Isotra Cetta 50 User manual

TECHNICAL MANUAL
EXTERIOR BLINDS
EN

A mark symbolising long tradition, inestimable investment into development, the use of quality
materials, state-of the-art technologies, reliable work from hundreds of employees and numerous other
parameters, constituting one entity – the nal product of ISOTRA.
Table of contents – Exterior blinds
CE Product Marking 3
Basic Technical Specication 7
Product Tolerances 8
Calculation of Solar and Light Transmittance 9
Wound Up Height 11
Cetta 50 13
Cetta 50 – cord 14
Cetta 50 – handle 14
Cetta 50 – motor 18
Cetta 65, 80, 80 Slim, 60 Flexi, 80 Flexi 23
Cetta 65, 80 – handle 24
Cetta 65, 80 – motor 26
Cetta 60 Flexi 28
Cetta 80 Flexi 30
Cetta 100 Flexi 32
Setta 65, 90 49
Setta 65, 90 – handle 50
Setta 65, 90 – motor 52
Zetta 70, 90 59
Zetta 70, 90 – handle 60
Zetta 70, 90 – motor 62
Shapes of Exterior Blind Slats 72
Control 77
Control - handle 77
Control – motor 80
Guidance 83
Guidance - wire 84
Guidance – guiding channel 86
Guiding Channel Holders 89
Holders for Exterior Blinds 96
Types of Front Covers 104
Measurement and Assembly 108
Alternative Designs of Exterior Blinds 115
DUO System 116
Atypical Designs of Exterior Blinds 117
Connected Exterior Blinds 118
Double Head Rail Exterior Blinds 119
Exterior Blind Windstabil 120
Solar power supply of exterior blinds 121
Special Designs 122
Exterior blinds Titan 90 123
Sloped Blind Cetta 80F TE 132
Facade Exterior Blinds 136
Self-Supporting Blinds STS 142
Self-Supporting Blinds VIVA 143
Self-Supporting Blinds BRAVO 150
Safety blinds EMERGENCY 154
Lintel Exterior Blinds HELUZ 155

EXTERIOR BLINDS
3
All exterior blinds of ISOTRA a.s.
comply with the standard ČSN EN 13659+A1:2009
European Marking of CE Compliance – marking on products
CE Product Marking
The wind resistance tests were conducted by Centrum stavebního inženýrství, a.s., Zlín, according to standard ČSN EN 13659+A1:2009.
Wind Resistance of Exterior Blinds
Cetta 50 - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 47362514
Max. wind speed vmax (km/h) 61 49 38 28
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 500 < L <= 5 000 5 000 < L <= 5 500 5 500 < L <= 5 800 5 800 < L <= 6 000
Wind resistance class 03020100
Max. wind speed vmax (km/h) 19 11 5 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Cetta 50 - wire
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L < 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 1403020100
Max. wind speed vmax (km/h) 28 19 11 5 1
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm) L < 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 000 < L <= 4 500
Wind resistance class 0302010000
Max. wind speed vmax (km/h) 19 11 5 1 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Cetta 65 - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 47362514
Max. wind speed vmax (km/h) 61 49 38 28
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 500 < L <= 5 000 5 000 < L <= 5 500 5 500 < L <= 5 800 5 800 < L <= 6 000
Wind resistance class 03020100
Max. wind speed vmax (km/h) 19 11 5 1
Max. eective height wing Hmax = 4000mm
Additional thermal
resistance ΔR
0,08 (m2.K/W)
Total solar energy tran-
smittance gtot
0,032 - 0,094 (according to the selected slat color)*
Cetta 65 - wire
Essential characteristics Performance
Wind resistance Width of construction hole L (mm)
L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 36251403020100
Max. wind speed vmax (km/h) 49 38 28 19 11 5 1
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm)
L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Wind resistance class 25140302010000
Max. wind speed vmax (km/h) 38 28 19 11 5 0 0
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
ISOTRA a.s.
Bílovecká 2411/1, 746 01 Opava
12
EN 13659:2015
ZETTA 90
CPR 008/2017
Exterior sun visor
Wind resistance: 0 – 4
Additional thermal resistance R:0,08 m2.K/W
Total solar energy transmittance gtot: 0,032 - 0,094
Note: Pattern of CE label

4
Setta 65 - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 58473625
Max. wind speed vmax (km/h) 74 61 49 38
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 500 < L <= 5 000 5 000 < L <= 5 500 5 500 < L <= 5 800 5 800 < L <= 6 000
Wind resistance class 14030201
Max. wind speed vmax (km/h) 28 19 11 5
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Setta 65 - wire
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 362514030201
Max. wind speed vmax (km/h) 49 38 28 19 11 5
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000
Wind resistance class 251403020100
Max. wind speed vmax (km/h) 38 28 19 11 5 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Setta 90 - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 58473625
Max. wind speed vmax (km/h) 74 61 49 38
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 500 < L <= 5 000 5 000 < L <= 5 500 5 500 < L <= 5 800 5 800 < L <= 6 000
Wind resistance class 14030201
Max. wind speed vmax (km/h) 28 19 11 5
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Setta 90 - wire
Essential characteristics Performance
Wind resistance Width of construction hole L (mm)
L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 3625140302010 0
Max. wind speed vmax (km/h) 49 38 28 19 11 5 1
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm)
L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Wind resistance class 2514030201000 0
Max. wind speed vmax (km/h) 38 28 19 11 5 1 0
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Zetta 70 - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 47362514
Max. wind speed vmax (km/h) 61 49 38 28
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 500 < L <= 5 000 5 000 < L <= 5 500 5 500 < L <= 5 800 5 800 < L <= 6 000
Wind resistance class 03020100
Max. wind speed vmax (km/h) 19 11 5 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*

