IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS
1. CAUTION – The battery used in this device may present a risk of fire or chemical burn if mistreated. Do not
disassemble, heat above 60°C(140°F), or incinerate. Only install the provided battery and don’t attempt re-
placement. Use of another battery may present a risk of fire or explosion.
2. CAUTION – This fixture provides more than one power supply output source. To reduce the risk of electrical
shock, disconnect both normal and emergency sources by turning off the A.C. branch circuit and by discon-
necting the battery unit connector.
3. CAUTION – Installation and servicing should be performed by qualified personnel only. De-energize before
opening. Not for field installation. Factory install only.
4. Do not join the battery unit connector until installation is complete. If AC voltage is supplied to the unit with the
unit connector open, the IPS Test Switch will start blinking after 10 seconds. This indicates that either the bat-
tery is disconnected or the unit connector is open.
5. The ILB CP18 HE CW LP64 is for use with grounded LED luminaires listed to UL standards. Not for use in
heated air outlets or hazardous locations.
6. The ILB CP18 HE CW LP64 requires an unswitched A.C. power source of 120 to 277 volts AC, 50/60Hz.
7. The ILB CP18 HE CW LP64 and A.C. driver must be on the same branch circuit.
8. Do not mount near gas or electric heaters.
9. The ILB CP18 HE CW LP64 should be mounted in locations and at heights where it will not readily be sub-
jected to tampering by unauthorized personnel.
10. The ILB CP18 HE CW LP64 will supply 20-58 VDC output at 18 Watts for 90 minutes.
11. The ILB CP18 HE CW LP64 is certified in the CA Title 20 Modernized Appliance Efficiency Database System
(MAEDBS) as a small battery charger.
12. Suitable for use in damp locations and enclosed and gasketed fixtures if proper ventilation method is present.
13. For use in -20° C minimum, 60° C maximum ambient temperatures.
14. The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition, void
warranty, and result in non-compliance with UL specifications.
15. Do not use this equipment for other than intended use.
16. Install in accordance with the National Electrical Code and local regulations.
17. Lighting fixture manufacturers, electricians, and end-users need to ensure product system compatibility before
final installation. See addendum for compatibility and covered luminaire requirements.
SAVE THESE INSTRUCTIONS
ILB CP18 HE CW LP64
COLD WEATHER
HIGH EFFICIENCY EMERGENCY
LIGHTING EQUIPMENT
FOR LED
INSTRUCTION MANUAL
P.O. BOX 11846 TUCSON, AZ 85734
[phone] • FAX [phone]
www.iotaengineering.com Patented. See iotaengineering.com/patents for more details
HIGH EFFICIENCY PERFORMANCE
MEETS CA T20 BATTERY CHARGER
EFFICIENCY STANDARDS
EMERGENCY LED DRIVER FOR USE
WITH LED LUMINAIRES IDENTIFIED
IN THE MANUFACTURER’S
INSTALLATION INSTRUCTIONS
E99113

Page 2
VERIFYING COMPATIBILITY
The ILB CP18 HE CW LP64 can be used with most LED loads that operate at 20-58 VDC up to a load rating of
18 Watts.
1. The ILB CP18 HE CW LP64 series has been evaluated to and found compliant to UL standard 924. The as-installed
performance of system must meet or exceed all Federal, State, and Local code requirements.
2. Refer to Addendum 11042014 for detailed specifications and methods to calculate emergency light levels.
CAUTION: Before installing, make certain A.C. power is off and the IP Rated Test Switch (IPS)
is disconnected.
STEP 1 - MOUNTING THE ILB CP18 HE CW LP64
Mount the ILB CP18 HE CW LP64 in the driver/lamp compartment or enclosed wireway so the wire leads are not
exposed, at least ½″
away from the AC Driver.
The battery must be mounted securely. Once the battery is secure, join the 4-pin battery connector, but do not join the
2-pin unit connector.
INSTALLATION INSTRUCTIONS
STEP 2 - WIRING TO THE LED LOAD AND NORMAL DRIVER
Refer to the appropriate wiring diagram below. Make sure all connections are in accordance with NEC and any other
local requirements.
