JAMEC PEM PRO Series User manual

AIR & WATER HOSE REEL
PRO SERIES EXTREME - RETRACTABLE
OPERATING INSTRUCTIONS
PRODUCT NO.
58.3067 - Air Hose Pro Series Extreme - Retractable 8 M
58.4023 - Water Hose Pro Series Extreme - Retractable 8 M

AIR & WATER HOSE REEL
PRO SERIES EXTREME - RETRACTABLE
Extreme Ultraex Reinforced Hose is a special blend of hose that has been
developed for today’s demanding conditions, it stay exible in the cold and doesn’t
kink in the heat, allowing full ow in all-weather conditions. It’s a tough hose for
tough conditions
FEATURES
Hose layering system
Auto lock / rewind
No tools required adjustable hose stop
Wall mount with 180° pivot
Weather resistant UV stabilised polypropylene case
Leader hose 1 m with brass ttings (AIR ONLY)
Leader hose 1 m with 12 mm brass tap ttings (WATER ONLY)
Includes Jamec Pem Extreme Ultraex Hose
Bench top / short reach applications
SPECIFICATIONS
Part No. 58.3067 58.4023
Hose length 8 m 8 m
Hose I.D 9.2 mm (3/8") 10.5 mm (1/2")
Hose O.D 15.2 mm (5/8") 16.5 mm (5/8")
Leader hose length 1 m with 1/4" BSP Male tting 1 m with brass tap ttings
Hose material Extreme Ultraex Reinforced Hose Extreme Ultraex Reinforced Hose
Reel / case type Retractable / polypropylene Retractable / polypropylene
Auto lock / rewind Yes Yes
Max. working pressure 300 psi 150 psi
Fitting size 1/4" BSP Male 12 mm Tap ttings
Bracket 180° Pivoting 180° Pivoting
Weight - kg 4.1 4.5
Product dimensions 451.9 L x 206 W x 314 D mm 451.9 L x 206 W x 314 D mm
Advised application Air Water
MAINTENANCE
Always keep the hose clean.
If the hose becomes dirty, clean it with a damp cloth while retracting.
DO NOT twist the hose while in use.
Mount the hose reel in a sheltered area to assist and protect the performance of
the hose and hose reel.
DO NOT allow the hose to contact any corrosive chemicals or uids.#Always
retract the hose when not in use.
The JamecPem Hose Reel contains
a pre-tensioned spring inside
the inner drum assembly.
PRODUCT IDENTIFICATION
1. Mounting bracket
2. Pivot pin
3. Fully enclosed case
4. Carry handle
5. 1 m Leader hose with
1/4" BSP Male tting
6. Hose with adjustable stopper
7. 1 m Leader hose with
brass tap ttings
8. 12 mm Tap ttings
1
3
5
7
8
6
2
4
0.8 metre min.
INSTALLATION
The Jamec Pem Hose Reel can
be mounted in a horizontal or
vertical position.
1. Choose a location that is
near to the compressed air
source.
2. For large areas, place the
hose reel at the centre of
the work area.
3. When mounting the hose
reel vertically, ensure there
is adequate clearance under the reel to prevent injury or
damage
4. Mounting bracket must be installed on a at surface.
Note: It is recommended to install the mounting bracket 0.8
metre (minimum) above the oor level
5. Drill 4 holes to match the holes located in the Mounting
Bracket. (Fig. 1)
6. Connect the hose reel to the Mounting Bracket with the
Pivot Pin. (Fig. 2)
Note: For xed in-line position, t the locking plate onto the
Mounting Bracket prior to inserting the pivot pin. (Fig. 3)
7. Connect the inlet leader hose to the compressed air
source.
Note: Apply thread sealing tape to all air line and air hose
ttings.
OPERATION
1. Slowly pull out the hose to the required length. A ‘clicking’
noise will be heard every revolution of the inner drum. To
lock the reel, allow the hose to retract slowly after hearing
the second or third ‘click’.
2. To release the hose, pull it out until the ‘clicking’ noise
stops, and then allow the hose to slowly retract while
guiding it back into the hose reel. The self layering
mechanism will coil the hose back onto the inner drum.
3. To avoid injury and damage, always hold the hose while it
is retracting.
Fig. 1 Mounting Bracket
Fig. 2 Pivot Pin
Fig. 3 Locking Plate
IMPORTANT:
If the hose becomes tangled and will not retract - slowly pull out the hose past the
tangled section and then allow the hose to slowly retract while guiding it back
into the hose reel.
Always ensure the hose is clean and not twisted.
• Do not attempt to open the inner drum assembly.
WARRANTY EXCLUSIONS
The hose, rubber o-rings and hose stopper are deemed normal wear items and are
not covered under warranty.
The warranty does not extend to parts or components affected or damaged by
accident, normal wear, misuse, neglect or faulty installation.
To register a warranty claim visit: jamecpem.com
Distributed by
TRADEPEM INDUSTRIAL PTY LTD.
