iQube Electric S 2022 User manual

OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022 1
FOREWORD
Hello!
You are now a proud owner of the iQube Electric S scooter from the house of TVS Motor Company.
The iQube Electric S is an electric scooter like no other. It gives you the unmatched combination of performance,
connected technology and practicality of use. So now you can ride in style and comfort, with all the savings
benets of an electric vehicle.
For getting the best out of your iQube Electric S, please read the manual carefully and understand all features
and operations of your vehicle. Follow the instructions and enjoy a smart and convenient experience that comes
with your iQube Electric S.
To ensure a worry free journey on your TVS iQube Electric S, we urge you to get your vehicle serviced only at
TVS Motor Company Authorized Dealers.
We hope you enjoy every aspect of being a proud owner of TVS iQube Electric S and being a part of our
community of smart, next-gen and sustainable riders.
Happy riding!
TVS MOTOR COMPANY LIMITED

2OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
CONTENTS
CONTACTS FOR SUPPORT .......................................................................................... 3
INTRODUCTION ............................................................................................................. 5
UNIQUE FEATURES OF TVS iQUBE ELECTRIC S ....................................................... 6
ACCESSORIES FOR YOUR SCOOTER ........................................................................ 9
SAFETY INFORMATION .............................................................................................. 10
KNOW YOUR TVS iQUBE ELECTRIC S ...................................................................... 12
CONTROLS ................................................................................................................... 16
CHARGER SOCKET ..................................................................................................... 24
VEHICLE CHARGING ................................................................................................... 26
INSTRUMENT CLUSTER ............................................................................................. 28
MAINTENANCE SCHEDULE ........................................................................................ 48
WARRANTY INFORMATION ........................................................................................ 52
TECHNICAL SPECIFICATIONS ................................................................................... 55
GENERAL INFORMATION ........................................................................................... 57

3
OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
TAMILNADU-1, 3 & 4
1. TVS Motor Company Limited
V Floor, Gee Gee Universal,
No. 2, MC Nichols Road,
Chetpet, Chennai - 600 031.
Phone : [phone]
Email : [e-mail]
[e-mail]
TAMILNADU-2
2. TVS Motor Company Limited
No. 10, 2nd oor,
Shree Shanmugapriya Towers,
Kannuswamy Street,
Behind Hotel Annapoorna,
R S Puram, Coimbatore - 641 002.
Phone : [phone]
Email : [e-mail]
KERALA
3. TVS Motor Company Limited
Ambady Towers, Second Floor,
Door No. 27/631, A6,
Edappally-Pookkattupady Road,
Edappally PO., Cochin - 682 024.
Phone : [phone]
Email : [e-mail]
KARNATAKA-1, 2 & GOA
4. TVS Motor Company Limited
No. 600, Anand Surya, 2nd Floor,
15th Cross, 6th Phase, JP Nagar,
Opp. BMTC Bus Stop,
Bangalore - 560 078.
Phone : [phone]
Email : [e-mail]
[e-mail]
ANDHRAPRADESH -1 & 2
5. TVS Motor Company Limited
Rukumani Towers, First Floor,
No. 3-11-30, Plot No. 11,
Paigha Colony, Behind Anand Theater,
Secunderabad - 500 003.
Phone : [phone]
Email : [e-mail]
[e-mail]
MAHARASHTRA-1 & 2
6. TVS Motor Company Limited
No. 401, 4th Floor, The Chambers,
Plot No. 4/12/3, Near Ganapati Chowk,
Viman Nagar, Pune - 411 014.
Phone : [phone]
Email : [e-mail]
MAHARASHTRA-3 & CHATTISGARH
7. TVS Motor Company Limited
No. 502B, 6th Floor, B Wing,
Shriram Shyam Towers,
Near LIC Square, Sardar,
Nagpur - 440 001.
Phone : [phone]
Email : [e-mail]
[e-mail]
GUJARATH
8. TVS Motor Company Limited
109, Ayna Complex,
Opp. Suvarna Villa Bungalows,
100 ft Thaltej Hebbatpur Road,
O󰀨 : S.G. Highway, Thaltej,
Ahmedabad - 380 054.
Phone : [phone]
Email : [e-mail]
MADHYA PRADESH-1 & 2
9. TVS Motor Company Limited
No. 211-212, 2nd Floor,
Chinar Incube Business Centre,
Chinar Fortune City,
Near Brindhavan Dhaba,
Hosangabad Road,
Bhopal - 462 026.
Phone : [phone]
Email : [e-mail]
[e-mail]
RAJASTHAN-1 & 2
10. TVS Motor Company Limited
Plot No. 17-18,
2nd Floor of National Motors Building,
Jhotwara Industrial Area,
Jaipur - 302 012.
Phone : [phone]
Email : [e-mail]
[e-mail]
CONTACTS FOR SUPPORT

4OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
DELHI & HARYANA
11. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
[e-mail]
PUNJAB & CHANDIGARH
12. TVS Motor Company Limited
4th Floor, Royal Business Park,
Chandigarh Ambala Highway,
Zirkapur - 140 603.
Phone : [phone]/465777
Email : [e-mail]
UTTAR PRADESH WEST
13. TVS Motor Company Limited
D-3 & D-4, 2nd Floor,
Sector - 10, Noida,
Uttar Pradesh - 201 301.
Phone : [phone]
Email : [e-mail]
UTTAR PRADESH CENTRAL & EAST
14. TVS Motor Company Limited
1st Floor, Cyber Tower, TC-34/V-2,
Vibhuti Khand, Gomti Nagar,
Lucknow - 226 010.
Phone : [phone]
Email : [e-mail]
[e-mail]
WEST BENGAL
15. TVS Motor Company Limited
Ground Floor & First Floor,
133 A. S. P. Mukherjee Road,
Opp. Tollygunge Police Station,
Kolkatta - 700 026
Phone : [phone]
Email : [e-mail]
BIHAR
16. TVS Motor Company Limited
N-Plaza, Jamal Road,
P.S. Kotwali,
Patna - 800 001.
Phone : [phone]
Email : [e-mail]
ORISSA & JHARKHAND
17. TVS Motor Company Limited
No. 303, 3rd Floor,
Creative Plaza, Rasulgarh,
Bhubaneshwar - 751 010.
Phone : [phone]
Email : [e-mail]
NORTH EAST STATES
18. TVS Motor Company Limited
147, Udayan, Ganesh Guri,
Opp. Punjab National Bank,
R G B. Road, Guwahati - 781005.
Phone : [phone]
Email : [e-mail]
Or
Toll Free Number Relationship Manager : 1800-572-1818 (Mon - Fri: 9am to 6pm)
Toll Free Number Roadside Assistance : 1800-258-7111 (Available 24 x 7)
Email: [email protected]

5
OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
INTRODUCTION
One of the nest and modern technology products of TVS Motor is waiting to be unveiled; an electric scooter
which is futuristic and contains plenty of features and technological advancements. However, before delving
further into this manual, let us rst have a glimpse of what your electric two wheeler is and how it is di󰀨erent
from an internal combustion engine powered vehicle. The below info-graphic provides a broad idea about an
electric two wheeler;
Powerful wheel mount hub motor
Fuel Tank
FUEL
TANK
An IC engine running on petrol
Conventional transmission
VS
BATTERY PACKS
12
MCU
MCU electronic device to control EV POWER TRAIN
Advanced Lithium ion battery

6OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
ADJUSTABLE REAR SHOCK ABSORBER
Your Scooter comes with Adjustable Shock Absorber,
a rst-in-the-industry feature. This allows you to adjust
the required level of hardness / softness as per the
usage requirement with just a push of a lever. Refer
page No. 50 for details
TUBELESS TYRES
Another important unique feature in your scooter is
‘Tubeless Tyres’. Tubeless tyres reduce the chances
of getting punctured. Even if there is a puncture,
sudden leakage of air is avoided, thereby providing
better safety and convenience. It is also very easy to
repair the punctured tyres.
UNIQUE FEATURES OF TVS iQUBE
ELECTRIC S
LCD / TFT INSTRUMENT CLUSTER
Unlike conventional scooters this vehicle is having
a digital instrument cluster which ensures brighter
display and allows ease of interaction between
vehicle and the rider.
RETRACTABLE BAG HOOKS
Your scooter has two retractable Bag Hooks to carry
light luggage like carry bags weighing upto 3 kg.
One hook is located below the handle bar on the rear
panel and the other one is located on the cover front
below the front end of seat Refer page No. 22 for
details
TELESCOPIC FRONT FORK
Your Scooter has Motorcycle-like ‘Telescopic Front
Suspension’ for extreme comfort for excellent riding
comfort even on bad roads.
33
9:15 am
30 Jan 2021
km/h
km
/
h
REGEN
930




