IRiver Spinn 4GB User manual

• Sleek SPINN System (Analog Toggle Wheel)
• 3.3” QVGA AMOLED(480 x 272)
• BLUETOOTH 2.0 / Touch Screen
• Plays up to 25 hours(Music)*2, 5 hours(Video)*3
• Supports music file of MP3, WMA, OGG, APE, FLAC
• Supports video file of MPEG4 SP, WMV9 SP, XVID SP
• Flash Lite 2.1 & 3D acceleration chip
• Displays album information of the song currently playing
• FM radio and recording
• Voice recording / Text Viewer
• Photo album + Slide show*4
• Movie player*5 / FLASH*6 player + Game
• UCI (User Create Interface) Function
• Alarm with real-time clock
• PodCasting*7
and Audiobook*8 Support
• SRS WOW HD Support
• USB 2.0, Ultra fast data transfer
• Firmware Upgradeable
• MSC/MTP conversion support, PFD support
Launching - Sept, 2008
Available Models
Iriver SPINN 4GB/8GB*1
Available Colors
Basic color
Silver/ White/Black
*1 1GB=1,000MB = 1,000,000,000Byte. Not all memory space available for file storage.
*2 Music based on MP3 format, 128kbps, 44.1kHz, Volume 20, EQ Normal and LCD off
*3 Video based on AVI format, 320×240 @15fps, Video(384kbps), Audio(128kbps, 44.1kHz)
*4 The Progressive JPG is not supported.
*5 MPEG4 simple profile QVGA (30fps) and WMV9 SP
*6 Macromedia Flash Lite 2.1
*7 PodCasting supports MSC mode only.
*8 Audiobook service via audible.com supports MTP mode only.
•Product Main Concept : Combines Warmth of Analog Control +
Advanced Digital Content
•Product Sales Point : AMOLED, BLUETOOTH, Touch Screen,
Pocket-Size MP4 Player, SPINN Wheel,
Flash UI & Theme Skin
UU30(SPINN).
SERIES

SERIES
Detailed Specification
Series U Series
Product SPINN (U30)
Capacity* / Color 4, 8GB / Black, White (Magnesium Body)
General
Continuous Playback Time MUSIC Approx. 25 Hours (MP3, 128kbps, 44.1kHz, EQ Normal, Vol 20, LCD Off)
VIDEO Approx. 5 Hours (Video MPEG4 SP QVGA at 30fps)
Connection Type 20Pin Connector (USB A to Mini B)
Equalizer Preset 7EQ, User 5EQ and SRS WOW HD
Dimensions 99.3 x 51.0 x 10.7 mm
Weight Approx. 70g
Operational Temperature -5℃~ 40℃
Voice Recording Yes
Display Color Depth 262K Color 3.3” AMOLED with FLASH GUI
Power supply USB/ Battery 3.7V 950mA, Li-Polymer 1 EA (Internal)
Audio
Codec Support (Decode) MP3, WMA, OGG, ASF, FLAC, APE
Codec Support (Encode) WMA
Bit Rate MP3,WMA : 8Kbps ~ 320Kbps
OGG : Up to Q10
Tag ID3 V1 Tag, ID3 V2 2.0, ID3 V2 3.0, ID3 V2 4.0
Frequency Range 20Hz~20kHz
Headphone Output Power 17mW(R) ＋17mW(L) (16 Ohm) at Max. Volume
S/N Ratio 90dB : A weighted
No. Channels Stereo (L+R)
FM Tuner
Frequency Range 76.0MHz ~ 108.0MHz
Antenna Headphone / Earphone-Antenna
FM Recording WMA
www.iriver.com
© COPYRIGHT 2008 iriver ALL RIGHTS RESERVED
iriver is a registered trademark of ReignCom Ltd. All other company or product names are trademarks or registered trademarks of their respective owners.
All technical features are subject to change without notice. The final version of the product may differ slightly from the pictures and verbal descriptions
provided herein.
U30(SPINN).
U
•Product Main Concept : Combines Warmth of Analog Control +
Advanced Digital Content
•Product Sales Point : AMOLED, BLUETOOTH, Touch Screen,
Pocket-Size MP4 Player, SPINN Wheel,
Flash UI & Theme Skin

SERIES
Detailed Specification
Video
Codec Support MPGE4 SP, WMV9 SP, XVID SP
Video Bit Rate 23 kbps~512 kbps
Audio Bit Rate 8 kbps~320 kbps
Resolution 480 X 272 (WQVGA)
Frame Rata (fps) 30 fps
Photo File Type JPEG Only
Enlarged Zoom out (max.) :1600 x 1200(UXGA), Zoom in (max.) : 480 x 272
Text File Type Txt
File Size Limit 100KB ~ 10MB
Recording FM Recording Yes (WMA)
MIC Recording Yes (WMA)
O/S Windows requirement MSC mode: Windows 2000/XP/Vista
MTP mode: Windows 2000/XP/Vista
www.iriver.com
© COPYRIGHT 2008 iriver ALL RIGHTS RESERVED
iriver is a registered trademark of ReignCom Ltd. All other company or product names are trademarks or registered trademarks of their respective owners.
All technical features are subject to change without notice. The final version of the product may differ slightly from the pictures and verbal descriptions
provided herein.
