Iva TR3 User manual

IVA TR3
GUIDE BOOK&USERMANUAL

FOR YOUR
SAFETY,
PLEASE WEAR THE HELMET CORRECTLY！
Please make sure the helmet covered your head
completely as below.
Correct Wrong

2
Technical specifica tion
Item
Item
L*W*H(mm)
1760*710*1080
Grade ability
≤15°
Ground clearance(mm)
120
Max speed(km/h)
35
Weight(kg)
74.7K G
Range(km)
70
Load(1 rider)
75K G
Charing time
4-8
Rated po w er
650W
Tire
3.0-10
Br ak e
front disc rear hub
*The date come from the corporate laboratory
tests in
ideal conditions and all date are for reference only.

3
1
rearview mirr or
2
direction handle
3
front turning light
4
he adlight
5
front shock absorp tion
6
front disc br ak e
7
seat armr es t
8
s ea t
9
t aillight
10
rear wheel hub
Parts dr awing
1
2
3
7
8
4
9
5
10
6

4
Display ins truc tion
high/low be
am
power display driving speed lighting switch speed control
handle
turning
light horn r e v er sed
switch of g
e ar

5
!
W arning: Driving operation
no tic e
In order to ensure your safety, please practice in the open place for the first time, master t h e
essentials after riding on the road, and please consciously obey the traffic rules, to ride on the
non-motorized road, do not lend to people who can not operate the three wheeler .
Therole of the manipulation p art
The structure of the manipulation part is shown on page 04, and the functions of each part in the
figure are as f ollo ws:
1. Theleft brake handle is the rear brake and brake cut off the power control switch handle, when hold the
brake handle, the rear brake stop, the brake light on, and the controller output to the motor voltage
down to zero, the motor stop working, make the rear wheel brake double insurance.
2. Lighting switch (headlight switch and variable lighting switch), when driving at night, first dial t he
lighting switch to the first gear position. At this time, the night taillights on; then dial the he adlight switch
to the second gear, the far and near light can w ork.
3. The high and low beam switch can convert the strength and distance of the light beam with high
light; the position and the beam irradiation down to the near light, weak light. Note: For safety
reasons, when driving at night, the current light switch should be pushed to the position.
4. Turn signal switch in the turn left or right and change the lane, the signal light switch. When di a li ng to R
(right), the front and rear turn lights on the right side flash to signal a right turn. When dialing to L (left), the
front and rear turn lights of the left side flash to signal a left turn. Close to the middle position, press
the switch inward to r e turn.

6
5. The speedometer of the instrument assembly isa device showing the driving speed (unit: k m / h ) a n d the
mileage. The power meter isthe sizeof the voltage in the battery, which refersto the high power in the H
position and the pointer showing the low power in the Lposition. When the pointed light on the instrument
flashes,it indicates the direction of turning or changing, and the middle light indicates the high beam and
low be am.
6. The right brake handle (front brake handle) is the handle of the front wheel brake brake and br ak e power
offcontrol switch. When holding the brake handle, the front brake works and the front wheel stops turning.
It is recommended that the front and rear brake handles should be used in emer genc y braking. Note: do not
useonly the front brake handle, otherwise the vehicle isprone to sideslip .
7. The rearview mirror is to observe whether there are pedestrian vehicles left or right, to ensure the
driving safety when turning (or ov ertaking ).
8. The main lock (ignition lock) isthe switch to control the vehicle power supply and the controller, t h e ignition
lock lock can control the vehicle work, when the vehicle abnormal fault, the speed c ontrol handle lost the
motor speed, please immediately close the switch to OFF, can safely stop the v ehicle work, to avoid safety
ac cident s.
9. Horn switch, pressthe switch, the horn rings.
10. The parking device is used for parking vehicle after parking. Hold the left brake handle after
driving, then hold the main lock device up and open the left brake handle. At this time, the p arking device
will have the effect of p arking.

