CU-A4 4-Stage Ultrafiltration Water System
INSTALLATION INSTRUCTIONS
& OPERATING MANUAL
Ver. 03/2021
Copyright ©2005-2021 ISPRING WATER SYSTEMS, LLC. All rights reserved.

We stand behind our products
Since 2005, iSpring has been dedicated to providing high-quality drinking water to families across
the United States. We provide various residential faucets and water filtration systems that purify
your water in everyday life and deliver pure, healthy, and tasty water to you and your family.
At iSpring, we strive to develop products to the highest of standards and aim to make excellent
drinking water accessible for all households.With affordable pricing, reliable quality, prompt
delivery, and top-notch customer service, we hope to assist in bringing you great water for years to
come.
Page 1www.123filter.com | [phone] | [email protected]

Prior to Installation
Read this instruction manual carefully prior to installation.
Keep this manual readily available for future reference.
Table of Contents
Introduction
Specifications ...............................................................................................................3
Parts List........................................................................................................................3
Quick Tips
Inlet Water Valve in Different Sizes.............................................................................3
Use of Quick-Fitting .....................................................................................................4
Drill a Hole on Sink or Countertop...............................................................................4
Installation
Installation.....................................................................................................................5
Installation Steps...........................................................................................................6
Troubleshooting...........................................................................................................7
Warranty
Warranty........................................................................................................................9
Warranty and Registration ..........................................................................................11
www.123filter.com | [phone] | [e-mail] Page 2

Congratulations on your purchase of the iSpring 4-stage Ultrafiltration water filter system.
Featuring a four-stage filtration process, the CU-A4 incorporates a 0.1-micron UF membrane, a
polypropylene sediment filter (PP), Active Carbon (AC), and Kinetic Degradation Fluxion (KDF)
to provide crisp-tasting mineral water straight from your tap.
Introduction
Specifications
Feed Water Pressure 20～80 psi*
Feed Water Temperature 40 -100ºF
Maximum Inlet Water TDS Value ≤1000 ppm
Clean Water Flow 0.56 GPM @ 45 psi
Filter Set Life Span 6～9 months @ 4 GPD
Part List
1. Pre-assembled machine head:
Four filter housing caps on the bottom and two quick-fitting elbow fittings on both sides.
2. Four filter housings and four cartridges
1) First stage: Disposable PP filter (1st one on the right when facing the front panel)
2) Second stage: Disposable UF membrane filter in hollow fiber
3) Third stage: Disposable 85C granular activated carbon filter + KDF filter
4) Fourth stage: Disposable post-activated carbon filter (1st one on the left)
3. Drinking faucet and installation kit
4. Feed Water Adapter (AFW43)
Taps into the cold water supply angle stop valve with 1/2" and 3/8" adapter.
5. 1/4 inch Tubing
Connects feed water adapter, filter unit, and drinking faucet.
Page 3www.123filter.com | [phone] | [email protected]

Quick Tips
Inlet Water Valve in Different Sizes
Some homes may have either a 1/2 or 3/8 inch inlet water valve. The Feed Water Adapter
(AFW43) includes a reversible adapter to match either size. For any other size, please get an
adapter from your local plumbing store or contact us. If drilling is necessary, make sure that no
power or water lines are in the way.
Use of Quick-Fitting
a.1.1 Viewing from the open end, quick-fitting starts with the Collet, Lock Clip (often in blue
color), and Fitting Body.
a.1.2 To connect, cut tubing evenly, remove the Lock Clip, push the tubing 1/2 inch into the
quick-fitting, and reinstall the Lock Clip. Pull on the tubing gently to make sure it is locked
in.
a.1.3 To disconnect, remove the Lock Clip, and compress and hold down the Collet into the
Fitting Body to eliminate the gap where the locking clip was occupying, and
simultaneously pull the tubing out.
*NOTE* Watch our YouTube video ‘iSpring RO Quick Fitting’
Drill a Hole on Sink or Countertop
a.2.1 Watch YouTube video “how to drill a hole in granite countertop”
a.2.2 Choose one inch Diamond hole saw for granite and titanium drill bit for steel
a.2.3 Use a coolant to disperse heat. Choose water for granite and oil for steel
www.123filter.com | [phone] | [e-mail] Page 4

a.2.4 Use a 1-1/2" Suction Base Drilling Ring to hold coolant and prevent the drill bit from
slipping on the counter
a.2.5 Start slowly. Be cautious with the power drill that might slip and damage the counter
surface.
a.2.6 Set variable speed power drill at 100 – 200 RPM. Do NOT use hammer drill on natural
stone, glass, and ceramic.
a.2.7 Hold drill bit vertically and swirl a little to apply pressure evenly in a circular motion.
Be patient and deliberate. It can take 20 - 40 minutes to drill through one inch.
Page 5www.123filter.com | [phone] | [email protected]

Note: Use the bushing (adapter) that goes with the AFW to fit the ½” NPT or ⅜” COMP threads on
your sink's Cold Water Pipe.
www.123filter.com | [phone] | [e-mail] Page 6

