Jandy®
Cartridge Pool Filters
CL and CV Versa-Plumb®
INSTALLATION AND
OPERATION MANUAL

Page 3
ENGLISH
Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
Table of Contents
EQUIPMENT INFORMATION RECORD
DATE OF INSTALLATION
INSTALLER INFORMATION
INITIAL PRESSURE GAUGE READING (WITH CLEAR FILTER)
PUMP MODEL HORSEPOWER
FILTER MODEL SERIAL NUMBER
NOTES:
Section 1. Important Safety Instructions........ 4
1.1 Important Safety Warning................................... 4
1.2 General Safety Instructions ................................ 4
Section 2. General Information ....................... 5
2.1 Introduction......................................................... 5
2.2 Description ......................................................... 5
2.3 General Requirements ....................................... 5
2.4 SpecicationsandDimensions .......................... 5
Section 3. Installation Instructions .....................6
3.1 Filter Location..................................................... 6
3.2 Anchor Bracket Installation................................. 6
3.3 Filter Preparation................................................ 6
3.4 Filter Plumbing ................................................... 7
3.5 Clamp Installation............................................. 10
Section 4. Start-Up and Operation ................ 10
Section 5. Filter Disassembly
and Assembly ................................11
Section 6. Maintenance.................................. 12
6.1 General Maintenance ....................................... 12
6.2 Pressure Gauge ............................................... 12
6.3 Cleaning the Filter Cartridge ............................ 12
Section 7. Winterizing .................................... 12
Section 8. Troubleshooting ........................... 13
Section 9. Parts List and Exploded View ..... 14
9.1 Jandy Pro CL and CV Cartridge
Filter Parts List ................................................ 14
9.2 Jandy Pro CL and CV Filters
Exploded View ................................................. 15
Section 10. Head Loss Curves ....................... 16
10.1 Jandy Pro CL and CV Cartridge
Filter Design Head Loss Curves....................... 16

Page 4 ENGLISH Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
WARNING
• Do not connect system to an unregulated city water system or other external source of
pressurized water producing pressures greater than 35 PSI.
• Pressurized air in system can cause product failure or also cause the filter lid to be blown off
which can result in death, serious personal injury, or property damage. Be sure all air is out
of system before operating or testing the equipment.
WARNING
MAXIMUM OPERATING PRESSURE OF THE FILTER IS 50 PSI. NEVER SUBJECT THE
FILTER TO ANY OPERATING PRESSURE EXCEEDING 50 PSI.
This filter operates under high pressure. When any part of the circulating system, i.e., filter,
pump, valve(s), clamp, etc. is serviced, air can enter the system and become pressurized when
the system is restarted. Pressurized air can cause product failure or also cause the filter lid to
be blown off which can result in death, serious personal injury or property damage. To avoid this
potential hazard, follow all of the instructions in this manual.
WARNING
To minimize risk of severe injury or death the filter and/or pump should not be subjected to the
piping system pressurization test.
Local codes may require the pool piping system to be subjected to a pressure test. These
requirements are generally not intended to apply to the pool equipment such as filters or pumps.
Jandy Pro Series pool equipment is pressure tested at the factory.
If however this WARNING cannot be followed and pressure testing of the piping system must include
the filter and/or pump BE SURE TO COMPLY WITH THE FOLLOWING SAFETY INSTRUCTIONS:
• Check all clamps, bolts, lids, lock rings and system accessories to ensure they are properly installed
and secured before testing.
• RELEASE ALL AIR in the system before testing.
• Water pressure for test must NOT EXCEED 35 PSI.
• Water temperature for test must NOT EXCEED 100°F (38°C).
• Limit test to 24 hours. After test, visually check system to be sure it is ready for operation.
Notice: These parameters apply to Jandy Pro Series equipment only. For non-Jandy equipment, consult equipment manufacturer.
Section 1. Important Safety Instructions
READ AND FOLLOW ALL INSTRUCTIONS
1.1 Important Safety Warning
1.2 General Safety Instructions
ATTENTION INSTALLER
This manual contains important information about the installation, operation and safe use of this
product. This information should be given to the owner/operator of this equipment.
1. Use equipment only in a pool or spa installation.
2. Before repositioning valve(s) and before beginning the assembly, disassembly, or adjustment of the clamp,
or any other service of the circulating system; (A) turn the pump off and shut off any automatic controls to
ensure the system is not inadvertently started during servicing; (B) open the air release valve; (C) wait until
all pressure is relieved (air will have stopped owing from the air release valve).
3. Whenever installing the lter clamp follow Section 3.5 of this manual, "Clamp Installation".
4.
Once service on the circulation system is complete, follow Section 4 of this manual, "Start-up and Operation".
5. Maintain circulation system properly. Replace worn or damaged parts immediately.
6. Be sure that the lter is properly mounted and positioned according to these installation instructions.
7. Do not pressure test above 35 PSI. Pressure testing must be done by a trained pool professional.
SAVE THESE INSTRUCTIONS

