Ispring RCC Series Manual

Copyright ©2005-2023 ISPRING WATER SYSTEMS, LLC. All rights reserved.

We stand behind our products
Since 2005, iSpring has been dedicated to providing high-quality drinking water to families across
the United States. We provide various residential faucets and water filtration systems that purify your
water in everyday life and deliver pure, healthy, and tasty water to you and your family.
At iSpring, we strive to develop products to the highest of standards and aim to make excellent
drinking water accessible for all households. With affordable pricing, reliable quality, prompt
delivery, and top-notch customer service, we hope to assist in bringing you great water for years to
come.

Table of Contents
User Information ......................................................................................................... 3
Product Features.......................................................................................................... 3
Understanding the Booster Pump and RO Process...................................................... 4
Component Identification............................................................................................ 5
Installation................................................................................................................... 6
Before you start the installation ........................................................................ 6
Step 1: Water Inlet – Three Options.................................................................. 7
Step 2: Install Drain Saddle (ADS1K) .............................................................. 8
Step 3: Install the Vertical Filters: Stages 1, 2, and 3........................................ 8
Step 4: Installing the Reverse Osmosis Membrane ........................................... 9
Step 5: Tubing Hook Up ................................................................................... 9
Step 6: Leak Stop Valve (ALS1) Installation .................................................. 11
Step 7: Mounting the System (Optional)......................................................... 11
Step 8: System Start-up................................................................................... 11
System Maintenance ................................................................................................. 12
Troubleshooting Guide.............................................................................................. 13
Glossary and Terms to Know .................................................................................... 15
Optional Add-on ....................................................................................................... 16
Warranty
iSpring Standard Limited Warranty (End-Users Only) .................................................
Warranty Registration Form..........................................................................................

Page 3 www.123filter.com | [phone] | [e-mail]
User Information
The user must adhere to the installation specifications described in this Product Installation and
Operation Manual (hereinafter referred to as the "instruction manual"). iSpring is not responsible for
damage, loss, or injury resulting from neglect, improper maintenance, or unauthorized modification
of products.
•This product is designed for residential use only. Contact iSpring customer service to inquire
about usage in non-residential settings.
•The operating temperature range is 40°F - 100°F (4 - 37 °C). This RO system is NOT designed
for HOT water. If the water temperature or ambient temperature falls below 40°F,
immediately shut off the inline water supply and drain the remaining water from the system.
Within the range, the warmer the water is, the faster is the RO process.
•In case of malfunction due to damage or failure of the power supply system, unplug the
system immediately and contact iSpring customer service for guidance.
•If leaking occurs, shut off the inline water supply. Then unplug the system and contact iSpring
customer service.
•Use only authorized iSpring parts and filters. Using unauthorized or aftermarket components
will void the product warranty.
•It is recommended that users check external fittings and connections regularly to ensure all
components are secure and operating properly.
•Unauthorized modification and disassembly are strictly prohibited and will void the warranty.
•Never touch the power cord connector when your hands are wet, as this may result in electric
shock.
•This appliance is not intended for use by persons (including children) with reduced physical,
sensory, or mental capabilities or lack of experience and knowledge unless they have been
given supervision or instruction concerning the use of the appliance by a person responsible
for their safety. Children should be supervised to ensure they do not play with the appliance.
•This appliance can be used by children aged 8 years and above and persons with reduced
physical, sensory, or mental capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning the use of the appliance in a safe way and
understand the hazards involved. Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children without supervision.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent, or
similarly qualified persons in order to avoid a hazard.
•The new hose sets supplied with the appliance are to be used, and the old hose sets should not
be reused.
Product Features
1) Filtration Performance
Stage
Filter
Purpose
1st
Polypropylene (PP)
Removes sediments, dust, dirt, sand, silt, rust, and particles.
2nd
Granular Activated
Carbon (GAC)
Removes chlorine, taste, odors, cloudiness, and colors.
3rd
Carbon Block (CTO)
Further enhances the sense and taste of the water.
4th
Reverse Osmosis (RO)
Membrane
Removes up to 99% of contaminants, such as lead, chlorine,
fluoride, arsenic, hormones, asbestos, calcium, sodium, iron, etc.
5th
Deionize (DI)
Produces filtered water with zero or near zero TDS.

