J D Williams 3 Door 3 Drawer Display 042 7165 Series User manual

Assembly Instructions - Please keep for future reference
Width - 71.3cm
3 Door 3 Drawer Display
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534 123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 34.8cm
Height - 153.3cm
042 xx 7165
MADE IN
GREAT BRITAIN
Rev D - 23/02/17

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergents, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Left End Panel
(136.1x32.8cm)
0561
Right End Panel
(136.1x32.8cm)
0562
Lh Divider Panel
(43.9x31.4cm)
0563
Lh Door x 2
(44.8x35.1cm)
0569
Rh Door
(44.8x35.1cm)
0570
Shelf Panel
(33.8x31.4cm)
0566
Drawer Front
(35.1x12.7cm)
0567
Drawer Front x 2
(35.1x15.7cm)
0568
Top (71.3x34.8cm)
0559
Shelf (67.9x31.4cm)
0564
Shelf x 3 (67.9x31.4cm)
0565
Bottom (71.3x34.8cm)
0560
Backpanel (137.1x68.8cm)
0571
Left drawer side x 3
(30.0x10.0cm)
Drawer back x 3
(27.6x10.0cm) Right drawer side x 3
(30.0x10.0cm)
622xx7002 624xx7003 623xx7002
Drawer Bottom x 3
(28.6x29.8cm)
4883
1 Shelf is Black

3
70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components - Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more
fittings may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534 123 Please turn to back page
for important information when contacting Customer Helpline.
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 22
Code 760001103
Metal dowel x 28
Code 760003004
ABC
E
DF
I
Small cam x 6
Code 760003005
8mm screw x 12
Code 700003510
GH
Left Bracket x 3
Code 760xx7110
Right Bracket x 3
Code 760xx7110
Right Runner x 3
Code 760xx7110
Left Runner x 3
Code 760xx7110
KN
Wooden dowel x 6
Code 770001006
L1 R1
R2
L2
12mm screw x 52
Code 690001008
Leg x 4
Code 721077160
Handle x 6
Code 640073515
20mm bolt x 6
Code 700002006
2” Woodscrew x 6
Code 690004529
Leg Bracket x 4
Code 760007160
J
Panel Holder x 4
Code 680003505
Hinge x 6
Code 651001128
Hingeplate x 6
Code 653006000
Q
P
Support Bracket x 1
Code 760001901
S
Screw x 2
Code 690001099
TUV
Shelf Support x 4
Code 681003001
Cam Sticker x 4
Code 682xx2011

Exploded View
4
0559
0571
0562
0560
0563
0566
0570
0565
0564
0565
0569
0561
0569
622xx7002
622xx7002 624xx7003
624xx7003
0565 - Black
Drawer x 2 Drawer
0568
623xx7002
623xx7002
4883
4883
0567

G
G
0559
Step 1
Assembly Instructions
5
B
x4
B
Fitting dowels to top
panel.
B
B
x16
B
B
B
B
Step 2
Fitting cams, hinge
plates, metal and
wooden dowels to the
end panels.
Insert 4 metal dowels
into the top panel 0559
Note: Tighten metal
dowels up fully against
the panel.
Do not over-tighten.
A
B
A
x4
G
G
x4
A: Insert 2 metal cams
2 wooden dowels ,
2 hinge plates
and 8 metal dowels
into right end panel
0562
A
A
A
A
A
0562
0561
G
G
A
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
B
G
B: Insert 2 metal cams
2 wooden dowels ,
4 hinge plates
and 8 metal dowels
into left end panel 0561
A
B
Q
Q
Q
Q
Q
Q
x6
Q
Q
Q

G
G
Assembly Instructions
6
Step 3
x3
E
E
N
x6
N
x3
L1
L1
0563
0563
0563
Step 4
E
N
Fitting right brackets
to the right end.
Using 2 screws
secure the bracket to
the right end
as shown in diagram 1.
Use 1 screw to
secure the front of the
bracket.
Repeat on other brackets
Fitting cams and wooden
dowels and attaching
left brackets to the
divider.
Insert 2 metal cams and
2 wooden dowels
into divider .
Using 2 screws ,
secure the bracket to
the divider
as shown in diagram 1.
Use 1 screw to
secure the front of the
bracket.
Repeat on other brackets
R1
0562
0562
x3
E
x6
N
x3
R1
A
A
A
x2
G
x2
A
G
Diagram 1
Diagram 2
L1
Diagram 1
Diagram 2
N
N
R1
E
1ST
L1
R1
1ST
Insert 2nd screw into
corresponding hole
Insert 2nd screw into
corresponding hole

