J D Williams 3 + 2 Drawer Chest User manual

Assembly Instructions - Please keep for future reference
Width - 66.8cm
3 + 2 Drawer Chest
Important - Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 01709 534123
Please turn to back page for important information when contacting Customer Helpline.
Dimensions
Depth - 33.0cm
Height - 75.2cm
Rev C - 31/01/2017
002 xx 6652
MADE IN
GREAT BRITAIN

Important - Please read these instructions fully before starting assembly
Safety and Care Advice
Check you have all the
components and tools listed on
pages 2 and 3.
Remove all fittings from the
plastic bags and seperate them
into their groups.
Keep children and animals
away from the work area, small
parts could choke if swallowed.
Make sure you have enough
space to layout the parts before
starting.
Do not stand or put weight on
the product, this could cause
damage.
Assemble the item as close
to its final position (in the same
room) as possible.
Assemble on a soft level
surface to avoid damaging the
unit or your floor.
Parts of the assembly will be
easier with 2 people.
We do not
recommend the
use of power
drill/drivers for
inserting screws,
as this could damage the unit.
Only use hand screwdrivers.
Care and maintenance
Always lift furniture when
moving it (do not drag)
otherwise the joints may be
damaged.
From time to time check that
there are no loose screws on
this unit.
This product should not be
discarded with household
waste. Take to your local
authority waste disposal centre.
1
Dust surfaces with a soft, dry,
lint free cloth.
More stubborn marks can be
removed using a damp
(not wet) cloth. Wipe the
surface dry immediately
using a soft lint free cloth.
Do not use detergents, abrasive
cleaning products or cleaning
products that contain ammonia,
solvents or silicone as these
may damage the surface finish.
To protect the furniture,
position the furniture out of
direct sunlight and away from
direct heat sources such as
radiators and fires.
Do not place the furniture in
excessively dry and humid
conditions.
Do not place hot or cold
objects on the surface, always
use protective mats to avoid
marking the furniture.
Clean spills up immediately
Dispose of all packaging
carefully and responsibly
when assembly complete.
Do Not dispose of packaging
until assembly complete.

Please check you have all the panels listed below
Components -Panels
2
Important - Thick lines indicate finished edges
Bottom(63.4x32.7cm)
0268
Left End Panel
(73.7x32.8m)
0269
Right End Panel
(73.7x32.8cm)
0270
Backpanel (67.0x66.0cm)7065
Plinth (63.4x7.6cm)8553
Drawer Front x3
(63.0x15.7cm)
0155
Drawer Bottom x 3
(61.2x29.8cm)
5671
Drawer Bottom x 2
(28.7x29.8cm)
4883
Divider Panel (31.1x16.0cm)
0271
624xx7010
Draw Front (Top Right)
(31.3x15.7cm)
0157
Left drawer side x5
(30.0x10.0cm)
Drawer back x2
(27.6x10.0cm)
Drawer back x3
(60.1x10.0cm)
Right drawer side x5
(30.0x10.0cm)
622xx7002
624xx7003
623xx7002
Draw Front (Top Left)
(31.3x15.7cm)
0156
Top (66.8x33.0cm)
9192

3
70 80 90 100 110 120
010 20 30 40 50 60
mm
130 140 150 160 170
Ruler - Use this ruler to help correctly identify the screws
Please check you have all the fittings listed below
Components - Fittings
Note: The quantities below are the correct amount to complete the assembly, In some case more
fittings may be supplied than are required.
Tools required
If you have damaged or missing components, call the
Customer Helpline: 01709 534123 Please turn to back page
for important information when contacting Customer Helpline.
Cross headed screwdriver
(medium & large )
Small Hammer
Tape Measure
Eye protection
(when using a
hammer)
Large cam x 14
Code 760001103
Metal dowel x 24
Code 760003004
ABC
E
DF
I
Small cam x 10
Code 760003005
Panel pin x 26
Code 760001012
Panel pin guide x 1
Code 684004501
G
20mm bolt x 5
Code 700002006
H
J
Runner x 10
Code 760001040
9mm bolt x 10
Code 690001078
8mm screw x 20
Code 700003510
Handle x 5
Code 640003511
L
K
L Bracket x1
Code 760001901
Screw x 2
Code 690001099