www.123filter.com | [phone] | [e-mail] Page 4
2) Water Treatment Process
Municipal Tap Water → PP Sediment Filter → GAC Filter →CTO Filter →RO Membrane →
Deionize Filter → Purified water
3) Operating Conditions
•Maximum water pressure: 70 psi, or a pressure regulator (part# APR70) is required if there is
high water pressure or water hammer.
•Minimum water pressure: 30 psi for model#RCC1DP, 45 psi for model#RCC1D, or an extra
booster pump is needed to improve RO efficiency
•Install this RO system where it is protected from hot/cold weather and direct sunlight. Avoid
hitting, dropping, or dragging as they may cause cracks and leaks.
Understanding the Booster Pump and RO Process
1. Source water enters the system and passes through the stage 1, 2, and 3 pre-filters. Located
between the pre-filters is the Low-pressure
Switch. This switch turns on when the
incoming water pressure is 6 psi or greater.
2. The High-pressure Switch turns on
when the pressure in pure water line is below
20 psi, and turns off at 45 psi.
3. When the Low-pressure Switch and
High-pressure Switch are both on, the Feed
Water Solenoid Valve opens, allowing water
to the Booster Pump.
4. The source water passes through the
Booster Pump, bringing it to approximately
100 psi entering the membrane housing.
5. Coming out of the RO membrane is a
pure water port and wastewater port. The RO
water is forced through the .0001 micron-sized
holes of the RO membrane and exits through
the one-way Check Valve on the membrane's
pure water exit port. The water rejected by the
RO membrane exits through the wastewater
exit port. On the drain line before the
wastewater is disposed of is the Flow
Restrictor, limiting the amount of drain water
allowed out to keep pressure in the system.
Parameter
Specification
Maximum Inlet Water Pressure
70 psi
Minimum Inlet Water Pressure
Model#RCC1D: 45 psi
Model#RCC1DP: 30 psi
Incoming Water Temperature
40 - 100 °F
Maximum TDS
750 ppm
ASOF
PUMP
RO MEMBRANE
AS
CTO GAC SED
OW
AHP
Drain Saddle
Source
Water
Drain Water
Purified High Pressure
Switch
Flow Restrictor
Auto Flush
Solenoid Valve
Feed Water Solenoid Valve
Low Pressure
Switch
Water
ALP

Page 5 www.123filter.com | [phone] | [e-mail]
*Actual product varies depending on the Model#. Model#RCC1DP comes with a booster pump that
is not pictured.

www.123filter.com | [phone] | [e-mail] Page 6
Installation
Before you start the installation
•It is highly recommended that you watch the video "iSpring RCC Series RO System with
Deionized Filter DIY Installation | Step by Step" on YouTube.
•Choose a suitable location for the system. Again, it must be placed on a flat surface, and make
sure this system is to be installed on INDOOR cold-water supply ONLY.
•Check the packing list to confirm that all accessories are included in the package. Contact
iSpring customer service if any components are missing.
•Required tools:
•Recommended tools:
Variable speed drill with two bits: 1/4" (for drilling a hole on PVC drain pipe)
5/8", 9/16" open-end wrench, or adjustable wrench, pliers
•Quick connect instruction:
It is highly recommended that you watch the video "How to Connect and Disconnect Quick
Connect Fittings | DIY Installation" on YouTube.
Cut the tubing end squarely using a utility knife or scissors. Insert the tubing into the quick
connect fitting for at least 1/2''. You will need to wiggle the tube and apply additional pressure
to create a seal.
HOW TO CONNECT
① ② ③
① ② ③
HOW TO DISCONNECT
PUSH IN
INSERT
REMOVE
PRESS
PULL
DISCONNECT
At least 1/2" in
LOCK

