iWave iW-RainboW-G15S Installation manual

Rev 1.1
Page 1 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
iW-RainboW-G15S
i.MX6 Pico ITX –Single Board Computer
Hardware User Guide

Rev 1.1
Page 2 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Document Revision History
Document Name
iW-PREBB-UM-01-R2.0-REL1.1-Hardware User Guide
Revision
Date
Description
Authors
0.1
21st Mar 2013
Initial Draft Version
Eshak
1.0
21st Jun 2013
Initial Offical Release
Pradap, Aneesh
1.1
27th Jan 2014
Offical Release for Production Version SBC
Pradap, Aneesh
PROPRIETARY NOTICE: This document contains proprietary material for the sole use of the intended
recipient(s). Do not read this document if you are not the intended recipient. Any review, use,
distribution or disclosure by others is strictly prohibited. If you are not the intended recipient (or
authorized to receive for the recipient), you are hereby notified that any disclosure, copying
distribution or use of any of the information contained within this document is STRICTLY PROHIBITED.
Thank you. “iWave Systems Tech. Pvt. Ltd.”

Rev 1.1
Page 3 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Disclaimer
iWave Systems reserves the right to change details in this publication including but not limited to any
Product specification without notice.
No warranty of accuracy is given concerning the contents of the information contained in this
publication. To the extent permitted by law no liability (including liability to any person by reason of
negligence) will be accepted by iWave Systems, its subsidiaries or employees for any direct or indirect
loss or damage caused by omissions from or inaccuracies in this document.
Trademarks
All registered trademarks and product names mentioned in this publication are used for identification
purposes only.
Technical Support
iWave Systems technical support team is committed to provide the best possible support for our
customers so that our Hardware and Software can be easily migrated and used.
For assistance, contact our Technical Support team at,
Address : iWave Systems Technologies Pvt. Ltd.
# 7/B, 29th Main,
BTM Layout 2nd Stage,
Bangalore,
India –560076
Email : [e-mail]
Website : www.iwavesystems.com

Rev 1.1
Page 4 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Table of Contents
1. INTRODUCTION .........................................................................................................................8
1.1 Purpose........................................................................................................................................ 8
1.2 Pico ITX Overview ........................................................................................................................ 8
1.3 List of Acronyms .......................................................................................................................... 8
1.4 References ................................................................................................................................... 9
1.5 Important Note..........................................................................................................................10
2. i.MX6 Pico ITX –SBC Architecture and Design ...........................................................................11
2.1 i.MX6 Pico ITX - SBC Features.................................................................................................... 12
2.2 i.MX6 CPU.................................................................................................................................. 14
2.3 Boot Mode Setting..................................................................................................................... 15
2.4 Memory .....................................................................................................................................16
2.4.1 DDR3 SDRAM.........................................................................................................................16
2.4.2 SPI NOR Flash Memory..........................................................................................................16
2.4.3 eMMC Flash Memory............................................................................................................16
2.4.4 Micro SD Connector .............................................................................................................. 16
2.4.5 Standard SD Connector .........................................................................................................17
2.5 Audio/Video Features................................................................................................................ 19
2.5.1 AC’97 audio codec Interface .................................................................................................19
2.5.2 HDMI interface...................................................................................................................... 21
2.5.3 LVDS Connector..................................................................................................................... 23
2.5.4 Resistive Touch Connector.................................................................................................... 26
2.5.5 CMOS Camera Connector .....................................................................................................27
2.5.6 MIPI Camera Connector ........................................................................................................ 29
2.6 Communication Features .......................................................................................................... 31
2.6.1 Gigabit Ethernet Interface.....................................................................................................31
2.6.2 USB OTG Connector .............................................................................................................. 33
2.6.3 USB Host Connector.............................................................................................................. 34
2.6.4 Mini PCIe Connector .............................................................................................................35
2.6.5 CAN Header...........................................................................................................................38
2.7 Debug Features..........................................................................................................................39
2.7.1 USB Micro AB Connector for Debug console ........................................................................ 39
2.7.2 JTAG Connector.....................................................................................................................40
2.7.3 4bit DIP Switch ......................................................................................................................42
2.7.4 Status Indication LEDs ...........................................................................................................43
2.8 Expansion Connector.................................................................................................................44