EXTERIOR BLINDS
4 5
Zetta 70 - wire
Essential characteristics Performance
Wind resistance Width of construction hole L (mm)
L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 36251403020100
Max. wind speed vmax (km/h) 49 38 28 19 11 5 1
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm)
L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Wind resistance class 25140302010000
Max. wind speed vmax (km/h) 38 28 19 11 5 1 0
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Zetta 90 - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 1 000 1 000 < L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 69584736
Max. wind speed vmax (km/h) 88 74 61 49
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 000 < L <= 4 500 4 500 < L <= 5 000 5 000 < L <= 5 500 5 500 < L <= 6 000
Wind resistance class 25140302
Max. wind speed vmax (km/h) 38 28 19 11
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Zetta 90 - wire
Essential characteristics Performance
Wind resistance Width of construction hole L (mm)
L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 36251403020100
Max. wind speed vmax (km/h) 49 38 28 19 11 5 1
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 4 800 4 800 < L <= 5 000 5 000 < L <= 6 000
Wind resistance class 25140302010000
Max. wind speed vmax (km/h) 38 28 19 11 5 1 0
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Cetta 60 Flexi - wire
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 800 800 < L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4000 4000 < L <= 4 500 4 500 < L <= 4 800
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 362514030201
Max. wind speed vmax (km/h) 49 38 28 19 11 5
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm) L <= 800 800 < L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4000 4000 < L <= 4 500 4 500 < L <= 4 800
Wind resistance class 251403020100
Max. wind speed vmax (km/h) 38 28 19 11 5 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (dle zvolené barvy lamely)*
Cetta 60 Flexi - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 1 000 1 000 < L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 473625 1 4
Max. wind speed vmax (km/h) 61 49 38 28
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 000 < L <= 4 500 4 500 < L <= 5 000 5 000 < L <= 5 500 5 500 < L <= 6 000
Wind resistance class 030201 0 0
Max. wind speed vmax (km/h) 19 11 5 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (dle zvolené barvy lamely)*

6
Cetta 80 - wire
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 0003 000 < L <= 4 0004 000 < L <= 4 5004 500 < L <= 4 8004 800 < L <= 5 0005 000 < L <= 6 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 36251403020100
Max. wind speed vmax (km/h) 49 38 28 19 11 5 1
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 0003 000 < L <= 4 0004 000 < L <= 4 5004 500 < L <= 4 8004 800 < L <= 5 0005 000 < L <= 6 000
Wind resistance class 25140302010000
Max. wind speed vmax (km/h) 38 28 19 11 5 1 0
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Cetta 80 - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 1 000 1 000 < L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 69584736
Max. wind speed vmax (km/h) 88 74 61 49
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 000 < L <= 4 500 4 500 < L <= 5 000 5 000 < L <= 5 500 5 500 < L <= 6 000
Wind resistance class 25140302
Max. wind speed vmax (km/h) 38 28 19 11
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Cetta 80 Flexi - wire
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 2 500 2 500 < L <= 3 000 3 000 < L <= 3 400 3 400 < L <= 3 800 3 800 < L <= 4 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 251403020100
Max. wind speed vmax (km/h) 38 28 19 11 5 1
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm) L <= 2 000 2 000 < L <= 2 500 2 500 < L <= 3 000 3 000 < L <= 3 400 3 400 < L <= 3 800 3 800 < L <= 4 000
Wind resistance class 140302010000
Max. wind speed vmax (km/h) 28 19 11 5 1 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Cetta 80 Flexi - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 25140302
Max. wind speed vmax (km/h) 38 28 19 11
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 500 < L <= 5 000 5 000 < L <= 6 000
Wind resistance class 0100
Max. wind speed vmax (km/h) 5 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Cetta 100 Flexi - wire
Essential
characteristics
Performance
Wind resistance Width of construction hole L (mm) L <= 800 800 < L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4000 < L <= 4 500 4 500 < L <= 4 800
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 362514030201
Max. wind speed vmax (km/h) 49 38 28 19 11 5
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm) L <= 800 800 < L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4000 4000 < L <= 4 500 4 500 < L <= 4 800
Wind resistance class 251403020100
Max. wind speed vmax (km/h) 38 28 19 11 5 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*

