Jantar POPULUS P Series User manual

POPULUS P –Access controller
5/2014
Black line
www.codeks.eu
POPULUS P –ACCESS CONTROLLER
The Populus P is an access controller that controls up to 8 readers
and 4 outputs for electric strikes. It is designed for residential and
business buildings, offices, shops, etc.
The entire set-up procedure is carried out with the software. The
controller allows access for up to 16000 users. It is intended for
controlling entries, exits and passes of users in the system and
controlling sliding doors, ramp, el. strike, turning alarm on/off… It
needs to be set with BLOCKER, V7 or CODEKS software.
It may also be used as a standalone controller. In this case, the
entire set-up procedure is carried out with master card or code.
User cards and codes can either be registered or deleted. The
controller allows access for up to 500 users (1 master card + 500
user cards or codes).
The SDK is also available for this controller. If a user or software
producer wants to develop its own application, please contact us.
TECHNICAL DATA
POPULUS P-1-3P and POPULUS P-1-3P-NET
Readers
1x direct or Wiegand, 1x protocol
Inputs
1x door status, 1x button
Outputs
1x max. 0.5 A active=GND
Relays
1x 5A 60V DC
POPULUS P-2-3P and POPULUS P-2-3P-NET
Readers
2x direct or Wiegand, 2x protocol
Inputs
2x door status, 2x button
Outputs
2x max. 0.5 A active=GND
Relays
2x 5A 60V DC
POPULUS P-4-3P and POPULUS P-4-3P-NET
Readers
4x direct or Wiegand, 4x protocol
Inputs
4x door status, 4x button
Outputs
4x max. 0.5 A active=GND
Relays
4x 5A 60V DC
*if Populus P is in Spider mode, the same data applies
Common features
Input voltage
110 –230 V AC 50–60 Hz
Output voltage
13.8 V DC
Primary fuse
(F100) T1AL, 250 V (5x20mm)
Current consumption
Up to 2W
Humidity
10-80 %, non-condensing
Dimensions (mm)
222x222x80 (WxHxD)
Operating temperature
From -20°C to 40°C
Communication
RS485 or Ethernet
Clock
Real time clock, battery backup
(max. ten hours)
Operation at an altitude of
<2000m
Appliance class
Class II - This is a class A
product. In a domestic
environment this product may
cause radio interference in which
case the user may be required to
take adequate measures.
CONNECTOR DESCRIPTION
Connectors are marked on the circuit board with AC, LAN, SYS,
COM, RDR and DOOR.
CONNECTOR AC –Power supply
Contact
Description
Specification
1
AC
Power supply
110 –230 V AC
50–60 Hz
CONNECTOR LAN –Ethernet connection
Contact
Description
Specification
1
LAN
Ethernet
CONNECTOR SYS –backup battery connection
Contact
Description
Specification
1
BAT
12 V DC from battery
2
GND
Ground
3
12V
Max. 0.5 A
4
GND
Ground
CONNECTOR COM –RS485 communication connection
Contact
Description
Specification
1
CA
RS485 A line
2
CB
RS485 B line
3
CA
RS485 A line
4
CB
RS485 B line
CONNECTOR RDR1, RDR2, RDR3, RDR4 –reader connection
Contact
Description
Specification
1
12V
12 V DC output
2
GND
Ground
3
D0
Data 0
4
D1
Data 1
5
BUZ
Buzzer output
6
LED
LED output
7
XA –RS485 XA line
For protocol reader
8
XB –RS485 XB line
For protocol reader
CONNECTOR DOOR1, DOOR2, DOOR3, DOOR4 –sensor,
button, el. strike and relay connections
Contact
Description
Specification
1
SWITCH
Door status switch input
active=GND
2
GND
Ground
3
BUTTON
Push button input
active=GND
4
12V
12 V DC output
5
LOCK
El. strike output
active=GND
6
NO
Relay –open contact
7
MIDDLE
Relay –middle
8
NC
Relay –closed contact
Power Supply
The controller can operate within a 110-230V AC, 50–60Hz input
range. The output power of the in-built power supply is 30W, 13.8V
fulltime. The power supply has protection against both short
circuits and current overload. In the event of protection activation,
the power will be switched off for 5s. If this is repeated 20 times,
the controller will switch off until electrical resetting takes place
(unplugging from mains voltage). This protection is activated if
external consumption exceeds 2A.
An appropriate disconnect device should be provided external to
the equipment. A multi-strand/stranded flexible wires connected to
the unit mains input require ferrules.

POPULUS P –Access controller
5/2014
Black line
www.codeks.eu
2.3Ah battery support is included with a charging limit of 13.8 V DC
and shut down at 10.5V. The charging time of an empty battery is
approximately 4 hours. The charging voltage and current are 13.8
V DC and max. 0.625 A. A 2.3Ah battery can be installed in the
box. Larger external 12V batteries, such as 7Ah, may also be
connected but recharging times will be longer. When operating
from battery, the output voltage will drop from 13.8V to 10.5V.