7
11.The three-speed switch (speed regulating switch) is a three-gear speed regulating switch designed for
special people. When the speed set at low speed switch is 15 km/h, the speed set at the medium speed
switch is 25 k m / h, and when the speed regulating switch is set at high speed state, the speed is 35km / h.
Note: For safety considerations, it is recommended to set the switch at low speed in the initial stageto
avoid acc ident s!
12.The reversing switch is to dial the R position of the switch and turn the speed control handle to play
the reversing function, and the reversing speed limit is 5km / h.
13.Remote control switch (anti-theftswitch) in the premise of user requirements selection.It has the function
of remote control power on and power off for the vehicle power supply .
14.The main switch (under the seat) controls the main power switch of the scooter. When riding, please
dial this switch to the closed state; if you do not ride for a long time, please cut the cir cuit breaker to the
off s t a t e.
15.Charging socket: In the non-charging state, please cover the charging socket cover with the
charging socket port to avoid other conductors touching the charging pin.

8
Thevehicle use pr ec autions.
Use and Maintenance
1. Insert the car key into the power switch, clockwise open, at this time the power supply and po w er
display light on the instrument screen ison, indicating that the power supply is c onnec t ed.
2. Afterstarting, the right hand will rotate slowly the throttle backward, gradually accelerate, loose the
throttle can reduce the speed until the motor power supply is cut off.When driving, please drive o n non-
motorized roads at a low speed.
3. The vehicle has the function of brake power-offprotection. Whatever the left and right br ak e
handlebars, the motor power supply can be cut off to ensure the safety of driving.
4. After parking, if want the motor to be restarted, reset the speed control handle and then slo wly rotate
the speed control gradually .
Note for the use of motor and c ontr oller .
1. When driving against the wind or climbing, do not accelerate rapidly, but should accelerate e v enly and
gradually to avoid excessive load on the motor and b a tt er y .
2. In the rainy season, the vehicle should avoid from the center line of the rear wheel, to avoid the
motor and battery damp, burn the motor.
3. When driving, should avoid operate the speed control and brake at the same time, so as not to
overload the motor and damage to other p art s.
4. The vehicle is not adapt to uneven or steep road driving, if the vibration is large, will cause poor

9
contact with electrical parts, if to this road, please try to slow down as well.

10
! W arning:
1. Do not instantly accelerate the speed, to ensure the safety of driving, while protecting the
mo t or , bat te r y .
2. The vehicle with differential rear axle motor, the differential for gear combination needs gear oil
lubrication, usually called gearbox, in normal driving conditions should be changed gear oil every 3
months.
Precautions for useof b a tt er y
1. Technical f e a tur e:
At present, the commonly used battery is "sealed maintainable lead-acid battery" as the energ y
storage component of leisure vehicles, with large capacity, long life and good maintainability .
2. Battery is a c onsumable:
Battery is equivalent to the "fuel tank" in the car, isthe place to store energy, but it isdifferent from the "fuel
tank" lies in: its "volume" will decrease with the depth of use, in this sense,battery belongs to
consumables. And this "reduction" "decline" speed isdifferent, the choice of high quality battery, t he
correct use of battery, good car condition, especially the use of high efficiency motor will effec tiv ely delay
the decline of battery c apacity .
3. Correct useof the battery, pr ec autions:
! Always put the battery in a sufficient power state. Lead acid battery should be replenished in time,
which
isbeneficial to prolong the life of the battery. If the battery is not used for a long time, please be sure to keep
the battery in a state of sufficient power, and charge once a month, it is strictly prohibit ed to "lose power"
storage. ！Pay attention to check whether the temperature on the surface of the

11
battery box when charging the battery, and whether the charger indicator is changed to "orange"
and
"green". If it cannot be converted, please immediately cut offthe power supply and send the cha r ger and
the battery to the maintenance center for inspec tion.
! At low temperature (below 15℃) conditions, the battery is easy to decline by 20%~30%, and the
corresponding range will also be r educ ed.
! When replacing the internal battery of the battery pack, it isstrictly prohibited to mix the battery w it h different
performance parameters, otherwise the battery will cause damag e.
! Battery shall not contact the flame, heat source and alkaline substances, avoid direct sunlight
exposure, otherwise it will shorten the battery life.

