ISHIDA Uni-3 User manual

UNI-3
Service Manual
1st Edition
IMPORTANT
•Read this manual thoroughly, and do not perform
installation, operation, maintenance, or inspection
unless you fully understand all of the contents.
•Keep this manual in a safe place where you can refer
to it easily while installing, operating, and carrying out
maintenance or inspections.
Issued on 30-Nov-2013

© ISHIDA Co., Ltd. 2012 All rights are reserved.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means
mechanical, electronic, photocopying, recording, or otherwise without prior written permission of ISHIDA.

NOTICES & PRECAUTIONS
UNI-3 Service Manual i
NOTICES
IMPORTANT NOTICE
Those who handle the machine must be aware of the hazards involved. These dangers may not be
obvious, so it is imperative to follow the instructions detailed in this manual when installing, operating,
inspecting, or servicing the machine. Therefore, we recommend that you thoroughly read and
understand this manual before installing, operating, inspecting, or servicing the machine.
ISHIDAis not liable for any damage, loss or injury that results from incorrect operation, insufficient
caution, unauthorized modifications to the machine, or failure to follow the instructions contained in
this manual.
LIMITATIONS OF LIABILITY
ISHIDAassumes no responsibility for special, indirect, or consequential damages, loss of profits or
commercial loss in any way connected with the machine, whether such claim is based on contract,
warranty, negligence, or strict liability.
ISHIDAassumes no responsibility for the user's programming of this machine, or any consequence
thereof.
In no event shall ISHIDAbe responsible for warranty, repair, or other claims regarding the machine
unless ISHIDA’s analysis confirms that the machines were properly handled, stored, installed, and
maintained and not subject to contamination, abuse, misuse, or inappropriate modification or repair.
CHANGE IN SPECIFICATIONS
Machine specifications and accessories may be changed at any time due to improvements or other
reasons. Consult with your ISHIDArepresentative at any time to confirm the actual specifications of
the purchased machine.
ERRORS AND OMISSIONS
The information in this manual has been carefully checked and is believed to be accurate; however,
no responsibility is assumed for clerical, typographical or proofreading errors, or omissions.

NOTICES & PRECAUTIONS
ii UNI-3 Service Manual
PRECAUTIONS
PRECAUTION SYMBOLS
This machine is manufactured for use according to proper procedures by a qualified person and only
for the purposes described in this manual. The following conventions are used to indicate and classify
precautions depending on the level of danger, or seriousness of potential injury.Always heed the
information provided in this manual. Failure to heed precautions can result in personal injury or
property damage.
Indicates a potentially hazardous situation which, if not avoided, may result in
serious injury or death.Additionally, there may be significant property damage.
Indicates a potentially hazardous situation where, if not avoided, may result in
minor or moderate injury or in property damage.
Indicates reference information for operation.
Indicates the referred page for operation.

NOTICES & PRECAUTIONS
UNI-3 Service Manual iii
PRECAUTIONS FOR HANDLING
•Do not allow water or any liquids to come into
contact with the machine.
Doing so may result in fire or cause the machine to
break down.
•
Do not drop or apply a strong shock to the
machine.
Doing so may cause the machine to break down.
•Do not disassemble, modify, or attempt to repair
the machine.
Doing so may damage the original safety functions.
•Do not hold the connector cover when carrying
the machine.
Dropping the machine may result in injury or cause
the machine to break down.
•Do not hold the operation panel or weigh platter
when carrying the machine.
Doing so may cause the operation panel or the
platter to break down.
•
Do not hold the customer display the when
carrying the pole type machine.
Dropping the machine may result in injury or cause
the machine to break down.
•
Do not drop the cassette.
Dropping the cassette may result in injury or cause
the cassette to break down.

NOTICES & PRECAUTIONS
iv UNI-3 Service Manual
•Handle with care when removing or inserting
the cassette.
Careless cassette handling may result in injury or
cause the cassette to break down.
•Do not dispose of batteries with normal
household waste. Please obey your local
regulations when disposing of used batteries.

NOTICES & PRECAUTIONS
UNI-3 Service Manual v
PRECAUTIONS WHEN USING CLEANING FLUIDS
Use a soft cloth and a neutral detergent to clean the machine.
Do not use thinner, benzene, etc. Doing so may damage the original safety functions.
For some parts, use cleaning fluid (isopropyl alcohol).
Do not use cleaning fluid near fire as the fluid is flammable.