Rev 1.1
Page 5 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.9 Optional Features ...................................................................................................................... 49
2.9.1 RTC Controller with Coin cell................................................................................................. 49
2.9.2 SATA Connector .................................................................................................................... 49
3. Electrical specification..............................................................................................................52
3.1 Power Input Requirement ......................................................................................................... 52
3.1.1 Power Jack.............................................................................................................................52
3.1.2 2 Pin Power connector ..........................................................................................................53
4. Board Numbering & Revision History........................................................................................55
4.1 i.MX6 Pico ITX SBC Numbering.................................................................................................. 55
4.2 i.MX6 Pico ITX SBC Revision History ..........................................................................................56
5. Mechanical Specification..........................................................................................................57
6. APPENDIX I ..............................................................................................................................60
6.1 i.MX6 Pico ITX-SBCSilk Screen ...................................................................................................60

Rev 1.1
Page 6 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
List of Figures
Figure 1: i.MX6 Pico ITX –SBC Block Diagram ............................................................................................11
Figure 2: i.MX6 CPU Simplified Block Diagram ...........................................................................................14
Figure 3: Micro SD Connector..................................................................................................................... 16
Figure 4: Standard SD Connector................................................................................................................ 18
Figure 5: Audio Jack ....................................................................................................................................19
Figure 6: HDMI Port .................................................................................................................................... 21
Figure 7: LVDS Connectors..........................................................................................................................24
Figure 8: Resistive Touch Connector........................................................................................................... 26
Figure 9: Camera Connector ....................................................................................................................... 27
Figure 10: MIPI Camera connector .............................................................................................................29
Figure 11: Gigabit Ethernet Connector.......................................................................................................31
Figure 12: USB1 OTG Connector ................................................................................................................. 33
Figure 13: USB Dual Stack Connector .........................................................................................................34
Figure 14: Mini PCIe Slot............................................................................................................................. 35
Figure 15: CAN Header................................................................................................................................ 38
Figure 16: Console Debug USB Micro AB Connector .................................................................................. 39
Figure 17: JTAG Connector.......................................................................................................................... 40
Figure 18: DIP Switch ..................................................................................................................................42
Figure 19: Expansion Connector ................................................................................................................. 45
Figure 20: SATA0 22pin Connector .............................................................................................................50
Figure 21: Power In Circuit.......................................................................................................................... 52
Figure 22: Power Jack .................................................................................................................................52
Figure 23: 2Pin Power Connector ............................................................................................................... 53
Figure 24: i.MX6 Pico ITX –SBC PCB Dimension ......................................................................................... 57
Figure 25: i.MX6 Pico ITX –SBC PCB Dimension Top Side .......................................................................... 58
Figure 26: .MX6 Pico ITX –SBC PCB Dimension Bottom Side .....................................................................59
Figure 27: Silk Screen Top View ..................................................................................................................60
Figure 28: Silk Screen Bottom View ............................................................................................................ 61

Rev 1.1
Page 7 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
List of Tables
Table 1: Acronyms & Abbreviations.............................................................................................................. 8
Table 2: Boot Mode Settings Truth Table ................................................................................................... 15
Table 3: Micro SD Connector Pin Assignment ............................................................................................ 17
Table 4: Standard SD Connector Pin Assignment ....................................................................................... 18
Table 5: Audio OUT Jack Pin Out................................................................................................................. 20
Table 6: MIC IN Header Pin Out .................................................................................................................. 20
Table 7: HDMI Port Pin Out......................................................................................................................... 22
Table 8: LVDS Connector Pin Out................................................................................................................24
Table 9: LVDS Backlight Connector Pin Out ................................................................................................ 25
Table 10: Resistive Touch Connector Pin Out............................................................................................. 26
Table 11: Camera Connector Pin Out ......................................................................................................... 28
Table 12: MIPI 5M Camera Interface Pin Out .............................................................................................30
Table 13: RJ45 Magjack Connector Pin Out ................................................................................................ 32
Table 14: USB OTG Connector Pin Out .......................................................................................................33
Table 15: USB Host Dual Stack Connector .................................................................................................. 35
Table 16: Mini PCIe Slot Pin Out ................................................................................................................. 36
Table 17: CAN Header Pin Out ....................................................................................................................38
Table 18: Console Debug USB Micro AB Connector Pin Out ......................................................................39
Table 19: JTAG Connector Pin Out.............................................................................................................. 41
Table 20: 4bit DIP Switch setting ................................................................................................................ 42
Table 21: Status LED setting........................................................................................................................ 43
Table 22: Expansion Connector Pin Out...................................................................................................... 45
Table 23: RTC Controller - BOM.................................................................................................................. 49
Table 24: SATA Connector Pin Out.............................................................................................................. 50
Table 25: SATA Connector - BOM ...............................................................................................................51
Table 26: Power Jack Pin Out......................................................................................................................53
Table 27: 2-Pin Power Connector Pin Out (Optional) .................................................................................54
Table 28: i.MX6 Pico ITX SBC Revision History............................................................................................56