12
!! After driving in summer, because the battery
temperature is high, it should not be charged
immediately. In winter, the battery is below 0℃Celsius, the battery is at low temperature, and t h e
charging should be carried out indoor s.
Note: There are three main ways to maintain sufficient range driving c apacity
1. As far as possible to drive at a low speed, the working current and speed of the electric vehicle into a
nonlinear rise relationship, the endurance and driving speed is inversely proportional, the battery lif e and
driving speed is inversely proportional, that is to say, maintaining good low speed driving habit s for
extending the battery usetime has great benefit s.
2. Asfar as possible to maintain the use of "frequent charging" habits, to prevent the battery fr om often
working in the "undervoltage" state, but also to reduce the probability of power loss.
3. The electric vehicles with low speed gear, try to use low speed gear. With low speed when dr i v in g , driving
ability is strong.
Charger and charging pr ec autions
1. Characteristicsof the charging t echnology
Charger internal using high-tech CPU chip, equipped with electric bicycle / electric vehicle b a tt er y
charging mode optimization program, using the random process control theory, the battery surplus
uncertain, after charging disconnected power time is uncertain, each time must be full of unc ertain under
the actual use of the optimal charging mode. In this intelligent charging mode, combined with batter y
maintenance technology, the online maintenance function can be realized without the intervention
of the user, and the battery can be reduced or not used for a long time automa tic ally repaired to the best
s t a t e.

13
Pay attention t o:
! In the area of unstable grid voltage, when the grid voltage fluctuation exceeds AC220V± 20%,
otherwise it is easy to cause the charger to undercharge the battery or the charger to f ail.
!This recharger does not need to be grounded
1. Open the charging port 2. Contact he charger

14
2. Charging
me thod
The charger indicator is"green" when the battery isfilled in the floating charge state, there isno need to cut
offthe power if there is an emergency, the indicator is "orange" can also be used.When y ou charge the
battery of the scooter, do not close the main switch. plug the charger output plug into the socket on the
vehicle body, and then insert the charger input power plug into the AV220V po w er sock e t.
3.Charging ins tructions
Charger in power to charge the battery, charging indicator display red state, said that the battery is in the
charger into constant current charging state, when the orange indicator, the battery has charg ed into 90%,
when the green and orange lights alternately, about an hour after the green battery c apacity , 100% full, if
continue to charge, online maintenance, maintain or restore capacity, maintenance af t er continue, the
charger into the battery micro current supplement, if still continue to charge the b a tt er y , and back to the
online maintenance stage.
! When charging, it is strictly prohibited to cover other items on the charger and battery box to
facilitate ventilation and heat dissipa tion.
! When carrying the charger, do not bump violently or collide, otherwise it iseasyto cause damag e.
4. Other important pr ec autions
When used and stored, liquid and metal chips should be prevented from penetrating into the charger to
prevent short circuit in damaging the charger .

15
! When used and stored, liquid and metal chips should be prevented from penetrating into the charger to
prevent short circuit and damaging the charger. The charger will generate some heat at the bottom of the
charger to prevent flammable and explosive items, such asflammable plastic or foam; the top and sidesof
the charger; please usethe charger in a well-ventilated environment. Ifyou smell the odor during the
charging process or find that the external temperature of the charger is too high (the surface
temperature of the shell is higher than 65℃),please stop charging immediately and send it to the
maintenance department for inspec tion.
! For the online maintenance of the battery, a proper long charging time is needed, and the user c an
maintain the battery online at the appropriate time and cycle. The long charging effect once a week is g ood.
The battery products of different battery factories, in different seasons (different oper a ting
temperatures), the online maintenance charger has an adaptive function. Automatic adjust the
charging voltage value, to ensure sufficient power without damage to the battery, battery c apacity
decline isslow, effectively prolong the working life of the b a tt er y .
Tip
! When the charger fails or the battery fails, the charger indicator may not change color for a long time
(generally more than 12h), the charger is always red, and the battery generates high heat. Please
immediately stop charging the battery and send it to the maintenance department for inspec tion.
! Online maintenance of the charger operation and other precautions refer to the use method c ont ent of the
charger .