Page 5
ENGLISH
Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
28 in.
18
"A"
10½in.
½in.
Section 2. General Information
2.1 Introduction
This manual contains information for the proper instal-
lation and operation of the CL and CV Jandy Cartridge
Filters. Procedures in this manual must be followed
exactly. For technical assistance, contact our Technical
Support Department at 1.800.822.7933.
2.2 Description
Cartridge lters do not require sand or diatomaceous
earth as the lter medium. Instead, the lter contains
lter elements which are easily removed for cleaning or
replacement.
Dirty water ows into the lter tank through the water
line connected to the lower bulkhead (inlet) on the
bottom half of the tank body. It is directed through the
lter cartridge inside of the lter. The debris is collected
in the lter and the clean water ows out of the lter
through the upper bulkhead (outlet) on the bottom half of
the tank body. Clean water is returned through the piping
system to the pool.
As debris collects in the lter, the pressure will rise
and water ow to the pool will diminish. The lter will
eventually become so plugged with debris that it will be
necessary to remove the lter cartridges and clean them
with soap and water.
NOTE A filter removes dirt and other suspended particles but
does not sanitize the pool. Pool water must be sanitized
and chemically balanced for clear water. The filtration
system should be designed to meet local health codes. At
a minimum, the system should turnover the total volume
of water in your pool two to four times in a 24 hour period.
2.3 General Requirements
1. For best overall performance place the system as
close to the pool as possible.
2. The lter should be located on a level concrete
slab so that the orientation of the valve outlets and
the pressure gauge are convenient and accessible
for the installation and operation of the unit.
3. Protect the lter from the weather.
4. If tting a chlorinator and/or any other device
into the ltration plumbing circuit, great care
must be exercised to ensure that the appliance is
installed in accordance with the Manufacturer’s
Instructions and any standards that may exist.
5. We recommend the use of barrel unions to connect
each component of the water conditioning system
to ease in future servicing. Barrel unions are
provided with all Jandy lters.
Figure 1. Dimensions, Jandy Pro CL and CV Series
Cartridge Filters
WARNING
The maximum operating pressure for this filter is 50
psi. Never subject the filter to operating pressure
exceeding 50 psi. Operating pressures above 50 psi
can cause product failure or also cause the lid to be
blown off, which can result in death, serious personal
injury, or property damage.
6. When performing hydrostatic pressure tests or
when testing for external leaks of the completed
ltration and plumbing system, ensure that
the maximum pressure the ltration system is
subjected to does not exceed the maximum
working pressure of any of the components
within the system.
2.4 SpecicationsandDimensions
See Table 1 and Figure 1.
Table1. CartridgeFilterSpecications
CL/CV 340 460 580
Filter Area (ft2) 340 460 580
Max. Flow (gpm) 127 150 150
Six Hour
Capacity (gal.) 45,720 54,000 54,000
Max. Working
Pressure (psi) 50 50 50
Normal Start Up
Pressure (psi) 6-15 6-15 6-15
Dimension "A" 41 in. 41 in. 47 in.
CL INLET
OUTLET CV INLET
Port on
CV Model
Only
Port on
CL Model
Only

Page 6 ENGLISH Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
Section 3. Installation Instructions
WARNING
Use equipment only in a pool or spa installation. Do not
connect system to an unregulated city water system or
other external source of pressurized water producing
pressures greater than 35 psi.
3.1 Filter Location
1. Select a well-drained area, one that does not ood
when it rains. Damp, non-ventilated areas should
be avoided.
2. The lter should be installed on a rm, solid, and
level surface or platform to avoid risk of settlement.
Do not use sand to level the lter as the sand will
wash away; lter systems can weight up to 800
pounds. Check local building codes for additional
requirements. (Ex. Equipment pads in Florida must
concrete and equipment must be secured to the pad.)
3. Install electrical controls at least ve (5) feet from
the lter. This will allow enough room to stand
away from the lter during start-up.
4. Allow sufcient clearance around the lter to permit
a visual inspection of the clamp ring. See Fig. 2.
5. Allow sufcient space above the lter to remove
the lter lid and lter element for cleaning and
servicing.
6. Position the lter to safely direct water drainage.
Align the air release valve to safely direct purged
air or water.
WARNING
Water discharged from an improperly positioned filter
or valve can create an electrical hazard which can
cause death, serious injury or property damage.
FILTER
Figure 2. Filter Location
6" MINIMUM
CLEARANCE
6" MINIMUM CLEARANCE
CAUTION
Maintain your pressure gauge in good working order.
The pressure gauge is the primary indicator of how
the filter is operating.
7. If the lter needs to be located above the water
level of the pool, it can be raised 2.5 ft. without
affecting the pump efciency. A check valve is
recommended on the suction line to the pump.
8. If the lter is to be installed below the water level
of the pool, isolation valves should be installed
on both the suction and return lines to prevent
back ow of pool water during any routine
servicing that may be required.
3.2 Anchor Bracket Installation
In some areas, for example Florida, building codes
require that all appliances be securely fastened to the
equipment pad in order to withstand high wind pressures
created by hurricanes. Zodiac Pool Systems LLC
provides an anchor bracket kit for this purpose. Please see
the Parts List in Section 9 of this manual for the correct
part number. Follow the Anchor Bracket Installation Kit
Instructions to attach the brackets to the lter.
NOTE Anchor screws and washers for securing the anchor
bracket to the equipment pad are not included with the
filter or the anchor bracket kit. Zodiac recommends
that a ¼" x 2¼" long stainless steel Tapcon® concrete
screw and stainless steel flat washer are used to
mount each anchor bracket to the equipment pad. The
Tapcon concrete screw meets Florida building code
requirements.
After placing the lter on the equipment pad, as outlined
in Section 3.1, drill a 5/32" hole in the concrete at each
of the four (4) brackets on the lter. (The correct size
concrete drill bit should be obtained when the concrete
screws are purchased.)
Install the Tapcon screws and washers through each of
the four (4) anchor brackets to secure the lter to the
equipment pad. See Figure 3. Do not over-torque the
screws.
3.3 Filter Preparation
1. Check carton for damage due to rough handling
in shipment. If carton or any lter components
are damaged, notify carrier immediately.
2. Carefully remove the accessory package.
3. A visual inspection of all parts should be made
now. See parts list in Section 9.
4. With the carton in an upright position, remove the
lter tank from the carton.

