IRiver E100 4GB User manual

User manual
E100

Getting Started
Components 4
Locating the Controls 5
LCD Display 6
Installing iriver plus 3 8
Basic Operations
Turning the Product
on/off 10
Menu selection 11
Using HOLD and RESET 12
Connecting Products 13
Using the Product
Music 20
Videos 23
Pictures 25
Texts 27
FM Radio 29
Recordings 31
File Manager 32
Settings 33
Other Information
iriver plus 3 Using the
Product 36
Copyrights/Certification/
Trademarks/Limited
Liability 40
Safety Instructions 41
Troubleshooting 44
C o n t e n t s

E100

Components 4
Locating the Controls 5
LCD Display 6
Installing iriver plus 3 8
01 Getting Started

4
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
E100 Earphones
Quick Start Guide & Warranty Card Installation CD & Manual USB cable
Getting Started
Components
Components are subject to change without notice and may vary from images shown.

5
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Components are subject to change without notice and may vary from images shown.
Getting Started
Locating the Controls
Speaker
RESET pinhole
HOLD switch
Volume button
MIC
POWER button
LCD
OK button
Menu buttons
LINE-IN jack
USB jack
Earphone jack
Micro SD card slot

6
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
While playing music While playing video
Getting Started
LCD Display
Current video
File name
Elapsed time /
Total playing time
Rating
EQ
Album art
A-B repeat
Elapsed time /
Total playing time for the
current le
Play Mode
Current time
Album Info
Previous
Battery
Progress bar
Progress bar
Volume
Play next le
Playing previous le
HOLD
Rewind
Fast Forward

7
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Getting Started
LCD Display
FM Radio While recording voice
Recording qualityPreset ON / OFF
Current frequency
Options
Frequency indicator
Channel number
Current status
Recorded time /
Remaining time

8
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Getting Started
Installing iriver plus 3
iriver plus 3 is an integrated software application that efciently manages music, video, and picture les.
iriver plus 3 gives you freedom to transfer music, video and picture les from PC to the device.
Insert the installation CD into your PC to display the installation process screen.1.
Select iriver plus 3 and click the2. Install button.
Complete the installation process by following the on-screen instructions.
Minimum requirements for using iriver plus 3
Windows® 2000/XP
Intel® Pentium® ll 233 MHz or higher processor speed 64 MB or greater memory 30 MB or greater hard disk space
16-bit enabled speaker and sound card Microsoft Internet Explorer version 6.0 or later
SVGA or high resolution monitor (1024x768 resolution or greater)
Windows® Vista (Windows® Vista only supports the 32-bit version and does not support the 64-bit version.)
Intel® Pentium® ll 800MHz or higher processor speed 512 MB or greater memory 20 GB or greater hard disk space
16-bit enabled speaker and sound card Microsoft Internet Explorer version 6.0 or later
SVGA or high resolution monitor (1024x768 resolution or greater)
For more information on using iriver plus 3, refer to pages 36 - 39.
Notice...

Turning the Product on/off 10
Menu selection 11
Using HOLD and RESET 12
Connecting Products
- Connecting Earphones to the E100 13
- Charging the product 13
- Inserting / Removing the micro SD card 14
- Recommended micro SD card types 15
- Connecting the E100 to your PC 16
- Copying files / folders to the product 17
- Deleting files / folders from the product 17
- Disconnecting the E100 from your PC 18
02 Basic Operations

10
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Basic Operations
Turning the Product on/off
Turning on the product
Press and hold the1. button on the product to
turn it on.
Press and hold the1. button on the product to
turn it o.
This product has an automatic power saving function to save battery power.
Based on the settings in power save mode, the product will be automatically turned off after a pre-determined period without operation.
For more information on setting this mode, refer to Settings > Timer > Auto Power off. (Refer to page 33.)
Notice...
Turning o the product

11
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Basic Operations
Menu selection
In the main menu, press the1. / button to select the menu.
Press and hold the2. button to display the main menu from any operation screen.

12
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Basic Operations
Using HOLD and RESET
Using HOLD
Slide the1. HOLD switch to the direction of arrow as
shown below to lock the product.
Slide the2. HOLD switch the opposite direction to
unlock the product.
If the player stops and does not respond to any1.
commands, press the RESET pinhole.
Using RESET
Performing RESET does not delete the date / time settings
and data in the integrated memory.
Notice...

