JABSCO 17800 series User manual

Model 17800-Series
PORTA QUICK OIL CHANGER
FEATURES
Pump Body: Bronze construction
Impeller: Nitrile (oil resistant)
Shaft Seal: Lip Type
Motor: Reversible with integral reversing
switch
Container: Plastic with 14 quart capacity
Power Cord: 8 feet with alligator clips
Suction Hose: 4 feet of neoprene hose with
40 inch Teflon* dipstick probe
Dimensions: 13-1/2" (343mm) diameter,
13-5/8" (354mm) high
Weight: 9 lb (4.1 kg)
OPERATING INSTRUCTIONS
1. Run the engine approximately 5 minutes to heat oil
(minimum oil temperature 140°F; maximum 185°F),
then shut off engine prior to oil removal.
2. Push the 1/2" suction hose onto the pump inlet hose
fitting. Position one hose clamp on the end and
tighten to secure the hose to the hose barb.
3. If using the 1/4" dipstick probe (instead of the
Female Garden Hose Connector), insert the probe
into the 1/4" x 1/2" (approximately 1" long) rubber
bushing until the end of the probe and the bushing
are flush with each other. Slide the hose clamp over
the end of the 1/2" hose and position the end of the
plastic probe, with bushing attached, in the end of
the suction hose. Slide the hose clamp to a position
where it will be approximately centered over the
probe/ hose bushing, and with a pair of pliers,
squeeze it together very tightly to affect a positive
airtight seal.
If using the Female Garden Hose Fitting, install it
onto the end of the 1/2" suction hose by inserting the
1/2" barb fitting into the
hose and secure it by
screwing together the
two halves of the plastic
clamp on the hose at the
position of the barb.
4. Clamp the power cord
alligator clips (red to
positive and black to
negative) to the termi-
nals of an appropriate
voltage battery.
NOTICE: Failure to use proper size fuse in power cord
fuse holder may cause motor damage and void
warranty.
Model Amp Fuse
Number Voltage Draw Size
17800-2000 12 7 10
17800-2090** 12 7 10
17800-2024** 24 3-1/2 5
** Models 17800-2090 and 17800-2024 conform with
EN50081-2 for suppression of electro-magnetic interference
and are marked.

5. If using the 1/4" dipstick probe, insert it into the
dipstick tube until it hits the bottom of the pan. If it is
not obvious when the probe hits the bottom of the
pan, it may be helpful to measure the distance from
the top of the dipstick tube to the bottom of the pan
and mark this length on the probe with a piece of
tape. Once the probe has hit the bottom of the pan,
pull it back up about 1/8" - 1/4" and hold the probe in
that position or secure it with some tape during the
oil removal process.
NOTICE: Do not push the dipstick probe too far into
the engine or it may get caught on internal
components and cause a problem when removing.
If using the Female Garden Hose Fitting, simply
screw it onto the Male Garden Hose Thread, when
provided, on the top of the dipstick tube until it is tight
enough to ensure an airtight seal. It is important,
when using this method, that the hose washer in the
garden hose fitting is pliable and in good serviceable
condition to ensure there is no air leak at this joint,
which will cause the pump to not prime.
6. The pump is reversible so it can pump oil in either
direction. The switch (at rear of motor) has two “on”
positions when it is moved to either side of center
with the center position being the “off” position. To
remove oil from the engine, move the switch in the
direction of required flow. If using the 1/4" probe,
watch for oil flowing through it. If oil does not appear
in about 10 seconds, check the probe for possible
sediment blockage and remove if present.
NOTICE: If the motor does not turn when first
switched on, switch off the pump and loosen each of
the end cover screws a couple of turns. Switch the
pump on until the motor turns and then switch it off
again. Retighten the end cover screws and start the
oil removal process again.
7. The motor will overspeed when the oil has been
pumped out of the engine. Switch off the pump
immediately to avoid impeller damage. Do not leave
the pump unattended while pumping oil from the
engine. Normal 6 quart pump-out takes less than
3 minutes.
8. After all the oil has been removed from the engine,
disconnect the alligator clips from the battery and
carefully remove the dipstick probe from the dipstick
tube.
9. To empty the container with the pump when
appropriate electrical power is nearby, remove 1/4"
probe from the 48" hose and insert hose end in an
approved receptacle. Do not attempt to discharge
oil through the 1/4"probe. Connect the power cord
to the proper power supply and switch on the pump
by moving the switch toggle in the direction of
desired flow. If proper electrical power is not
available, pull up the retractable pour spout and
carefully pour oil into a suitable receptacle.
NOTICE: Always recycle used oil in compliance
with federal and local legislation. Handle petroleum
products in an environmentally responsible manner.

