ITW Mima GIROTEC TWIN User manual

V3.0
OPERATING INSTRUCTIONS (1-6)
SEMI-AUTOMATIC MACHINES
GIROTEC TWIN
GIROTEC STR

Girotec TWIN Girotec STR
Height 2460mm 2400mm
Length 2570mm 1700mm
Width 750mm 730mm
Machine weight 380kg 160kg
Max. weight of film roll 2x3kg 3kg
Rollcage Dimenstions Girotec Twin/STR 720/810/1900mm
Max. pallet dimensions in Girotec STR 1000*1200*1850/2050mm
Rotation Area (RA) Girotec Twin 1700mm
STR 2055mm
Electrical supply STR 220-240v/50Hz
Girotec Twin power supply 24v, battery charger 220-240v/50Hz
TECHNICAL SPECIFICATIONS
SEMI-AUTOMATIC MACHINES
V3.0
TWIN STR

1. MACHINE MAIN COMPONENTS 1
2. OPERATION 2
2.1 Control panel 2
2.2 Preparations 2
2.3 Mount the film roll 3
2.4 Adjust film tension 3
2.5 Adjust the wrapping settings 3
2.6 Wrapping 4
3. SAFETY 5
5.1 General 5
5.2 Safety equipment 5
5.3 Hazard Zone 5
5.4 Safety notes 5
In case questions appears, contact your local
distributor.
Authorized representative:
ITW Mima Packaging systems Finland
Tel:[phone]
Technical support
www.mimaitw.com
SEMI-AUTOMATIC MACHINES
TABLE OF CONTENTS
V3.0
GIROTEC TWIN
GIROTEC STR

MACHINE MAIN COMPONENTS
1
GIROTEC TWIN:
1. Boom
2. Rotary arm
3. Film distributor
4. Film roll
5. Bottom frame
6. Operating panel
7. Tower
8. Battery cover
9. Rollcage Holder
SEMI-AUTOMATIC MACHINES
1 2
3
3
4
4
5
6
7
8
9
GIROTEC STR:
1. Boom
2. Rotary arm
3. Film distributor
4. Film roll
5. Bottom frame
6. Operating panel
7. Tower
8. Tensioner
9. Rollcage Holder
1
3
4
5
6
2
7
8
9

OPERATION
2
2.1 Control panel
1. Emergency stop
2. Plus Top wrapping layers, overlapping
adjustment (much, medium, less)and
selection of language
3. Plus bottom wrappings
4. Battery charging status
5. Wrapping height display
6. Wrapping mode selector button
7. Minus bottom wrappings
8. START button
9. Main power switch
10. STOP button
11. RESET button
12. Info button (Menu items)
13. Minus Top wrapping layers,
overlapping adjustment (much, medium,
less) and selection of language
2.2 Preparations
1. Open the arm
locking device
(twin model only)
2. Turn main switch to
its ON position
3. Push the reset
button (1.)to move
machine to its home
position.
SEMI-AUTOMATIC MACHINES

3
2.3 Mount the
film roll
1. Press the film roll
up to the lowest
surface of the film
distributor
2. Pull a length of
film off the film roll
and thread the film
around the guide
rollers as shown in
the adjacent
drawing
2.5 Adjust the
wrapping settings
1. Select wrapping mode
You may select any of
three different wrapping
modes:
- First wrapping height of
77cm. (1.)
- Second wrapping height
of 133cm. (2.)
- Third wrapping height of
190cm. (3.)
2. Adjust top and bottom
wrapping by pressing the
push buttons (▲or ▼).
3. Adjust the degree of
overlap
Press info button
Adjust overlap degree by
pressing the push buttons
(▲or ▼).
Choose one of three
choices:
- Much
- Medium
- Little
2.4 Adjust film
tension
Use the brake wheel to
adjust the optimum film
tension
Release roller brake (lift
brake plate up)
OPERATION
SEMI-AUTOMATIC MACHINES
1. 2.
3.

4
2.6 Wrapping
1. Complete machine
can be moved by
forklift or pallet truck
next to the rollcages.
(twin model only)
2. Move rollcage to
one of two wrapping
stations and fix it in
the rollcage holder.
3. Press Reset button
4. Pull the film out far
enough to enable it to
be fastened to the
corner of the rollcage.
Tie the film firmly to
the pallet.
5. Press the Start
button
OPERATION
SEMI-AUTOMATIC MACHINES

5
SAFETY
SEMI-AUTOMATIC MACHINES
5.1 General
Please read the operating instructions
carefully before operating the
machine. The machine has automatic
functions which could endanger the
safety of an inexperienced operator.
5.3 Hazard zone
No persons or objects other than the
product to be wrapped shall be
present in the hazard zone during
operation of the machine. The
hazard zone is the light colored area
shown in the adjacent drawing.
5.2 Safety equipment
1. The EMERGENCY-STOP button
stops the unit in a safe position. The
unit cannot be restarted until the
button is pulled out again.
2. The rotary arm is equipped with a
safety edges which stops the
machine in case of contact.
(counterforce of ≥100N).
3. Flashing warning light
- Flashing when machine is operating.
Do not enter the hazard zone while
warning light is flashing.
5.4 Safety notes
1. Never enter the area
between the tower and the
pallet while the machine is
in operation. You could be
trapped and seriously
injured.
2. Never enter in the hazard
zone after hearing
“wrapping start” warning
signal.
(4 *signal). Few seconds
after signal the wrapping
cycle is starting.
When moving the machine,
always ensure that the two
wrapping arms are locked.
Check that the machine is
stable before you begin
wrapping.

6
SEMI-AUTOMATIC MACHINES
Position: _______________________________________
Name: _______________________________________
EC DECLARATION OF CONFORMITY
We hereby declare that the following machinery complies with the essential health and
safety requirements of the Machinery Directive 2006/42/EO and the Electromagnetic
Compatibility Directive 2004/108/EC.
Description of machinery: Semi-Automatic wrapping machine
Machine types: Girotec TWIN
Girotec STR
Authorized representative: ITW MIMA Packaging Systems
Ruskontie 16
FI –21250 MASKU
This machinery has been designed and manufactured using the provisions of EN 415-6 Safety of packaging
machines.
Signed: _______________________________________ Date:____________
29.08.2011
Alexander Kolev
Manager Semi-automatic Machines
