TrueNAS® X-Series Unied Storage Array
Basic Setup Guide
Version 1.8

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]
Copyright © 2021 iXsystems, Inc. All rights reserved. All trademarks are the property of their respective owners.
Contents
1 Unpacking the Unit ......................................................................... 1
2 Become Familiar with the X-Series System ............................................. 2
3 Rail Kit Assembly ............................................................................ 3
3.1 Rail Extenders ................................................................................... 3
3.2 Rail Spring ....................................................................................... 3
3.3 Attaching Rails to the Rack ................................................................... 4
4 Install Drive Trays ........................................................................... 5
4.1 Replacing Drives ................................................................................ 5
5 Connect Expansion Shelves ............................................................... 7
6 Connect Network Cables .................................................................. 7
7 Connect Power Cord ....................................................................... 7
8 Install Bezel (Optional) ..................................................................... 7
9 Controller Removal and Installation ..................................................... 8
9.1 Removing a Controller ........................................................................ 8
9.2 Installing or Adding Controller ............................................................. 10
10 Logging in to the TrueNAS Web Interface ............................................ 11
11 Out-of-Band Management ............................................................. 11
11.1 Console Modes .............................................................................. 12
11.2 Remote Connections ........................................................................ 13
11.3 Logging Out .................................................................................. 13
12 Additional Resources .................................................................... 14
13 Contacting iXsystems .................................................................... 14

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 1
The TrueNAS X-Series Unied Storage Array is a 2U, 12-bay, hybrid unied data storage array.
Accessory kit with 2 IEC C13 to NEMA 5-15P power
cords, 2 IEC C13 to C14 cords, and a set of velcro
cable ties.
X-Series Bezel
X-Series Unied Storage Array
Set of rackmount rails. The rails have a specic
front end, identied by a label visible on the left
above. The front ends of the rails must be in-
stalled facing the front of the rack.
A total of 12 populated or empty “air baffle” drive
trays. Trays must be installed in all bays to main-
tain proper airflow for cooling. Up to ten drive
trays are packed in a cardboard tray. Additional
drive trays are packed with the accessory kit.
Rail Extenders for racks over 30” (762mm) deep
Black USB to 3.5mm, 3.3V serial cable
1 Unpacking the Unit
TrueNAS units are carefully packed and shipped with trusted carriers. If there is any shipping damage or any
parts are missing, please take photos and contact iXsystems support immediately at [email protected],
1-855-GREP4-iX (1-855-473-7449), or 1-408-943-4100.
Please locate and record the hardware “A1-”serial numbers on the back of each chassis (typically on the controllers’
locking arms) for quick reference.
Carefully unpack the shipping boxes and locate these components:

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 2
2 Become Familiar with the X-Series System
The X-Series has front panel indicators for power, locate ID, and fault. The fault indicator is on during the initial pow-
er-on self-test (POST) and turns o during normal operation. It turns on if the TrueNAS software issues an alert.
The X-Series has one or two storage controllers in a side-by-side conguration.
1. Gigabit Ethernet connector 1
2. Gigabit Ethernet connector 2
3. USB device (reserved, do not remove)
4. USB 2.0 connector
5. Out-of-Band (OOB) serial port (3.5mm)
6. Out-of-Band Management Ethernet connector
7. HD mini SAS3 connectors 1 & 2
8. PCIe x8 expansion port
9. System console port (reserved)
10. MAC address label
Controller 1 Controller 2
Power Supply 1 Power Supply 2

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 3
3 Rail Kit Assembly
On racks that are 30 inches deep or less, skip to “3.2 Rail Spring”.
3.1 Rail Extenders
Racks from 31 to 36 inches deep require installation of the included rail extenders. For these deeper racks, install
cage nuts on the outside rear of the rack. The tabs on the cage nuts must be horizontal as shown.
Using the included bolts, install the rail extender inside the rear of the rack. Repeat the process for the second ex-
tender, which is a mirror image of the rst.
3.2 Rail Spring
If not already present, install a spring on the silver posts in the side of each rail.