ILB CP CW - SINGLE LEAD ACID BATTERY CONFIGURATION - WIRING TO LOAD AND NORMAL DRIVER
ILB CP CW 1LA.EPS
AC (NORMAL)
DRIVER
IOTA ILB CP CW
EMERGENCY DRIVER
LED
LOAD
BLACK
BLACK/WHITE RED (+)
BLUE/WHITE (-)
RED/WHITE (+)
LED INPUT(-)
LED INPUT (+)LED OUTPUT (+)
LED OUTPUT (-)
ILB CP CW - LITHIUM 6 X 4 CONFIGURATION
ILB CP CW LP64.EPS
IOTA ILB CP CW
EMERGENCY DRIVER
BATTERY
RED (+) RED (+) BLACK(-) BLACK(-)
-
-
+
+
UNIT CONNECTOR
4-PIN BATTERY CONNECTOR
STEP 3 - INSTALLING THE BATTERIES

Page 3
ILB CP CW - SINGLE LEAD ACID BATTERY CONFIGURATION - TEST SWITCH CONNECTIONS
ILB CP CW 1LA.EPS
IPS
TEST ACCESSORY
BROWN
VIOLET
WHT
RED
CHANNEL COVER
IPS
EMERGENCY
DRIVER
LUMINAIRE HOUSING
IPS NUT
STEP 4 - INSTALLING THE IP RATED TEST SWITCH (IPS)
A. Locate a suitable location for the IPS and
cable that is visible outside the fixture.
Drill or punch a 0.537" diameter hole in
the fixture wall or wireway cover. Insert
the IPS into the hole so that the LED test
button/pilot light is located outside of the
fixture.
B. Secure the IPS using the IPS
nut.
C. Connect the IPS White wire to
the Brown lead on the ILB. Then
connect the IPS Red wire to the
Violet lead.
COMPLETING INSTALLATION
STEP 6 - APPLY AC POWER AND JOIN UNIT CONNECTOR
A. Apply continuous AC power to the unit, and then, join the 2-pin unit connector. Allow the unit to charge for at least
1 hour before performing a functional test.
B. Verify that the IPS light is solid on.
C. Press and hold the IPS button. The LED Module should be operating in the emergency mode at a reduced light output.
Release the IPS button. If the LED Module in the fixture returns to normal operation, the unit is ready for normal and
emergency service. If not, contact Customer Service.
OPERATION
Normal Mode
A.C. power is present. The A.C. Driver operates the LED Module as intended. The ILB CP18 HE CW LP64 is in the standby
charging mode. The IPS will be lit providing a visual indication that the battery is being charged.
Emergency Mode
The A.C. power fails. The ILB CP18 HE CW LP64 senses the A.C. power failure and automatically switches to the Emergency
Mode. The LED Module is illuminated for a minimum of 90 minutes. When the A.C. power is restored, the ILB CP18 HE CW
LP64 switches the system back to the Normal Mode and resumes battery charging.
ILB CP CW - SINGLE LEAD ACID BATTERY CONFIGURATION - CONNECTING AC INPUT
ILB CP CW 1LA.EPS
IOTA ILB CP CW
EMERGENCY DRIVER
WHITE
BLACK
COMMON
UNSWITCHED
24/7 POWER
BLK/ORG (120 TO 277V, 50/60HZ)
SWITCHED OR
UNSWITCHED HOT
STEP 5 - WIRING THE AC INPUT
The ILB CP18 HE CW LP64 requires an unswitched AC input of 120/277 volts. Connect the BLACK/ORANGE wire to the
unswitched 120/277 Line, and the WHITE wire to the Neutral. Connect the BLACK wire to a switched or unswitched AC
input of 120/277 volts.
ILB CP CW
PANEL CUTOUT
0.537 in - 0.545 in

Page 4
68018-001
REV 2000
ILB CP CW - LITHIUM 6 X 4 CONFIGURATION
ILB CP CW LP64.EPS
AC (NORMAL)
DRIVER
IOTA ILB CP CW
EMERGENCY DRIVER
LED
LOAD
BATTERY
BLACK
WHITE
BLACK
BLACK/WHITE
COMMON
UNSWITCHED
24/7 POWER
BLK/ORG (120 TO 277V, 50/60HZ)
WHITE
SWITCHED OR
UNSWITCHED
HOT
IPS
TEST ACCESSORY
RED (+)
BLUE/WHITE (-)
RED/WHITE (+)
LED INPUT(-)
LED INPUT (+)LED OUTPUT (+)
LED OUTPUT (-)
BROWN
VIOLET
RED (+) RED (+) BLACK(-) BLACK(-)
-
-
+
+
WHT
RED
UNIT CONNECTOR
4-PIN BATTERY CONNECTOR
TESTING & MAINTENANCE
COMPLETE WIRING DIAGRAM
Pressing the IPS turns off the light on the IPS and forces the unit into emergency mode, interrupting power to the desig-
nated A.C. driver. The LED load is now being lit by the ILB CP18 HE CW LP64 unit. After releasing the IPS, the fixture
returns to normal operation after a momentary delay.