Rev 1.1
Page 8 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
1. INTRODUCTION
1.1 Purpose
This document is the Hardware User Guide for the i.MX6 Pico-ITX SBC which is based on the Freescale’s
i.MX6 Applications Processor. This board is fully supported by iWave Systems Technologies Pvt. Ltd. This
Guide provides detailed information on the overall design and usage of the i.MX6 Pico-ITX SBC from a
Hardware Systems perspective.
1.2 Pico ITX Overview
The Pico ITX is a PC mother board form factor. Pico ITX concept is an off-the-shelf, Single-Board-
Computer that integrates all the core features of a common PC. Pico ITX modules have a standardized
form factor of 100mm x 72mm which is half the area of Nano ITX, and provides the functional
requirements for an embedded application.
1.3 List of Acronyms
The following acronyms are used throughout this document.
Table 1: Acronyms & Abbreviations
Acronyms
Abbreviations
AC’97
Audio Codec ‘97
ARM
Advanced RISC Machine
BOM
Bill Of Materials
C
Celsius/Centigrade
CAN
Controller Area Network
eCSPI
Enhanced Configurable Serial Peripheral Interface
GB
Giga Byte
GBE
Gigabit Ethernet
GPIO
General Purpose Input Output
HDMI
High-Definition Multimedia Interface
I2C
Inter-Integrated Circuit
IC
Integrated Circuit
I/O
Input/output
JTAG
Joint Test Action Group
KB
Kilo Byte
LCD
Liquid Crystal Display
LDO
Low Drop-Out
LED
Light Emitting Diode

Rev 1.1
Page 9 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
LVDS
Low-Voltage Differential Signalling
MB
Mega Byte
Mbps
Megabits per sec
MHz
Mega Hertz
MIPI
Mobile Industry Processor Interface
MMC
Multi Media Card
mm
milli-meter
ms
milli second
OTG
On The Go
PCB
Printed Circuit Board
PCI
Peripheral Controller Interconnect
RJ45
Registered Jack 45
RMII
Reduced Media Independent Interface
ROHS
Restriction of Hazardous Substances
RTC
Real Time Clock
SD
Secure Digital
SPI
Serial Peripheral Interface
UART
Universal Asynchronous Receiver/Transmitters
USB
Universal Serial Bus
1.4 References
i.MX6 Applications Processors Products Datasheet
i.MX6 Applications Processor Reference Manual
iW-RainboW-G15S Quick Start Guide R3.0

Rev 1.1
Page 10 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
1.5 Important Note
In this document, wherever i.MX6 CPU signal name is mentioned, it is followed as per below format.
If CPU pin functionality name and CPU pad name is same, Signal name is mentioned as
“CPU_Pad_Name”
Example: SD3_DATA2
In this signal, functionality which we are using and CPU Pad name is SD3_DATA2.
If CPU pin functionality name and pad name is different, Signal name is mentioned as
“Functionality_name (CPU_Pad_name)”
Example:UART3_RTS (SD3_RST)
In this signal, UART3_RTS is the functionality which we are using and SD3_RST is the CPU Pad
name.
If CPU pin functionality is GPIO, Signal name is mentioned as
“GPIONumber_FunctionalityDescription (CPU_Pad_name)”
Example:GPIO7_0_SD1_CD(SD3_DAT5)
In this signal, GPIO7_0 is the GPIO number,SD1_CD (SD1 card detect) is the functionality which
we are using and SD3_DAT5 is the CPU pad name.
Note: The above naming is not applicable for other signals which are not connected to CPU.

