J.Burrows MONACO JBMONAHBBK User manual

MONACO ERGONOMIC CHAIR
ASSEMBLY
INSTRUCTIONS
JBMONAHBBK
1/7
www.officeworks.com.au 1 CTN
This design and instruction booklet is subject to copyright.

2/7
Estimated Assembly Time: 30 minutes
Assembly Video
Customer Service Contact Details
Spare Parts & Hardware
1300 OFFICE
People Required
General Advice
To view an assembly video, go to https://www.officeworks.com.au/
Search the product by item code or name:
Click on the icon to watch the video.

3/7
Officeworks Ltd. | 236-262 East Boundary Road | Bentleigh East VIC 3165 | AUSTRALIA
NOTE
•Please check you have all hardware before assembling.
•If you are missing any hardware, please contact the store of purchase.
•Please ensure you have the name of the item, required hardware part and quantity.
•Please retain your receipt as proof of purchase to validate your warranty.
CAUTION
•Do not tighten screws before all screws are in the right place.
•Do not use this product unless all bolts, screws and knobs are firmly secured.
•Check that all bolts and screws are securely tightened at least every 4 m onths.
WARNING
•If parts are missing, broken, damaged or worn stop using the product until all repairs are made
using manufacturer authorised parts.
•
Failure to follow these warnings could result in serious injury.
DANGER
CHILDREN MUST BE SUPERVISED.
••
•

Parts List
Hardware List
4/7
AX5
DX1 EX1
GX4 HX6 IX1
FX2
BX1 CX1
5/16”x3/4” 5/16”x1-3/4”

Gx4
Ix1
Step 1
Step 2
5/7
5/16”x3/4”
C
B
A
F-R F-L
I
H
D
Assembly
H

Ix1
Step 3
Step 4
6/7
Hx6
E
G
I
IMPORTANT: To make assembly easier, do not tighten screws completely at this time.
5/16”x1-3/4”

7/7
Pull lever up whilst moving the
arm up or down. Release lever
at desired height.
Arm Height Adjustment
Push the first lever on the left
side of the seat cushion to
extend the seat forward or
backward to a desired position.
Release lever to lock.
Seat Slide Adjustment
Turn knob located underneath
left side counter clockwise, to
release the lock.
Adjust the seat to your desired
angle, then turn the knob
clockwise to lock the seat into
position.
Turn the knob counter
clockwise to unlock from set
position and slightly lean back
to allow seat to return to its
original position.
Tilt Lock
Arm Pad Swivel
To raise the seat: lean slightly
forward while seated to relieve the
pressure on the tilt mechanism.
Reach under the right side of the
chair and locate the handle.
Raise yourself up slightly to allow
the chair to reach your desired height.
To lower the seat: remain seated
and lift the handle upwards until the
chair lowers to your desired height.
Locate the first knob on the right side of the seat and
twist the knob to adjust tilt tension.
For firmer/stiffer--turn clockwise.
For softer/looser--turn counterclockwise.
Seat Height Adjustment
Tilt Tension
Locate the second knob
underneath the right side of
the chair to adjust seat angle.
To angle seat upward – turn
clockwise.
To angle seat downward –
turn counterclockwise.
Seat Angle Adjustment
Care Instructions-Fabric Chairs
Clean, check & tighten all parts regularly.
Wipe over surfaces with damp cloth rinsed in warm water & mild detergent.
Dust & vacuum chair fabric to remove dust & dirt.
detelpmocsitsettopsaerusnE.renaelcdesab-retawaesu,tsisrepsniatsynafI
first to ensure it does not affect the fabric colour.
Do not use harsh detergents, solvents or abrasive cleaners.
Thank you for your purchase. Please retain your receipt to validate warranty.
If you would like to know more about our furniture products,
please visit www.officeworks.com.au
