J D Williams Taylor User manual

Assembly Instructions - Please keep for future reference
Width - 68.5cm
1 Drawer Dresser
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 38.8cm
Height - 83.1cm
Rev A - 09/04/19
004 xx 9414
MADE IN
GREAT BRITAIN

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergents, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Top (68.5x38.8cm)
0834
Left End Panel
(81.6x38.6m)
0853
Right End Panel
(81.6x38.6cm)
0854
Back Rail (65.1x35.1cm)0108
Drawer Front
(64.7x12.7cm)
0855
Drawer Bottom
(61.2x34.8cm)
0575
Left drawer side (35.0x10.0cm)
Drawer back (60.1x10.0cm) Right drawer side (35.0x10.0cm)
622xx7014
624xx7010 623xx7014
Please check you have all the fittings listed below
Components - Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more
fittings may be supplied than are required.
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
Large cam x 8
Code 760001103
Metal dowel x 10
Code 760003004
ABC
EI
Small cam x 2
Code 760003005
8mm screw x 4
Code 700003510
G
18mm bolt x 2
Code 700002021
N
Handle x 2
Code 640391127
Left Bracket x 1
Code 760xx7002
Right Bracket x 1
Code 760xx7002
Right Runner x 1
Code 760xx7002
Left Runner x 1
Code 760xx7002
L1 R1
R2
L2
12mm screw x 8
Code 690001008
O
P
12mm screw x 2
Code 690001099 Support bracket x 1
Code 760001901

3
70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Tools required
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Exploded View
624xx7010
0575
0855
0108
0853
0834
0854
622xx7014
623xx7014

A: Insert 2 metal cams
and 2 metal dowels
into the right end panel
Assembly Instructions
4
Step 1
B
x4
B
Fitting dowels to top
panel.
B
B
B
B
x4
0834
B
B
Step 2
Fitting cams and
dowels to the end
panels.
Insert 4 metal dowels
into the top panel 0834
Note: Tighten metal
dowels up fully against
the panel.
Do not over-tighten.
A
A
B
A
x4
0854
A
B: Insert 2 metal cams
and 2 metal dowels
into the left end panel
0853
A
B
B
B
B
A
A
B
B
0853
0854
A
A
Step 3
A
A
A
A
Fitting cams to the
back rail panel.
0108
A
Insert 4 cams into the
back rail 0108
A
x4
These holes
not used

Assembly Instructions
5
Step 4
x1
E
E
E
E
N
x2
N
x1
Attaching the left
bracket to the left end.
Using 2 screws ,
secure the bracket to
the left end panel
as shown in diagram 1.
Use 1 screw to
secure the front of the
bracket.
Corresponding
hole
1ST
Diagram 1
Diagram 2
L1
L1
L1
Diagram 1
Diagram 2
L1
0853
Step 5
E
N
Attaching the right
bracket to the right end.
Using 2 screws ,
secure the bracket to
the right end panel
as shown in diagram 1.
Use 1 screw to
secure the front of the
bracket.
R1
0854
x1
E
x2
N
N
N
x1
R1
R1
Corresponding
hole
1ST
E
E
E
E
0854
0853

Assembly Instructions
6
B: Insert wooden dowels
in drawer back
into holes in
left &
right hand
drawer sides.
623xx7014
624xx7010
622xx7014
B
C
C: Sit drawer bottom
into groove on drawer
front. Ensure foil on the
drawer bottom is facing
upwards.
Step 6
x2
B
x2
A: Insert small cams
into left
and right
drawer sides.
Note: Ensure cam arrow
points towards the edge
with hole.
622xx7014
623xx7014
C
Step 7
A
G
x2
I
x2
A
Insert 2 metal dowels
into the the drawer
front .
0855
B
Fitting dowels to the
drawer front.
B
B
0855
C
C
Left hand side
Right hand side
Left hand side
Right hand side
Drawer Back
622xx7014
624xx7010
623xx7014
622xx7014
623xx7014
0855
0575
Foil surface facing upwards.
Plain chipboard surface
to underside.

Assembly Instructions
7
D
E
D:Locate the metal
dowels (already inserted)
in the drawer front into the
small cams in the left and
right hand drawer sides.
Ensure drawer sides are
pressed against drawer
front.
Turn cams 180 degrees to
lock.
E:
Fit bolts through
the pre-drilled holes in
the drawer front
and connect to the handles
.
I
0855
Using 6 screws
secure the left runner
and the right runner
to the drawer box.
Ensure that the wheel on
the runners is to the
back of the drawer box.
G
N
N
N
N
N
L2
L2
L2
R2
R2
x6 x1
Step 8x1
If these fronts have a
gloss finish they may
require a protective film
to be removed.
Please peel off before
attaching handles.
TURN DRAWER OVER
0855
0855
G
G
I
I
R2
L2

Assembly Instructions
8
Edged face.
(This can be attached
with fittings at the rear
if customer chooses).
Step 9
Step 10
Connect the dowels in
the right end to the
cams in the back rail
Turn cams 180 degrees
to lock.
Connect back rail to
the right hand end
0854
0108
Connect the dowels in
the left end to the
cams in the back rail
Turn cams 180 degrees
to lock.
0853
0108
Connect left end to
the back rail
0854
0108
0108
08360853

Assembly Instructions
9
Step 11
Step 12
Connect the dowels in
the top to the
cams in the end panels
and rail .
Turn cams 180 degrees
to lock.
Connect top to
the end panels.
0834
08540853
0854
0834
0836
0853
Fit the drawers.
Stand the unit up.
Tilt the drawers as
shown and slide onto the
runner brackets.

Assembly Instructions
10
Step 13
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing. We have
included a fixing bracket
for this. No fixing screws
are provided as they will
need to suit the wall
type, and the length of
screw will depend on
the distance from the
back of the unit to the
wall. Please ensure
fixings used are
appropriate to your wall
type. Locate the bracket
to the top panel or to the
end panel as close to
top as possible. We do
not specify exact
location for the bracket,
this is left to the
customer’s discretion.
Fixing to wall
Please take care when
drilling into the wall,
avoiding any pipes and
wires. Wear safety
goggles when drilling.
The use of residual
current device (RCD) is
recommended when
working with tools.If in
doubt consult a
qualified person.
Warning:
2 people to lift.
Lift with care.
With help move the
unit into position.
Warning:
x1 x2
OP

Assembly Instructions
Congratulations! Your unit is complete.
Important Information
If you need help or have damaged or missing parts, call the Customer Helpline:
01709 534123 8am - 4.30pm (Monday toThursday)
8am - 2.30pm (Fridays)
Please have the following information to hand:
>> Unit Description
>> Product Code
>> Product Colour
>> Place of Purchase
>> Catalogue Ref. No.
>> Item Code
>> Assembly Instructions
You can also e-mail your requests to us at:
[e-mail]
Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
(by contacting the customer service line your statutory rights are not affected)
