J D Williams 0449432 Series User manual

Assembly Instructions - Please keep for future reference
Width - 70.0cm
2 Door 1 Drawer Cupboard
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 36.8cm
Height - 74.7cm
Rev A - 15/05/2019
044 xx 9432

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergents, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Top (70x36.8cm)
1344 Bottom (66.6x33.5cm)
2344
Left End Panel
(73.2x35cm)
1343
Plinth (66.6x6cm)
2348
Right End Panel
(73.2x35cm)
1339
Door
(66.6x34.5cm)
2349
Backpanel (67.6x67.2cm)
2350
Shelf (66.6x29.7cm)
2347
Door
(50.6x34.5cm)
1340
Division (16x33.5cm)
1341 Drawer Front (34.5x15.7cm)
1342
Drawer Bottom
(28.7x29.8cm)
4883
Drawer back (27.6x10cm)
Right drawer side (30.0x10cm)
624xx7003
623xx7002
Left drawer side (30.0x10cm)
622xx7002
Rail (32.6x6cm)
1451

3
70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components-Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more fittings
may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 16
Code 760001103
Metal dowel x 18
Code 760003004
ABC
E
Drill
D
Panel pin x 10
Code 760001012
18mm bolt x 6
Code 700002021
12mm screw x 16
Code 690001008
F
Hinge x 4
Code 652001128
H
Hingeplate x 4
Code 653006000
GI
Handle x 3
Code 643003506
J
Panel Pin Locator
Code 684004501
M
K
Wooden Dowel x 4
Code 770001006
12mm screw x 2
Code 690001099
Support bracket x 1
Code 760001901
Left Bracket x 1
Code 760xx7000
L1
Right Bracket x 1
Code 760xx7000
Left Runner x 1
Code 760xx7000
R1
L2
Right Runner x 1
Code 760xx7000
R2
Small cam x 2
Code 760003005
8mm screw x 4
Code 700003510
OP
N
Panel Holder x 3
Code 680003505
Screw x 2
Code 690001075
Q

Please check you have all the fittings listed below
Exploded View
4
1340
2347
2349
2344
1343
2350
622xx7002
624xx7003
623xx7002
4883
1342
1341
1344
1339
1451

Step 1
Assembly Instructions
5
B
x6
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
B
A
x8
Fitting dowels to top
panel.
Fitting cams to the
bottom and shelf
panels.
Step 2
Step 3
Fitting cams, dowels
and hingeplates to
the end panels.
B
Note: Ensure cam
arrow points towards
the edge with hole.
A
Ensure that the hinge
points towards the
grooved edge of the
panel.
B
B
B
B
J
x4
A
A
A
A
J
J
J
1344
2347
1339
A
A
A
A
2344
B
B
A
x4
B
x8
J
J
A
A
A
A
B
B
B
B
B
B
B
B
1343
B
B

1341
Step 4
Assembly Instructions
6
Step 5
Step 5
Fitting cams to divider
and rail panels and
fitting dowels to the
plinth panel.
F
A
x4
F
x4
2348
F
F
F
Insert 4 wooden
dowels into the pre-
drilled holes in the end of
the plinth panel .
F
2348
Step 6
1339
1341
P
P
2ND
1ST
Diagram 1
Diagram 2
L1
L1
Diagram 2
E
E
R1
x1
P
x2
E
x1
L1
x1
R1
Attaching the left bracket
to the divider panel.
Using 2 screws ,
secure the bracket to
the divder panel
as shown in diagram 1.
Use 1 screw to
secure the front of the
bracket.
1341
P
E
L1
1339
AA
1451
A
A
Insert 2 cams into the
divider and 2 cams
into the rail .
1341
1451
A
A
P
x2
E
x1
Diagram 1
1ST
Corresponding
Hole
P
P
Attaching the right
bracket to the right end.
Using 2 screws ,
secure the bracket to
the RH end panel
as shown in diagram 1.
Use 1 screw to
secure the front of the
bracket.
P
E
R1

Assembly Instructions
7
Step 7
Attach hinges and
handles to doors
a: Insert hinges
into holes, ensure
the hinge is straight
(90 degree angle).
b: Before securing the
hinges , we recommend
you pre - mark the doors
using a bradawl.
Important:
I
I
90
98
Bradawl
c: Secure hinges to
doors using screws .
I
E
d: Secure handle to
doors using bolts
Repeat on door
K
D
I
x4
D
x4
E
x8
K
x2
2349
2349
2349
2349
D
D
E
E
I
I
I
I
I
I
A
B
C
D
K
1340
E
E
E
E

a: Insert dowels into
drawer front .
Note: Insert metal
dowels as far as
shown by arrows.
Do not over tighten.
8
Drawer assembly
B
B
C
Step 8
c: Insert wooden dowels
in drawer back
into holes in
left
right hand
drawer sides.
B
b: Insert small cams
into left
and right
drawer sides.
Note: Ensure cam arrow
points towards the edge
with hole.
C
C
B
B
C
C
a:
b:
c:
Right hand side
Left hand side Drawer Back
Continued on next page.
1342
1342
624xx7003
622xx7002
623xx7002
622xx7002
623xx7002
623xx7002
624xx7003
622xx7002
Assembly Instructions
x2
x4
K
D
x1
x2 x1 x1
E
x6
L2
R2
Right hand side
623xx7002
Left hand side
622xx7002

