IRiver Astell & Kern AKT1 User manual

INSTRUCTION BOOK
AKT1
User Guide

Safety Precautions
Package Contents
AKT1 at a Glance
Assembly
Power Cable Management
Connections
Firmware Upgrade
02
06
07
09
11
12
15
Getting Started _01
Basic Operations
Home Screen
Playback Screen
Selecting Music
MQS Streaming
AK Connect App
Listening to Music
Listening to Internet Radio
Purchasing Music from the Store
Connecting an External Device
Settings
Connecting to a Network
Equalizer Setup
16
20
22
24
26
27
32
33
35
36
38
42
43
Using the Device _02
Notes
Troubleshooting
Copyright
Certifications
Registered Trademarks
Disclaimers
Specifications
45
45
47
47
48
48
49
Miscellaneous _03
CONTENTS

User Guide
Getting Started 02
Safety
Precautions
Device
Discontinue use of this product immediately if it does not
operate normally or a failure occurs.
When a plug is inserted into the AUX, Optical, or USB
port or a card is inserted into the microSD slot, do not
apply any force or shock to the plug or card.
Do not insert any metal objects (coins, hairpins, etc.) or
flammable debris into the device.
Do not place heavy objects on the device.
If water or other liquids enter the device, immediately
disconnect the power cord from the outlet, wipe the
surface with a dry cloth, and contact the nearest 'iRiver
Zone' for customer support.
Water-damaged devices will be repaired for a fee regardless
of warranty status, but the device may not be repairable.
Do not attempt to disassemble, repair, or modify the product.
iRiver is not liable for any damage incurred due to
unauthorized disassembly, repair, or modification of the
product.
Never use chemicals or cleaning products on the device
since they can damage the paint and surface coating.
Avoid dropping or subjecting the device to a strong impact
(excessive vibration, etc.).
When inserting a cable into any audio connection port,
do not apply force or shock to the plug.
This may cause damage to the audio ports.
The use of defective USB plugs or microSD cards may
cause the product to malfunction.
To ensure safe product usage, check the [Safety Precautions]
before you begin using the product.

User Guide
Never attempt to insert an unsuitable cable into a connector.
Never connect a damaged cable to the product.
Doing so may cause a malfunction.
Using poor quality protective films or adhesive stickers
on the screen may cause damage.
Use clean, dry hands when touching the screen.
Do not apply excessive pressure when touching the screen.
Displaying one image for an extended period may cause
screen burn-in (afterimage).
Power Cable and Plug
Do not connect/disconnect the power plug with wet hands.
Insert the power plug into a 110V - 220V (50Hz - 60Hz)
AC outlet.
Unplug the power plug from the outlet before attempting
to clean the power plug pins or mounting surface.
Observe the following when handling the power cord:
Do not damage the power code. / Do not attempt to modify
the cord. (e.g. extension) / Do not subject the cord to
excessive heat or heavy weight. / Do not pull the cord. /
Do not attempt to jam the cord into a tight space. /
Do not forcibly bend the cord. / Do not twist the cord. /
Do not tie multiple power cords together.
This may cause a fire or electric shock.
Avoid touching the power cord during lightning strikes or
thunderstorms.
This may cause a fire or electric shock.
Do not use any power cords other than the one supplied
with the product.
Do not use the supplied power cord with any other device.
This may cause a fire or electric shock.
Getting Started 03

User Guide
Installation
To reduce the risk of fire or electric shock, do not expose
this product to rain or moisture.
Avoid exposing the product to water, and do not place
objects filled with liquids, such as vases, on top of the device.
Do not place the device in the following locations:
Doing so may cause a fire or electric shock.
Humid areas such as bathrooms or areas where water may
splash / Areas where the device may be in direct contact
with rain or mist / Outdoor areas with exposure to rain /
High-temperature areas such as near a fire or radiator /
Areas where the device is exposed to direct sunlight /
Areas with high concentrations of dust, oil, or smoke
(e.g. kitchen) / Areas with extreme temperatures (Normal
operating temperatures: -5°C ~ 40°C / 23°F ~ 113°F) /
Areas with rapidly fluctuating temperatures / Areas exposed
to strong vibrations / Unstable or sloped surfaces / Near
objects with strong magnetic fields such as magnets, TVs,
monitors, or speakers / Near corrosive gases (e.g. sulfite,
hydrogen sulfide, chlorine, ammonia, etc.)
Plug the power cord into a grounded power outlet.
Hold the power plug firmly when disconnecting it from
the outlet.
Disconnect the power cord from the outlet when the
device is not being used for an extended period.
This may cause a fire or electric shock.
If you notice any color changes on a TV in the vicinity of this
product or audio interference from the TV, relocate the
product farther away from the TV.
Getting Started 04