Initial Testing – Allow the unit to charge approximately 1 hour, then conduct a short discharge test. Allow a 24 hour
charge before conducting a one hour test.
The ILB CP18 HE CW LP64 is a maintenance free unit, however, periodic inspection and testing is required. NFPA
101, Life Safety Code, outlines the following schedule:
Monthly – Insure that the IPS light is illuminated. Conduct a 30 second discharge test by depressing the IPS. At least
one LED should operate at reduced output.
Annually – Insure that the IPS light is illuminated. Conduct a full 90 minute discharge test. The unit should operate as
intended for the duration of the test.
“Written records of testing shall be kept by the owner for inspection by the authority having jurisdiction.”
SERVICING SHOULD BE PERFORMED BY QUALIFIED PERSONNEL.
Consult Customer Service or visit www.iotaengineering.com for current warranty information.

CP Series Compatibility and Suitability of Use Guidelines
Addendum (Rev.11042014)
The purpose of this addendum is to sufficiently identify electrical compatibility and predictable emergency light output of
the LED luminaire when used with the IOTA ILB-CP Series LED emergency drivers. Verification of these operating traits
does not constitute a code-compliant, as-installed emergency egress system. It is still the responsibility of the Designer/
Specifier to assure appropriate light levels are achieved during emergency operation of the luminaire in accordance
with Federal, state and local municipal codes regarding path of egress illumination.
1. Determining Electrical Compatibility
1.1 Verify Class 2 compliant driver per driver manufacture specifications.
1.2 Verify that the Emergency Driver (ILB-CP Series) selected does not exceed the power delivered to the LED
array (voltage and current) of the normal driver.
2. Calculating Lumen Output During Emergency Operation
2.1 Assess luminaire/fixture data.
2.1.1 DESIGNLIGHTS CONSORTIUM
- Log onto the DesignLights Consortium website (www.designlights.org).
- Click on “search the DLC Qualified Product List” button on the DLC homepage.
- In the “search by keyword” text window enter: luminaire manufacturer name and part number.
- Click on “Search” tab to open the “Qualified Products List.”
- Determine per “RATED DATA” efficacy shown in lumens per watt - (lm/w).
- Multiply lumens per watt by ILB-CP rated output (example: lm/w x 5 watts). Refer to table “ILB
MODEL SPECIFICATION CHART” below for the wattage of the specific ILB-CP model to be
used in the luminaire. (lm/w) x (ILB-CP Watts) = Minimum emergency lumens of fixture.
- Determine per “RATED DATA” the “wattage of the luminaire”.
3. Determining Adequacy of Means-of-Egress Lighting Levels
3.1 Follow industry standards by utilizing available .ies files and lighting design software for your dedicated
emergency luminaires, with the above calculated emergency lumens, and validate your as-installed plans
in accordance with the applicable life safety codes governing your project, typically 1 fc on the ground
along the full means of egress.
While the ILB-CP series has been found compliant with the requirements of UL Standard 924, it is ulti-
mately the responsibility of the Designer/Specifier to assure the as-installed system delivers code-compli-
ant path of egress illumination in accordance with Federal, State or local municipal requirements.
ILB CP05
ILB CP07
ILB CP10
5 WATTS
7 WATTS
10 WATTS
ILB MODEL SPECIFICATION CHART
OUTPUT POWER (CONSTANT)
ILB CP12 12 WATTS
ILBSL CP05
ILBSL CP07
ILBSL CP10
5 WATTS
7 WATTS
10 WATTS
ILBSL CP12 12 WATTS
ILB CP20 20 WATTS
ILB CP30 30 WATTS
ILB CP18 18 WATTS
ILBSL CP08 8 WATTS