DTE
73
km
70
%


ODO
013614.3
km
12.2 km
Avg Speed
85 km

Trip

7
OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
UNDER-SEAT STORAGE (UTILITY BOX)
Your scooter has a 10 litre under-seat storage space
to carry your luggage belongings. Refer page No. 22
for details.
ALL LED ILLUMINATION
Your Scooter comes in with premium LED lamps.
E󰀩cient and bright, this gives TVS iQube Electric S
a totally upgraded Look and Style with better visibility
for night rides. LED lamps consume less power with
increased luminous intensity.
ALL BLACK LARGER ALLOY WHEELS
All ‘Black Larger Alloy Wheels’ with high mechanical
advantage gives progressive braking of your scooter,
results in best-in-class ‘shortest distance’ braking. It
also provide superior comfort in bad road conditions.
PARKING BRAKE (BRAKE LOCK LEVER)
‘Parking Brake’ is another unique safety feature which
protects your scooter from falling due to wheel rotation
when it is parked with the side stand on a slope. Refer
page No. 17 for details.
DISC SYNCHRONISED BRAKE TECHNOLOGY
(SBT)
Taking technological innovation to next level, your
scooter comes with ‘Synchronised Brake Technology
(SBT)’. This feature enhances the safety by avoiding
skidding during sudden braking.

8OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
SIDE STAND INDICATION
Vehicle will be immobile and side stand indication will
be shown in the instrument cluster if the vehicle is on
side stand.
Caution
Always release the side stand to its full up position
before moving the vehicle
MALFUNCTION INDICATION AND SERVICE
REMINDER
Malfunction indication noties you to take the vehicle
for diagnostic and troubleshooting, whereas service
reminder recalls you to take the vehicle for periodic
maintenance (care) at Authorised Service station
based on the alert.
FLIP KEY WITH LED LIGHT
Foldable key with LED light helps you to see ignition
lock in dark.
PLEASANT HORN TONE
A newly designed horn produces a pleasant tone
when pressed by user.
TEXTURED FLOORBOARD
Your scooter comes with a stylish textured oor board.

9
OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
TEXTURED FLOOR MAT
Your scooter comes with a stylish textures oor mat.
ACCESSORIES FOR YOUR SCOOTER
SMART PHONE CHARGER**
Your TVS iQube Electric S is provided with a socket
for charging your smart phone even while you are
traveling and it is located in the utility box below the
seat assembly. Refer page No. 23 for usage details.

10 OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
SAFETY INFORMATION
Operating this vehicle safely is an important responsibility of the rider. To help you make safe decisions while
operating the vehicle, we have provided necessary operating procedures and other information in this manual.
This information alerts you on potential hazards that could cause injury to you or others. Since it is not possible
to warn you about all the hazards associated with operating or maintaining the vehicle, you must use your own
judgement.
You will nd important safety information in following form in this manual. These words carry the following
connotations:
Note
This message provides further clarication for clear understanding of any particular.
Caution
This message indicates special procedures or precautions to be followed to avoid damage to the vehicle.
Warning
Disregarding this message might result in accidents or injury to the rider.
Note
• All information, illustrations, photographs and specications contained in this owners manual are based on
the latest product information available at the time of this publication. TVS Motor Company Limited may,
however, incorporate modications or improvements on its vehicles at any time without notice and therefore,
in such events it is possible that the relevant part of the owner’s manual does not apply to your vehicle.
• Prior permission of TVS Motor Company Limited is required for quoting, copying or reproducing any part of
the owner’s manual.
• Accessories shown in the picture may not be part of the standard equipment.
• Pictures shown in this manual are of TVS iQube Electric S Disc Brake version unless specied.

