITE
BLACK
EMERGENCY
BALLAST
2LRSB_4PT
TWO LAMP RAPID START BALLAST
BLK/WHT
COMMON
TEST ACCESSORY LEAD - REFER TO INSTALLATION
INSTRUCTIONS FOR PROPER POLARITY WIRING.
NO POLARITY ON BLK/WHT LEADS - USE EITHER LEAD
FOR CONNECTION TO THE AC CIRCUIT AND BALLAST.
ATTENTION: DO NOT MATE UNIT CONNECTOR UNTIL
INSTALLATION IS COMPLETE AND A.C. POWER IS SUPPLIED
1
1
1
2
3
2
3
BLUE
BLUE
RED
RED
BLUE
BLU/WHT
RED
*LAMP
RED/WHT
YELLOW
LAMP
YELLOW
YELLOW
*A.C./EMERGENCY LAMP
TWO LAMP
A.C.
BALLAST
I-4PT-A
I-4PT-A
Wiring and Troubleshooting Tips are available on-line at http://www.iotaengineering.com/wiringtips.pdf

Rev. 1901
68C42-109
Addendum Insert
I-4PT Lamp Compatibility Addendum (Rev.112818)
Refer to the table below for UL Listed lamps that have been tested and verified compatible with the I-4PT-A
I-4PT-A Table: Operable Lamps
Lamp Manufacturer
GE
GE
GE
GE
GE
GE
Green Creative
Green Creative
Green Creative
Green Creative
Green Creative
Green Creative
Green Creative
Green Creative
Keystone
Keystone
Maxlite
Maxlite
Philips
Philips
Philips
Satco
Satco
Satco
Satco
Sylvania
Sylvania
Model
LED9G24Q-H/835
LED9G24Q-V/840
LED12G24Q-H/835
LED12G24Q-V/830
LED19GX24Q-H/827
LED19GX24Q-V/830
5.5PLH/840/DIR/R
6PLV/840/DIR
8.5PLH/840/DIR
9.5PLH/840/DIR
9.5PLV/840/DIR
10PLV/840/DIR
10.5PLH/930/DIR
11PLV/930/DIR
KT-LED94P-H-840-S
KT-LED94P-V-840-S
12PLG24QHLED40
11PLG24QVLED40
8.5PL-C/T LED/26H-4000 IF 4P
10.5PL-C/T LED/26V-4000 IF 4P
12PLC/T LED/32H/830/IF/4P/DIM
9WPLH/LED/840/DR/4P
9WPLV/LED/840/DR/4P
13W/V/LED/CFL/840/4P
13W/VL/LED/CFL/840/4P
LED9PBGX24QH841
LED9PBGX24QV841
Lumens*
217
249
278
250
409
444
248
241
274
304
268
274
255
201
323
300
395
330
251
300
235
432
374
355
344
323
276
Max. Height**
13 ft
13 ft
15 ft
13 ft
15 ft
17 ft
11 ft
11 ft
11 ft
12 ft
12 ft
13 ft
11 ft
10 ft
12 ft
12 ft
14 ft
14 ft
11 ft
11 ft
11 ft
14 ft
11 ft
12 ft
13 ft
12 ft
10 ft
**Heights based on 1 FC delivery
*Lumen performance based on bare lamp operation
