Jarvis SEC 280-4 User manual

TABLE OF
CONTENTS Page............................
Models SEC 280--4
with DC Brake page 11...........
with Mechanical Brake page 13....
Blade (280mm)
78 Tooth, Skip Tooth 1023388......
150 Tooth, Tip to Root 1023288.....
72 Tooth, Tip to Root 1023393......
Noise Reduction 1023295..........
Balancer 4042035....................
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
Model SEC 280--4
Circular Breaking Saw
EQUIPMENT
SELECTION Ordering No..............
•Notice to Employer and Safety
Director 2.................................
•Notice to Operators, Maintenance
and Cleanup Personnel 3...................
•Parts Diagram and List 4....................
•Wiring Diagrams 13........................
•Special Tools 17...........................
•Specifications 18...........................
•Installation Instructions 18...................
•Operation Instructions 19....................
•Maintenance Instructions 19.................
Dual Trigger Model
JARVIS®
6204009::::

noticetoemployer
and safety director
Model SEC 280--4 page 2 of 24
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6204009::::
®
1. Remove and repair any tool that malfunctions. All personnel must be instructed to remove any
malfunctioning equipment.
2. Ensure that all employees who use this tool are trained in the proper use of this tool and are aware of
the dangers that may arise if they do not follow procedures outlined in this brochure.
3. Ensure that all employees are instructed not to walk in front of the tool during its use.
4. Enclosed are four (4) copies of “NOTICE TO OPERATORS, MAINTENANCE AND CLEANUP
PERSONNEL”. Post one copy on the employees’ bulletin board; give one copy to the operator(s);
give one copy to the maintenance foreman; and give one copy to the sub-contract cleanup / internal
cleanup foreman. Additional copies will be provided upon request.
5. The tool is designed and intended to be powerful. This fact should be obvious to your employees, but
you must emphasize it to them.
6. Ensure that eye protection is worn in accordance with OSHA’s eye and face protection requirements
(29 CFR 1910.133) when operating the tool.
7. Never make modifications or alterations to the tool. Replace any missing or illegible labels.
8. Ensure that proper procedures are established in accordance with OSHA’s lockout/tagout procedures
(29 CFR 1910.147) to prevent accidental startup or release of stored energy.
9. Follow our installation and maintenance instructions for proper installation and care of the tool.
10. Avoid injury. Do not permit the tool to be misused.
11. If you resell or distribute a Jarvis product, you must provide the purchaser with the appropriate safety
sheets and tool brochure. Additional copies of safety sheets and tool brochures will be provided upon
request.
NOTICE TO EMPLOYER AND SAFETY DIRECTOR
AVOID INJURY
Keep hands clear.

notice to operators, maintenance
and cleanup personnel
Model SEC 280--4
page 3 of 24
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6204009::::
®
NOTICE TO OPERATORS, MAINTENANCE AND CLEANUP PERSONNEL
REMOVE ANY MALFUNCTIONING TOOL FROM SERVICE
REPORT ANY PROBLEMS TO YOUR SUPERVISOR
1. Disconnect the power supply in accordance with OSHA’s lockout/tagout procedures (29 CFR
1910.147) before making any blade changes.
2. Disconnect the power supply in accordance with OSHA’s lockout/tagout procedures (29 CFR
1910.147) before performing any repair or maintenance.
3. Disconnect the power supply - or have the power supply disconnected - in accordance with OSHA’s
lockout/tagout procedures (29 CFR 1910.147) before performing any cleanup.
4. Disconnect the power supply when the tool is not being used.
5. Always wear eye protection in accordance with OSHA’s eye and face protection requirements (29 CFR
1910.133) when operating the tool.
6. Never put fingers, hands or other parts of the body on the cutting edge or within the cutting path of the
tool.
7. Never allow people to walk in front of the tool during its use.
8. Never allow people to hold / restrain the carcass while operating the tool.
9. Test the tool prior to use or daily. For models with dual anti--tie--down control handles: Depress each
trigger separately and the tool should not start. Depress one trigger, then pause one second and depress
the other trigger and the tool should not start. Repeat this procedure reversing the triggers. Depress
both triggers simultaneously and the tool should start. With the tool running, release one trigger and
the tool should stop. Continue holding the depressed trigger and then depress the other trigger. The
tool should not start. Repeat this procedure holding the other trigger. For models with single trigger:
Depress the trigger and the tool should start. Release the trigger and the tool should stop. If the tool
malfunctions, remove it from service and report or repair it immediately.
10. Test the brake prior to use and daily. After releasing either or both triggers, the tool should stop within
2.5 seconds. If the tool malfunctions, remove it from service and report or repair it immediately.
11. Never depress the trigger(s) unless you want to use or test the tool.
12. Never make modifications or alterations to the tool. Replace any missing or illegible labels.
13. Always use both hands when starting and operating the tool to avoid the risk of possible “kick back”
or “recoil”. Continue holding the tool with both hands until the saw blade comes to a complete stop.
Keep hands clear.