EXTERIOR BLINDS
6 7
Basic Technical Specication
Engineering Limit Values
Type
Width (mm) Height (mm) Area (m2)
Guidance Slat Weight
(kg per m2)
Blind Weight
(kg per m2)
Holder
Weight
(kg per m2)
6 Nm Motor
Weight (kg)
min. max. max. Cord Handle Motor
Cetta 50 400/600** 3150 3000 6 8 10 wire / channel 0,76 2,1 0,087
1,84
Cetta 60 Flexi 600 4000 4000 - 8 16 wire / channel 1,31 3,30
Cetta 65 600 6000* 4000 - 8 24 wire / channel 1,44 3,42
0,35
Setta 65 600 6000* 4000 - 8 24 wire / channel 1,59 3,57
Cetta 80 Flexi 600 4000 4000 - 8 16 wire / channel 1,12 3,55
Cetta 100 Flexi 600 4000 4000 - 8 16 wire / channel 1,36 3,55
Cetta 80
Cetta 80 -Slim
600 6000* 4000
- 8 24 wire / channel 1,54 3,47
Zetta 70 - 8 18 wire / channel 1,60 3,55
Zetta 90 - 8 24 wire / channel 1,56 3,53
Setta 90 - 8 24 wire / channel 1,66 3,63
Titan 90 600 2800 4000 - - 8 wire / channel 2,1 - -
Note: Two guidance types (wire / guiding channel) can be combined, or Venetian blind with no guidance can be chosen, for some Venetian blind types.
*Note: The wider the blind, the lower its wind resistance class - see“Wind resistance of exterior blinds”, page 3-4.
** motor
Warning: Inclined slat operation cannot be avoided with small width.
Titan 90
Essential characteristics Performance
Wind resistance Class 6 (for all dimensions)
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Sloped blind Cetta 80F TE
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 2 500
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 2514
Max. wind speed vmax (km/h) 38 28
Hmax (mm) 2500 2500
Wind resistance class 1403
Max. wind speed vmax (km/h) 19 11
Hmax (mm) 4000 4000
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
VIVA
Essential characteristics Performance
Wind resistance Class 3,4 (according to the slat type)
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Cetta 100 Flexi - channel
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 1 000 1 000 < L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 47362514
Max. wind speed vmax (km/h) 61 49 38 28
Max. eective height wing Hmax = 4000mm
Width of construction hole L (mm) 4 000 < L <= 4 500 4 500 < L <= 5 000 5 000 < L <= 5 500 5 500 < L <= 6 000
Wind resistance class 03020100
Max. wind speed vmax (km/h) 19 11 5 1
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*
Windstabil (Z90, C80, S90)
Essential characteristics Performance
Wind resistance Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 5 000 5 000 < L <= 5 400
Standard EN/Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort 13659 Beaufort
Wind resistance class 584736251403
Max. wind speed vmax (km/h) 74 61 49 38 28 19
Max. eective height wing Hmax = 2500mm
Width of construction hole L (mm) L <= 2 000 2 000 < L <= 3 000 3 000 < L <= 4 000 4 000 < L <= 4 500 4 500 < L <= 5 000 5 000 < L <= 5 400
Wind resistance class 473625140302
Max. wind speed vmax (km/h) 61 49 38 28 19 11
Max. eective height wing Hmax = 4000mm
Additional thermal resistance ΔR 0,08 (m2.K/W)
Total solar energy transmittance gtot 0,032 - 0,094 (according to the selected slat color)*

8
PRODUCT TOLERANCES
Manufacturer: ISOTRA a.s., Bílovecká 2411/1, 746 01 Opava, ID: 47679191
Product: EXTERNAL BLINDS
The review should help you to recognize the permissible limits of compliance and incompliance. At the same time the sheet will
help you with reasoning as regards any unjust claims of the clients.
External blinds comprise of many metal and textile elements with various material features and production tolerances. Despite
the optimally selected products, deviations from ideal function may occur even in case of new installation due to the product
tolerances.
The external blinds are permanently exposed to the eect of weather, particularly temperature, moisture content, wind, and
contamination. They have a great eect on the function and appearance of external blinds.
The basic function of the blinds is fullled when the slats are turning, and when the light is not directly focused on the glazing
in closed state.
The deviations from the table values can be corrected by our technicians within a specic scope.
Please, be aware:
The specied limit values are created based on the actual state of technology, respective technical standards, and based on
many years of experience.
The table values are valid only for the external blinds within the permitted production dimensions available in our actual techni-
cal catalogue.
Feature Description of deviation Tolerance
1 Blind width
Blind width up to 2000 mm max 3mm
Blind width from 2000mm to 4000mm max 4mm
Blind width over 4,000mm max 5mm
2 Blind height
Blind height up to 1,500mm max 4mm
Blind height from 1500 to 2500mm max 6mm
Blind height over 2,500mm max 10mm
3 Packet height Packet height up to 2,500mm +/-0.5% height EL
Packet is higher than 2,500mm +/-1 % height EL
4 Dierence of the packet height Between individual packets of the same height max 20mm
5The packet parallelism in the upper
position
The height dierence of the packets at height up to 3,500mm +/- 30mm
The height dierence of the packets at height over 3,500mm +/- 40mm
6 Tolerance for lamellas
Permitted deviation for twisting and longitudinal bending – lamella
width up to 1 m max 3mm
Permitted deviation for twisting and longitudinal bending – lamella
width up to 2m max 4mm
Permitted deviation for twisting and longitudinal bending – lamella
width up to 3m max 5mm
Permitted deviation for twisting and longitudinal bending – lamella
width up to 4m max 6mm
Permitted deviation for twisting and longitudinal bending – lamella
width up to 5m max 7mm
Permitted deviation for twisting and longitudinal bending – lamella
width over 5m max 10mm
Permitted deviation for longitudinal bending – lamella width up to 1 m max 2mm
Permitted deviation for longitudinal bending – lamella width up to 2m max 3mm
Permitted deviation for longitudinal bending – lamella width up to 3m max 4mm
Permitted deviation for longitudinal bending – lamella width up to 4m max 5mm
Permitted deviation for longitudinal bending – lamella width up to 5m max 6mm
Permitted deviation for longitudinal bending – lamella width over 5m max 10mm
7 Bottom slat exion
In the upper position at width over 800mm max 15mm
In the upper position at width under 800mm max 30mm
In the lower position +/- 15mm/m
8 Oblique operation of the lower slat Deviation from the balance up to height 3500mm +/- 10mm
Deviation from the balance over height 3500mm +/-15mm
9 Oblique run of packet Ladder braiding between slats permissible
10 Packet operation length Permanent length of the motor operation max 4min
11 Tex During the operation, visible tex location on lamellas permissible
12 Light permeability – as per EN 14501 In closed state, there is no horizontal view from outside inside. permissible
In closed state, there is no horizontal view from inside outside. permissible
13 Acoustics The operation and disconnection sounds result from technical solutions. permissible
Noise as per the wind force and lamella position. permissible
14 Tolerance for front covers For input values a, b, c, d +/- 2 mm