Page 7 www.123filter.com | [phone] | [e-mail]
Step 1: Water Inlet – Three Options
Water Inlet Option 1 –
Connect from Cold Water Valve Under Sink w/ Feed Water Adapter (AFW43)
It is highly recommended that you watch the video "How to Install a Feed Water Adapter for
Reverse Osmosis (RO) and Other Applications | iSpring AFW43" on YouTube.
Step 1. a. Turn off the Cold Water Supply Valve (CWSV) under the sink and open the kitchen
faucet to release pressure. Get a towel or bucket to catch any water drips. Disconnect the
kitchen faucet connector pipe from the CWSV.
Step 1. b. Install the Feed Water Adapter onto the CWSV and tighten it using a wrench or pliers.
Make sure the O-ring is seated inside the adaptor. Plumber's tape may be used to seal the
connection.
Step 1. c. Re-install the kitchen faucet connector pipe onto the male end of the Feed Water
Adapter. Turn the handle of the Feed Water Adapter to the perpendicular OFF position. Turn
on the CWSV slowly, and ensure you get a proper seal.
Step 1. d. Connect the 1/4'' RED tubing to the Feed Water Adapter.
The included bushing can be threaded on either side of the Feed Water Adapter to fit the configuration
of both 3/8'' COMP and 1/2'' NPT.
Water Inlet Option 2 –
Connect from Kitchen/Bathroom Faucet w/ 156F34GH + 34GH14K Connectors
Step 1. a. Remove the aerator from the faucet. Your hands should be enough, but pliers can be
used. Save the aerator, which may be needed if the system is removed.
Step 1. b. Screw the 156F34GH adaptor onto the 34GH14K connector, then screw the whole
connector onto the faucet. Usually, the connectors can be hand tightened; if necessary, use a
plier. Plumber's tape may be used to seal the connection.
Step 1. c. Connect the 1/4'' RED tubing to the 34GH14K connector.
Water Inlet Option 3 –
Connect from Garden Hose Bibb w/ 34GH14K Connector
Step 1. a. Twist the 34GH14K connector onto the garden hose bibb by hand, then use a plier to
tighten it as needed. Plumber's tape may be used to seal the connection.
Step 1. b. Connect the 1/4'' RED tubing to the 34GH14K connector.

www.123filter.com | [phone] | [e-mail] Page 8
Step 2: Install Drain Saddle (ADS1K)
It is highly recommended that you watch the video "How to Install iSpring Drain Saddle (ADS1K)
for Reverse Osmosis (RO) System | DIY Installation" on YouTube.
Step 2. a. Choose a proper spot anywhere before the P-trap on the drain pipe to install the drain
saddle and tubing. Remember that the drain saddle should NOT be installed after the P-trap
to prevent potential microorganism growth.
Step 2. b. Drill a 1 /4" hole in the drain pipe, and paste the black sticky pad around the hole.
Step 2. c. Cut the BLACK tubing end to make a 45° angle. Insert the tubing into the 1/4'' hole
in the drain pipe, install the back plate, and tighten the two screws with hex nuts while the
tubing remains in the hole.
Step 2. d. Insert Lock Clip. Pull the tubing lightly to make sure it is secure.
Step 3: Install the Vertical Filters: Stages 1, 2, and 3
Step 3. a. Make sure that the O-ring is seated inside the
groove at the top of the filter housing. Food-grade
silicone jelly may help the O-ring stay in place and
seal better.
Step 3. b. Filter cartridges are preserved in shrink wrap.
Note the direction sign on the sticker before
removing the wrap.
Step 3. c. When placing the filter cartridge into its
housing, make sure it is centered, and the knob is
protruding from the bottom of the housing fits in the
central hole of the filter.
Step 3. d. Screw the housing, with filters attached, onto
the housing caps (caps are pre-assembled on the
machine head). The cap also has a center knob that
should be inserted into the center hole of the filter
cartridge. Twist the housing on in a counter-clockwise direction by hand, and then use a
housing wrench to tighten it up for about 1/4 – 1/2 turn. Do not overtighten. This can cause
leaks and make it difficult to unscrew the housing when replacing filters.
*Note* the second stage GAC is the only filter that must go in a certain direction. Make sure that
the end with the rubber washer faces up, attaching to the housing cap.