Rev 1.1
Page 11 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2. i.MX6 Pico ITX –SBC Architecture and Design
This section provides detailed information about the i.MX6 Pico-ITX SBC Features and Hardware
architecture with high level block diagram. Also this section provides detailed information about
Expansion connector’s pin assignment and usage.
CPU
i.MX6 DUAL LITE
RJ45
Connector
HDMI
Connector
Dual Stack
USB Host
Connector
Audio Out
Jack
Power Jack /
2 pin Power
Connector
USB HUB
Gigabit
Ethernet
PHY
Audio In
Header
AC97 Audio
Codec
USB-Debug
Port
Resistive
Touch
Connector
SD/MMC
Connector
LVDS +
Backlight
Connector
PMIC
USB OTG
Connector
MIPI
Camera
Connector
CMOS
Camera
Connector
Micro SD
Connector
CAN
Header
7 pin SATA
Conn*
Mini PCIE
Connector
Expansion Header
DDR3
1GB
eMMC
4GB
CAN
Transceiver
UART to USB
Touch
Controller
User DIP
Switch &
Status LEDs
USB OTG
MIPI CSI
CSI1
SD3
CAN1
PCIe
GPIOs
SATA*
LVDS0
I2C1
UART2
RGMIIHDMI
USB HOST
AUD4-AC97
MMDC SD4
GPIOs, UARTs, SPI, CAN,
I2C, CSI, MIPI DSI, MLB*,
LVDS1
100mm
72mm
iMX6 SBC BLOCK DIAGRAM
*Not Supported
5V
I2C2
SPI Flash
2MB
eCSPI1
RTC
Controller
(Optional)
SD1
Figure 1: i.MX6 Pico ITX –SBC Block Diagram

Rev 1.1
Page 12 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.1 i.MX6 Pico ITX - SBC Features
The i.MX6 Pico ITX - SBC supports the following features.
CPU
Freescale’s i.MX6 DualLite ARM Cortex-A9 core based CPU (Quad/Dual/Solo compatible)
PMIC
Freescale’s PMIC (MMPF0100F0EP)
Boot Mode Setting
Boot Mode Selection Switch
Memory
1GB DDR3 (Expandable)
SPI Flash (2MB)
4GB eMMC Flash
Micro SD Connector
Standard SD Connector
Audio/Video Features
AC’97 Audio Codec with 3.5mm Stereo Head Phone Out Jack & Mic Input Header
HDMI 1.4Port
LVDS LCD Connector with Backlight Power Header
Resistive Touch Connector
CMOS Camera Connector
MIPI Camera Connector
Communication Features
Gigabit Ethernet PHY with RJ45 Magjack
USB OTG 2.0 through Micro AB Connector
USB Host 2.0 through Dual Stack Type A Connector
Half Mini PCIe Gen2.0 Connector(with PCIe & USB interface)
CAN Header (CAN1 with PHY)

Rev 1.1
Page 13 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Debug Features
USB Micro AB Connector through UART to USB convertor for Debug console
JTAG Connector
4bit DIP Switch (through GPIOs)
4 Status Indication LEDs (through GPIOs)
Expansion Connector Interfaces
2nd LVDS interface (LVDS1)
MIPI DSI interface
8bit Camera interface (CSI0)
SPI Interface-1 Port
2nd CAN Interface (CAN2)
UART –3 Ports
I2C –3 Ports
GPIOs
MLB interface with 6 pin & 3 pin signals*
Optional features
RTC Controller with Coincell
SATA Connector*
General specifications
Power Input - 5V, 2A
Temperature Supported: -20°C to +85°C
Form factor: Pico ITX (100 x 72mm)
*Note: MLB & SATA signals will be available only in i.MX6 Quad & Dual CPU.

Rev 1.1
Page 14 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.2 i.MX6 CPU
i.MX6 is based on Freescale’s Dual Lite/Solo ARM™ Cortex-A9 core based CPU which can operate up to
800MHz speed/core. i.MX6 CPU is Freescale’s latest achievement in integrated multimedia application
processors which is part of growing multimedia-focused products that offers high performance
processing and are optimized for lowest power consumption. The simplified Block Diagram of i.MX6 CPU
is shown below for your reference.
Figure 2: i.MX6 CPU Simplified Block Diagram
Note: Please refer the latest i.MX6 Datasheet& Reference Manual from Freescale website for Electrical
characteristics of i.MX6 Application CPU which may be revised from time to time.