parts diagram and list
Model SEC 280--4 page 4 of 24
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6204009::::
®
YNot used in current tools.
** Wrench 8039147 is included.
1 1055746 Socket Head Cap Screw 7
1054135YBlade Ret. Screw, 1 Hole 1
2 1004330 Blade Ret. Washer, 4 Hole 1
1004267YBlade Ret. Washer, 1 Hole
1004318YBlade Ret. Washer, 2 Hole
3 1023388 Blade, Standard Skip Tooth 1
1023288 Blade, 150 Tooth
1023393 Blade, 72 Tooth
1023295 Blade, Noise Reduction
4 1004268 Flinger 1
5 1024130 Blade Guard 1
6 1055835 Flat Head Slotted Screw 5
7 1002393 Gear Head Cover 1
1002336YGear Head Cover
8 1035435 O-ring 1
9 1035544 Oil Seal 1
1035436YOil Seal
10 1013247 External Retaining Ring 1
11 1021350 Ball Bearing 1
12 1010432 Blade Retaining Pin 2
13 1026195 Crown Gear with item 12 1
1026161YCrown Gear w/o item 12
14 1021351 Ball Bearing 1
15 1055833 Cheese Hd. Slotted Screw 8
16 3016251 Right Angle Gear Housing 1
(with items 18 and 40)
17 1035437 O-ring 1
18 1021352 Needle Bearing 1
19 1026160 Pinion Gear 1
20 1009127 Inner Ring 1
21 1021238 Ball Bearing, 2 Row 1
1021348YBall Bearing, 1 Row
22 1013219 Internal Retaining Ring 1
23 3020039 Shaft Assembly 1
24 1002332 Motor Front Cover 1
1002417♦Motor Cover (Mech Brake)
ITEM PART NO. PART NAME QTY
25 1035461 O--ring 1
26 1021513 Ball Bearing 1
27 1030058 Square Key 1
28 1064034 Rotor 1
29 1021306 Ball Bearing 1
30 1035296 O--ring (with item 31) 1
31 Table 1 Housing and Stator Assembly 1
(DC Brake)
Table 2♦Housing and Stator Assembly
(Mechanical Brake)
32 1017188 Name and Info Label 1
33 1055590 Pan Head Slotted Screw 4
34 1055829 Socket Head Cap Screw 1
1055020♦SHC Screw (Mech Brake)
35 1055894 Socket Head Cap Screw 2
36 1042316 Rear Handle Bracket 1
1042414♦Rear Bracket (Mech Brake)
37 1011269 Shaft Coupling 1
1011355♦Shaft Coupling (Mech Brake)
38 1013309 Internal Retaining Ring 1
39 1035474♦Oil Seal (Mechanical Brake) 1
40 1038006 Grease Fitting 1
41 1061575 Damper 1
42 8039099 Blade Locking Pin 1
3016252 Gear Hsg Assy (items 1, 2, 4,
(6--14, 16, 18--22 and 40
3026063 Spiral Bevel Gear Set
(includes item 12, 13, 19
and 20)
3026049YSpiral Bevel Gear Set
(incls items 13, 19 and 20)
ITEM PART NO. PART NAME QTY
♦Used in models equipped with mechanical brake only.
♦
**
Figure A
♦