Do not use cleaning fluid in a poorly ventilated area. Always provide adequate
ventilation when cleaning.
Take the following actions in the event of an accident:
If the fluid gets in your eye
Immediately wash your eye(s) with water for at least 15 minutes, and consult your doctor.
If you wear contact lenses, remove and wash them.
If the fluid comes into contact with your skin
Immediately rinse the area of contact with water, and then wash with soap.
If you notice any skin abnormalities at the area of contact, or if any pain persists, consult
your doctor.
If the fumes of the fluid are inhaled
Immediately move the victim to an area where fresh air is available, and have the victim
lie down and keep warm.
If breathing becomes difficult or stops, provide artificial respiration and seek medical
attention immediately.
If the fluid is swallowed
Do not try to induce vomiting.
Do not give the victim anything to drink, and do not rinse the mouth.
If vomiting occurs naturally, have the victim lean forward to reduce risk of aspiration.

Keep the victim warm and seek medical attention.

TABLE OF CONTENTS
vi UNI-3 Service Manual
TABLE OF CONTENTS
Chapter 1 BASIC INFORMATION
1.1 OUTER DIMENSIONS FOR EACH TYPE.....................................................1-1
1.1.1 OUTER DIMENSIONS FOR BENCH TYPE..................................................1-1
1.1.2 OUTER DIMENSIONS FOR ELEVATED TYPE ...........................................1-2
1.1.3 OUTER DIMENSIONS FOR POLE TYPE.....................................................1-3
1.1.4 OUTER DIMENSIONS FOR HANGING TYPE .............................................1-4
1.2 SPECIFICATIONS.........................................................................................1-5
1.3 INSTALLATION ............................................................................................1-6
1.3.1 POWER SUPPLY ..........................................................................................1-6
1.3.2 PRECAUTIONS FOR INSTALLATION..........................................................1-7
Chapter 2 ASSEMBLY DRAWINGS
2.1 BENCH TYPE (L2) ........................................................................................2-1
2.2 BENCH TYPE (L1) ........................................................................................2-3
2.3 POLE TYPE (L2)...........................................................................................2-5
2.4 POLE TYPE (L1)...........................................................................................2-7
Chapter 3 BLOCK DIAGRAMS
3.1 BLOCK DIAGRAM (BENCH TYPE/ELEVATED TYPE/POLE TYPE) ...........3-1
3.2 BLOCK DIAGRAM (HANGING TYPE)..........................................................3-2
3.3 HARNESS LIST ............................................................................................3-3
Chapter 4 ELECTRICAL SIGNALS
4.1 MAIN BOARD ...............................................................................................4-1
4.2 A/D BOARD ..................................................................................................4-5
4.3 KEY BOARD PS-068 (BENCH/POLE/EV), PS-037(HANGING)....................4-5
4.4 L1 TYPE LCD DISPLAY BOARD..................................................................4-6
4.5 L2 TYPE LCD DISPLAY BOARD..................................................................4-6
4.6 WIRELESS LAN BOARD (PK-265) ..............................................................4-7
Chapter 5 MACHINE DISASSEMBLY
5.1 DISASSEMBLY PROCEDURE FOR EACH TYPE........................................5-1
5.1.1 CASE COVER................................................................................................5-1
5.1.2 SUPPORT AND LOAD CELL........................................................................5-3
5.1.3 MAIN BOARD.................................................................................................5-5
5.1.4 CASE COVER BOARD..................................................................................5-6

TABLE OF CONTENTS
UNI-3 Service Manual vii
5.1.5 POWER BOARD............................................................................................5-7
5.1.6 THERMAL HEAD...........................................................................................5-7
5.2 ELEVATED TYPE .........................................................................................5-8
5.2.1 POLE UNIT ...................................................................................................5-8
5.2.2 NOTE FOR SETUP OF ELEVATED TYPE (L2) .........................................5-10
5.3 DIFFERENTIAL POINTS FOR EACH COUNTRY.......................................5-11
Chapter 6 SETUP MODE.............................................................................. 6-1
Chapter 7ADJUSTMENT MODE.................................................................. 7-1

TABLE OF CONTENTS
viii UNI-3 Service Manual
MEMO

Chapter 1 BASIC INFORMATION
UNI-3 Service Manual 1-1
BASIC INFORMATION
1.1 OUTER DIMENSIONS FOR EACH TYPE
1.1.1 OUTER DIMENSIONS FOR BENCH TYPE
(unit : mm)
1

Chapter 1 BASIC INFORMATION
1-2 UNI-3 Service Manual
1.1.2 OUTER DIMENSIONS FOR ELEVATED TYPE
(unit : mm)