16
Common tr oubleshooting
Common fault phenomenon
Troubleshooting me thod
Turn on the power supply, and the
instrument is not display ed.
1. Whether the key switch isopened;
2. Whether the power plug isinserted;
3. Whether the broken electrical switch is opened.
Turn on the power supply, the
controller works normally, turn the
handle, but the motor does not
r ot a t e.
1. Check whether the control line of the right hand falls off, whether the
controller or motor joint fallsoff;
2. Theinitial speed isnot enough, and external assistance isneeded;
3. Whether the left and right switch bars are power off .
C y cling is laborious and slow
speed.
1. Checkwhether the brake is lock ed;
2. Whether the tire pressure is appropria t e;
3. Whether the battery voltage is sufficient, if insufficient, ple as e charg e;
4. Whether beyond the limit ramp or he adwind
Short driving dis t ance.
1. Ifthe battery isplaced for a long time, please r echarg e;
2. Whether the tire pressure isinsufficient ;
3. Checkwhether the brake istoo tight ;
4. Whether the battery charging issufficient ;
5. Whether the battery is uphill or he adwind;
6. Whether the temperature istoo lo w .
The battery can not be charg ed.
1 . C h e c k t h e c h a r g e r a n d p o w e r s u p p l y, w h e t h e r t h e b a tt e r y
connection isintact and r eliable;
2. Whether the external power supply is charged and the voltage is
normal.

17
Daily inspection and adjus tment
In order to ensure driving safety, users should pay attention to the following important ma tt er s.
Checkand adjust of the brake sys t em：
1. Arethe left and right brake bars well? Can the power supply be cut off automatically during br aking ?
2.When isrunning at a speed of 20 km/h, emergency braking should be made safely parked within 5m; if the
braking distance istoo long, the brake should be adjusted; if the brake pad isworn, it should be replaced in
time.
3.The front and rear wheels are not power-supply switched on. Is the idling normal? Is there any friction
resistance?Adjust the brake system by adjusting the jacking screw on the brake hubcap, so that the brake
hand can safely hold 1 / 2 of the brake brake. Note: Different hand strength, and the 2 paragraph shall
pr e v ail.
Inspection and adjustment of other security systems:
1. Is the front and rear tire pressure normal? If the air pressure is insufficient, it should be inflated in time.
2.Do the left and right turn signals and rear taillights work pr operly?
3.Whether the power-off brake isworking normally
?
Matters needing attention in driving:
1.Whether the start issmooth, whether the driving speed issuddenly fastand slow f eeling.
2.The bars steering isfreely, light and fle xible.
3.Whether the front and rear brakes are flexible and reliable, and whether the abnormal sound is
produced when the front and rear wheels rot a t e.

18
4.Turn signal, horn, headlight and rear taillight, instrument light, iswork normal or
not.
5.Whether the front and rear tire pressure issufficient .
6.Whether the fastening screws, screws and nuts of the whole car are loose phenomenon.
7.Whether the free driving of the front and rear brake cable is appropria t e.
Note: If the above situation is abnormal, it should be replaced immedia t ely .
Simple adjustment of the v ehicle：
1.The brake hand can brake safely when it reaches 1 / 2.
2.Maintain proper tire air pressure (standard pressure: 300kpa(3.0kpa/cm2)).

19
Matters needing a tt ention Notesfor
c y cling
1. Strictly abide by the rules of traffic, drive the lane in accordance with the traffic r e gulations
2. The rated carrier of recreational vehicles is the same as electric bicycles and bicycles, and it is strictly
prohibited to drive with adults (except childr en);
3. Thehandlebars can not be hung object driving, so asnot to operate out of c ontrol.
4. Driving in the rain can only wear a poncho, not with an umbrella, it is strictly prohibited to oper a t e the
vehicle with one hand;
5. When cleaning vehicles, do not clean directly with water. It isforbidden to wash with high-pressure water
gun to prevent electrical damp short cir cuit
6. It isstrictly prohibited to overspeed downhill. Athigh speed, do not useone hand or brake quickly to avoid
the danger of the center of gravity f or ward;
7. Unauthorized dismantling of the vehicle body, will bring potential safety risks to your v ehicle,
causing thr e a t s
8. Before riding, we must ensure that the fastenersare safe and reliable to avoid ac cident s
9. Avoid driving on uneven, muddy, gravel and steps of the road, so as to avoid tire burst, hub
deformation damaged your vehicle to dang erous
! Note: The premise of braking distance should be increased when riding in rain or sno w .