EXPLODED VIEW
1
7
8
56 9 4
2
3
Part
Key Description Qty. Number
1 Lid 1 17794-0000
2 Power Cord 1 43922-0000
3 Pail 1 17089-0000
4 Hose Adaptor Sleeve 1 34423-1000
5 Dipstick Probe 1 18753-0608
6 Hose 1 17795-1000
7 Port Elbow & Tube 1 17834-1000
8 Port Adaptor Straight 1 93009-0190
9 1/2" Hose by Female 1 †
Garden Hose Thread Fitting
†
Available from Hardware Store.
PARTS LIST
Key Description Part No.
1Screw Kit (includes 3 screws) 91004-0090
2 End Cover 18647-0000
3 O-Ring* 18753-0660
4 Impeller* 9200-0023
5 Sea* 18753-0384
6Screw Kit (includes 3 screws) 98019-0020
DISASSEMBLY
1. Remove end cover screws, end cover and O-ring.
2. Withdraw impeller.
3. Loosen and remove two slotted hex screws, which
attach body to motor.
4. Tap body lightly between ports and remove body
from motor.
5. With a 1/2" diameter dowel, push against the shaft
seal from back (motor) side of the body to dislodge
it from the seal bore.
NOTE: Do not tamper with or disassemble motor.
ASSEMBLY
1. Lubricate seal with water and position it in seal bore
with lip, or hollowed-out side of seal, pointing
towards the impeller bore. With a 1/2" diameter
dowel, push against the shaft seal into its bore until
it contacts the bottom.
2. Lubricate motor shaft and install body on motor.
3. Lubricate impeller bore and, aligning flat in impeller
with flat on motor shaft, install impeller with clock-
wise rotary motion.
4. Install O-ring, end cover and screws.
Key Description Part No.
7 Body 18646-0000
8 Slinger 6342-0000
9 Motor: 12 Volt, EMC 18753-0067
24 Volt, EMC 18753-0636
10 Switch Polarity Reversing 18753-0652
Service Kit 90061-0053
*Parts contained in Service Kit.
34
2
1
5678910

U.S.A.
Jabsco
20 Icon
Foothill Ranch, CA 92610-3000
Tel: [phone]
Fax: [phone]
UNITED KINGDOM
Jabsco
Bingley Road, Hoddesdon
Hertfordsire EN11 OBU
Tel: [phone]
Fax: [phone]
CANADA
Fluid Products Canada
55 Royal Road
Guelph, Ontario N1H 1T1
Tel: [phone]
Fax: [phone]
JAPAN
NHK Jabsco Company Ltd.
3-21-10, Shin-Yokohama
Kohoku-Ku, Yokohama, 222
Tel: [phone]
Fax: [phone]
GERMANY
Jabsco GmbH
Oststrasse 28
22840 Norderstedt
Tel: [phone]
Fax: [phone]
© Copyright 2001, ITTIndustries Printed in U.S.A. All Rights Reserved Form: 43000-0750 Rev. 10/2001
A. LIMITED WARRANTY:
Jabsco warrants that at the time of shipment, the
products manufactured by Jabsco and sold hereunder
shall be in conformity with applicable written
specifications and descriptions referred to or set
forth herein, free from defects in material and,
merchantable, and suitable for a particular purpose,
provided such is implied by State law under the
circumstances of this sale.
B. WARRANTY ADJUSTMENT:
1. Jabsco agrees to repair or furnish a replacement for,
but not to remove or install, any product or
component thereof which, within one (1) year from
date of purchase, shall upon test and examination
by Jabsco prove defective within the above
warranty. Receipt verifying purchase date is required
to obtain adjustment.
2. Buyer shall notify Jabsco of any defect within this
warranty no later than ninety (90) days after the
defect is discovered.
3. No product will be accepted for return or replacement
without the prior written authorization of Jabsco.
Upon such authorization, and in accordance with
instructions from Jabsco, the product will be
returned to Jabsco, shipping charges prepaid by
Buyer. Products returned to Jabsco will be
addressed as follows:
JABSCO
1485 Dale Way
Costa Mesa, California 92626-3998
Or to such alternate locations as may be designated
on the product, its container, or this sheet.
Repair or replacement made under this warranty
will be shipped prepaid to Buyer.
C. EXCLUSIONS FROM WARRANTY AND
LIMITATION OF LIABILITY:
1. The foregoing warranty is limited solely as set
forth herein and applies only for the period
designated above.
2. JABSCO SHALL NOT BE LIABLE FOR ANY LOSS,
DAMAGE, SPECIAL OR CONSEQUENTIAL
DAMAGE OF ANY KIND, WHETHER BASED
UPON WARRANTY, CONTRACT, NEGLIGENCE,
OR STRICT LIABILITY ARISING IN CONNECTION
WITH THE SALE, USE, OR REPAIR OF THE
PRODUCT.
3. THE MAXIMUM LIABILITY OF JABSCO IN
CONNECTION WITH THIS WARRANTY SHALL
NOT IN ANY CASE EXCEED THE CONTRACT
PRICE FOR THE PRODUCT CLAIMED TO BE
DEFECTIVE OR UNSUITABLE.
4. This warranty does not extend to any product
manufactured by Jabsco which has been subjected
to misuse, neglect, accident, improper installation, or
use in violation of instructions furnished by Jabsco.
5. This warranty does not extend to or apply to any unit
which has been repaired or altered at any place
other than Jabsco’s factory, or by persons not
expressly approved by Jabsco, nor to any unit the
serial number, model number, or identification of
which has been removed, defaced or changed.
6. Components manufactured by any supplier other
than Jabsco shall bear only that warranty made by
the manufacturer of that product.
7. This warranty applies to products defined as
“consumer products” by the Consumer Product
Warranties Act as from time to time amended.
D. CONSUMER RIGHTS:
This warranty gives you specific legal rights, and you
may have other rights which vary from state to state.
Some states do not allow exclusion or limitation
of damages.
STANDARDWARRANTY: If the products manufactured
and sold hereunder are not Consumer Products, the
warranty extended to Buyer shall be as set forth in
subparagraphs (A), (B), and (C), EXCEPT THAT ALL
EXPRESS OR IMPLIED WARRANTIES OR
MERCHANTABILITY OR SUITABILITY FOR ANY
PARTICULAR PURPOSE ARE EXCLUDED.
ONE YEAR LIMITED WARRANTY