Page 7
ENGLISH
Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
Filter Base
Drill 5/32” Hole
Mounting Tab
Mounting Bracket
#12x1” Stainless Steel Pan
Head Screws (Qty 2)
Drill Two 3/32” Holes
Through Filter Base
1/4” x 2-1/4” S.S. Tapcon®
Screw and S.S. Washer
3-1/2” Thick
(Min.)
Concrete Pad
than the maximum rating of any component,
install an ASME® approved automatic
pressure relief valve or pressure regulator in
the circulation system. Set the relief valve or
pressure regulator to lowest working pressure of
any of the components in the system.
3. Place the lter on the concrete pad, lined up with
the inlet/outlet pipes. See Figures 5 and 5A.
4. To reduce pressure losses, 2" (minimum) piping
is recommended for plumbing the system.
5. For best efciency use the fewest possible
number of ttings. This will prevent a restriction
in the water ow.
5.1 The CV model lter comes with a Jandy Pro
Sweep Elbow for this purpose. The sweep
elbow also includes a threaded port and plug
so that a ½" hose bib can be connected for
pressure testing. See Figure 7.
5.2 To install the sweep elbow use the following
instructions:
WARNING
To avoid an electrical shock hazard, which can result
in serious injury or death, ensure that all electrical
power to the system is turned off before approaching,
inspecting or troubleshooting any leaking valves
or plumbing that may have caused other electrical
devices in the surrounding area to get wet.
5. To mount the pressure gauge/air release assembly
to the top of the lter tank (located in the
accessory bag):
a. Place the smaller, thicker o-ring onto the
threads of the tank adapter, see Figure 4. Slide
the tank adapter through the coupling nut and
into the lter tank. Use the ats on the tank
adapter to tighten. Do not overtighten.
b. Place the larger, thinner o-ring onto the gauge
housing. Thread the housing into the coupler
on the tank adapter.
c. Orient the gauge/air release assembly in the
desired position. Raise and thread the locknut
onto the bottom of the gauge/air release
assembly. Hand tighten the nut only. Using a
wrench to tighten the nut may damage the nut,
gauge or air release assembly.
3.4 Filter Plumbing
1. This lter operates under pressure. When
clamped properly and operated without air in
the water system, this lter will operate in a safe
manner.
2. If the system can be subjected to higher pressure
Figure 4. Pressure Gauge/Air Release Assembly
Housing
O-Ring
O-Ring
Tank Adapter
Tank Adapter to Housing
Coupler
Anchor
Bracket
(Qty 4)
#12x1” Pan Head
Stainless Steel
Screw (Qty 8)
Tank Bottom
Filter Tank Anchor Bracket Installation Anchor Bracket to Platform Installation
Figure 3. Anchor Bracket Installation

Page 8 ENGLISH Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
Figure 5. CL Cartridge Filter Plumbing for Pool/Spa Combination
Heater
Waterfall
Pool Return
Spa Make Up
Spa Return
From Pool Skimmer
From Pool
Drain
Spa Suction
Pump
Check
Valve
From Outlet Port
To Inlet Port
Filter
Figure 5A. CV Cartridge Filter Plumbing for Pool/Spa Combination
Heater
Waterfall
Pool Return
Spa Make Up
Spa Return
From Pool Skimmer
From Pool
Drain
Spa Suction
Pump
Check
Valve
Outlet Port Inlet Port
Filter
Figure6. JandyProCLandCVSeriesCartridgeFilterDrainCongurations
CL/CV Filter
Tank Bottom
2" Ball
Valve
2" Pipe
Nut
Cap
O-ring
Alt Universal Union
for Plumbing
Bulkhead
OR