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 4
3.3 Attaching Rails to the Rack
Chassis rails are congured to attach to round hole racks. Additional pins are included in the accessory kit to
congure the rails for square or 4mm hole racks. To reset the rails to t a square or 4mm hole rack, unscrew the
pins at each end of the rails and replace them with the correct pins.
To secure a rail to the rack, open the clamp latches on the ends of each rail. Place the rail in the rack with the front
end toward the front of the rack, aligning the pins on both ends of the rail with the mounting holes in the rack.
Swing the clamp latch closed to hold the rail in place. Use two of the supplied screws to secure the back end of the
rail in place. Repeat the process for the second rail.
Caution: Two people are required to safely lift the chassis for rack installation or removal. Do not install
drives until after the chassis has been installed in the rack, and remove all drives before removing the chassis from
the rack. Carefully place the chassis onto the rails mounted in the rack. Push the chassis in until the ears are flush
with the front of the rack. If needed, attach the bezel. Use two of the supplied screws to secure each ear to the rack.

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 5
4 Install Drive Trays
Drive trays are used to mount drives in the chassis. Each drive tray has two status LEDs. The top LED is blue when
the drive is active or a hot spare. The bottom LED changes to amber if a fault has occurred.
A tray must be placed in each drive bay to maintain proper airflow for cooling. If fewer than twelve drives are con-
nected, empty “air baffle” trays must be placed in the empty bays.
A standard drive tray installation order simplies support and is strongly recommended:
• SSD drives for write cache (W), if present
• SSD drives for read cache (R), if present
• Hard drives or SSD drives for data storage
• Air baffle ller trays to ll any remaining empty bays
Install the rst drive tray in the top left drive bay. Install the next drive tray to the right of the rst. Install remaining
drive trays to the right across the row. After a row is lled with drives, move down to the next row and start again
with the left bay.
This example shows the proper order for a write cache (W) SSD, a read cache (R) SSD, eight hard drives, and two
empty air baffle trays.
To load an individual drive tray into a bay, press the blue button to open the latch. Carefully slide the tray into a
drive bay until the left side of the latch touches the metal front edge of the chassis, then gently swing the latch
closed until it clicks into place.
TrueNAS appliances only support qualied hard drives and SSDs. Contact the Sales Team if you need more drives
or replacements. Adding unqualied drives to the system voids the warranty. Call Support if drives are improperly
installed in trays.
4.1 Replacing Drives
Depending on the conguration ordered, X-Series drive trays come preinstalled with 3.5” drives, 2.5” drives with
adapter, 2.5” read intensive (RI) drives with interposer and adapter, and/or empty air baffles that preserve system
air flow. Drives that lose functionality can be removed from the tray and a new drive installed in its place or a sys-
tem upgraded by removing the air baffles and installing new drives ordered from iXsystems.

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 6
Place the tray on a flat surface and remove the four screws holding the drive to the tray, two on each side (1). Place
the new drive in the tray with the drive connector to the rear of the tray (2), and secure the hard drive in the tray
with four screws, two on each side. (3).
4.1.1 3.5” Drive Replacement
4.1.2 2.5” Drive Replacement
4.1.3 2.5” Read Intensive Drive Replacement
Place the tray on a flat surface and remove the three screws holding the adapter to the tray, two on one side and
one on the other (1). Remove the adapter from the tray and remove the two screws that hold the 2.5” drive to the
adapter (2). Follow this process in reverse to add the new 2.5” drive to an adapter and attach to the drive tray.
Warning: the interposer is considered part of the 2.5” drive and must be removed with it. Attempting to reuse an
interposer can result in a system malfunction or data loss!
Place the tray on a flat surface and remove the three screws holding the adapter in place, two from one side and
one on the other (1). Remove the adapter from the tray and remove the three screws that hold the 2.5” drive and
interposer in place, two from the side and one underneath the adapter (2). Gently lift the 2.5” drive and interposer
free from the adapter.
When installing the new drive, follow the previous procedure in reverse, but make sure the edge of the new inter-
poser slides under the retention tab (circled) on the adapter.

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 7
5 Connect Expansion Shelves
Expansion shelves connect to the HD mini SAS3 connectors on the X-Series. For detailed connection instructions
and diagrams, refer to the Basic Setup Guide included with your iXsystems TrueNAS expansion shelf or see the
online SAS Connections Guide.
6 Connect Network Cables
Network cables vary by conguration and are not included. Please contact iX Support with any questions.
Connect network cables to the Ethernet ports and Out-of-Band (OOB) management port before powering on and
conguring the X-Series for the the rst time.
The Out-of-Band management port on the X-Series must be connected with a shielded Ethernet cable.
7 Connect Power Cord
If any TrueNAS expansion shelves are connected to the X-Series, power on the expansion shelves and wait at least
two minutes before connecting power cables to the X-Series.
Do not plug the power cords into a power outlet yet.
Connect a power cord to the back of one power supply, pressing it into the plastic clamp and pressing on the tab to
lock it in place. Repeat the process for the second power supply and cord.
After connecting both power cords to the X-Series, plug them into power outlets. The system automatically powers
on when connected to a power outlet. This design ensures that the X-Series powers back on after a power failure.
If you want to disconnect the physical power remotely, you can connect the X-Series to a remotely-managed Power
Distribution Unit (PDU).