Risk of explosion if battery is replaced by an incorrect type.
Dispose of used batteries according to the manufacturer's
instructions.
Voltage drops
When you connect devices to the controller, use a cable of at least
0.2mm2diameter. Take into consideration the fact that this cable
has a resistance of approximately 9ohm per 100m. You should
have a minimum of 10V for power supply at device point (for our
readers). With our readers you can achieve cable length of more
than 200m (see our black line readers). For total case scenario,
consider also the supply voltage drop when operating on a battery.
Door
A One-Door connector is a set of one output, for a door strike or
magnet, 2 inputs for the door switch and push button and 3 relay
contacts. With Wiegand readers max. two-door with two-way
access control or four-door one-way access control setups are
possible. In combination with protocol readers, four-door two-way
access control is also possible. Select magnet or door strike and
readers so that their total consumption does not exceed 1.5A at
12V.
Inputs, outputs and environment
Inputs:
Inputs are realized with opto-isolators. The input is active, when
pulled to ground with an open collector transistor or mechanical
switch, which is connecting the input pin of the controller to the
Ground.
Outputs:
Output has a pre-installed protection diode for an inductive load. It
is also protected from current overload. The best way is to use a
0.25A el. strike or a 0.5A el. magnet, which has to be connected to
the same positive pole (+) as the controller. Connect the negative
pole (-) to the door strike output (LOCK). When the output is active
it is pulled to ground.
Environment:
Do not install the controller on/in a place, where it can come in
contact with water. You must assure good cable joints, protected
against moisture, otherwise corrosion may damage the controller.
Damage in such cases is not covered by the warranty. You have to
install the controller in an airy place.
Communication
Ethernet:
Connect the controller to the computer through your LAN via
Ethernet connector. Use at least UTP CAT 5e cable. Adjust network
settings of the controller using the Codeks Device Manager
software so that it will function properly in your network. Please
consult Codeks Device Manager’s manual.
S - Spider mode
In the Spider mode the controller can be used as a communication
converter, from which you can continue RS485 communication line
to the other controllers. When the controller is reset to the factory
settings (brainwash), the controller address is set to 254.
RS485:
Connect the controller to the computer, with one of the power
supplies, with communication converter, from the Spider family:
Spider W5-USB, Spider W5-NET, Spider W40+NET.
The RS485 communication bus is used between the controllers and
Jantar software. Up to 128 controllers can be lined up into one
communication line. The maximum length of the communication
line is 1000 cable meters. It is recommended that you use an FTP
or S-FTP cable. Only a serial connection of controllers in a single
communication line is allowed. Star (parallel) connection is not
allowed.
All shields of S-FTP cables must be wired together and at one
point connected to the earth. Individual connections to the earth
are not allowed. Do not connect the shield of the cable to the
ground of the controller.
In the event of problems in communication, a termination
resistor needs to be added. We recommend using 120 Ohm
resistors on each side of the cable. Converters are, on the
RS485 side, protected with slow-blow fuses and transient
voltage suppressors.
Reset to the factory settings (brainwash):
When the controller is reset to the factory settings (brainwash), the
controller address is set to 254.
ORDERING CODES
Populus [box]-[card]-[software]
Box: P
Nb. of outputs for el. strikes: 1 –1 output, max. 2 readers
2 –2 outputs, max. 4 readers
4 –4 outputs, max. 8 readers
Card: 3P - high secure access control hardware
Communication: NET –Ethernet connection
Communication mode: S–Spider mode
Code
Specification
POPULUS P-2-3P
Access controller in Pbox, 2
outputs, max. 4 readers, for
JantarV7, BLOCKER, CODEKS
POPULUS P-2-3P-NET
Access controller in Pbox, 2
outputs, max. 4 readers, for
JantarV7, BLOCKER, CODEKS,
Integrated Ethernet
POPULUS P-2-3P-NET-S
Access controller in Pbox, 2
outputs, max. 4 readers, for
JantarV7, BLOCKER, CODEKS,
Integrated Ethernet, Spider mode
POPULUS P-4-3P
Access controller in Pbox, 4
outputs, max. 8 readers, for
JantarV7, BLOCKER, CODEKS
POPULUS P-4-3P-NET
Access controller in Pbox, 4
outputs, max. 8 readers, for
JantarV7, BLOCKER, CODEKS,
Integrated Ethernet
POPULUS P-4-3P-NET-S
Access controller in Pbox, 4
outputs, max. 8 readers, for
JantarV7, BLOCKER, CODEKS,
Integrated Ethernet, Spider mode
OTHER
Please read through our warranty and disclaimer statements.
Connection scheme and additional support for the use of this
product can be found on:
http://www.jantar.si/forum/en
CONTACT:
Jantar d.o.o.
Kranjska cesta 24
4202 Naklo web: www.codeks.eu
SLOVENIA mail: sales@jantar.si