Page 9
ENGLISH
Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
LXi Heater CV Filter
SHP
Pump
Sweep Elbow
P/N SEAQL1001
Sweep Elbow
P/N SEFL1002
7½”
Minimum
Figure 7. Sweep Elbow
Note: Do not
overtighten.
Figure 8. LXi™Heater, CV Filter and SHP Pump Sweep Elbow Installation
NOTE The SHP pump shown in Figure 8 is for reference only.
The Jandy Pro sweep elbow also works with the MHP
and PHP series pumps.
NOTE Be sure to use 2" or 2½" schedule 40 PVC pipe.
c. Clean the cut ends of the pipe and both ends of
the sweep elbow(s) with an appropriate NSF®
approved All Purpose cleaner/primer. Glue the
sweep elbow(s) onto the cut pipe ends using
an appropriate All Purpose NSF approved
adhesive/glue.
NOTE Zodiac recommends Weld-On 724 PVC to CPVC
Cement to glue Schedule 40 PVC.
d. After the glue is cured, close the pressure
relief valve on top of the lter, start the system
and check for proper water ow.
6. Make all plumbing connections in accordance
with local plumbing and building codes. Filter
connections are provided with an o-ring seal. To
avoid damage to the o-rings, use only a silicone
base lubricant on the o-rings. Do not use pipe
joint compound, glue or solvent on inlet/
outlet union coupling nuts.
7. Keep piping tight and free of leaks. Pump
suction line leaks may cause air to be entrapped
in lter tank or loss of prime at the pump. Pump
discharge line leaks may show up as dampness or
jets of water.
8. Support the inlet/outlet pipes independently to
prevent any undue strains on the lter valve.
9. Connect the pipes using the unions supplied with
the lter. Do not use Teflon tape or pipe dope
on any unions. Assemble the unions dry and
hand tighten. See Figure 6.
WARNING
Follow all filter manufacturer’s
instructions. NEVER attempt to
assemble, disassemble or adjust the
filter when there is pressurized air in
the system. Starting the pump while
there is any pressurized air in the
system can cause product failure or
also cause the filter lid to be blown
off, which can cause death, serious
personal injury or property damage.
a. Switch off the circuit breaker to the equipment
and open the air relief valve on top of the lter
(leave it open during this procedure).
NOTE If the filter is below pool level, close the suction and
return line valves to isolate the filtration system.
Remove the drain plug from the filter. Let the water
drain from the filter.
b. Be sure there is a minimum distance of
7½ inches between the center of the pump
outlet port and the lter inlet bulkhead to
accommodate the sweep elbow(s). See Figure
8 for recommended installation conguration.

Page 10 ENGLISH Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
10. If desired, the CV lter drain can be plumbed
using a Jandy Pro universal union. The plumbing
must contain a ball valve as shown in Figure 6.
CAUTION
Be sure that all provisions for wastewater disposal
meet local, state or national codes. During any
draining process, one hundred gallons (100 gals.)
or more of pool water will be discharged. CL and CV
(Cartridge) Filters are not subject to backwashing. Do
not discharge water where it will cause flooding or
damage.
3.5 Clamp Installation
1. Be certain the o-ring is in position in the lower
tank half. Press the lter lid over the lower half
sandwiching the o-ring between the two halves.
2. Holding the ends of the lter clamp apart,
position the hinged segment of the lter clamp
over both upper and lower tank anges. Bring the
ends of the lter clamp together.
3. Place the "T" nut and threaded rod assembly into
the clamp. Be sure the "T" nut is seated in the
clamp in the proper orientation. See Fig. 9.
4. Use a 9/16" socket on the tightening nut until
the clamp ring halves touch each other, or are
within 1/16", see Fig. 9 but do not overtighten
as the clamp can break. If unable to tighten
as indicated, do not operate the lter and call a
service technician immediately.
5. After the rst week of operation, check the clamp
and retighten if necessary.
6. Check the lter clamp at least once a month.
Figure 9. Filter Clamp Ring
Clamp Ring
"T" Nut and
Threaded Rod Tightening Nut
w/ Shoulder
WARNING
Follow these instructions carefully.
Improper clamp installation can
cause product failure or also cause
the filter lid to be blown off, which
can result in death, serious personal
injury, or property damage.
Section 4. Start-Up and
Operation
NOTE This section applies to both new pool and
seasonal start-up.
1. Turn off the pump. Switch off the circuit breaker
to the pump motor.
2. Check that the drain plug for CL lters or drain
cap for CV lters is in place and tight.
3. Check that the tank clamp is correctly seated and
tight. See Figs. 9 and 10.
WARNING
NEVER start pump while standing
within five (5) feet of the filter. Starting
the pump while there is pressurized air
in the system can cause product failure
or also cause the filter lid to be blown
off, which can cause death, serious
personal injury or property damage.
WARNING
NEVER operate the filter system
at more than 50 psi of pressure.
Operating the filter system in excess
of 50 psi can cause the product failure
or also cause filter lid to be blown
off, which can cause death, serious
personal injury or property damage.
CAUTION
DO NOT operate filter at water temperatures above
105° F (40.6° C). Water temperatures above the
manufacturer’s recommendations will shorten the life
span of the filter and void the warranty.
4. Open the pump hair/lint pot lid and ll the pump
basket with water to prime the system. Replace
the lid. (You may have to do this several times on
new and seasonal start-ups.)
5. Completely open the air release valve on
the gauge/air release assembly by turning
the knob on the back of the assembly fully
counterclockwise (do not remove the knob).