Installation Steps
CAUTION: Improperly installed systems could result in water damage due to leaks or flooding.
Proper installation of this system requires familiarity with standard sink plumbing and proper use of
common hand and power tools. If you are not familiar with standard sink plumbing and proper use
of common hand and power tools or have any difficulty with installing this system, please consult a
licensed professional, such as a contractor or plumber.
1. Preparation
①Location: This water filter can be installed anywhere with a proper cold water supply,
such as under the kitchen sink, behind the refrigerator, next to your aquarium, inside
the RV, etc.
②Tools needed:
1. 3/8 inch and 1/4 inch wrenches or adjustable wrench
2. Phillips and flathead screwdrivers
3. Scissors or utility knife
4. Bucket and towel to catch water drips
5. Variable speed power drill with 1-inch steel or marble hole saw bit if a hole on the counter
is to be drilled
2. Steps for installing under the kitchen sink (other locations may vary)
①Installing the Feed Water Adapter
1.1 Turn off your Inlet Water Valve (COLD) and open the kitchen faucet to release water
pressure.
1.2 With a towel or bucket underneath, disconnect the Faucet water hose from Inlet Water
Valve using the 3/8 inch wrench and install the Feed Water Adapter (AFW) between them.
Make sure the rubber washers are still in place. It is usually not necessary to use Teflon tape
here. Hand tighten the hex nut and use the wrench for the final 1/4 - 1/2 turn. Do not
overtighten.
1.3 Install the 1/4 inch WHITE tubing on the Feed Water Adapter using the 1/4 inch wrench.
Hand tightens it, then tightens up half to one turn using the wrench. If you received the feed
water adapter with quick fitting, insert the tubing 1/2 inch deep into the fitting. It will lock
automatically.
②Installing the drinking faucet
2.1 If your kitchen sink does not have a spare 1” hole, you will need to drill one. (Refer to
Quick Tips for Drilling a Hole in Sink or Counter-top). Wipe clean, and dry the area.
2.2 If there is a blue protection film on the Front Plate, remove it. Slip the front plate with a
black rubber washer onto the faucet stem. Insert the faucet stem into the hole on the counter.
Optionally, plumber glue or sealer could be used.
2.3 Under the sink, slip on the Back Plate and tighten the Hex Nut.
NOTE: Please contact us if you plan to “tee off” the pure water line and connect it to your
fridge, as you would need a regular RO faucet along with a pressure regulator.
Page 7www.123filter.com | [phone] | [email protected]

③Installing the unit and filter cartridges
3.1 Match the stage labels and twist filter cartridges clockwise into the machine head in order.
3.2 On the cabinet wall, mark the two holes of the bracket and install two #8 x 1” round head
screws to hang the unit.
④Installing the tubing (check Quick Tips for using Quick-fitting)
4.1 Connect the blue tubing with AFW, red tubing with 1st stage, white tubing with 4th stage.
4.2 Check water route: cold water valve →blue tubing →drinking faucet valve →red tubing
→1,2,3,4 stages →white tubing →drinking faucet.
⑤System startup
5.1 With a towel or bucket underneath, slowly turn on the Cold Water Valve, feel the vibration
and noise of the water flow. If your water pressure is high, DO NOT turn the Inlet Water
Valve all the way up, but sparingly to a level position.
5.2 If it leaks, check if the tubing is fully inserted into quick-fittings and that the nuts and
cartridges are properly tightened.
5.3 Turn on the Drinking Faucet. Water should start flowing. Let it run for 5 - 15 minutes or
until carbon particles are flushed out and water turns clear. The water filter is now ready for
use. Write down the current date on cartridge for future reference. The cartridge set has a
life span of about 6 – 9 months depending on water quality and usage.
⑥Filter Replacement
6.1 Turn off the inlet water ball valve (COLD) and open the kitchen and drinking faucets to
release pressure.
6.2 With a towel or bucket underneath, twist the filter cartridge wrench counterclockwise to
remove and immediately put the replacement back on. Work in the order from the 1st stage
to the 4th stage, which is from right to left when facing the front label of the machine head.
Troubleshooting
Symptom
Reason
Resolution
No clean water
from the faucet
1. No water or water pressure < 20 psi
2. Incorrect tubing connections
3. Drinking faucet is off
1. Check water source
2. Check the tubing connections
3. Check the faucet
Slow water
flow
1. Water pressure lower than 20 psi
2. Filter cartridges are due for
replacement
3. 1st stage is clogged by sediments
1. Open kitchen faucet to check cold
water pressure
2. Check the installation date and
replacement schedule
3. A whole-house sediment filter is
needed to protect water appliances
No water from
the fridge
Using the included faucet with an ice
maker kit to connect to the fridge
Get iSpring ICEK fridge connector
to connect your ice maker to water
filter
www.123filter.com | [phone] | [e-mail] Page 8