Exploded View
4
0155
5671
Large Drawers x3
622xx7002
622xx7002
623xx7002
624xx7003
4883
0156 622xx7002
623xx7002
623xx7002
624xx7003
624xx7010
4883
0157
8553
0271
9192
7065
0268
0269
0270

Step 1
Assembly Instructions
5
B
x6
B
Fitting dowels to top
panel.
B
Insert 6 metal dowels
into the top panel 9192
Note: Tighten metal
dowels up fully against
the panel.
Do not over-tighten.
A
x8
Step 2
A
B
x8
Step 3
A
A
Fitting cams to the
bottom and plinth.
Fitting cams and
dowels to the end
panels.
B
a: Insert 2 metal cams
and 4 metal dowels
into left end panel
.
0269
A
Insert 4 cams into
the plinth and
bottom panel
8553
0268
B
B
B
B
B
B
0269
9192
0270
A
B
A
x4
A
B
b: Insert 2 metal cams
and 4 metal dowels
into right end panel
.
0270
A
BB
BB
B
B
B
B
A
A
A
A
8553
0268
A
A
A
A
A
A

Insert the runner and
2 cams into the left
face of the divider panel
.
Turn the panel over and
insert runner .
Take care not to damage
the floor when turning
panel with exposed fittings
over.
Assembly Instructions
6
Step 4
H
E
H
E
Front of Runner
Back of Runner
E
E
H
E
E
H
E
E
H
E
E
H
E
E
H
E
E
H
E
E
H
E
E
H
E
E
H
A
B
H
x8
E
x16
H
x2
E
x4
Attaching runners to
the end panels.
Position the runner so
that the second hole
from the front of the
runner lines up with the
pre-drilled hole nearest
to the edge of the panel.
Use screws to secure
the runner.
Slide the runner forward
revealing the back of the
runner. The second hole
to the back of the runner
will now line up with
the second pre-drilled
hole.
E
Front of runner
Step 5
0271
Fitting cams and
runners to the divider.
A
A
x2
H
H
0271
E
E
H
A
A
0269
0270

Assembly Instructions
7
B
B
B
B
B
B
0155
Step 6
Fitting dowels to
drawer fronts.
B
Insert 2 metal dowels
into the the drawer
fronts , and
Repeat on the remaining
large drawer fronts .
0155 0156
0157
x10
B
x10
B: Insert wooden dowels
in drawer back
into holes in
left
right hand
drawer sides.
A: Insert small cams
into left
and right
drawer sides.
Note: Ensure cam arrow
points towards the edge
with hole.
Left hand side
Left hand side
Right hand side
622xx7002
623xx7002
622xx7002
622xx7002
623xx7002
623xx7002
624xx7010
622xx7002
C
C
C
Step 7
A
B
G
x5
I
x5
Drawer Backs
&
624xx7010
Right hand side
623xx7002
0156
0157
0155
624xx7003
Insert wooden dowels
in drawer back
into holes in
left
right hand
drawer sides.
623xx7002
624xx7003
622xx7002

Assembly Instructions
8
E
E:
G
I
Fit 1 bolts through
the pre-drilled hole in
the drawer front
and connect to the handle
.
Repeat on the remaining
drawers ,
and .
G
I
0155
C
C: Sit drawer bottom
into groove on drawer
front.
Ensure foil on the
drawer bottom is facing
upwards.
D:Locate grooves in
left and right drawer sides
around drawer bottom
and slide down locating
cams already inserted
in left and right
drawer sides onto
dowels in drawer front.
Turn cams 180 degrees
to lock.
D
Foil surface facing upwards.
Plain chipboard surface
to underside.
0155
622xx7002
623xx7002
Drawer Backs
&
624xx7010
624xx7003
5671
4883
&
0156
0157
0155
5671
4883
&
0156
0157
0156
0157
0155

0268
Assembly Instructions
9
Step 9
Connect the metal dowels
in the left end panel
to the cams in the bottom
and plinth panels
.
Step 10
0269
0268
8553
Connect the left end
panel to the bottom and
plinth panels.
Connect the metal dowels
in the right end panel
to the cams in the bottom
and plinth panels
.
0270
0268
8553
Connect the right end
panel to the bottom and
plinth panels.
Step 8
Connect the dowels in the
top panel to the
cams in the divider panel
.
Turn cams 180 degrees to
lock.
Connect the top panel
to the divider panel.
9192
0271 9192
0271
8553
0269
0268
8553
Ensure plinth is
not overhanging.
Ensure plinth sits
flush.
0270
Turn cams 180 degrees to
lock.