EXTERIOR BLINDS
8 9
Calculation of solar and light transmittance
The standard CSN EN 13363-1+A1 Solar protection devices combined with glazing - Calculation of solar and light
transmittance denes a simplied method of calculation of a sun protection device combined with glazing based on
thermal transmittance and total solar transmittance through glazing, and on light transmittance and reectivity of a sun
protection device for the evaluation of total solar transmittance.
The method is applicable to any type of sun protection devices in parallel with glazing, such as shutters or blinds. Sun
protection devices can be installed inside a protected room, outside or in a gap between double glazing. The method is
applicable in cases when total solar transmittance through glazing ranges between 0.15 and 0.85. It is anticipated that roller
shutters have to be fastened to prevent direct solar radiation. It is presumed that in exterior sun protection devices and
in-built sun protection installations the space between sun protection devices and the glazing is not ventilated, whilst it is
ventilated in interior sun protection installations.
Basic concepts used
Transmittance - radiation that is transmitted through window into an interior; radiation transmittance factor τe achieves
values between 0 and 100; i.e. 0 to 1.
Reection (take-o) - shine that is returned to the external area by window, coecient of returned shine ρeacquires the
values from 0 to 100 % that is 0 to 1.
Absorption - radiation that is absorbed by window and increases its temperature; the radiation factor αe achieves values
between 0 and 100; i.e. 0 to 1.
Emissivity - ability to radiate heat εe; it applies that ε = α
As result, the following equation applies: τe+ ρe+ αe= 100 %; or 1.
Value of factor g for the calculation is usually dened by the manufacturer of window panes or windows.
gtot - total solar transmittance factor with solar protection.
Fc- reduction coecient. The value of the coecient ranges between 0 (theoretically best protection from solar radiation) and
1 (zero protection from solar radiation; in that case it applies that: g = gtot).
Type and specication of glazing:
Insulated transparent glazing (ČSN EN 14501)
Thermal transmittance Ug2,90 W/(m2.K)
Overall solar transmittance g0,76
Exterior shading
G=(1/Ug+1/G1+1/G2)-1
G15,00 W/(m2.K)
G210,00 W/(m2.K)
G1,55 W/(m2.K)
Interior shading
G=(1/Ug+1/G2)-1
G230,00 W/(m2.K)
G2,64 W/(m2.K)
Calculation gtot:
a) Exterior shading: gt= τe*g+αe*G/G2+τe*(1-g)*G/G2
b) Interior shading: gt= g(1-g*ρe-αe*G/G2)
Example of calculation n.1:
Exterior blind Iostra, white aluminium colour (RAL 9006) + insulated transparent glazing
1. Measured values:
Transmittance τe0,00
Reectance ρe0,55
Absorption capacity αe0,45