13
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Basic Operations
Connecting Products
Charging the product
Turn on your PC and connect the E100 to it using the1.
USB cable provided.
While the product is connected to a PC using the USB cable, the
integrated battery will be charged automatically.
Do not use any USB cable other than the one included with the
product. It may cause a malfunction.
Check if the E100 is connected to a high-power USB 2.0 port.
Some low-power USB ports built into certain peripheral devices,
such as some types of keyboards and USB hubs without integrated
power may not provide enough power to charge.
While the PC is switched to standby mode, the product may not
be charged.
Charge the product only at room temperature.
The product may not be charged in extreme hot or cold temperatures.
The charging time might be extended if you use the product while
charging.
Notice...
Connecting Earphones to the E100
Connect earphones to the earphone jack.1.

14
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Basic Operations
Connecting Products
Inserting / Removing the micro SD card
Open the cover of micro SD card after turning o the1.
product.
Insert and slightly press a micro SD card in the2.
direction as shown below.
Press again to remove the micro SD card.3.
Be sure to insert / remove a micro SD card only after turning off the product.
Do not use excessive power to insert a micro SD card.
This can cause product malfunction or damage the micro SD card.
Do not remove a micro SD card while in use.
This can cause a deletion of data, product malfunction or damage micro SD card.
Do not insert or remove a micro SD card repeatedly.
If you insert a micro SD card improperly, it can cause product malfunction or cause the card to jam.
Notice...

15
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Basic Operations
Connecting Products
Manufacturer: SanDisk
Recommended micro SD card types
Using improper type of micro SD card may cause product malfunction.
Transfer speed of micro SD card is variable depending on your PC.
Always backup valuable data first since formatting the micro SD card will delete all data on it.
Do not turn off the product or remove a micro SD card while it is being formatted.
This can cause a malfunction of the product and damage the micro SD card.
It is recommended to format a micro SD card as a FAT32 system in case its size is over 2 GB.
If a micro SD card has already been formatted by the product, reset the product after disconnecting the USB cable and connect the cable again.
Format the micro SD card if it is not detected or causes a malfunction.
The micro SD card is not included with the product. (Optional item)
Only SanDisk supports 8 GB. For more information, refer to the iriver website.
Notice...

16
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Basic Operations
Connecting Products
Connecting the E100 to your PC
Press and hold the1. button on the product to turn
it on.
Turn on your PC and connect the E100 to it using the2.
USB cable provided.
If properly connected, the LCD will display as below.3.
Charge & Data Transfer : The product is currently being
charged and data is being transferred.
Charge & Play : The product is currently being charged and
a le is being played.
Charge :The product is currently being charged.

17
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Basic Operations
Connecting Products (Using as a removable disk)
Copying les / folders to the product
Select the desired les / folders in your PC and1.
drag & drop to the drive which appears as the product.
After selecting the desired le / folder, right-click with1.
your mouse and select Delete.
Click2. Yes in the Conrm File Delete / Conrm Folder
Delete popup window to delete the le / folder.
Always connect the USB cable properly.
While transferring data using the USB cable, never disconnect it or turn off the power to protect your data from loss or damage.
Notice...
Deleting les / folders from the product

18
iriver Music Videos Pictures Texts FM Radio Recordings File Manager Settings
Basic Operations
Connecting Products
Disconnecting the E100 from your PC
Click the icon on the taskbar to disconnect the product1.
using the Safely Remove Hardware menu.
Click the [Stop] button to conrm disconnection.2.
The icon on the taskbar may be hidden in some operating systems.
Click Show hidden icons to display the hidden icon.
The Safely Remove Hardware function may not be available while using some applications such as Windows Explorer or Windows Media Player.
Close all applications first before performing the Safely Remove Hardware.
If the Safely Remove Hardware is not performed properly, try again after a few minutes.
If the product is removed without observing the above process, data in the product might be damaged.
Notice...

Music
- Selecting Music 20
- Playing Music 20
- Additional Features 21
Videos
- Selecting Video 23
- Playing Video 23
- Additional Features 24
Pictures
- Selecting Pictures 25
- Viewing Picture 25
- Additional Features 26
Texts
- Selecting Text 27
- Viewing Text 27
- Additional Features 28
FM Radio
- Listening to FM Radio 29
- Scanning FM Radio
Station 29
- Additional Features 30
Recordings
- Recording 31
- Additional Features 31
File Manager
- Browsing Device 32
- Deleting File 32
Settings
- Selecting Setting 33
- Date & Time 33
- Display 33
- Timer 33
- Advanced 34
- Language 34
03 Using the Product