Page 9 www.123filter.com | [phone] | [e-mail]
Step 4: Installing the Reverse Osmosis Membrane
Step 4. a. Disconnect the tubing from the quick-fitting connection on the membrane cap.
Step 4. b. Open the membrane housing cap. A thick rubber band can be slipped on the housing
body for better grip.
Step 4. c. Find the inner end with 2 O-rings, cut open the end of the sealed bag, use it to hold
the RO membrane to avoid contamination, and firmly insert the membrane into the housing
until the outer end without the O-ring is completely inside the housing. See Figure above.
Step 4. d. Before twisting the housing cap back on, check that the O-ring is evenly snagged on
the membrane housing. Hang tight and tighten up for about 1/4 – 1/2 turns using a small
plastic housing wrench, but do not over tighten. DO NOT reconnect the tubing to the inlet on
the cap at this point (will do it in system start-up).
Step 5: Tubing Hook Up
OUTLET
WASTE
RO WATER HOUSING O-RING
MEMBRANE
O-RING RO MEMBRANE OPEN
INLET
CAP
System Inlet Option 2
A2 to System
Kitchen/Bathroom Faucet
System Inlet Option 1
A1
to System
Hot Cold
Cold Water Valve Under the Sink
System Inlet Option 3
A3 to System
Garden Hose Bibb
O-RING
MEMBRANE
CAP
TUBING
INLET
HOUSING

www.123filter.com | [phone] | [e-mail] Page 10
RCC1D Top View
RCC1DP Top View
Note: The sequence of connection for different colors can be adjusted.
RED tubing: connect source water (Point A) to the 1st Stage water inlet elbow fitting (Point B)
BLACK tubing: connect wastewater from the Flow Restrictor (Point C) to the Drain
Saddle/drain pipe (Point D)
BLUE tubing: pure water outlet connecting from the 5th Stage DI Filter (Point E)
You may neatly organize the tubing, but make sure to leave enough length so the filter system
can be moved freely in and out of the cabinet when replacing filters.

Page 11 www.123filter.com | [phone] | [e-mail]
Step 6: Leak Stop Valve (ALS1) Installation
The Leak Stop Valve is a reusable mechanical leakage protector. Whenever a water leakage is
detected, it will shut down the feed water.
Step 6. a. Make sure the end of the tubing is cut square before connecting it to the fitting.
Step 6. b. Follow the water flow direction indicated on the Leak Stop Valve to connect it to the
water inlet pipeline.
Step 6. c. Tape the bottom of the Leak Stop Valve against the floor.
Step 7: Mounting the System (Optional)
•Mounting the system is NOT required. The system does NOT need to be
mounted to work correctly.
•Please note if the system is to be mounted, it is recommended to use two 10
x 1-1/4 Phillips Flat Wood Screws (not included). This will make replacing
filter cartridges easier.
Note: If you plan on mounting/hanging the system, it is highly recommended to include supports
under each of the bottom three housings. Supports under the housings will take the water weight
off the housing threads and ensure the thread strength does not decay over the years.
Step 8: System Start-up
Note for model#RCC1DP: You may now plug in the booster pump to an outlet. The pump will
not turn on until the water is flowing.
Step 8. a. Make sure no tubings are kinked. Place a towel under the system to catch any possible
water leaks.
Step 8. b. Disconnect the RO membrane housing cap inlet tubing. Turn on the water inlet, and
flush the first three stages into a bucket until the water turns clear. The water may appear
black at first due to loose carbon from new carbon filters.
Step 8. c. Once the water is clear, shut off the water inlet and reconnect the tubing to the RO
membrane housing cap. You will want to flush the first three stages like this whenever
they are changed.
Step 8. d. Open the pure water outlet. Slowly open the water inlet and check for any leaks. The
top 3 causes of leaks are 1) The tubing is not fully inserted into the quick-connect fitting.
2) The O-ring is not in the correct place or is kinked. 3) The Housing/Cap is not
tightened properly or is misaligned with the threads.