Page 11
ENGLISH
Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
6. Be sure to open any lter isolation valves that
were installed in the system.
7. Stand clear of the filter and start the pump
to circulate water through the system. When a
steady stream of water starts to come out of the
air release valve, close the valve.
8. Watch the pressure gauge to be sure that the
pressure does not exceed 50 psi (with clean
cartridges). If the pressure approaches 50 psi,
immediately turn the pump off and clean the
lter cartridges, see Section 6.3. If the pressure
remains high after cleaning the lter, refer to the
troubleshooting guide in Section 8 for possible
causes and solutions.
9. After the pressure gauge has stabilized, turn the
bezel ring so that the arrow next to the word
"CLEAN" aligns with the needle of the gauge.
As the lter cleans the water, and the cartridges
begin to clog the pressure begins to increase.
When the needle of the pressure gauge aligns
with the arrow next to the word "DIRTY" on the
bezel, it is time to clean the lter, see Section 6.3.
This indicates an increased pressure of between
10 and 12 psi above original starting pressure.
Section 5. Filter Disassembly
and Assembly
WARNING
Never attempt to assemble,
disassemble or adjust the filter when
there is pressurized air in the system.
Starting the pump while there is any
pressurized air in the system can
cause product failure or also cause
the filter lid to be blown off, which can
cause death, serious personal injury
or property damage.
1. Turn off the pump. Switch off the circuit breaker
to the pump motor.
2. IMPORTANT: Completely open air release
valve on top of the filter tank to release all
pressure from inside the tank and system.
3. If the equipment is installed below water level,
close the lter isolation valves on the system to
prevent ooding.
4. Remove the drain plug located at the bottom of
the lter tank and allow the tank to drain.
5. Replace the drain plug.
6. Loosen the tank clamp ring retainer and remove
the clamp ring.
7. Remove the top of the lter tank by lifting it
straight up until it clears the cartridges on the
inside of the tank.
8. Remove the manifold assembly by lifting it off of
the outlet tube and out of the tank.
9. Pull the cartridges out of the lter tank and clean
the cartridge using the instructions in Section 6.3.
10. Using new cartridges or the clean original ones,
place the cartridges back into the lter tank. Be
sure that they are correctly seated on the cartridge
support on the bottom of the tank.
11. Inspect the o-ring at the top of the outlet tube for
cracks and wear marks. Replace if necessary.
12. Reinstall the manifold making sure that it ts
squarely over the cartridges and outlet tube.
13. Inspect the tank o-ring for cracks or wear marks.
Replace if necessary. Place the o-ring back onto
the lter bottom.
14. Place the lter lid onto the lter tank bottom.
15. Replace the tank clamp ring. See Section 3.5 for
clamp installation.
16. If applicable, open the valves closed in step 3.
17. Start the pump by following the procedures
outlined in steps 2 through 7 of Section 4.
Figure 10. Filter Clamp Ring Assembly
"T" Nut Threaded
Rod
Tighten-
ing Nut w/
Shoulder
Clamp
Ring
Tighten-
ing Nut w/
Shoulder
Use a 9/16" Socket
Clamp Ring,
Closed Position
GAP NOT TO EXCEED
1/16"

Page 12 ENGLISH Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
Section 6. Maintenance
6.1 General Maintenance
1. Wash outside of lter with a mild detergent and
water. Rinse off with a hose. Do not use solvents
to clean the filter, solvents will damage the
plastic components of the filter.
2. Check pressure during operation at least once a
week.
3. Remove any debris from the skimmer basket and
hair/lint pot on pump.
4. Check pump and lter for any leaks. If any
leaks develop, turn off the pump and call a
qualified pool service technician.
5. Product safety signs or labels should be
periodically inspected and cleaned by the product
user as necessary to maintain good legibility for
safe viewing distance.
6. Product safety signs or labels should be replaced
by the product user when a person with normal
vision, including corrected vision, is no longer
able to read the safety signs or label message panel
text at a safe viewing distance from the hazard.
In cases where the product has an extensive
expected life or is exposed to extreme conditions,
the product user should contact either the product
manufacturer or some other source to determine
means for obtaining replacement signs or labels.
7. Installation of new replacement safety signs or
labels should be in accordance with the sign or
label manufacturer's recommended procedure.
6.2 Pressure Gauge
1. During operation of the ltration system, check
the pressure gauge/air release assembly for air or
water leaks at least once a week.
2. Keep the pressure gauge in good working order.
If you suspect a problem with the gauge, Zodiac
recommends you call a service technician to do
any work on the lter/pump system.
CAUTION
Maintain your pressure gauge in good working order.
The pressure gauge is the primary indicator of how the
filter is operating.
6.3 Cleaning the Filter Cartridge
1. Follow the procedures outlined in steps 1 through
8 of Section 5.1 to expose the cartridge elements
inside the lter.
2. Remove cartridge elements and place them
upright in an area suitable for washing.
3. Use a garden hose and nozzle to wash each pleat
of each element.
NOTE Algae, suntan oil, calcium and body oils can form
coatings on filter element which may not be removed
by normal hosing. To remove such materials, soak
the element in de-greaser and then a de-scaler. Your
local pool dealer will be able to recommend suitable
products.
4. Inspect each cartridge for holes, tears or
excessively worn pleats. Replace if necessary.
5. To reassemble the lter with the new or clean
cartridges follow the procedure outlined in steps
10 through 16 of Section 5.
Section 7. Winterizing
1. Turn off the pump and circuit breakers.
2. Open air release valve on top of the lter.
3. Remove the drain plug at the base of the lter to
ensure that the tank is empty. Store the drain plug
and seal in a safe place. Do not reinstall until
next season at start-up.
4. Drain system piping of all water.
5. Cover the system with a tarpaulin or plastic sheet
to protect it from the weather.