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 8
9 Controller Removal and Installation
Warning: To avoid the potential for data loss, iXsystems must be contacted before replacing a controller or upgrad-
ing to High Availability. See section “13 Contacting iXsystems”.
9.1 Removing a Controller
Press in the blue clip on the bottom of the controller to release the two black locking levers. Swing the locking levers
outward and pull the controller out of the system.
8 Install Bezel (Optional)
The system does not require the bezel to operate. If desired, install the bezel by screwing in the bezel posts to the
system ears. The longer posts go in the top positions on the ears. Align the bezel with the posts on the chassis ears
and press it into place. To remove, grasp the bezel from the front and pull away from the chassis.

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 9
9.1.1 Removing a Blanking Plate
If you purchased your X-Series with only one controller, you can upgrade it by adding a second controller. To re-
move the blanking plate from the empty controller slot, press in the blue clip on the bottom of the plate to release
the two black locking levers. Swing the locking levers outward and pull the blanking plate out of the system.

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 10
9.2 Installing or Adding a Controller
Hold the controller by the sides and align with the opening on the back of the chassis. Slide the controller into the
X-Series chassis until it stops (1). Swing the locking levers inward until they snap into the blue clip on the bottom of
the controller (2).

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 11
10 Logging in to the TrueNAS Web Interface
The IP address of the TrueNAS graphical web interface is on the TrueNAS hardware sales order or conguration
sheet. The system console also displays it after powering on (see section 11.1.1). Please contact iX Support if the
TrueNAS web interface IP address was not provided with these documents or cannot be identied from the True-
NAS system console.
Enter the IP address into a browser on a computer on the same network to access the web interface. To log into the
TrueNAS web interface, enter the default credentials:
Username: root
Password: abcd1234
Your system is equipped with the optimal BIOS and IPMI rmware out of the box.
DO NOT UPGRADE your system’s BIOS and IPMI rmware.
11 Out-of-Band Management
Out-of-Band Management (OOBM) allows you to connect directly to the TrueNAS hardware and make changes us-
ing the system console. You should immediately test to conrm the OOBM Ethernet port IP address is active.
Remote support requires functioning addresses. If iXsystems precongured the system, they have set the OOBM
interfaces to the requested IP addresses. Otherwise, the OOBM IP addresses default to these static addresses:
• TrueNAS Controller 1: 192.168.100.100, subnet mask 255.255.255.0
• TrueNAS Controller 2 (if present): 192.168.100.101, subnet mask 255.255.255.0
Viewing or resetting these IP addresses to dierent values requires directly connecting to the X-Series system using
a USB-3.5mm cable and client system with a serial terminal program.
Temporarily connect the included black USB serial cable to the 3.5mm port on the back of the TrueNAS controller.
Be sure to disconnect this cable when done!
Connect the serial cable’s USB end to a computer running serial terminal software. The device name can vary by
operating system. Here are some typical examples:
• Windows: COM{4}
• macOS: /dev/tty.usbserial{xynnn}
• FreeBSD: /dev/cuaU{0}
• Linux: /dev/ttyUSB{0}
Set the terminal software to: 38400 baud, 8 data bits, 1 stop bit, no parity, no ow control
After connecting, you might need to wait for the X-Series to power up, then press Enter to display the console
menu. When prompted, use these credentials to log in to the interface:
Username / Password: sysadmin / superuser