User Guide
USB Storage Device
The USB port on this product only supports USB host
functionality.
A computer cannot be connected to the USB device port.
Large-capacity USB devices may require several minutes
to fully scan.
If static electricity is generated when connecting a USB
device, playback may not function normally.
In this case, disconnect and then reconnect the USB device.
DRM-protected files (WMA-DRM*tracks) cannot be
played on this product.
*DRM (Digital Rights Management): Technical means
used to control or limit the use of digital media content.
Specially encoded or encrypted files cannot be played
on this product.
Do not disconnect a USB device while a file on the device
is being played.
This may cause both the product and the USB device
to malfunction.
USB devices connected via a USB hub or extension
cable may not be recognized by the product.
Devices that require separate drivers are not supported.
Some USB devices may not be recognized or work correctly.
Some USB devices that require a separate power supply
(external HDD, etc.) may not function properly.
iRiver is not responsible for any data loss that occurs on
a USB device used in conjunction with this product.
Getting Started 05

User Guide
Base: Connects to the bottom of the AKT1.
Power Cord & Adapter: Connects to the device to supply power.
T-wrench: Used to fasten/loosen bolts.
Bolts: Used to fasten/loosen the base and support.
Quick Start Guide: Basic overview of device functionality.
Warranty Card: The Warranty Card is required for customer
and technical support. Do not misplace the card.
User Guide: The User Guide can be downloaded from the
Astell&Kern website. [http://www.astellnkern.com > Support
> Download]
Components may be changed without prior notice to improve
the performance or quality of the product.
Package
Contents
AKT1 Base
Power Cord
T-wrench Quick Start Guide
& Product Warranty
Bolts
Adapter
Getting Started 06

User Guide
The appearance of the product as well as printed and
engraved information may vary depending on the model.
AKT1 at a
Glance
Main Unit
Tweeter/
Mid-range
microSD Card Slot
Woofer Port
Woofer
AUX Port
USB-HOST Port
OPTICAL IN Port
Power/Volume Key
Back Button
Home Button
LCD Touchscreen
Power InputLAN Port
Getting Started 07
The AKT1 requires assembly of the top, main unit, base, and
support by the user.
Refer to [Assembly] on page 9~10 or assembly guide printed on
the packaging above the stand for detailed assembly instructions.

User Guide
Power/Volume Key: When the wheel key is pressed, the
product will power on, and the [ ] logo will appear on the
screen.
LCD Touchscreen: Display with touch control.
Back Button: Pressure-sensitive metal capacitive touch
interface.
A light touch will return the user to the previous screen.
Home Button: Pressure-sensitive metal capacitive touch
interface.
A light touch will redirect the user to the main menu.
microSD Card Slot: A microSD card can be inserted, and
music files can be selected for playback.
USB-HOST Port: A USB storage device can be connected
and music files selected for playback.
AUX Port: An external device can be connected for music
playback.
OPTICAL IN Port: An external device can be connected for
music playback.
LAN Port: Connect a LAN cable for a wired connection.
Power Input: Connect the power cable. The power input is
located at the base of the product.
(Refer to [Connecting the Power Supply] on page 11 for
detailed instructions.)
Getting Started 08

User Guide
Assembly 1. Please refer to the assembly guide printed on the packaging
above the stand.
2. Align the bolt holes on the main unit and base, and secure
the base to the main unit using the supplied T-wrench and
bolts.
3. Connect the power cord to the adapter, and then connect
the adapter to the [Power Input] port on at the base of the
main unit.
Getting Started 09