Page 13
ENGLISH
Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
Table 2. Troubleshooting Guide
Fault Symptom Possible Problems Solutions
Water is not clear. Insufficient disinfectant level.
Incorrect pool chemistry.
Heavy bathing and/or dirt loads.
Insufficient running times.
Filter is dirty.
Hole in filter element.
Check and adjust disinfectant level.
Test and adjust water chemistry.
Adjust filter time and/or water chemistry.
Increase pump run time.
Clean filter cartridges per instructions.
Replace cartridge.
Low water flow. Filter system strainer baskets dirty.
Air leaks on suction side of pump.
Restrictions or blockage in either
suction or return lines.
Filter cartridges need to be cleaned or
replaced.
Pool water level too low.
Pump not primed.
Pump impeller vanes blocked.
Strainer baskets not being used and/or
broken. (Allow debris into pump.)
Pump operating under speed (low
voltage).
Check and clean strainer baskets.
Check all connections between pool
intake and pump.
Check all lines for debris or partially
closed valves.
Clean or replace filter cartridges per
instructions.
Fill pool so level is above pump inlet line.
Fill pump with water at basket and
replace lid.
Technician required.
Replace baskets.
Technician or electrician required.
Short filter cycles. Presence of algae clogging filter.
Incorrect water chemistry.
Pump output exceeds design flow rate
of filter.
Ineffective cleaning.
Check disinfectant content.
Check pH, total alkalinity and TDS.
Check pump performance.
Clean or replace filter cartridge per
instructions.
High pressure on start-up. Small eyeball fitting in Pool/Spa.
Partially closed valve on return line.
Too large of pump.
Filter cartridges dirty.
Replace with larger diameter fitting.
Check and fully open all valves on return
line.
Check pump and filter selection.
Clean filter cartridges per instructions.
Dirt returns to pool. Hole in filter cartridge.
Worn o-ring seal inside filter.
Cracked manifold.
Replace filter cartridge per instructions.
Replace o-ring.
Replace the manifold assembly.
Section 8. Troubleshooting
1. For a list of common problems and solutions see
the Troubleshooting Guide below.
2. Zodiac recommends that you call a service
technician to do any work on the lter/pump
system. For technical assistance, contact our
Technical Support Department at 1.800.822.793.

Page 14 ENGLISH Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
Key
No. Description Model No. Part No.
1 Handle Assembly w/ hardware (set of 2) All R0357100
2 Handle Hardware (set of 4) All R0359900
3Gauge/Air Release Assembly All R0357200
4 Pressure Gauge All R0359600
5 Tank Adapter w/O-ring & Union Nut All R0552000
6Tank Top 580 R0357300
Tank Top 340,460 R0554700
7 Top Spacer All R0357700
8Breather Tube Assembly All R0358700
9Manifold Assembly All R0357600
10 Filter Cartridge, 145 sq. ft. (4 required) 580 R0357900
Filter Cartridge, 115 sq. ft. (4 required) 460 R0554600
Filter Cartridge, 85 sq. ft. (4 required) 340 R0554500
11 Tank Clamp Ring w/Rod Assembly All R0357400
12 Threaded Rod and Retainer and Nut All R0357500
13 Tank O-ring All R0357800
14 Outlet Tube/Elbow Assembly w/ O-rings All R0555100
15 Inlet Elbow w/O-ring All R0358400
16 Filter Cartridge Support All R0358500
17* O-ring Replacement Kit All R0358000
18 Ring, Retaining All R0405200
19 Bulkhead Assembly w/O-ring, CV Filter All R0465600
20 Anchor Bracket (Qty 4) All R0465500
21 Tank Bottom Assembly, CV Filter All R0465400
22 Tank Bottom Assembly, CL Filter All R0466500
23 Universal Half Unions (Set of 3) and Drain Plug Cap All R0461800
24* Sweep Elbow All SEFL1002
25 Universal Half Union (Set of 1) All R0522900
26 Drain Cap Assembly All R0523000
Section 9. Parts List and Exploded View
9.1 Jandy Pro CL and CV Cartridge Filter Parts List
*Parts not shown on key view

