Ispring UVF11A Manual


Copyright ©2005-2022 ISPRING WATER SYSTEMS, LLC. All rights reserved.




We stand behind our products
Since 2005, iSpring has been dedicated to providing high-quality drinking water to
families across the United States. We provide various residential faucets and water
filtration systems that purify your water in everyday life and deliver pure, healthy,
and tasty water to you and your family.
At iSpring, we strive to develop products to the highest standards and make
excellent drinking water accessible for all households. With affordable pricing,
reliable quality, prompt delivery, and top-notch customer service, we hope to assist
in bringing you great water for years to come.

Read this instruction manual carefully prior to installation.
Keep this manual readily available for future reference.
Packing List
Product Overview
The iSpring Ultraviolet Water Filter (Model: UVF11A/UVF11B/UVF11B-A/UVF11B-E) is an
innovative way to purify water and is suitable for residential use.
The UVF11 series are designed for easy installation. It is also designed to operate with a
minimal amount of maintenance. It allows for quick and easy lamp change requiring no tools.
The dual-chamber heads of the UVF11 series are removable and may be rotated
independently, which aids in the installation, maintenance, or retrofitting of an existing
system.
No.
Part
Quantity
a
Stainless Steel Reactor Chamber
1
b
UV Lamp
1
c
Quartz Tube
1
d
Electronic Ballast with Flow Sensor
1
e
1/4'' Elbow Fittings (with clips installed)
2
f
O-rings
2
g
Clamp Clips
2
h
Cable (blue)
1
i
Spare Clips
4
www.123filter.com | [phone] | [e-mail] Page 5

The UVF11 series come with a flow sensor that turns the UV on and off automatically with
water flow. It automatically turns off when the flow sensor detects there is no water flowing
through the unit. This special design reduces energy consumption and prolongs the life span
of the UV lamp.
The UVF11 series are capable of self-cleaning. Suppose the unit has been idled for 24 hours
but still has power on. In that case, it will start the self-cleaning process by turning itself on
for 300 seconds to ensure that water in the reactor chamber will not deteriorate.
The UVF11 series work as follows:
a. Water enters the UVF11 series and flows into the annular space between the quartz
tube and the inner wall of the stainless steel reactor chamber.
b. The UV lamp emits UV rays to start the purification process. The green LED indicator on
the electronic ballast will immediately light up, indicating that the UV lamp is in
operation and working properly. There is no dead corner in the chamber for water
without being purified.
c. Water that leaves the UVF11 series is ready for use; no further contact time is required.
d. When the UVF11 series are not functioning properly, the red LED indicator starts
flashing, and the alarm sounds off.
e. When there is no water flowing through the UVF11 series, the unit will be in standby
mode, and all the indicator lights will be off.
Product Features
Note: Water quality plays a major role in the UV light performance. The incoming water
should not exceed the requirements as shown in the table above.
Item
Specification
Lamp Power
11w
Rated Voltage
220V or 110V depends on model
Operating Pressure
5 - 115 psi
Minimum UVT
70%
Installation Position
Vertical or Horizontal
Rated Flow
1 GPM
Rated Service life of the lamp
1 Year
Flow Sensor Model
FS-7
Ballast Model
UVT11
Quartz Tube Model
UVQ11
Quartz Tube Dimension
23mm x 245mm
Incoming Water Requirements
Temperature
36 - 104 °F (2 - 40 °C)
TDS
< 10 ppm
Hardness
< 120 ppm
Iron
< 0.3 ppm
Manganese
< 0.05 ppm
Turbidity
< 1 NTU
pH
6.5 - 9.5
Page 6www.123filter.com | [phone] | [e-mail]