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 12
11.1 Console Modes
The X-Series console has two modes: SES (SCSI Enclosure Services) mode, and the standard x86 console mode.
If ESM A => or ESM B => is displayed, the X-Series is in SES mode.
Switch to the X86 console mode by typing: $%^0
Press Enter twice after typing the characters. The normal x86 console is displayed.
To switch back to the SES console, type: $%^2
After logging in, the console will display the TrueNAS serial menu and boot/BIOS information.
Note: The X-Series comes with a gray console port cable that connects IPMI to the console. Ensure the cable is in
place, since IPMI will not work if the cable is not properly connected.
11.1.2 Conguring Remote Connections
To show the current Out-of-Band management IP address:
ifcong eth0 | grep ‘inet addr’
inet addr:10.20.1.227 Bcast:10.20.1.255 Mask:255.255.254.0
To show Out-of-Band network cong settings: ipmitool -H 127.0.0.1 -U admin -P {random} lan print
To reset the Serial Over LAN system using the Out-of-Band serial port, use the eth0 IP address.
This example uses the eth0ipaddress address: ipmitool -H eth0ipaddress -U admin bmc reset cold
Conguring Static IP Addresses
The OOBM system can be set to use a static IP address and netmask. This example shows setting the IP address to
192.168.100.100 with a netmask of 255.255.255.0, and a default gateway of 192.168.100.1:
ipmitool -H 127.0.0.1 -U admin -P {random} lan set 1 ipsrc static
ipmitool -H 127.0.0.1 -U admin -P {random} lan set 1 ipaddr 192.168.100.10
ipmitool -H 127.0.0.1 -U admin -P {random} lan set 1 netmask 255.255.255.0
ipmitool -H 127.0.0.1 -U admin -P {random} lan set 1 defgw ipaddr 192.168.100.1
Conguring DHCP IP Addresses
We do not recommend conguring the OOBM IP address with DHCP. However, you can congure the local DHCP
server to provide a xed IP address for OOBM using the MAC address. You can then nd the assigned IP address by
checking the local DHCP server logs for the MAC addresses axed to the back panel of each X-Series controller.
To congure DHCP: ipmitool -H 127.0.0.1 -U admin -P {random} lan set 1 ipsrc dhcp
The ipmitool command uses a randomized password that is unique to the X-Series system.
Replace the {random} strings in these examples with the randomized password on the sticker
placed on the back of the chassis under the Out-of-Band (OOB) serial port.

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 13
11.2 Remote Connections
Log out of the Out-of-Band management system by typing exit and pressing Enter.
11.3 Logging Out
A remote connection requires that the X-Series system has a shielded RJ45 cable connecting the Out-of-Band net-
working port to the local network.
The IPMItool (https://github.com/ipmitool/ipmitool) remote management utility must be installed on the com-
puter used to manage the X-Series remotely, and that computer must have access to the same network as the X-Se-
ries system. FreeBSD, macOS, and Linux have package systems which can be used to install IPMItool. For Windows,
a simple option is to install IPMItool through Cygwin.
Only use IPMItool for remote Out-of-Band management on the X-Series. Other IPMI utilities may not work
correctly or even damage the X-Series system.
The ipmitool connection password is randomized for security and attached as a sticker to the back of the X-Series
system. For more details, see https://www.truenas.com/docs/sb327/.
In this example, 192.168.100.100 is the IP address assigned to the Out-of-Band management interface.
ipmitool -I lanplus -H 192.168.100.100 -U admin -a sol activate
SOL on another session is displayed when a Serial Over LAN connection is already in use. To reset the Serial Over
LAN system from the remote laptop or desktop computer, use:
ipmitool -H 192.168.100.100 -U admin bmc reset cold
and enter the unique randomized password.
Note: the Serial Over LAN system can also be reset with the Out-of-Band serial port.
Repeat the sol activate command above and enter the randomized password to connect to the X-Series con-
sole.

Support: 1-855-473-7449 or 1-408-943-4100 Email: [email protected]Page 14
13 Contacting iXsystems
For assistance, please contact iX Support:
Contact Method Contact Options
Web https://support.ixsystems.com
Email [email protected]
Telephone Monday-Friday, 6:00AM to 6:00PM Pacic Standard
Time:
• US-only toll-free: 1-855-473-7449 option 2
• Local and international: 1-408-943-4100 option 2
Telephone Telephone After Hours (24x7 Gold Level Support only):
• US-only toll-free: 1-855-499-5131
• International: 1-408-878-3140
(International calling rates will apply)
12 Additional Resources
The TrueNAS Documentation Hub has complete software conguration and usage instructions. It is available by
clicking Guide in the TrueNAS web interface or going directly to:
https://www.truenas.com/docs/
Additional hardware guides and articles are available in the Hardware section of the Documentation Hub:
https://www.truenas.com/docs/hardware/
The TrueNAS Community forums provide an opportunity to interact with other TrueNAS users and to discuss their
congurations. The forums are available at:
https://www.truenas.com/community/