www.123filter.com | [phone] | [e-mail] Page 12
Step 8. e. Within 5 minutes, the booster pump on model#RCC1DP will kick on, and the RO
water will start slowly trickling from the pure water outlet. Let the water trickle for at least
15 minutes to flush out the entire system. It will eventually turn clear apart from many tiny
air bubbles leaving the system.
Step 8. f. Shut off the system.
Step 8. g. The TDS (total dissolved solids) of the water should be tested periodically to verify
that the system is performing properly. iSpring RO systems have exceeded the minimum
requirements for NSF/ANSI standard 58. They should be giving an average TDS reduction
rate of 90%+, so if your tap water is 100 ppm, you should be getting 10 ppm or less from the
RO water (200/20>, 400/40>, etc This reverse osmosis system contains a replaceable
treatment component critical for the effective reduction of total dissolved solids. That product
water should be tested periodically. TDS is measured with a TDS meter - it is an inexpensive,
easy-to-use device that can be found on Amazon.com or 123filter.com by searching "iSpring
TDS."
Step 8. h. Check for leaks daily for the first two weeks after installation to ensure the system is
functioning properly. Install the Flood Alarm (optional, model: WD01) to provide additional
peace of mind and protection.
Note: Do not use microbiologically unsafe water or unknown quality without adequate disinfection
before or after the system. Systems certified for cyst reduction may be used on disinfected water that
may contain filterable cysts.
System Maintenance
All iSpring RO systems are designed with ease of use and low maintenance in mind. If the filter
cartridges are changed on schedule as suggested, the system will work properly for years to come.
See the chart below for the filter pack model numbers for your system. The filter packs can be found
on 123filter.com, Amazon, or HomeDepot.com.
1-Year Filter Pack
2-Year Filter Pack
3-Year Filter Pack
F7D
F15-150
F22-150
*Please note, the general filter cartridge replacement schedule is for reference only. Not all filters
included in the same filter pack, Carefully choose the filter pack that suits your RO system.
*Filter replacement schedule may vary depending on the quality of your source water.

Page 13 www.123filter.com | [phone] | [e-mail]
When to change the filter?
The filters are highly suggested to be replaced when they reach their recommended replacement cycle.
However, the actual lifespan of filters may vary depending on the source water quality and daily
usage. If you notice a great decrease in the tap water flow or detect an unpleasant smell, taste, and
odor, it would be a good time to get your filters changed.
How to change the filters?
Carefully follow the instructions that come with the filter package.
O-rings: Replace every 3 years or sooner if a leak happens at the O-ring.
The package comes with spare O-rings for the pre-filter housing and the membrane housing. Please
save them with this manual.
What should I do with the system when going out of town?
When you leave for an extended time, you will want to shut off the water supply to the system. To
do this, shut off the water inlet supply, and open the pure water outlet until it stops running. The
filters should be replaced if the system is not used for over a week, as they will be sitting in stagnant
water.
Leak Stop Valve Pads (ALS1P3) Replacement
It is highly recommended that you watch the video "Absorb Pad Replacement of iSpring Leak
Stop Valve | Easy DIY | Step by Step" on YouTube.
Troubleshooting Guide
Model#RCC1DP