The UVF11 series are NOT intended to treat water with obvious contamination or intentional
source, such as raw sewage; nor is the unit intended to convert wastewater to safe drinking
water.
Precautions
Warning:
- Changes or modifications made to this system without the manufacturer's consent could
render the system unsafe for operation and may void the manufacturer's warranty.
- Do not operate the UV Lamp when removed from the reactor chamber, as this may cause
exposure to dangerous UV radiation.
•To avoid possible electric shock, special care should be taken since water is near the
electrical equipment.
•Do not operate the unit if it has a damaged cord or plug, malfunctioning, or has been
dropped or damaged in any manner.
•This unit is only designed for potable water applications. Using attachments not
recommended or sold by the manufacturer may cause unsafe conditions.
•Please do not install this product outside or at a place where it is exposed to direct
sunlight or freezing temperature.
•Please install this product at a place where it is easy to access and maintain.
•The UV lamp contains mercury. If the lamp breaks, avoid inhalation or ingestion the
debris and avoid exposure to eyes and skin. Never use a vacuum cleaner to clean up a
broken lamp, which may scatter the spilled mercury. Follow local regulations and
guidelines for the removal and disposal of mercury waste.
Installation
Note:
•Make sure the quartz tube and UV Lamp are clean before installation. Use alcohol or
mild detergent to clean if necessary.
•The UVF11 series are designed for continuous operation. Frequent switching will reduce
the UV radiation and service life.
•Always turn the main power off before any actions on the UV system.
•The UV system should be installed after the filters as the last stage.
•Keep the UV system away from children to avoid potential injury.
Step 1. Remove both the open end nut and closed-end nut from the reactor chamber.
www.123filter.com | [phone] | [e-mail] Page 7

Step 2. Install one of the O-rings onto the open end of the quartz tube (about 5 mm from the
opening).
Step 3. Insert the quartz tube into the reactor chamber.
Step 4. Install the other O-ring onto the closed end of the quartz tube.
Step 5. Hand-tighten the closed-end nut onto the reactor chamber (where the closed end of
the quartz tube is). Do not over tighten.
Page 8www.123filter.com | [phone] | [e-mail]

Step 6. Insert the two pins of one end of the UV lamp into the female end of the blue cable.
Step 7. Carefully insert the UV lamp and the blue cable into the quartz tube. Hand-tighten
the open end nut onto the reactor chamber.
Step 8. Insert the male end of the blue cable into the indented female end of the lamp
socket of the ballast.
Step 9. Insert the two pins of the other end of the UV lamp into the protruding female end
lamp socket of the ballast.
www.123filter.com | [phone] | [e-mail] Page 9

Step 10. Carefully insert the UV lamp and the blue cable all the way down into the reactor
chamber. Install the black cover cap attached to the ballast onto the open end nut.
Step 11. Install the elbow fittings onto the water inlet and outlet of the reactor chamber: 1)
remove one clip from each of the fittings; 2) push the end of the fitting all the way down into
the reactor chamber; and 3) re-
install the blue clips onto the fittings to secure the
connections. Be sure to push the clips all the way down.
Step 12. Install 1/4'' tubings (not included) onto both elbow fittings: 1) remove clips from the
fittings; 2) push tubing all the way (about half an inch) into the fittings; 3) re-install the clips
onto the fittings to secure the connections by pushing them all the way down.
Step 13. Install the flow sensor onto the inlet tubing of the unit. Follow the flow direction on
the flow sensor. Be sure to install the blue clips to secure the connection.
Page 10 www.123filter.com | [phone] | [e-mail]

Step 14. Install the two supporting pieces when needed. Place the UVF11 unit in a proper
location.
Note: Cut the 1/4'' tubing (not included) using a sharp blade to an appropriate length to
avoid kinking. Ensure the tubing is fully inserted into the quick-fitting connection about half
an inch deep and secure the connection with the supplied blue clips.
Perform the following steps to complete the installation process:
a. After completing all plumbing connections, slowly turn on the water supply and check
for leaks. Also, check to see if water flow activates the UV light.
b. Allow the water to run for a few minutes to clear any air or dust potentially in the
reactor chamber.
c. Plug in the power for starting up.
d. The system is now ready to use.
The completed system connection should be as shown below.
www.123filter.com | [phone] | [e-mail] Page 11