Rev 1.1
Page 15 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.3 Boot Mode Setting
i.MX6 CPU boot process begins at Power On Reset (POR) where the hardware reset logic forces the ARM
core to begin execution starting from the on-chip boot ROM. The i.MX6 Boot ROM code uses the state
of the internal register BOOT_MODE [1:0] as well as the state of various eFUSEs and/or GPIO settings to
determine the boot flow behaviour of the device.
i.MX6 Pico ITX SBC supports Boot Mode Switch (SW4) which is physically located in the top of the PCB.
This Switch is used to select the boot mode setting of i.MX6 CPU as explained in the below table. SPI
Flash used as Default Booting Media.
Table 2: Boot Mode Settings Truth Table
Boot Mode Setting
On i.MX6 Pico ITX -SBC
Description
Switch (SW4) Position
POS 1
POS 2
Internal Boot Mode
(Default)
In this mode, i.MX6 boot
media is selected by GPIO
Pin’s settings
OFF
ON
Boot From eFuses
In this mode, i.MX6 boot
media is selected by i.MX6
eFUSE settings
Note: i.MX6 eFuse setting is
NOT modified by iWave from
silicon shipped value.
OFF
OFF
Serial Downloader
Mode
In this mode, i.MX6 boot
device can be Programmed
through its USB OTG
interface using MFG Tool
ON
OFF
ON –High
OFF - Low

Rev 1.1
Page 16 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
2.4 Memory
2.4.1 DDR3 SDRAM
i.MX6 Pico ITX –SBC uses four 256MB DDR3 SDRAM ICs to support a total on board RAM memory of
1GB (expandable). These devices will operate at 1.5V voltage level. The DRAM calibration resistor used
on board is 240 Ohm 1% resistor. A pair of DDR3 IC is physically located on either side of the board.
2.4.2 SPI NOR Flash Memory
The i.MX6 Pico ITX –SBC supports SPI NOR Flash as default boot device. This is connected to Enhanced
Configurable SPI port 1 (eCSPI1) of the i.MX6 CPU and device will operates under 3.3 Voltage level.
RainboW-G15S Pico–ITX SBC will be shipped with 2MB SPI Flash on it (expandable). The SPI flash
memory is physically located on top side of the Pico ITX –SBC.
2.4.3 eMMC Flash Memory
The i.MX6 Pico ITX –SBC supports 4GB eMMC (expandable) Flash memory as Mass storage also an
optional boot device. eMMC is directly connected to the eSDHC Port 4 (SD4) of the i.MX6 CPU and
operating under 3.3V Voltage level.
2.4.4 Micro SD Connector
Micro SD Card Connector (J13) is directly connected to the eSDHC channel 3 (SD3) of the i.MX6 CPU. This
connector supports up to a 4-bit data transfer along with card detect feature. The main power to Micro
SD Card Connector is 3.3Voltage. Micro SD Connector is physically located on top of the i.MX6 Pico ITX –
SBC as shown below..
Figure 3: Micro SD Connector

Rev 1.1
Page 17 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Table 3: Micro SD Connector Pin Assignment
Pin No
Signal Name
Signal Type
Voltage Level/
Termination
Description
1
SD3_DATA2
Input / Output
3.3V CMOS
SD3 Data Line (Bit2)
2
SD3_DATA3
Input / Output
3.3V CMOS
SD3 Data Line (Bit3)
3
SD3_CMD
Input / Output
3.3V CMOS/
10K Pull-up
SD3 Command Response
4
VCC_3V3
Power
3.3V
Card Supply Voltage
5
SD3_CLK
Output
3.3V CMOS
SD3 Clock
6
VSS
Power
0V
Ground
7
SD3_DATA0
Input / Output
3.3V CMOS
SD3 Data Line (Bit0)
8
SD3_DATA1
Input / Output
3.3V CMOS
SD3 Data Line (Bit1)
9
GPIO7_1_SD3_CD
(SD3_DAT4)
Input
3.3V CMOS/
10K Pull-up
SD3 Card Detect
10,11,
12,13
GND
Power
0V
Ground
2.4.5 Standard SD Connector
The Standard SD Connector (J23) is directly connected to the eSDHC channel 1 (SD1) of the i.MX6 CPU.
This connector supports up to 4 bit data transfer along with card detect feature. The main power to the
Standard SD connector is 3.3V. Optionally, 8bit data connector footprint is provided in the board and
not supported by default.
The Standard SD connector can support SD memory cards, SDIO cards (Wi-Fi, BT etc.) which are
designed to fit in a standard SD connector. Standard SD connector is physically located on bottom of the
board.