www.123filter.com | [phone] | [e-mail] Page 14
Trouble
Possible Issue
Possible Solution
No output water
from the pure
water outlet
a. Water supply is turned off.
b. Incorrect installation.
c. Crimped tubing impedes the
water flow.
d. The pump is not running,
therefore not allowing water
through.
a. Turn on the water supply.
b. Verify all tubing connections.
c. Check and uncrimp all tubings.
d. Make sure the pump is plugged into a
live outlet that gets continuous power.
Leakage in
connections
a. Tubing is not inserted
properly into the port.
b. The O-ring inside the fitting is
not creating a seal.
c. Not applied enough Plumber's
tape to the threads.
d. The housing/cap is not
tightened properly or misaligned
with the threads.
a. Reinsert the tubing about 1/2'' into the
port.
b. Check the O-ring. Replace it if
necessary.
c. Reapply and increase the wraps of
Plumber's tape to ensure a proper seal.
d. Retighten the housing/cap properly.
Leaking from
between the
membrane cap
and membrane
housing
a. The O-ring is not seated
correctly.
a. The O-ring should be seated on the
end of the membrane housing before the
threads begin. The membrane cap is
then screwed on over it. When
positioned incorrectly, it will create a
gap or damage the O-ring. When in the
correct place, there will not be any
pressure or tension on the O-ring.
High TDS in RO
water
a. Incorrect installation.
b. The RO membrane in not
installed.
a. Verify all tubing connections and the
direction of filter installation. Contact
the iSpring Customer Service Team if
the trouble still exists.
b. If the TDS of the tap water and water
from the system is about the same,
ensure the RO membrane is installed.
The semi-permeable membrane is blue,
comes in sealed packaging, and goes in
the stage 4 membrane housing.
The system has a
continuous drain
a. Incoming water pressure is
below 45 psi (Model#RCC1D)
or 30 psi (Model#RCC1DP)
b. The Automatic Shut-Off
Valve (AAS2) or check valve is
defective.
c. The inlet water solenoid valve
is bad and cannot shut off the
incoming water supply.
a. Increase the incoming water pressure,
such as adding a booster pump.
b. Contact the iSpring Customer Service
Team for replacement.
c. Contact the iSpring Customer Service
Team for replacement.
Cloudy water
after installation
a. In the weeks after installing
the system or changing the
filters, you will see many tiny
air bubbles in the RO water.
This can cause the water to
appear "cloudy."
a. The bubbles will disappear as the
system clears itself of trapped air and
are harmless for the time being.

Page 15 www.123filter.com | [phone] | [e-mail]
Pump does not
start
a. No power.
b. Incoming water pressure is
below 30 psi.
c. Low-pressure switch is not
functioning correctly.
a. Make sure the pump is plugged in. If
it is plugged in and still not kicking on,
make sure it is not plugged into the
same outlet as the garbage disposal.
Typically this outlet only has power
when the garbage disposal is switched
on.
b. Increase the incoming water pressure,
such as adding a booster pump.
c. Contact the iSpring Customer Service
Team for replacement.
Pump runs 24/7
a. If the output flow remains
normal, the high-pressure switch
is faulty.
b. If the output flow is little to
no, either the check valve is
losing pressure, or the pump
itself is faulty.
a. Contact the iSpring Customer Service
Team for replacement.
b. Contact the iSpring Customer Service
Team for replacement.
For questions or concerns, please contact us at [e-mail] or visit our help page at
123filter.com/support
Glossary and Terms to Know
Add-On Kit (#ACL1): Filter add-on kit for adding additional inline filters to an existing system. It
comes with quick-connect elbow fittings, filter clamps, and extra tubing
Auto Flush Solenoid Valve (#ASOF7): Automatically flushes the RO membrane to preserve
membrane life and efficiency
Booster Pump (#PMP150): 24-volt booster pump used by residential iSpring RO systems
Check Valve (#ACV1K): One-way valve that does not allow water back into the membrane housing.
It looks like a standard fitting and is located on the RO water port of the membrane housing
CTO Carbon Block Filter (#FC15): 3rd stage. 5-micron 10" carbon block filter. Further reduces
any residual chlorine, tastes, and odors before the water reaches the RO membrane
Drain Saddle (#ADS1K): Attaches to your under-sink drain pipe to secure the drain tube coming
from the system
Elbow Fittings (#4044K): Quick connect elbow fittings used on the system (except the membrane
housing and cap). 1/4" tubing connection and 1/4" NPT male thread
Feed Water Adapter (#AFW43): It goes in line with your cold water line and branches off a water
supply line to the RO system. Can adapt to 3/8" and 1/2" cold water lines
Feed Water Solenoid Valve (#ASOW7): Opens the water supply to the booster pump when the
low-pressure switch and high-pressure switch are both on. Shuts off the water supply when one or
both turn off
Flow Restrictor (#AFR300): Limits the drain water flow, keeping pressure in the system and
allowing the RO process to occur
GAC Filter (#FG15): 2nd stage. 5-micron 10" granulated activated carbon filter. Reduces chlorine,
tastes, and odors from the water
GPD: Gallons Per Day