10
Solar and light transmittance according to CSN EN 13363-1+A1 for selected products of ISOTRA a.s.
2. Values as per ČSN EN 13363-1+A1
Thermal transmittance through glass Ug2,90 W/(m2.K)
Overall solar transmittance through glass
g0,76
G15,00 W/(m2.K)
G210,00 W/(m2.K)
3. Calculation
G= (1/Ug+1/G1+1/G2)-1 = (1/2,9+1/5+1/10)-1 = 1,55
gtot = τe*g+αe*G/G2+τe*(1-g)*G/G2
gtot = 0*2,9+0,45*1,55/10+0*(1-0,76)*1,55/10 = 0,070
Fc= gtot/g = 0,07/0,76 = 0,092
Example of calculation n. 2:
Exterior blind Isotra, white aluminium colour (RAL 9006) + insulated transparent glazing, angle 45°
1. Calculation of transmittance, reectance and absorptance:
Transmittance: τe= 0,65*τe+0,15*αe= 0,65*0+0,15*0,45 = 0,07
Reectance: ρe= ρe*(0,75+0,7*τe) = 0,55*(0,75+0,7*0) = 0,41
Absorption capacity: αe= 1-τe–αe= 1-0,07-0,41= 0,52
2. Valoues as per ČSN EN 13363-1+A1
Thermal transmittance through glass Ug2,90 W/(m2.K)
Overall solar transmittance through glass g0,76
G15,00 W/(m2.K)
G210,00 W/(m2.K)
3. Calculation
G = (1/Ug+1/G1+1/G2)-1 = (1/2,9+1/5+1/10)-1 = 1,55
gtot = τe*g+αe*G/G2+τe*(1-g)*G/G2= 0,137
Fc= gtot/g = 0,137/0,76 = 0,18
Slat colour Reection (%) Absorption (%) gtot Fc
RAL 7038 39 61 0,064 0,107
RAL 7048 34 66 0,069 0,114
RAL 9010 74 26 0,034 0,057
RAL 9016 76 24 0,032 0,054
RAL 9006 58 42 0,048 0,080
RAL 8014 8 92 0,091 0,152
RAL 6005 22 78 0,079 0,132
RAL 7016 17 83 0,083 0,139
RAL 9002 62 38 0,044 0,074
RAL 9007 39 61 0,064 0,107
RAL 1015 66 34 0,041 0,068
W210 31 69 0,071 0,119
DB 703 23 77 0,078 0,130
DB 702 29 71 0,073 0,122
VSR 780 22 78 0,079 0,132
RAL 3000S 42 58 0,048 0,08
RAL 3004 35 65 0,068 0,113
RAL 5002 32 68 0,070 0,117
RAL 5014 39 61 0,064 0,107
RAL 7022 18 82 0,083 0,138
RAL 7035 51 49 0,054 0,090
RAL 9005 5 95 0,094 0,156
*valid for glazing with parameters g = 0,59, Ug = 1,2 W/m2K

EXTERIOR BLINDS
10 11
Wound Up Venetian Blind Height Including
Head Rail and Bottom Rail without Blind holder
Gap between the lower edge of the channel
and the rst slat when closed.
Cetta 60 Flexi 32 - 92mm
Cetta 65 32 - 92 mm
Cetta 80 35 - 103 mm
Cetta 80 Flexi 38 - 106 mm
Cetta 100 Flexi 45 - 130 mm
Zetta 70 44 - 104 mm
Zetta 90 62 - 142 mm
Setta 65 44 - 104 mm
Setta 90 66 - 152 mm
Titan 90 60 - 150 mm
The values fall within the manufacturing
tolerance of the blind height.
Blind Type
Control - Handle Coiling Height Based on Blind Height (mm)
500 600 700 800 900 1000 1100 1200 1300 1400 1500 1600 1700 1800
Cetta 50 - channel 130 135 145 160 170 180 190 200 210 220 230 240 250 265
Cetta 50 - wire 85 90 95 100 100 105 110 110 115 120 120 125 125 130
Cetta 65 135 145 155 160 165 175 185 190 195 205 215 220 230 235
Cetta 60 Flexi - channel 125 130 135 140 145 150 155 160 170 170 175 180 185 190
Cetta 60 Flexi - wire 115 120 120 125 130 135 135 140 145 145 150 150 155 160
Cetta 80 Flexi - channel 110 110 115 115 120 125 125 130 130 135 135 140 145 145
Cetta 80 Flexi - wire 110 115 115 120 120 125 130 130 135 135 140 140 145 145
Cetta 100 Flexi - channel 120 120 125 130 130 135 135 140 145 150 155 155 160 160
Cetta 100 Flexi - wire 110 110 115 115 115 120 120 120 125 130 130 130 135 135
Cetta 80 130 140 145 155 155 165 170 180 185 190 195 205 210 215
Cetta 80 Slim 125 135 135 145 150 155 160 165 170 180 180 190 195 195
Setta 65 135 145 150 160 170 175 185 190 195 205 215 220 230 240
Setta 90 125 135 140 145 150 155 165 170 170 175 185 190 195 200
Zetta 70 135 140 145 155 165 165 175 185 190 195 205 210 220 225
Zetta 90 125 135 140 145 150 160 165 170 170 180 185 190 195 205
Titan 90 (Motor control) 150 158 165 180 188 195 203 218 225 233 240 255 263 270
Blind Type
Control - Handle Coiling Height Based on Blind Height (mm)
1900 2000 2100 2200 2300 2400 2500 2600 2700 2800 2900 3000 3100 3200
Cetta 50 - channel 275 280 295 305 315 325 335 350 355 365 380 385 400 410
Cetta 50 - wire 135 140 145 145 150 155 160 170 175 180 185 195 200 205
Cetta 65 245 250 260 265 270 280 290 300 300 310 320 325 335 340
Cetta 60 Flexi - channel 195 205 210 215 220 225 230 235 240 245 250 255 260 265
Cetta 60 Flexi - wire 160 165 170 175 175 180 185 185 190 190 195 200 200 205
Cetta 80 Flexi - channel 150 155 155 160 160 165 165 170 175 175 180 185 185 190
Cetta 80 Flexi - wire 150 150 155 155 160 160 165 165 170 170 175 175 180 180
Cetta 100 Flexi - channel 165 170 170 175 180 180 185 190 195 195 200 200 205 210
Cetta 100 Flexi - wire 135 140 140 140 145 145 150 150 150 155 155 155 160 160
Cetta 80 225 230 235 240 250 255 265 265 275 280 290 295 300 305
Cetta 80 Slim 205 205 215 220 225 230 235 240 250 250 260 265 270 275
Setta 65 245 250 260 265 275 285 290 300 305 310 320 330 335 345
Setta 90 205 215 215 220 225 235 240 245 250 255 260 265 270 275
Zetta 70 230 240 245 250 260 270 270 280 290 295 300 310 315 325
Zetta 90 210 215 215 225 230 235 240 250 255 260 260 270 275 280
Titan 90 (Motor control) 278 293 300 308 315 330 338 345 353 368 375 383 390 405
Wound Up Height