Step 5
Assembly Instructions
7
Step 6
0564
0565 x 3
A
A
A
A
A
A
A
A
A
x16
Fitting cams and
dowels to the
shelf panels.
A: Insert 4 metal cams
and 2 metal dowels
into shelf panel .
0564
A
Fitting dowels to the
drawer fronts.
B
B
B: Insert 4 metal cams
into shelf panel .
0565
A
Insert 2 metal dowels
into the the drawer
fronts . Repeat on
.
0568
0567
x6
B
x2
B
B
B
B
0568
B
B
A

Assembly Instructions
8
x6
C
Step 7
H
x3
I
x3
B
C
A
Left hand side
Right hand side
622xx7002
623xx7002
622xx7002
623xx7002
C
C
B: Insert wooden dowels
in drawer back
into holes in
left
right hand
drawer sides.
Right hand side
Left hand side Drawer Back
624xx7003
622xx7002
623xx7002
623xx7002
624xx7003
622xx7002
0568
4883
Foil surface facing upwards.
Plain chipboard surface
to underside.
C: Sit drawer bottom
into groove on
drawer front .
Ensure foil on the
drawer bottom is facing
upwards.
0568
4883
A: Insert small cams
into left
and right
drawer sides.
Note: Ensure cam arrow
points towards the edge
with hole.

Assembly Instructions
9
Step 7 cont...
D
E
D:Locate the metal
dowels (already inserted)
in the drawer front into the
small cams in the left and
right hand drawer sides.
Ensure drawer sides are
pressed against drawer
front.
Turn the cam 180 degrees
to lock.
E:
Fit bolt through
the pre-drilled holes in
the drawer front
and connect to the handle
.
H
I
0568
Using 6 screws
secure the left runner
and the right runner
to the drawer box.
Ensure that the wheel on
the runners is to the
back of the drawer box.
N
N
L2
L2
R2
R2
x18 x3
Step 8x3
Turn drawer upside
down
H
I
0568
N
N
N
L2
L2
R2
H
0568
Repeat on remaining
drawers
Repeat on remaining
drawers

Assembly Instructions
10
Step 9
Attach hinges and
handles to 2 doors
a: Insert hinges
into holes, ensure
the hinge is straight
(90 degree angle).
b: Before securing the
hinges , we recommend
you pre - mark the doors
using a bradawl.
Important:
Bradawl
c: Secure hinges to
doors using screws .
d: Secure handle to
doors using bolts
I
x6 x3 x12
I
x3
0570
0570
0570
0570
A
B
C
D
I
90
Correct
98
Incorrect
Repeat on the other
doors
0569
P
P
P
P
P
P
P
P
P
P
N
N
N
N
N
N
H
H
H
N
N

Assembly Instructions
11
Step 10
Step 11
Connect the dowels in
the shelf panel to the
cams in the divider
panel .
Turn cams 180 degrees
clockwise to lock.
Connect the divider to
the shelf.
0564
0563
Connect the dowels in
the right end
to the cams in shelf
panels &
Connect the shelves
to right end.
0562
0564 0565
Turn cams 180 degrees
clockwise to lock. 0562
0565-Black
0565
0565
0564
0564
0563

Assembly Instructions
12
Step 12
Step 13
Connect the dowels in
the left end to the
cams in the shelf panels
& .
Turn cams 180 degrees
clockwise to lock.
Connect the left end
to the shelves.
0561
0564 0565
Connect the dowels in
the top panel to the
cams in the left and end
panels & .
Turn cams 180 degrees
clockwise to lock.
Connect the top panel
to the left and right
end panels.
0559
0562
0561
0565-Black
0565
0565
0564
0561
0562
0561
0559
Overhang

Assembly Instructions
13
Step 14
Step 15
0562
0559
Overhang
0561
0571
Taped side
Slide the back panel
into the grooves.
Slide the back panel
into the grooves in the end
panels and into the top
panel.
0571
x6
F
Secure the bottom
panel to the divider
and end panels.
Using 6 screws attach
the bottom panel to
the left end , right
end and divider
0560
0561
0562
0563
F
F
FF
FF
F
Groove to this side
0562
0561
0560
0563
0562
0562
Unit may need standing
onto its top to ensure
back panel slides into
top panel groove.
Please ensure that wooden
dowels in ends and divider
panels locate into bottom
panel before securing.