parts diagram and list
Model SEC 280--4
page 5 of 24
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6204009::::
®
D
DUsed on SEC 280--4 DC brake models with single cord only.
43 1055831 Oval Head Slotted Screw 8
44 1002340 Switch Cover 1
45 1035438 Switch Cover Seal 1
46 3005017 Switch Assembly 1
47 1019145 Front Handle 1
1019165 Front Handle (no trigger)
48 1035282 O-ring 1
49 1042310 Handle Mtg. Bracket, Left 1
50 1012119 Split Collar 2
51 1042317 Hanger Bracket 1
52 1042389 Hanger Bracket Half 1
53 1063209* Trigger Plug 1
54 Table 1* Trigger Cord 1
55 1042391 Hanger Bracket Half 1
56 1055612 Socket Head Cap Screw 2
57 1042311 Handle Mtg. Bracket, Right 1
58 1055832 Oval Head Slotted Screw 2
59 Table 1 Electric Plug, Motor 1
60 Table 1 Electric Cord, Motor 1
61 1011260* Strain Relief Connector 1
62 Table 1 Strain Relief Connector 1
63 1017083 Danger Label 1
64 1002339* Rear Handle Cover 1
1002349DRear Handle Cover
(includes item 63)
65 1035414 Rear Handle Cover Gasket 1
66 1013220 Internal Retaining Ring 1
67 1004257 Ring Washer 1
68 1035413 Diaphragm Seal 1
69 1005104 Electric Switch 2
70 1055834 Pan Head Slotted Screw 1
71 1042282 Switch Holder 1
72 1010356 Dowel Pin 1
73 1018126 Switch Actuating Lever 1
74 1010167 Roll Pin (incl. with item 76) 2
75 1055913 Self Tapping Screw 2
76 1019144 Rear Handle (2 Trig.) 1
1019141 Rear Handle (1 Trig.)
77 1014097 Spring 1
78 1055828 Oval Head Screw 1
79 1035439 O--ring 1
ITEM PART NO. PART NAME QTY
80 1010362 Dowel Pin 1
81 1018162 Trigger Lever with item 77 1
82 1055848 Cup Point Set Screw 1
83 1007283 Hex Jam Nut 2
84 1004227 Internal Tooth Lock Washer 2
85 1055777 Cheese Head Screw 3
86 1018127 Trigger Lever 1
87 1059067 Conduit Assembly 1
88 1055725 Pan Head Screw 2
89 1004274 Flat Washer 1
90 1014137 Spring 1
91 1029320 Lever Stop Spacer 1
92 1010355 Threaded Pin 2
93 1055847 Socket Head Cap Screw 3
ITEM PART NO. PART NAME QTY
* Used on SEC 280--4 DC brake models with dual cords only.
Figure B
*
*
*
*

parts diagram and list
Model SEC 280--4 page 6 of 24
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6204009::::
®
94 Table 2 Electric Cord 1
95 Table 2 Strain Relief Connector 1
96 1055055 Hex Head Screw 4
97 1005143 Push Button Switch 1
98 1032529 Switch Mounting Plate 1
99 1055915 Cheese Head Screw 3
100 1010457 Dowel Pin 1
101 1055744 Socket Head Cap Screw 2
102 1063860 Terminal Block 1
103 1036260 Trigger Bushing 1
104 1035395 U--cup Seal 1
105 1019195 Rear Handle 1
106 1035596 Bottom Handle Gasket 1
107 1010456 Dowel Pin 1
108 1018153 Trigger Lever 1
109 1014208 Spring 1
110 1039077 Spring Plunger 1
111 1035595 Rear Handle Gasket 1
112 1055150 Pan Hd Screw, Lock Washer 1
113 1055617 Socket Head Cap Screw 6
114 1055960 Socket Head Cap Screw 4
115 1035563 Handle Cover Gasket 1
116 Table 2 Handle Cover with item 63 1
117 1004361 Plain Washer 6
118 1055872 Hex Head Screw 2
119 1035354 Oil Seal (24 mm) 1
1035486** Oil Seal (22 mm)
120 1071071 Brake Drum (24 mm seal) 1
1061801** Brake Drum (22 mm seal)
121 1055918 Flat Head Screw 3
122 1061800 Brake Shoe 3
123 1014066 Compression Spring (50Hz) 3
1014171 Compression Spring (60Hz)
124 1055616 Cheese Head Screw 3
125 1004360 Split Lock Washer 3
126 1031041 Brake Hub (24 mm seal) 1
1031029** Brake Hub (22 mm seal)
127 1010455 Dowel Pin 3
128 1010454 Dowel Pin 3
ITEM PART NO. PART NAME QTY
Figure C
Rear Handle Assembly
for Mechanical Brake Models
Mechanical
Brake
*Install with open end facing away from motor
** not used in current tools
*
3019219 Rear Hdl. Assy, 115--380v
3019221 Rear Handle Assy, 42v
(includes items 63, 96--105,
107--110, and 114--118)
ITEM PART NO. PART NAME QTY
Figure D

parts diagram and list
Model SEC 280--4
page 7 of 24
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6204009::::
®
Figure E Control Box Assembly
Direct Current Braking with Dual Cords
See Table 1, page 11 for part numbers
Figure E above shows general control box layout with dual cords.
For specific voltages, see appropraite wiring diagram label inside
cover.