12
Blind Type
Control - Handle Coiling Height Based on Blind Height (mm)
3300 3400 3500 3600 3700 3800 3900 4000 4100 4200 4300 4400 4500 4600
Cetta 50 - channel 420 430 440 450 460 470 485 495 - - - - - -
Cetta 50 - wire 210 215 215 220 225 230 235 235 - - - - - -
Cetta 65 350 355 365 375 380 385 395 405 415 420 430 435 445 455
Cetta 60 Flexi - channel 270 275 280 285 290 295 305 305 310 315 320 325 330 340
Cetta 60 Flexi - wire 210 210 215 220 225 225 230 230 235 240 240 245 250 250
Cetta 80 Flexi - channel 190 195 195 200 205 205 210 215 220 220 225 225 230 235
Cetta 80 Flexi - wire 185 185 190 190 195 195 200 200 205 205 210 215 215 220
Cetta 100 Flexi - channel 210 215 220 225 225 230 235 235 240 245 245 250 250 255
Cetta 100 Flexi - wire 160 165 165 170 170 175 175 175 180 180 180 185 185 185
Cetta 80 315 320 325 335 340 345 350 360 365 370 380 385 390 400
Cetta 80 Slim 280 285 290 295 300 305 310 320 315 320 330 335 340 350
Setta 65 355 360 365 375 380 390 400 405 410 415 420 430 440 445
Setta 90 285 290 295 300 305 310 315 320 320 325 330 340 345 350
Zetta 70 330 335 345 350 355 365 375 375 380 390 395 400 410 415
Zetta 90 285 295 300 305 305 315 320 325 325 330 335 345 350 355
Titan 90 (Motor control) 413 420 428 443 450 458 465 480 - - - - - -
Blind Type
Control - Handle Coiling Height Based on Blind Height (mm)
4700 4800 4900 5000 5100 5200 5300 5400 5500 5600 5700 5800 5900 6000
Cetta 50 - channel --------------
Cetta 50 - wire --------------
Cetta 65 460 470 480 485 490 500 510 515 525 530 540 550 555 560
Cetta 60 Flexi - channel 345 350 355 360 365 370 375 380 385 390 395 400 405 410
Cetta 60 Flexi - wire 255 260 265 265 270 275 275 280 280 285 290 290 295 300
Cetta 80 Flexi - channel 235 240 245 250 250 255 255 260 260 265 270 275 275 280
Cetta 80 Flexi - wire 225 230 235 235 240 240 245 250 250 255 255 260 265 270
Cetta 100 Flexi - channel 260 265 265 270 275 275 280 285 285 290 290 295 300 305
Cetta 100 Flexi - wire 190 190 195 195 195 200 200 200 205 205 205 210 210 215
Cetta 80 405 410 420 425 430 435 445 450 455 465 470 475 485 490
Cetta 80 Slim 355 360 370 375 380 385 395 400 405 415 420 425 425 430
Setta 65 455 465 475 480 485 495 505 510 520 525 535 545 550 555
Setta 90 360 365 370 375 380 385 390 400 405 410 415 420 425 430
Zetta 70 425 430 440 445 450 460 465 470 480 485 495 500 505 510
Zetta 90 360 370 375 380 385 390 400 405 410 415 420 425 430 435
Titan 90 (Motor control) --------------
Note: For Cetta 50 (motor), the coiling height will change by +40 mm. For Cetta 65, 80, 80-Flexi and Zetta 70 a 90 (motor), the coiling height will change by +20 mm.
The coiling heights are approximate values which can deviate positively or negatively for technical reasons.

EXTERIOR BLINDS
12 13
Suitable for shading small areas
Optional assembly in interior
Electrical control option
Cetta 50
SLAT SHAPE

