J D Williams Chinoiserie XK091 User manual

Dimensions
Width - 42cm
Depth - 32cm
Height - 59.5cm
Important– Please read these instructions fully before starting assembly
Assembly Instructions- please keep for future reference
464/3944
3 Drawer Bedside Unit
Issue 1 - 12/04/2017
XK091
PX946

1
Safety and Care Advice
Important – Please read these instructions fully before starting assembly
• Check you have all the
components and tools listed on
page 2
plastic bags and separate them
into their groups.
• Keep children and animals
away from the work area, small
parts could choke if swallowed.
• Make sure you have enough
space to layout the parts before
starting.
• During assembly do not stand
or put weight on the product,
this could cause damage.
•Assemble the item as close
room) as possible.
•Assemble on a soft level
surface to avoid damaging the
• Parts of the assembly will be
easier with 2 people.
• Only clean using a damp cloth
and mild detergent, do no use
bleach or abrasive cleaners.
• From time to time check that
there are no loose screws on
this unit.
•This product should not be
discarded with household waste.
Take to your local authority
waste disposal centre.
Care and maintenance
•Assemble all parts and bolts
loosely during assembly, only
once the product is complete
should you fully tighten the bolts
• Regularly check and ensure
tightend properly.
Handy Hints
• We do not
recommend the use
of power drill/drivers
for inserting screws,
as this could damage
the using. Only use hand
screwdrivers
WARNING
In order to help prevent overturning –
To help prevent product toppling over please follow the below steps:-
Do not allow children to climb or hang on the furniture
Do not place heavy items in the top drawers
Do not place heavy items on top of the furniture, unless the furniture has been
designed for this purpose
You will need to provide wall plugs and screws applicable for your wall type

2
Components -Panels
Please check you have all the panels listed below
Components - Fittings
Note:
may be supplied than are required.
Tools required
Phillips screwdriver
(medium & large)
A×1
B×1
C×1
1 ×30 2 ×11 3 ×20 4 ×20 5 ×12 6 ×13 7 ×3
8 ×3 9 ×2 10 ×3 11 ×3
13 ×3 14 ×1 15 ×1 16 ×1
D×1 E×1
F×1
I×3
J×3
K×3
L×3
H×3
G×1
123456 7
89 10 11 12
13 14 15 16
A
A
A
A
A
B
A
A
C
A
A
DA
A
E
A
A
F
A
A
G
A
A
H
A
A
I
A
A
J
A
A
K
A
A
L
16 ×2
17

3

4
Assembly Instructions
Step 1
Step 3
Step 2
4
4
9
9
4
4
10
11
4
4
4
4
1. Insert 4 x Male
Camlocks 4 into the
underside of Top Panel A
2. Connect Front Bar G to
Top Panel A using 2 x
Screw 9 as shown
4
A
A
A
A
A
A
4
4
4
9
9
A
A
G
4
A
A
A
A
A
G
A
A
A
9
1. To Right Side Panel E
Insert 2 x Male Camlocks
4
2. Connect 3 x Runners
11 in positions shown
using 3 x Screw 1
per Runner.
Please ensure runners
are facing the direction
shown.
Repeat above step for
Left Side Panel D using
3 x Runners 10 as
shown
A
A
E
4
4
4
A
A
E
A
A
D
4
4
11
11
10
10
A
A
D
1x3 1x3 1x3
1x3
1x3 1x3
1
A
A
B
A
A
C
5
5
5
5
5
5
5
5
1. Into Base Plinth B and
Base Panel C insert
8 x Dowels 5
A
A
B
A
A
C
5

5
Assembly Instructions
Step 4
Step 5
3
3
A
A
C
A
A
B
A
A
D
3
3
1. Locate Base Panel C
onto Male Camlocks in
Left Side Panel D as
shown.
2. Into the underside of
Base Panel C insert 2 x
Female Camlocks 3 as
shown.
A
A
C
A
A
D
A
A
C
3
3. Locate Base Plinth B
into Side Panel D
A
A
B
A
A
D
1. Locate Right Side Panel
E into position by
inserting Male Camlocks
into adjacent Holes
2. Into the underside of
Base Panel C insert 2 x
Female Camlocks 3 as
shown.
A
A
E
3
3
A
A
E
A
A
C
A
A
C
3

Assembly Instructions
Step 6
6
Step 7
Step 8
2
F
2
2
13
12
12
I
A
A
A
5
5
5
5
3x4
1. Insert 4 x Dowels
into the Top Edge of Side
Panels D and E
2. Locate Top Panel A
onto Side Panels
3. Into the holes shown in
Side Panels D and E
insert 4 x Female
Camlocks 3 as shown.
5
A
A
E
A
A
D
A
A
E
A
A
D
A
A
A
A
A
E
A
A
D
3
1. Connect Back Panel F
to the reverse of the unit
using 11 x Screw 2
2. On the reverse of the
unit, in position shown,
fix 1 x Wall Straps
using 1 x Washer
and 1 x Screws L
This unit is floor
standing but we
recommend
A
A
F
2
2
2
22
22
2
2
2
2
14 15
A
A
F
2
14
15
1. To Drawer Panel I
connect Runner 12 as
shown using 2 x Screw 1
2. To Drawer Panel J
connect Runner 13 as
shown using 2 x Screw 1
Please ensure runners
are facing the direction
shown.
A
A
I
A
A
J
1
1
1
1
13 13
A
A
I
12
12
12
1
A
A
J
13
1
17
17

7
Assembly Instructions
Step 9
Step 10
J
I
H
7
8
4
4
4
L
3
6
63
3
6
6
1. Into Drawer Front H
Insert 4 x Male
Camlocks
2. Locate Side Panels I
and J onto Male
Camlocks
3. Connect Handle 8
using 1 x Screw 7
Slide Drawer Base L
into position
Step 11
1. Locate Drawer Back
Panel K into position
shown.
2. Connect Back Panel K
using 4 x Screw 6
3. Insert 4 x Female
Camlocks 3 into holes
shown
A
A
H
A
A
J
A
A
I
4
4
4
4
8
7
A
A
H
4
A
A
I
A
A
J
8
7
A
A
L
A
A
L
A
A
K
A
A
K
A
A
K
6
6
6
6
3
3
3
3
6
3

Step 12
8
Assembly Instructions
WALL
6
17
16
6
1.Move the unit into
desired position.
2. Mark the wall with a
suitable scribe the
position of the fixing
holes.
4. Drill hole and insert 1 x
wall plug D
5. Connect to the wall
using 1 x Washer
and 1 x Screw
as shown
Warning:
Before driling,check
wall for hidden pipes
and cables.
Warning:
The unit
is heavy.
Lift with care.
Assembly Complete
This unit is floor
standing but we
recommend
16
6
17
Step 13
1. Insert 3 x Drawers
into the unit
17