parts diagram
Model SEC 280--4 page 8 of 24
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6204009::::
®
Figure F
Control Box Assembly
Direct Current Braking with Single Cord
See Table 1, page 11 for part numbers
Figure F above shows general control box layout with single cord.
For specific voltages, see appropraite wiring diagram label inside
cover.

parts diagram and list
Model SEC 280--4
page 9 of 24
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6204009::::
®
Figure G
Control Box Assembly 42V DC Brake Only.
Direct Current Braking with Dual Cords.
1 1063607 Transformer, T1 1
2 1072310 Fuse F2 1
3 1072091 Fuse F1, 115V 1
1063862 Fuse F1, 230V
4 1063632 Overload Mounting Adapter 1
5 1063631 Overload Relay 1
6 1063656 Heater Pack 1
1063655* Heater Pack (1 Trigger)
7 1055863 Pan Head Screw 2
8 1004242 Lock Washer 2
9 1011248* Cord Connector 1
10 1007249* Locking Nut 1
11 1001089* Electric Cord 1
12 1001107 Electric Cord 2
13 1011249* Cord Connector 2
1011249DCord Connector 1
14 1007256* Locking Nut 2
1007256DLocking Nut 1
ITEM PART NO. PART NAME QTY
15 1001119 Electric Cord 1
16 1063455 Fuse Terminal Block 1
17 1011262 Cord Connector 2
18 1007266 Locking Nut 2
19 1063208* Electrical Outlet 1
20 1063624* Electrical Outlet 1
21 1063662* Grommet 2
22 1063625* Electrical Plug 1
23 1001108* Electric Cord 1
24 1063520 Gray Terminal Block 6
25 1063494* Gray Terminal Block 7
1063494DGray Terminal Block 9
26 1063495 Blue Terminal Block 1
27 1063496 Yel/Green Terminal Block 2
28 1032386 Mounting Plate 1
29 1042300 Terminal Rail 1
ITEM PART NO. PART NAME QTY
See page10foritems30--56partnumbers.
* Used on control box assembly with dual cords only.
DUsed on control box assembly with single cord only.
For specific voltages,
see appropraite wiring
diagram label inside
cover.
******

parts diagram and list
Model SEC 280--4 page 10 of 24
JARVIS PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457-4926
UNITED STATES OF AMERICA
TEL. [phone] FAX. [phone]
6204009::::
®
30 1016416* Electrical Enclosure 1
1016572DElectrical Enclosure
31 1063363* Terminal Marker 9
1063363DTerminal Marker 11
32 1063456 Terminal Marker 7
33 1055803 Pan Head Screw 6
34 1004247 External Lock Washer 6
35 1063570 Fuse 1
36 1063702 Suppressor, 2 Sup 1
37 1063502 Terminal Fork 9
38 1063571 ATD/Brake Circuit Board 1
39 1029445 Spacer 4
40 1004244 Internal Lock Washer 4
41 1073072 Plastic Screw 4
42 1061617 Heat Sink 1
43 1063757 Suppressor, 1 Sup 1
44 1055741 Cheese Head Screw 8
45 1004230 Lock Washer 16
46 1017085 Danger Label 1
ITEM PART NO. PART NAME QTY
47 1017210* Connection Diagram 1
1017339DConnection Diagram
48 1004216 Flat Washer 2
49 1063605 Bridge Rectifier 1
50 1063446 Terminal Ring 4
51 1063079 Terminal Ring 5
52 1063759 SCR Rectifier 1
53 1060068 Threaded Insert 6
54 1055845 Pan Head Screw 8
55 1072186 Dual SCR Rectifier 3
56 1063633 Ring Terminal 12
57 1063629DBase Connector w/gasket 1
58 1063627DInsert Connector (Female) 1
59 1055979DHex Head Screw 4
60 1004226DPlain Washer 4
61 1004227DInternal Tooth Washer 4
62 1007318DHex Nut 4
63 1001159DGrey Cord 2 ft
ITEM PART NO. PART NAME QTY
See page 9 for items 1--29 part numbers.
DUsed on control box assembly with single cord only.
Control Box Assembly 42V DC
Brake Only. Direct Current Braking
with Single Cord.
Figure H
* Used on control box assembly with dual cords only.
For specific voltages,
see appropraite wiring
diagram label inside
cover.
DDDDDDD