Assembly Instructions
14
Step 16
Step 17
Square up the unit.
IMPORTANT
Ensure a tape
measure is used
to square up unit!
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
Slide the back panel into
the grooves in the left &
right end panels and the
top panel.
x4
Add stability blocks.
Slide the thin point of the
stability blocks
between the back panel
and the grooves.
Once inserted fully,
tighten the screws in the
stability blocks.
0571
J
J
J
DIAG 1 DIAG 2 DIAG 3
XX
XX
YY
YY
XX
XX
YY
YY
XX
XX
YY
YY
YY
YY
XX
XX

Assembly Instructions
15
Step 18
x4
N
x16
K
Attach foot plates
to the bottom panel.
Attach the foot plates
to the bottom panel
with 4 screws .
0560
N
K
K
N
N
N
N
IMPORTANT :
Please ensure the
plates are attached
as shown (Dia. 1).
Front of unit
Foot Plate
Foot Plate
Dia.1
N
N
N
N
Step 19
Secure he legs to the
leg plates.
Screw legs into plates
until tight.
x4
D
D
K
D
D
Stand the unit upright
2 people required.
K
K K
K
0560
N
K
K K
K
D
D

Assembly Instructions
16
Step 20
Insert shelf studs.
Fit the drawers and
shelf.
Tilt the drawer as
shown and slide onto the
runner brackets.
The small drawer is the
top drawer.
x4
Push shelf studs
into panels
and .
0561
0563
Locate shelf
onto shelf studs
0566
U
U
U
U

17
Assembly Instructions
Step 21
a:
a: With help, slot door
hinges onto hinge
plates .
Ensure screw on hinge
slides into the slot
on hingeplate .
See Diagrams.
Hanging doors
b: Tighten screw shown
to lock hinges in
position. Repeat a and b
on remaining door.
See ‘Hinge adjustment’
page if the doors need
adjusting.
Please note diagrams
may not reflect the
hinge included in your
pack.
The principal of the hinge
fitting to the hingeplate
shown applies to all our
hinges.
B
Underside view
Ensure the underside of screw
B slides into slot on hingeplate.
Diagram 1
B
Hinge correctly attached to
hingeplate.
Diagram 2
Q
P
P
Q
PQ
0311
b:
P
Q

Assembly Instructions
18
Step 22
a: To move doors up
or down: loosen screws
shown and move doors
to suit.
Re-tighten screws.
Hinge adjustment
b: To move doors in or
out: loosen screw
shown and move doors
to suit.
Re-tighten screws.
c: To move doors left
or right: loosen or
tighten screw as shown.
Be careful not to fully
unscrew.
P
Q
P
Q
P
Q

Assembly Instructions
19
Step 23
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing. We have
included a fixing bracket
for this. No fixing screws
are provided as they will
need to suit the wall
type, and the length of
screw will depend on
the distance from the
back of the unit to the
wall. Please ensure
fixings used are
appropriate to your wall
type. Locate the bracket
to the top panel or to the
end panel as close to
top as possible. We do
not specify exact
location for the bracket,
this is left to the
customer’s discretion.
Fixing to wall and
attaching cover caps
Please take care when
drilling into the wall,
avoiding any pipes and
wires. Wear safety
goggles when drilling.
The use of residual
current device (RCD) is
recommended when
working with tools.If in
doubt consult a
qualified person.
Warning:
2 people to lift.
Lift with care.
With help move the
unit into position.
Warning:
S
x1
T
x2
V
V
x2
Use adhesive cover caps
to cover cams in the
left and right end panels
& .
V
V
V
V
0562
0561
0562
0561