Page 15
ENGLISH
Jandy®Versa-Plumb®Cartridge Pool Filters |Installation & Operation Manual
,6
6
,6
6
8,9 8,9
,22
11,
16
22,18
11,
16
11,
,21
11,
22
20
22
14
26
19
22
15,22
23,25
18,21
14
15
26
21
23,25
21
20
15,21
19
21
21
9.2 Jandy Pro CL and CV Filters Exploded View
CL Filter CV Filter

Zodiac Pool Systems LLC
2882 Whiptail Loop East #100, Carlsbad, CA 92010
1.800.822.7933 | www.ZodiacPoolSystems.com
Zodiac Pool Systems Canada, Inc.
2-3365 Mainway Burlington, Ontario L7M 1A6
1-888-647-4004 | www.ZodiacPoolSystems.ca
©2019 Zodiac Pool Systems LLC. ZODIAC®is a registered trademark of Zodiac International,
S.A.S.U., used under license. All trademarks referenced herein are the property of their respective
owners.
H0291800 Rev H
Section 10. Head Loss Curves
10.1 Jandy®Pro CL and CV Cartridge Filter Design Head Loss Curves
0
2
4
6
8
10
12
14
16
18
20
22
24
26
28
0 30 60 90 120 150
Flow Rate (gpm)
Design
Head
Loss
(ft head)
0
2
4
6
8
10
12
CL340 CV340
CL460 CV460
CL580 CV580
Design
Pressure
Drop
(psi)

H0291800 Rev H
AVERTISSEMENT
POUR VOTRE SÉCURITÉ – L’installation et l’entretien de ce produit doivent être effectués par un technicien autorisé
et qualifié pour la réparation des équipements de piscine par les autorités compétentes du territoire dans lequel ledit
produit est installé lorsque de telles exigences locales ou provinciales sont édictées. Le responsable de l’entretien
doit être un professionnel ayant une expérience suffisante dans l’installation et l’entretien des équipements de piscine
de manière à ce que les consignes du présent manuel puissent être suivies à la lettre. Avant d’installer ce produit, lire
toutes les consignes de mise en garde et les instructions incluses avec ce produit et respectez-les. Le non-respect
des avertissements et des instructions pourrait causer des dommages matériels, des blessures graves ou même un
décès. L’installation ou l’utilisation inappropriée annuleront la garantie.
L’installation ou l’utilisation inappropriée peuvent créer un danger électrique indésirable qui peut
provoquer des blessures graves, des dommages à la propriété ou la mort.
ATTENTION À L’INSTALLATEUR - Ce manuel contient de l’information importante sur l’installation,
le fonctionnement et l’utilisation de ce produit en sécurité. Ces renseignements doivent être donnés
au propriétaire ou à l’utilisateur de cet appareil.
ENGLISH |FRANÇAIS
Jandy®
Filtres à cartouche pour piscine
CL et CV Versa-Plumb®
MANUEL D’INSTALLATION
ET D’UTILISATION

Page 18 FRANÇAIS Jandy®Filtres à cartouche pour piscine |Manuel d’installation et d’utilisation

Page 19
FRANÇAIS
Jandy®Filtres à cartouche pour piscine |Manuel d’installation et d’utilisation
FICHE DE RENSEIGNEMENTS SUR L’ÉQUIPEMENT
DATE D’INSTALLATION
INFORMATION SUR L’INSTALLATEUR
LECTURE INITIALE DU MANOMÈTRE (AVEC FILTRE PROPRE)
MODÈLE DE POMPE PUISSANCE EN CHEVAUX
MODÈLE DE FILTRE NUMÉRO DE SÉRIE
REMARQUES :
Table des matières
Section 1. Consignes De Sécurité
Importantes................................... 20
1.1 Avertissements de sécurité importants............. 20
1.2 Consignes générales de sécurité ..................... 20
Section 2. Informations générales .................. 21
2.1 Introduction ...................................................... 21
2.2 Description ....................................................... 21
2.3 Exigences générales ....................................... 21
2.4 Spécicationsetdimensions ........................... 21
Section 3. Guide d’installation ..................... 22
3.1 Emplacementdultre...................................... 22
3.2 Installation des supports d'ancrage ................. 22
3.3 Préparationdultre ......................................... 22
3.4 Plomberiedultre ........................................... 23
3.5 Installation du serre-joint ................................. 26
Section 4. Démarrage et fonctionnement..... 26
Section 5. Démontage et montage
du ltre 27
Section 6. Entretien ....................................... 28
6.1 Entretien général ............................................. 28
6.2 Manomètre ...................................................... 28
6.3 Nettoyagedelacartoucheltre....................... 28
Section 7. Hivernage ..................................... 28
Section 8. Dépannage ................................... 29
Section 9. Liste des pièces et vue
éclatée ..30
9.1 Listedespiècesdesltresàcartouche
CL et CV .......................................................... 30
9.2 VueéclatéedesltresCLetCV...................... 31
Section 10. Courbes de perte de charge ....... 32
10.1 Courbesdepertedechargedesltres
àcartoucheCLetCV ...................................... 32