14
Specication Cetta 50
Head Rail
Bottom Rail Slat
Side Guidance
Ladder Textile
Band Assembly
Cord/Handle Motor Motor Steel Wire Guiding
Channel
Commercial Name
Dimension (mm)
Material
P 528
40 x 40
F440
P 001
56 x 58
Fe
P 001/2
58 x 60
Al
P 508
49 x 12
Fe
P 529
0,23 x 50
Al
P 501
ø 2,2
Fe/PVC
See Chapter
“Guidance” for
guiding channel
alternatives
P 509
42 x 54
PES
P 531
6 x 0,28
PES
See chapter “As-
sembly”
Color Standard:
RAL 9003 White
RAL 9006 Silver
galvanized (Fe prol); natural (Al prol)
Other RAL colors sprayed, DECORAL
Galvanized steel plate or anodized aluminum for motor alternative.
According to
current ISOTRA
a.s. scheme
grey Basic design –
anodized
Varnished in RAL
colors
Extra charge:
other RAL,
DECORAL
grey
white
grey
We do not make atypical designs.
Standard Dimensions Width (mm) Height (mm) Guaranteed Area (m2)
min. max min. max max.
400
400
600
3500
3500
3500
500
500
500
3000
3000
3000
6 (Cord control)
8 (Handle control)
10 (Motor control)
Control
Used for pulling the blind up and down and setting the slat
Cord - a plastic cord bushing is installed on the window frame from the interior, which protects the cord against abrasion. The
head rail is shortened by 20 mm against the required length from the control side in order to facilitate the cord gearing instal-
lation (color: black-white).
Handle - The control wand mechanism is protracted to the interior at the angle of 45° and 90° using a bushing and a hexagonal wand
(color design: white / anodized).
Motor - Optional control using the sun / wind sensor or by a remote control or switch. One motor can control even more Venetian
blinds simultaneously based on blind dimensions. The motor is then installed on one Venetian blind of the group.
Cetta 50 - cord
Basic Product Specication
CETTA 50 - CORD 2-00152-XXXX-G
10
P 528
20
P 508
30
P 225/1
40
P 241
51
P 227
60
P 526
70
P 530
75
IL 126/1
80
P 529/1
240
P 532
P 527
171
82
P 506
100
P 531
110
P 509/1
120
P 525/1
143
P 505
160
P 502/1
165
P 514
230
243
YX 00041
241
D
C
B
A
2
1
5
6
6
5
2
3
4
1
D
C
A
B
2-00152-XXXX CETTA 50 - ŠŇŮRA

EXTERIOR BLINDS
14 15
Cetta 50 - cord (2-00152-5001)
Position Item name Business name Drawing number
10 Head rail 40x40 P 528 6-001277-xxxx
20 Bottom rail - 50 mm P 508 6-001230-xxxx
30 Bearing C50 - without ball cord P 225/1 2-00365-0000
40 End stop 40x40 P 241 2-00049-0000
51 Gearing 40x40 - plastic - cord P 227 2-00133-XXXX
60 Ladder connector P 526 6-001275-0000
70 Tilt rod - hexagonal 6 mm P 530 6-001278-0000
75 Hexagonal metal ring P 529/1 6-010981-0000
80 Al slat See Slats
80 End guidance "C" L+R P 033/2 2-00047-xxxx
80 End guidance - metal "C" - right P 033/22 7-301466-PU19
80 End guidance - metal "C" - left P 033/21 7-301467-PU19
82 Pad for slat and wire P 506 3-00170-0000
100 Texband P 531 6-001284-xxxx
110 Ladder C50 P 509/1 6-010452-xxxx
120 Bottom rail plug P 525/1 6-001273-0001
143 Fixed bracket for slat 50 mm P 505 6-001226-0000
160 Bottom rail cover C50 P 502/1 6-004280-XXXX
165 Side head rail cover P 514 6-001245-0000
171 Guidance - wire/guiding channel + holder See Guidance
230 Blind holders See Blind Holders
240 Cord grey P 532 6-001258-xxxx
241 Cord holder P 527 6-001276-9010
242 Bushing cord - white P 515 6-001248-0000
243 Cord holder XY 00041 3-02427-0000
242 Bushing cord - white P 515 6-001248-0000
243 Cord holder XY 00041 3-02427-0000
Special Designs Alternative Designs Measurement and Assembly Front Covers Blinds Holders Guidance Control Slats Technical Specication

16
P 225/1
P 505
20
P 508
IL 126/1
160
P 502/1
80
P 529/1
100
P 531
110
P 509/1
120
P 525/1
130
P 150/1
SK 52
171
12
31
41
P 241
50, 51
P 517/2
P 517
P 228
60
P 526
71
P 530
75
143
165
P 514
171
P 506
82
21
210-212
5-217
230
P 512/61
P 528
230
P 033/2
P 033/22
P 033/21
D
C
B
A
2
1
5
6
6
5
2
3
4
1
D
C
A
B
2-00151-XXXX-H CETTA 50 - KLIKA
10
P 001/1
P 001/2
10
P 025/35
10
P 041
10
P 045/4
P 045/5
P 045/6
10
P 046
P 046/42
10
20
P 508
P 006
160
P 502/1
80
P 529/1
100
P 531
110
P 509/1
120
P 525/1
130
P 150/1
SK 52
170
230
P 506
82
P 033/2
P 033/22
P 033/21
21
210-212
5-217
170
170
P 002/7
P 002/8
P 023/1
170
D
C
B
A
2
1
5
6
6
5
2
3
4
1
D
C
A
B
2-00151-XXXX-H
CETTA 50 - KLIKA
Control - handle, channel 56x58
Cetta 50 - handle
Control - handle, channel 40x40
CETTA 50 - HANDLE 2-00151-XXXX-H
CETTA 50 - HANDLE 2-00151-XXXX-H