Maintenance and Inspection
For your safety, always wear eyewear and turn the power off before servicing the unit.
Servicing the unit with the power on will also cause damage to the ballast.
A. Clean the UV Lamp and the Quartz Tube
Clean the UV lamp and quartz tube at least three times a year if the unit can be dismounted
easily. Otherwise, please replace the lamp and quartz tube every 1-2 years.
Follow the steps below to clean the lamp and the quartz tube. Use great care when handling
the quartz tube as it is very fragile; avoid bumping or jarring it.
a. Wear appropriate gloves to avoid contaminating the lamp.
b. Unplug the power, shut off both inlet and outlet valves, and remove the entire unit
from the waterline.
c. Drain the water, remove the black rubber cap with the attached power cord, and
remove the lamp from the quartz tube.
d. Wipe the lamp with a piece of lint-free cloth moistened with white vinegar.
e. Pour vinegar into the water inlet and soak the quartz tube until it is clear. Rinse
thoroughly.
B. Maintain the UV Lamp
•Regularly inspect the UVF11 unit to ensure that the UV lamp is still in operation. An LED
indicator light, located on the ballast, visually indicates UV lamp operation. This indicates
lamp operation and does not indicate the level of UV intensity or transmission through
the water. Ballasts have a built-in audio alarm which will indicate lamp failure.
•To ensure the proper operation of the UVF11 unit, regular biological testing of your
water (e.g., quarterly) by an accredited agency is highly recommended. Additional
testing may be performed whenever modifications, change, or additions are made to the
plumbing system, pumps, well source water, etc., to ensure adequate purification under
new conditions.
•Other maintenance measures may include ensuring that grounding wires are secure,
replacing any damaged or broken components.
Page 12 www.123filter.com | [phone] | [e-mail]

Troubleshooting
Problem
Solution
After turning on the water supply, the
ballast does not turn on automatically.
1. Ensure that the water flow switch is correctly
connected. Verify that the direction of the water
flow on the water flow switch is correct.
2. Verify that the unit has been correctly
connected to the power supply.
3. Verify that the power supply voltage is within
the rated voltage range.
4. Verify that the water flow rate ≥0.08 GPM.
The ballast alarms, the lamp does not
light up.
1. Verify that the lamp tube is firmly connected.
2. Check whether the lamp tube has the end of
its life. If yes, replace it with a new UV lamp.
3. If 1 and 2 do not work out, the ballast is likely
damaged. Replace it with a new ballast.
The ballast alarms, the lamp lights up.
The ballast alarm system is damaged, replace the
ballast.
The timer number does not change.
Please reset the timing mode. If there is a
decimal point behind, it means the timing is in
minutes, and it will count one after one minute.
Leaking from the reactor chamber.
The O-ring inside the quartz tube might be
damaged. Replace it with a new one.
Leaking from the quartz tube.
Replace the quartz tube.
Leaking at the water inlet/outlet of the
reactor chamber.
Wrap plumber's tape on the threads and
reconnect the tubing.
Lamp does not turn on after replacing.
Check the lamp connection.
Lamp turns on, but indicator lights and
alarm are abnormal.
Indicator lights are broken. Replace the ballast.
For any questions or concerns, please contact us at [e-mail] or visit our help
page at 123filter.com/support
www.123filter.com | [phone] | [e-mail] Page 13

Warranty Registration
To register your product for the warranty, visit our website at 123filter.com and go to the
"Warranty" tab.
We provide a 30-day money-back guarantee, a 1-year manufacturer warranty, and lifetime
tech support for all of our products. However, we do not have the order information from
websites other than 123Filter.com (Amazon, Home Depot, etc.), so please fill in that
information upon registration of your system. If you have any questions or concerns about
your product, please call or email us or put it in the notes/comments upon your warranty
registration. Your satisfaction is our business!
If you are happy with our products and service, please show your support by writing a
product review on Amazon, even just a single line. It takes you just a minute but means a
lot to us. Thank you!
Page 14 www.123filter.com | [phone] | [e-mail]

Atlanta, GA USA
iSpringFilter.com
For questions, comments, or technical support, contact us at:
[e-mail]
[phone]
Monday-Friday 8:30 a.m. - 5:30 p.m. EST
www.123filter.com | [phone] | [e-mail] 16