11
OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
Caution
1. Leaving the ignition cum steering lock in ‘ON’ position for a prolonged time will drain the battery when the
vehicle is not in use. Switch OFF and take the key out when the vehicle is not in use.
2. Always lock the steering while parking for safety.
3. It is recommended to use the tool kit in case of emergency only. It is always advisable to take your vehicle
to TVS Motor CompanyAuthorized Main Dealer.
4. Never sit on vehicle when it is supported by stands.
5. Utility box can be used to carry a load of maximum 10 kg.
6. Do not carry perishable items inside the utility box. It is not fully sealed. Do not allow / spray water inside the
utility box. Take care not to spill liquid into the utility box.
7. Care should be taken not to attach the luggage which hangs out of your scooter. Please note that the
luggage attached to your scooter should not interfere with your feet movement.
8. The charging time of the vehicle may vary, depending on the vehicle’s battery state of charge.
9. The ap has been designed to prevent water entry inside the charging port and is not replaceable. No
warranty for charger is applicable in case of ap damage.
10. Always release the side stand to its full up position before moving the vehicle.
11. Be aware of reverse park assist mode. In this mode, the vehicle will move in reverse when throttle is given.
12. Always park the vehicle on a at, rm surface, in shaded area and away from ood, re and other unsafe
environments.
13. While charging vehicle always switch on AC supply, only after plugging in both end of the charging cord at
their respective positions.
Warning
1. Never attempt to move the vehicle when the steering is locked, you may lose balance.
2. Use appropriate head lamp beam ‘high / low’ as per the tra󰀩c and road conditions for your safety and avoid
inconvenience to other riders.
3. Operating the TVS iQube Electric S overloaded will hamper riding stability and may lead to loss of control.
Hence, it is advisable to carry the recommended amount of load only.
4. Don’t touch any open cables or terminals.

12 OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
KNOW YOUR TVS iQUBE ELECTRIC S
VEHICLE IDENTIFICATION NUMBER
The frame and traction motor serial numbers are the only means of identifying your vehicle from others of the
same type. They are also required to assist your Dealer for ordering parts or referring to special information.
The frame serial number is stamped on the frame, at the rear end below the seat assembly. Open the seat
assembly and remove the VIN cover to read the frame number.
The traction motor serial number is stamped on the hub of the rear wheel assembly. Rotate the rear wheel
assembly to read the motor number.

13
OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
VEHICLE LEFT SIDE
1. Brake Disc
2. Front wheel axle
3. Side stand
4. Pillion foot rest L
VEHICLE RIGHT SIDE
1. Seat assembly
2. Crash Guard
3. Pillion foot rest R
4. Cover front
5. Bag hook (rear)
6. Front wheel axle nut
24
1
3
2 63 4
1
5

14 OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
VEHICLE FRONT SIDE
1. Front Position Lamp
2. Turn signal lamp front L
3. Headlamp (AHO)
4. Turn signal lamp front R
VEHICLE REAR SIDE
1. Tail/ brake lamp
2. Turn signal lamp rear R
3. License plate lamp
4. Turn signal lamp rear L
5. Pillion handle 1
24
3
5
1
24
3

15
OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
VEHICLE TOP SIDE
1. Instrument cluster 10. Charging socket
2. Rear view mirror R 11. Horn switch
3. Hazard switch 12. Turn signal lamp switch
4. Right hand brake lever 13. HMI Switch
5. Throttle grip 14. Left hand brake lever
6. Park assist switch 15. Left hand brake lever lock
7. Mode switch 16. High/low beam switch
8. Ignition cum steering lock 17. Rear view mirror L
9. Bag hook (front)
1 217
3
414
5
6
13
12 7
8
9
10
11
16
15