Chapter 1 BASIC INFORMATION
UNI-3 Service Manual 1-3
1.1.3 OUTER DIMENSIONS FOR POLE TYPE
(unit : mm)

Chapter 1 BASIC INFORMATION
1-4 UNI-3 Service Manual
1.1.4 OUTER DIMENSIONS FOR HANGING TYPE
(unit : mm)

Chapter 1 BASIC INFORMATION
UNI-3 Service Manual 1-5
1.2 SPECIFICATIONS
Items
Descriptions
Use conditions Temperature: -5 to 40°C
Humidity: 30 to 85%, Non condensing.
Power supply /
Power consumption For EU: AC220 – 240V / 0.5A For South Africa: AC220 – 240V / 0.5A
For USA: AC100 – 120V / 1.0A
For Argentina: AC220 – 240V / 0.5A
Weighing capacity
Scale interval
15 kg: 0 to 6/0.002 kg, 6 to 15/0.005 kg,30kg: 0.01kg
30 lb: 0 to 15/0.005 lb, 15 to 30/0.01 lb, 60lb: 0.02lb
Weighting accuracy
1/3000
Operator/Customer display L1:One line
16 segments x 23 digits, liquid crystal with backlight
L2:Two lines
<upper>192 x 16 dots
<lower>7 segments x 23 digits, liquid crystal with backlight
Printing method
Direct thermal method
Thermal head
2 inches (448dots) and 8 dots/mm
Printing speed 100mm/second
Note: The printing speed may vary according to label conditions.
Printing effective size
56mm
Label size Label width: 38mm to 64mm
Label length: 30mm to 175mm
Number of label cassettes
non cassette
Input/Output LAN 1 channel
USB 1 channel
Drawer 1 channel
Program store medium
Flash ROM (32M bytes)

Chapter 1 BASIC INFORMATION
1-6 UNI-3 Service Manual
1.3 INSTALLATION
1.3.1 POWER SUPPLY
It is strongly advised that the following safety measures must be observed to ensure the safe
operation of the machine:
•Read precaution instructions described in this manual before connecting the power plug
into the outlet.
•Always use a power supply with rated voltage. Never connect the machine power input with
an AC power supply exceeding the rated voltage. To avoid any potential electrical shock,
ensure that the protective ground wire is connected to the main grounding provision.
Using the machine outside of the rated voltage may result in machine failure or danger such as
electric shock.
•Prepare a dedicated power source.
A power supply that generates voltage variation may cause a malfunction.
•Do not stand on the power cable, and do not place anything heavy on the cable.
Doing so may damage the cable, resulting in accident or trouble.
•Disconnect power supply before servicing.
To ensure your personal safety, disconnect the power supply before servicing.
•Take precaution against residual electrical charge hazard.
Capacitors inside the machine may still hold an electrical charge even after power is disconnected.
•Do not remove covers or enclosures.
To avoid personal injury and shock, do not open or remove any covers or enclosures of the machine
unless specified in the manual.
•Do not perform unspecified maintenance.
For your personal safety, do not perform any maintenance procedures which are not specified in the
manual.

Chapter 1 BASIC INFORMATION
UNI-3 Service Manual 1-7
1.3.2 PRECAUTIONS FOR INSTALLATION
Do not install the machine in the following types of places:
•
Places subject to high
temperatures or high humidity
•Places exposed to direct
sunlight
•Places where water or other
liquids are easily spilled on the
machine
•
Places subject to excessive
vibration or unstable
foundations
•Places exposed to direct cold
air from air conditioners or
refrigerators
•Places where the floor or
foundation is unstable
•
Places subject to a lot of
dust or dirt
•Places with large voltage
fluctuations

Chapter 1 BASIC INFORMATION
1-8 UNI-3 Service Manual
MEMO

Chapter 2 ASSEMBLY DRAWINGS
UNI-3 Service Manual 2-1
ASSEMBLY DRAWINGS
2.1 BENCH TYPE (L2)
2