e:Insert cams already
inserted in left and right
drawer sides onto
dowels in drawer
front .
9
Drawer assembly
Continued...
C
Assembly Instructions
Step 8- Continued
d: Slide drawer bottom
into grooves in
left,right drawer sides
and drawer back.
Ensure foil on the
drawer bottom is facing
upwards.
B
Turn cam 180 degrees
to lock
f: Secure handle to
drawer front
using bolts
C
D
D
d:
e:
f:
4883
4883
1342
1342
1342
FOIL FACE
g: Using 6 screws
secure the left runner
and the right runner
to the drawer box.
Ensure that the wheel on
the runners is to the
back of the drawer box.
E
E
E
E
g:
L2
L2
R2L2
R2
K
K
Turn Drawer upside
down.
1342
D

Assembly Instructions
10
Step 9
Connect top panel to
divider panel.
1344
Insert the dowels in the
top panel into cams
in the divider panel .
1344
1341
Step 11
Insert the dowels in the
left end panel into
the cams in the shelf
and bottom
panels then place
plinth with wooden dowels
into left hand panel
Connect bottom, shelf
and plinth
to the end panel.
1343
1343
2348
2347 2344
2347
Step 10
1341
Connect rail to
right hand end.
Insert the dowels in the
right end panel to
the cams in the rail .
1451
1451
2348
2344
1339
1339

Step 13
Assembly Instructions
11
Connect the dowels in
the top panel with
the cams in the right end
panel and the
left end panel
Attach the rail to
the divider panel
securing with screws .
Attach the top panel.
1343
1339
1344 1344
1343
Step 12
Attach right end panel
2348
Insert the dowels in the
right end panel into
the cams in the shelf
and bottom panel
and the plinth
1339
2348
2347
2344
2344
1339
1341
1451
2347
1339
Q
x2
Q
Q
1451
Q
1341

Step 15
Assembly Instructions
12
Attach backpanel to
bottom
Slide the back panel into
the grooves.
Use the panel pin guide
when locating the panel
pins. This will hold the
panel pins vertical and
ensure the correct
distance from the edge.
O
O
x10
H
x1
N
x3
O
UNFINISHED FACE
Loosen screw in stability
block then slide the thin
point of the stability
blocks between the
back panel and the
grooves in the top and
end panels.
Once inserted fully,
tighten the screws in the
stability blocks.
N
N
N
N
N
Step 14
DIAG 1 DIAG 2 DIAG 3
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
Measure to external corners
YY
XX
YY
Squaring up the unit.
Ensure a tape
measure is used
to square up unit!
Important:
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
XX

Assembly Instructions
13
Step 16
a: With help, slot door
hinges onto hinge plates.
Ensure screw on hinge
slides into the slot on
hingeplate.
See Diagrams 1, 2 and 3.
Hanging doors
b: Tighten screw shown
to lock hinges in
position.
See ‘Hinge adjustment’
page if the doors
need adjusting.
B
B
B
Underside view
Ensure the underside of screw
B slides into slot on hingeplate.
Hinge correctly attached to
hingeplate.
Hinge incorrectly attached to
hingeplate.
A
B
Diagram 1
Diagram 2
Diagram 3
REPEAT ON REMAINING DOOR
2349

Assembly Instructions
14
Step 16
a: To move doors up
or down: loosen screws
shown and move doors
to suit.
Re-tighten screws.
Hinge adjustment
b: To move doors in or
out: loosen screw
shown and move doors
to suit.
Re-tighten screws.
c: To move doors left
or right: loosen or
tighten screw as shown.
Be careful not to fully
unscrew.
A

Assembly Instructions
15
Step 17
Fit the drawer.
Tilt the drawer as shown
and slide onto the runner
brackets.

Assembly Instructions
16
Step 19
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing. We have
included a fixing bracket
for this. No fixing screws
are provided as they will
need to suit the wall
type, and the length of
screw will depend on
the distance from the
back of the unit to the
wall. Please ensure
fixings used are
appropriate to your wall
type. Locate the bracket
to the top panel or to the
end panel as close to
top as possible. We do
not specify exact
location for the bracket,
this is left to the
customer’s discretion.
Fixing to wall
Please take care when
drilling into the wall,
avoiding any pipes and
wires. Wear safety
goggles when drilling.
The use of residual
current device (RCD) is
recommended when
working with tools.If in
doubt consult a
qualified person.
With help move the
unit into position.
Warning:
2 people required.
Lift with care.
Warning:
G
x1
M
x2

Assembly Instructions
Congratulations! Your unit is complete.
Important Information
If you need help or have damaged or missing parts, call the Customer Helpline:
01709 534123 8am - 4.30pm (Monday toThursday)
8am - 2.30pm (Fridays)
Please have the following information to hand:
>> Unit Description
>> Product Code
>> Product Colour
>> Place of Purchase
>> Catalogue Ref. No.
>> Item Code
>> Assembly Instructions
You can also e-mail your requests to us at:
[e-mail]
Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, SouthYorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
(by contacting the customer service line your statutory rights are not affected)

Notes;

Notes;