www.123filter.com | [phone] | [e-mail] Page 16
High-Pressure Switch (#AHP1): Receives pressure signals from the pure water line. It turns on
when the pure water line pressure is below 20 psi and turns off when pure water line pressure reaches
45 psi.
Housing Wrench for Membrane and Stages 1, 2, and 3 Housings (#AWR2): Housing wrench
used to screw on and unscrew the membrane housing cap and the stage 1, 2, and 3 filter housings
Leak Stopper (#ALS1): Protects from any possible leaks by cutting off the water supply when the
sponge absorbs water
Low-Pressure Switch (#ALP1): Turns on when the source water pressure reaches 6 psi, turns off
when source water pressure drops below 6 psi
Membrane Housing and Cap (#NW12): Horizontal housing that the RO membrane is inserted into
Membrane Housing O-Ring (#ORM): 2 1/2" O.D. O-ring used to create the seal between the
membrane housing and the membrane cap
PPM: Parts Per Million, a unit used to measure TDS readings
psi: Pounds Per Square Inch, a unit used to measure water pressure
Quick Connect Fitting: A secure, easy-to-connect, and disconnect type of fitting used on the system.
The tubing is inserted past the tiny O-ring located inside each fitting, then locked into place by the
spider lock and blue clip
Reverse Osmosis (RO) Membrane (#MC150): 4th stage. High rejection, 0.0001 micron, thin-film
composite (TFC) reverse osmosis membrane, the heart of the reverse osmosis process
Sediment Filter (#FP15): 1st stage. 5-micron 10" polypropylene sediment filter. Traps particulate
matter such as dirt, rust, and silt
Stage 1, 2, and 3 housing O-Rings (#ORF): 3 5/8" O.D. O-ring used to create the seal between the
stage 1, 2, and 3 filter housings and their respective caps
Stage 1 See-Through Sediment Filter Housing (#HC12): Transparent stage 1 housing holds the
sediment filter. The see-through housing allows for the sediment filter to be visually inspected
Stage 2 GAC Filter Housing (#HW12): Solid white housing that holds the stage 2 GAC filter
Stage 3 CTO Filter Housing (#HW12): Solid white housing that holds the stage 3 CTO filter
TDS: Total Dissolved Solids, a measure of the contamination level of a water source
Transformer for Booster Pump (#ATRF150): Power supply used for the PMP150 booster pump
on residential iSpring RO systems
Optional Add-on
Ice Maker Connection Kit (Model# ICEK)
The iSpring ICEK can be purchased separately to feed RO water to your refrigerator for crystal-clear
ice cubes. It can be easily installed to connect the RO system to your fridge's ice maker or water
dispenser.
TDS Test Meter (Model# TDS2 or TDS3)
The TDS test meter can be used to check your tap water quality regularly and help determine the time
for filter replacement.
Tubing (Model# T14B or T14W)
1/4'' food-grade tubing in a 50' roll is good for tubing replacement and extension as needed.
iSpring Tanks
This RO system can be used with a 4 – 200 gallons storage tank. A tank helps meet the impulsive
high-volume demand and build a commercial or whole-house Reverse Osmosis solution.

.
on incoming water quality.

__________________ __________________
__________________ __________________
______________________________________________
____________ ______________ _________________
___________________________________________
______ _________________ ___________________________________