Notes
★Before you leave home or stop using the water filter for a period of time, turn off the cold
water valve, AFW valve (cross position) and turn on drinking faucet to make sure no there’s
no remaining pressure.
★Should any leak and damage to the parts occur, immediately turn off the AFW valve and
contact us for assistance. (678-261-7611, [email protected])
Warranty
This Limited Warranty extends to the original purchaser of the system only. This warranty covers
all Manufacturer-supplied items only that prove to be defective in material, workmanship or factory
preparation. This warranty covers parts only; all labor is excluded from this warranty, including,
but not limited to, services related to the removal, replacement, installation, adjustment,
maintenance and/or repair of the unit or its components items. excludes all non-Manufacturer labor
required for any servicing of the unit, including, but not limited to, servicing related to installation,
adjustment, maintenance and repair of the unit. This warranty applies only for the first full calendar
year from date of purchase. The following items are excluded from this warranty: membranes,
filters, O-rings, and all other parts or components that require regular replacement as a result of
ordinary usage.
Disclaimers: This Limited Warranty applies only if the system is installed, used and maintained in
compliance with all instructions and requirements enclosed with the system. This warranty will be
void for failure to observe the following conditions:
1. The system is to be used with potable water from a municipal water system.
2. Feed water pressure to the unit is no less than 20 psi and no greater than 50 psi.
3. The system is to be used on water supplies with chlorine concentrations of 1.0 mg/L (ppm) or
less.
4. Feed water temperature to the unit must be no less than 40°F and no more than 100°F.
5. Total dissolved solids in feed water must be less than 1,000 mg/L (ppm).
6. Feed water must have a pH between 4 and 8.
7. Turbidity must be less than 1.0 NTU.
8. SDI must be less than 5.
9. Feed water must be completely free of iron, manganese or hydrogen sulfide.
Do not use with water that is microbiologically unsafe or of unknown quality without adequate
disinfection before or after the system.
The Manufacturer does not know the characteristics of your water supply. The quality of water
supplies may vary seasonably or over a period of time. Your water usage may vary as well. Water
characteristics can also change if the drinking water appliance is moved to a new location. The
Manufacturer assumes no liability for the determination of the proper equipment necessary to meet
your requirements, and we do not authorize others to assume such obligation on our behalf.
Page 9www.123filter.com | [phone] | [email protected]

This Limited Warranty does not cover any Manufacturer-supplied items that are defective as a
result of the use of improper parts, equipment or materials. This warranty does not cover alterations
or modifications of the unit, or failure of a unit caused by such alterations and modifications.
This Limited Warranty does not cover malfunctions of the unit due to tampering, misuse, alteration,
lack of regular maintenance, misapplication, fouling due to hydrogen sulfide, manganese or iron,
scaling from excessive hardness, turbidity greater than 1.0 NTU, Silt Density
Index (SDI) greater than 5.0 SDI, or excessive membrane hydrolysis due to chlorine levels in
excess of 1.0 mg/L (ppm). In addition, damage to the unit due to fire, accident, negligence, act of
God, or events beyond the control of the Manufacturer are not covered by this warranty.
Incidental and Consequential Damages Limitation: The Manufacturer will not be responsible for
any incidental or consequential damages as a result of the failure of this unit to comply with
express or implied warranties or any defect in the unit, including but not limited to, lost time,
inconvenience, damage to personal property, loss of revenue, commercial losses, postage, travel,
telephone expenditures, or other losses of this nature. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so this exclusion may not apply to you.
Owner’s Warranty Responsibilities: As a condition of this Limited Warranty, the owner must
ensure periodic maintenance of the system is performed as described in the literature enclosed with
the system. Neglect, improper maintenance, abuse, modification or alteration of the unit will
invalidate this Warranty. Should your unit develop a defect or otherwise fail to perform in
accordance with this warranty, you should contact the retailer from whom the product was
originally purchased.
Implied Warranties: The implied at-law warranties of merchantability and fitness for a particular
purpose shall terminate on the date one year after the date of purchase. Note: some states do not
allow limitations on how long an implied warranty lasts, so the above limitations may not apply to
you.
Other Rights: This Warranty gives you specific legal rights and you may also have other rights
which vary from state to state.
www.123filter.com | [phone] | [e-mail] Page 10

Warranty Registration
To register your product for the warranty, visit our website at 123filter.com and go to the
“Warranty” tab.
We provide a 30-day money back guarantee, a 1-year manufacturer warranty, and lifetime tech
support for all of our products. However, we do not have the order information from websites other
than 123Filter.com (Amazon, Home Depot, etc.), so please be sure to fill in that information upon
registration of your system. If you have any questions or concerns about your product, please do
not hesitate to call or email us, or put it in the notes/comments upon your warranty registration.
Your satisfaction is our business!
If you are happy with our products and service, please show your support by
writing a product review on Amazon, even just a single line. It takes you just a
minute but means a lot to us. Thank you!
Page 11 www.123filter.com | [phone] | [email protected]

Atlanta, GA, USA
iSpringFilter.com
For questions, comments, or technical support, please contact us at:
[email protected]
[phone]
Monday-Friday 8:30 a.m. - 5:30 p.m. EST