Page 20 FRANÇAIS Jandy®Filtres à cartouche pour piscine |Manuel d’installation et d’utilisation
AVERTISSEMENT
• Nepasraccorderlesystèmeàunréseauurbaindedistributiond’eaunonréglementéouàuneautresource
externed‘eausouspressionproduisantdespressionssupérieuresà2,4bars(35lb/po²).
• L’airsouspressiondanslesystèmepeutprovoquerunmauvaisfonctionnementduproduitoufairesauterle
couvercledufiltre,cequipourraitcauserdesblessuresgraves,voirelamort,oudesdommagesmatériels.
S’assurerquetoutl’airestpurgédusystèmeavantdefairefonctionneroudetesterl’équipement.
AVERTISSEMENT
LA PRESSION DE FONCTIONNEMENT DU FILTRE EST DE 3,4 BARS (50 LB/PO²). NE JAMAIS SOUMETTRE
LE FILTRE À UNE PRESSION DE FONCTIONNEMENT SUPÉRIEURE À 3,4 BARS (50 LB/PO²).
Cefiltrefonctionnesoushautepression.Lorsquetoutepartiedusystèmedecirculation,c’est-à-direlefiltre,la
pompe,lessoupapes,leserre-joint,etc.,fontl’objetd’unentretien,l’airpeutentrerdanslesystèmeetdevenir
souspressionaumomentduredémarrage.L’airsouspressionpeutprovoquerunmauvaisfonctionnementdu
produitoufairesauterlecouvercledufiltre,cequipourraitcauserdesblessuresgraves,voirelamort,oudes
dommagesmatériels.Pourévitercedangerpotentiel,suivretouteslesconsignesduprésentmanuel.
AVERTISSEMENT
Pourréduirelesrisquesdeblessuresgraves,voiredemort,lefiltreet/oulapompenedoiventpas
être soumis au test de mise sous pression du système de tuyauterie.
Lescodeslocauxpeuventexigerl’applicationd’unessaidepressionausystèmedetuyauteriedelapiscine.
Cesexigencesnes’appliquentgénéralementpasàl’équipementdepiscine,telquelesfiltresoulespompes.
L’équipementdepiscineSérieJandyProestsoumisàl’essaidepressionenusine.
Toutefois,sicetAVERTISSEMENTnepeutpasêtrerespectéetqueletestdemisesouspression
dusystèmedetuyauteriedoitinclurelefiltreet/oulapompe,S’ASSURERQUELESCONSIGNES
DESÉCURITÉSUIVANTESSONTRESPECTÉES:
• Vérifierquetouslesserre-joints,lesboulons,lescouvercles,lesanneauxdeblocageetlesaccessoiresdu
systèmesontcorrectementinstallésetfixéssolidementavantd’effectueruntest.
• PURGER TOUT L’AIRdusystèmeavantd’effectuerletest.
• Lapressiond’eaupourletestNEDOITPASDÉPASSER2,4BARS(35LB/PO²).
• Latempératuredel’eaupourletestNEDOITPASDÉPASSER38°C(100°F).
• Limiterletestà24heures.Aprèsletest,vérifiervisuellementlesystèmepours’assurerqu’ilestprêtàfonctionner.
Avis :Cesparamètress’appliquentàl’équipementSérieJandyProuniquement.Pourl’équipementnonfabriquéparJandy,consulterlefabricantdel’équipement.
Section 1. Consignes De Sécurité Importantes
LIRE ET SUIVRE TOUTES LES CONSIGNES
1.1 Avertissements de sécurité importants
1.2 Consignes générales de sécurité
A I’ATTENTION DE L’INSTALLATEUR :
Ceguidecontientdesrenseignementsimportantsconcernantl’installation,lefonctionnementetles
consignesdesécuritépourceproduit.Cesrenseignementsdoiventêtredonnésaupropriétaire/à
l’opérateurdecetéquipement.
1. Utiliser l’équipement uniquement dans une piscine ou un spa.
2. Avant de repositionner les soupapes et de commencer la pose, le retrait ou le réglage du serre-joint ou tout autre
entretien du système de circulation : (A) désactiver la pompe et fermer toutes les commandes automatiques pour
s’assurer que le système ne va pas démarrer par inadvertance pendant l’entretien, (B) ouvrir le purgeur d’air, (C)
attendre que la pression s’atténue (l’air aura cessé de circuler en provenance de la soupape).
3.
À chaque installation du serre-joint du ltre, suivre la Section 3.5 du présent manuel, « Installation du serre-joint ».
4. Une fois que l’entretien du système de circulation est terminé, suivre la Section 4, « Démarrage et fonctionnement ».
5. Faire l’entretien approprié du système de circulation. Remplacer immédiatement les pièces usées ou endommagées.
6. S’assurer que le ltre est correctement installé et positionné selon ces consignes d’installation.
7. Ne pas soumettre à une pression de test supérieure à 2,4 bars (35lb/po²). Le test de pression doit être fait par
un professionnel de piscines qualié.
CONSERVER CES CONSIGNES.