16 OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
CONTROLS
Your TVS iQube Electric S comes with a pair of
identical control keys. These keys are to operate
ignition cum steering lock and seat lock.
IGNITION CUM STEERING LOCK
The ignition switch enables and disables the electrical
circuit and steering lock. The three positions of the
switch are described below.
1. ‘OFF’ position
All electrical circuits are deactivated. The key can
be removed from the lock.
2. ‘ON’ position
All electrical circuits are activated. Vehicle’s
instrument cluster will wake up and the vehicle
can be shifted to drive mode.
Control key cannot be taken out from the lock in
this position.
P
U
S
H
O
F
F
O
N
L
O
C
K
P
U
S
H
O
F
F
O
N
L
O
C
K
3. ‘LOCK’ position
Your TVS iQube Electric S steering can be
locked in both ‘left’ and ‘right’ directions. Turn the
handlebar to the ‘left’ or ‘right’. Press the key IN
and rotate it to the ‘LOCK’ position from ‘OFF’
position.
All electrical circuits are deactivated and the
steering is locked. Control key can be removed
from the lock.
Insert the key into the lock and press the key IN
and turn it to ‘OFF’ or ‘ON’ position to unlock the
steering.
Note
Instrument cluster background illumination, front
position lamp, illuminating logo, automatic headlamp
on (AHO) and tail lamp glow automatically once the
ignition key is turned ‘ON’ without activating any other
switches.
Caution
Leaving the ignition cum steering lock in ‘ON’ position
for a prolonged time will drain the battery when the
vehicle is not in use. Switch OFF and take the key out
when the vehicle is not in use.
Always lock the steering while parking for safety.
Warning
Never attempt to move the vehicle when the steering
is locked, you may lose balance.

17
OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
HANDLE BAR LEFT SIDE
11. Horn switch
Press the switch ‘ ’ to operate the horn.
12. Turn signal lamp switch
Slide the turn signal lamp switch to left ‘ ’
or right side ‘ ’ to operate respective turn
signal lamps (LH / RH). Press the center button of
the switch to turn ‘OFF’.
13. HMI switch
The HMI switch is used to operate the menu
screens on the cluster.
14. Left hand brake lever
The rear brake is applied by squeezing the rear
brake lever gently towards the handle grip. The
brake lamp glows on application of rear brake .
15. Left hand brake lever lock
Left hand brake lever lock is useful when your
scooter is parked with side stand on a slope to
avoid falling.
To apply the left hand brake lever lock, squeeze
the left hand brake lock lever fully towards the
grip. Hold the brake lever at the same position,
press and hold the left hand brake lever lock. Now
release the brake lever and ensure that the brake
is locked properly.
To release the left hand brake lever lock, squeeze
the left hand brake lever further in and the lock
will release automatically, release the brake lever
upon releasing the brake lever lock.
1514 16
11
13
12
16. High/low beam switch
Withthe headlamp ‘ON’,press theswitch towards
‘ ’ to operate head lamp high beam or press
it towards ‘ ’ to operate head lamp low beam.
Note
Ensure that the brake lever lock is released (if applied)
before riding the vehicle.
Caution
Use appropriate head lamp beam ‘high / low’ as per
the tra󰀩c and road conditions for your safety and
avoid inconvenience to other riders.

18 OM TVS iQube Electric S - Rev 0 -As on 08 Jun 2022
HANDLE BAR RIGHT SIDE
3. Hazard Switch
Whenever it is necessary to park TVS iQube
Electric S in a hazardous location, press the
hazard switch in ignition ‘ON’ condition to start
simultaneously ashing of all turn signal lamps, so
asto makeothers awareof yourvehicle presence.
Press the switch again to turn-o󰀨 the lamps.
4. Right hand brake lever
The brake lever controls a hydraulic circuit while
squeezing and the hydraulic circuit operates the
front brake system. The brake lamp glows on
application of front brake.
5. Throttle grip
Vehicle speed is controlled by the rotation of
the throttle grip. Twist it towards you to increase
the vehicle speed and twist it away from you or
release it to decrease the vehicle speed.
6. Park assist switch
Park assist switch activates park assist mode
and allows vehicle to roll forward or backward in
restricted speed thereby to reduce the e󰀨ort of
parking by yourself.
3
57
4
6
7. Mode switch
Mode switch allows to switch between
following modes;
1. Economy mode
2. Power mode
AUTOMATIC HEAD LAMP ON (AHO)
TVS iQube Electric S comes with a Automatic
Headlamp ON (AHO) LED lamp which glows
automatically once the ignition is turned ‘ON’.