Rev 1.1
Page 18 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Figure 4: Standard SD Connector
Table 4: Standard SD Connector Pin Assignment
Pin No
Signal Name
Signal Type
Voltage Level/
Termination
Description
1
GPIO6_11_SD1_WP(NANDF_CS0)
Input
3.3V CMOS/
10K Pull-up
Write Protect
2
GPIO7_0_SD1_CD(SD3_DAT5)
Input
3.3V CMOS/
10K Pull-up
Card Detect
3
SD1_DAT1
Input / Output
3.3V CMOS
Data Line (bit1)
4
SD1_DAT0
Input / Output
3.3V CMOS
Data Line (bit0)
5
SD1_DAT7(NANDF_D3)
Input / Output
3.3V CMOS
Data Line (bit7)
Optional, Not
supported by
default.
6
VSS1
Power
0V
Ground
7
SD1_DAT6(NANDF_D2)
Input / Output
3.3V CMOS
Data Line (bit6)
Optional, Not
supported by
default.
8
SD1_CLK
Output
3.3V CMOS
Clock

Rev 1.1
Page 19 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
9
VCC/VDD
Power
3.3V
Supply Voltage
10
VSS2
Power
0V
Ground
11
SD1_DAT5(NANDF_D1)
Input / Output
3.3V CMOS
Data Line (bit5)
Optional, Not
supported by
default.
12
SD1_CMD
Input / Output
3.3V CMOS/
10K Pull-up
Command/
Response
13
SD1_DAT4(NANDF_D0)
Input / Output
3.3V CMOS
Data Line (bit4)
Optional, Not
supported by
default.
14
SD1_DAT3
Input / Output
3.3V CMOS
Data Line (bit3)
15
SD1_DAT2
Input / Output
3.3V CMOS
Data Line (bit2)
2.5 Audio/Video Features
2.5.1 AC’97 audio codec Interface
The Audio CODEC used on the i.MX6 Pico ITX –SBC is ALC5610 from Realtek with inbuilt Headphone
amplifier and MIC which is used to provide a complete audio solution for portable products. This Audio
codec is connected to AUDMUX channel 3 of the i.MX6 CPU. i.MX6 Pico ITX –SBC supports 3.5mm
stereo Headphone Out Jack and 3pin MIC In header which are physically located on top of the board.
Figure 5: Audio Jack

Rev 1.1
Page 20 of 61
i.MX6 Pico ITX - SBC Hardware User Guide
iWave Systems Technologies Pvt. Ltd.
Table 5: Audio OUT Jack Pin Out
Pin.NO
Signal Name
Signal Type
Voltage Level/
Termination
Description
1
GND
Power
0V
Ground
2
HP_L_ESD
Analog Output
1Vrms
Headphone Left
3
HP_R_ESD
Analog Output
1Vrms
Headphone Right
4
GPIO5_05_HP_DETECT(DISP0_D
AT11)
Output
3.3V CMOS
Head Phone
Detection
5
NC
-
-
No Connection
Table 6: MIC IN Header Pin Out
Pin.NO
Pin Detail
Signal Type
Voltage Level/
Termination
Description
1
GND
Power
0V
Ground
2
GPIO5_07_MIC_IN_DETECT(DISP
0_DAT13)
Output
3.3V CMOS
Microphone
Detection
3
MIC1P_ESD
Analog Input
1Vrms
MIC Positive Input
Number of Pins - 03
Connector Part Number- GRPB031VWVN-RC
Mating Connector - LPPB031NGCN-RC from Sullins Connector Solutions