9192
Assembly Instructions
10
Step 11
Connect the dowels in
the top panel to the
cams in the right end panel
, the left end panel
.
Connect the end
panels to the top.
9192
0270
0269
Step 12
Squaring up the unit.
IMPORTANT!
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
Ensure a tape
measure is used
to square unit up.
DIAG 3
DIAG 1
XX
XX
YY
YY
XX
XX
YY
YY
DIAG 2
XX
XX
YY
YY
0270
0269
Turn cams 180 degrees to
lock.
XX
YY
YY
XX

Assembly Instructions
11
Step 13
D
F
D
x26
F
x1
Attach the back panel
to the unit.
Use the panel pin guide
when locating the panel
pins. This will hold the
panel pins vertical and
ensure the correct
distance from the edge.
Step 14
Fit the drawers.
Stand the unit up.
For this step we
recommend you follow
the helpful hints on the
next page. 2nd Hole
J
x10
J

Assembly Instructions
12
Step 15
a: Pull sliding part of
drawer runners out
so they are fully
extended.
Locate drawers helpful
hints
H
b: Locate drawer onto
runners.
c: Locate screwdriver
into second threaded
hole in drawer runner .
d: Keeping screwdriver
in place push the drawer
in until the screwdriver
pushes against the
panel.
Remove the screwdriver.
e/f: Pull drawer out slowly
and line the front hole in the
drawer side with the 2nd
threaded hole in runner .
Holding runner and
drawer side together
insert bolts through the
drawer side and
into threaded hole in
runner .
J
J
Now repeat these
steps for the other
side of the drawer.
J
D
EF
AB
C
2nd Hole
H
2nd Hole
J
L
L
L
L
L
J
H
H
H
H
H
H

Assembly Instructions
13
Step 16
We recommend that this
unit is fixed to a suitable
wall to prevent possible
overbalancing. We have
included a fixing bracket
for this. No fixing screws
are provided as they will
need to suit the wall
type, and the length of
screw will depend on
the distance from the
back of the unit to the
wall. Please ensure
fixings used are
appropriate to your wall
type. Locate the bracket
to the top panel or to the
end panel as close to
top as possible. We do
not specify exact
location for the bracket,
this is left to the
customer’s discretion.
Fixing to wall
Please take care when
drilling into the wall,
avoiding any pipes and
wires. Wear safety
goggles when drilling.
The use of residual
current device (RCD) is
recommended when
working with tools.If in
doubt consult a
qualified person.
Warning:
2 people to lift.
Lift with care.
With help move the
unit into position.
Warning:
K
x1
L
x2

Assembly Instructions
Congratulations! Your unit is complete.
Important Information
If you need help or have damaged or missing parts, call the Customer Helpline:
01709 534123 8am - 4.30pm (Monday toThursday)
8am - 2.30pm (Fridays)
Please have the following information to hand:
>> Unit Description
>> Product Code
>> Product Colour
>> Place of Purchase
>> Catalogue Ref. No.
>> Item Code
>> Assembly Instructions
You can also e-mail your requests to us at:
[e-mail]
Alternatively, you can write to us at: Customer Service Department, Addspace Furniture Limited,
Braithwell Way, Hellaby Industrial Estate, Hellaby, Rotherham, South Yorkshire, S66 8QY.
We do have an answer machine should you contact us out of office hours, so in addition to
the above information could you leave your name, address, daytime telephone number and
the nature of your call on the answerphone. All calls will be actioned asap.
(by contacting the customer service line your statutory rights are not affected)