EXTERIOR BLINDS
16 17
Cetta 50 - handle (2-00151-5001)
Position Item name Business name Drawing number
10 Head rail, Fe 56x58 P 001/1 3-00166-PU22
10 Head rail, Al 58x60 P 001/2 7-301180-0000
10 End stop 56x58 P 041 2-00048-9004
10 Bearing C35/C50 P 025/35 2-01100-9004
10 Gearing plastic 4 mm hexagonal, STS-extended P 045/4 6-008115-0000
10 Gearing plastic 8 mm hexagonal 14 mm exit, 46 mm P 045/5 6-013232-0000
10 Gearing plastic 6 mm hexagonal 14 mm exit, 46 mm P 045/6 6-013233-0000
10 Gearing holder P 046 6-001181-0000
10 Gearing holder 111 510 Stoma, inbus P 046/42 6-014239-0000
10 Shaft P 006 7-300198-0000
12 Head rail 40x40 P 528 6-001277-xxxx
20 Bottom rail - 50 mm P 508 6-001230-xxxx
31 Bearing C50 - without ball cord P 225/1 2-00365-0000
41 End stop 40x40 P 241 2-00049-0000
50 Hexagonal gearing P 517 6-001250-0000
50 Hexagonal gearing - interior P 517/2 6-001250-0002
51 Gearing 40x40 - plastic P 228 2-00132-0000
60 Ladder connector P 526 6-001275-0000
71 Tilt rod - hexagonal 6 mm P 530 6-001278-0000
75 Hexagonal metal ring IL 126/1 6-010981-0000
80 Al slat See Slats
82 Pad for slat and wire P 506 3-00170-0000
100 Texband 6x0,28 mm P 531 6-001284-xxxx
110 Ladder C50 P 509/1 6-010452-xxxx
120 Bottom rail plug P 525/1 6-001273-0001
130 Handle See Controls
143 Fixed bracket for slat 50 mm P 505 6-001226-0000
160 Bottom rail cover C50 P 502/1 6-004280-xxxx
165 Side head rail cover P 514 6-001245-0000
170, 171 Guidance - wire/guiding channel + holder See Guidance
210, 215 End guidance "C" L+R P 033/2 2-00047-xxxx
211, 216 End guidance - metal "C" - right P 033/22 7-301466-PU19
212, 217 End guidance - metal "C" - left P 033/21 7-301467-PU19
230 Blind holder See Blind Holders
Special Designs Alternative Designs Measurement and Assembly Front Covers Blinds Holders Guidance Control Slats Technical Specication

18
Cetta 50 - motor
Control - motor, channel 40x40
Control - motor, channel 56x58
CETTA 50 - MOTOR 2-00301-XXXX-J
CETTA 50 - MOTOR 2-00301-XXXX-J
P 528
P 225/1
120
80
P 529/1
P 506
100
P 531
110
P 509/1
160
P 502/1
P 525/1
20
P 508
12
50
31
60
P 526
71
P 530
75
IL 126/1
143
P 505
171
230
82
171
215-217
210-212
P 033/2
P 033/22
P 033/21
D
C
B
A
2
1
5
6
6
5
2
3
4
1
D
C
A
B
2-00301-XXXX-J CETTA 50 - MOTOR
10
P 001/1
P 001/2
10
P 025/35
120
10
80
82
P 506
100
P 531
110
P 509/1
160
P 502/1
220
221, 222
P 077
P 313
230
10
P 006
20
P 508
P 525/1
P 529/1
P 073
P 093
P 096
170
215-217
210-212
P 033/2
P 033/22
P 033/21
D
C
B
A
2
1
5
6
6
5
2
3
4
1
D
C
A
B
2-00301-XXXX-J CETTA 50 - MOTOR

EXTERIOR BLINDS
18 19
Cetta 50 - motor (2-00301-5001)
Position Item name Business name Drawing number
10 Head rail, Fe 56x58 P 001/1 3-00166-PU22
10 Head rail, Al 58x60 P 001/2 7-301180-0000
10 Bearing C35/C50 P 025/35 2-01100-9004
10 Motors (SOMFY) EX. BLINDS P 073 2-00512-0000
10 Motors (GEIGER) EX. BLINDS P 093 2-00572-0000
10 Motors (ELERO) EX. BLINDS P 096 2-00648-0000
10 Shaft P 006 7-300198-0000
12 Head rail 40x40 P 528 6-001277-xxxx
20 Bottom rail - 50 mm P 508 6-001230-xxxx
31 Bearing C50 - without ball cord P 225/1 2-00365-0000
50 Motor See Controls
60 Ladder connector P 526 6-001275-0000
71 Tilt rod - hexagonal 6 mm P 530 6-001278-0000
75 Hexagonal metal ring IL 126/1 6-010981-0000
80 Al slat See Slats
82 Pad for slat and wire P 506 3-00170-0000
100 Texband 6x0,28 mm P 531 6-001284-xxxx
110 Ladder C50 P 509/1 6-010452-xxxx
120 Bottom rail plug P 525/1 6-001273-0001
143 Fixed bracket for lat 50 mm P 505 6-001226-0000
160 Bottom rail cover C50 P 502/1 6-004280-xxxx
170, 171 Guidance - wire/guiding channel + holder See Guidance
210, 215 End guidance "C" L+R P 033/2 2-00047-xxxx
211, 216 End guidance - metal "C" - right P 033/22 7-301466-PU19
212, 217 End guidance - metal "C" - left P 033/21 7-301467-PU19
220 Rod connector P 077 6-001198-0000
221 Rod connector P 313 6-003075-0000
222 Rod connector P 313 6-003075-0000
230 Blind holder See Blind Holders
Special Designs Alternative Designs Measurement and Assembly Front Covers Blinds Holders Guidance Control Slats Technical Specication

20
CETTA 50 EXTERIOR BLIND DIAGRAM
HORIZONTAL SECTION HANDLE CONTROL
Center space for cord