Chapter 2 ASSEMBLY DRAWINGS
2-2 UNI-3 Service Manual
Parts List (Bench Type L2)
NO. PARTS NAME Q'TY NO. PARTS NAME Q'TY
1 Sheet(Keysheet Protect BC-8000) 1 53 Spring(Bobbin) 1
2 Edit-Keysheet(UNI-3 EU) 1 54 Shaft(Bobbin) 1
3 Membrane Keypad(BC-8000) 1 55 Support(Sensor)-NL 1
4 PWB'PS-068'KEY(BC-8000) 1 56 Axile Bush(BC-6000-NL) 32
5 Case(UNI-3 UL) 1 57 Support(Roll)-NL 1
6 Platter(SUS304 BC-8000) 1 58 Cover(BC-6000-NL 1
7 Guard(Platter BC-8000) 1 59 BUSH'LEFT' 2
8 Cover-Customer(UNI-3 UL) 1 60 Axis01(BC-6000-NL) 1
9 Hens 1 61 Axis02(UNI-3) 1
10 Support-Poweroutlet(UNI-3 UL) 1 62 Shaft 1 1
11 Support(platter Astra) 1 63 FRAME'HEAD' 1
12 RUBBER PLATE SUPPORT 4 64 BRACKET'HEAD' 1
13
LOAD CELL
（
C2G1-25K-S18-25kg-350 NMB
）
1 65 Thermal head CHX56-9719A 1
14 BASE(Loadcell BC-8000) 1 66 BRACKET'LOCK' 1
15 HARNESS 'C3' POWER 1 67 BRACKET'PUSH' 1
16
POWER CORD HY-01/HY-02
（
3×0.75mm²×2m
）
USA
1 68 Axis-Hold(BC-6000 Printer) 1
17 SWITCH（BR-22C-11L-S）1 69 TEAR BAR 1
18 Nameplate(UNI-3 L2BENCH 30lb USA) 1 70 Bracket(Sensor BC-6000-NL) 2
19 Connector(UNI-3 UL) 1 71 Spring Coil 1 2
20 PWB'PS-990G-2'MAIN 2M(UNI-3) 1 72 Spring Coil 2 2
21 PWB, PS-067, A/D 1 73 LABEL SENSOR Assy 1
22 Cover(Base Port BC-8000) 1 74 HARNESS 'S2' THERMAL HEAD 1
23 BASE02(BC-8000) 1 75 HARNESS 'C4' POWER 1
24 Bracket(Display-L1 BC-8000)
2
76 HARNESS 'S2' DISPLAY 1
25 DISPLAY 'LCD' DOT(SMMD0202-A-00-SPC) 2 77 HARNESS 'S2' LCD 1
26 Cover-PrinterFront(UNI-3 UL) 1 78 HARNESS 'S2' keyboard 1
27 LEG
4
79 HARNESS 'S2' POWER 1
28 BASE01(BC-8000) 1 80 BREAKET(FOR PRINTER) 1
29 POWER SUPPLY LSF10024 1 81 RESISTOR ASSY '' 1
30 Cover-Printerside(UNI-3 UL) 1 82 Bracket(Magnet) 1
31 Printer Nameplate(NL)(English) 1 83 LABEL GND CORD 1
32 HINGE(Plastic) 2 84 BUSH(CSB-EPBF-0608-04) 1
33 Displaysheet(UNI-3 L2B CUST-M30lb USA) 1 85 Bracket(Cutter) 1
34 Displaysheet(UNI-3 L2 OP-M30lb USA) 1 86 Screw(UNI-3 Cutter) 2
35 MOTOR'STEPPING',49P048L0-00702 1 87 ZCAR1518-0730 1
36 Bracket Motor(BC-8000) 1 89 Bracket(Peel Sensor AC-4000B) 1
37 Bracket01(Printer-Rewind BC-8000) 1 90 Peel Sensor 1
38 Axis-Rewind(BC-8000) 1 91 HARNESS PEEL SENSOR L-150mm 1
39 BUSH(CSB-EPBF-0507-04) 1 92 BUSH 1
40 OLTC6-1500B 1 93 Shaft(POM) 1
41 Gear-Rewind(BC-8000) 1 94 Breaket of peel off 1
42 3M-HTD-330 1 95 Breaket of Fixed 1
43 Gear Dual(BC-8000) 1 96 Lable Guide 1
44 Gear-Driver(BC-8000) 1
45 Cover(Gear-Driver BC-8000) 1
46 ROLLER'RUBBER' (BC-4000 NL) 1
73 LABEL SENSOR Assy
47 Frame(Printer BC-8000) 1 73.1 HARNESS,C5,LABEL SENSOR
48 LEVEL UNIT 07901 1 73.2 LED IR928-6C(E4 E5 E6)
49 HOLDER'GUIDE'LABEL 1 73.3 PHOTO TR PT928-6B(6-1 6-2 7-1)
50 LEVER'GUIDE'LABEL 1
51 HOLDER'LABEL' 1
52 Bracket(Bobbin) 1
