Jarvis WELLSAW 404 User manual

Table Of Contents Page..........................................
•Notice to Employer and Safety Director 2..........................
•Notice to Operators, Maintenance and Cleanup Personnel 3.........
•Parts Diagram 4................................................
•Parts List 5....................................................
•Specifications 6................................................
•Installation Instructions 6........................................
•General Safety Instructions 7.....................................
•Operation Instructions 8.........................................
•Maintenance Instructions 9.......................................
NOT FOR HOME USE
PORTABLE POWER SAW
MODEL 404
Owner’s Manual For:
JARVIS
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
6205006;:
®

pg 2 of 12
MODEL 404
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
JARVIS
®
6205006;:
1. Remove and repair any tool that malfunctions. All personnel must be instructed to remove any
malfunctioning equipment.
2. Ensure that all employees who use this tool are trained in the proper use of this tool and are aware
of the dangers that may arise if they do not follow the procedures outlined in this brochure.
3. Enclosed are four (4) copies of “NOTICE TO OPERATORS, MAINTENANCE AND CLEAN-
UP PERSONNEL.” Post one copy on the employees’ bulletin board; give one copy to operator(s);
give one copy to the maintenance foreman; and give one copy to the sub-contract cleanup / internal
cleanup foreman. Additional copies will be provided upon request.
4. The tool is designed and intended to be powerful. That fact should be obvious to your employees,
but you must emphasize it to them.
5. Never make modifications or alterations to the tool. Replace any missing or illegible labels.
6. Always disconnect the tool from its power supply when it is not in use.
7. Follow our installation and maintenance instructions for proper installation and care of the tool.
8. Ensure that employees wear eye protection in accordance with OSHA’s eye and face protection re-
quirements (29 CFR 1910.133) at all times.
9. Hand/Wrist/Arm injury and other Cumulative Trauma Disorders may result from repetitive work,
motion or vibration. You must make your employees aware of hazards, symptoms of injury and ap-
propriate prevention. See OSHA’s “Ergonomics Program Management Guidelines for Meat Pack-
ing Plants.”
10. Avoid injury. Do not permit the tool to be misused.
11. If you resell or distribute a Jarvis product, you must provide the purchaser with the appropriate safe-
ty sheets and tool brochure. Additional copies of safety sheets and tool brochures will be provided
upon request.
NOTICE TO EMPLOYER AND SAFETY DIRECTOR
AVOID INJURY
Keep hands clear.
noticetoemployer
and safety director

pg 3 of 12 MODEL 404
JARVIS
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
6205006;:
®
1. Always wear eye protection in accordance with OSHA’s eye and face protection requirements (29
CFR 1910.133), and when needed, a dust mask.
2. Do not operate near flammable liquids or in gaseous atmospheres.
3. Do not operate in outdoor locations or in damp or wet locations.
4. Do not overreach; keep proper footing and balance when using the tool.
5. Disconnect the power supply in accordance with OSHA’s lockout/tagout procedures (29 CFR
1910.147) before changing the blade.
6. Disconnect the power supply in accordance with OSHA’s lockout/tagout procedures (29 CFR
1910.147) before performing any repair or maintenance.
7. Disconnect the power supply -- or have the power supply disconnected -- in accordance with OSHA’s
lockout/tagout procedures (29 CFR 1910.147) before performing any cleanup.
8. Disconnect the power supply when the tool is not in use.
9. Never put fingers, hands or other parts of the body on the cutting edge of the blade or in the cutting
path.
10. Test the tool prior to use or daily. Depress the trigger and the tool should start. Release the trigger
and the tool should stop. If the tool malfunctions, remove it from service and report or repair it im-
mediately.
11. Never depress the trigger unless you are going to use or test the tool.
12. Never make any alterations to the tool. Report or replace any missing or illegible labels.
13. Always use both hands when starting and operating the tool to avoid the risk of possible “kick back”
or “recoil.” Continue holding the tool with both hands until the saw blade comes to a complete stop.
NOTICE TO OPERATORS, MAINTENANCE AND CLEANUP PERSONNEL
REMOVE ANY MALFUNCTIONING TOOL FROM SERVICE
REPORT ANY PROBLEMS TO YOUR SUPERVISOR
Keep hands clear.
notice to operators, maintenance
and cleanup personnel

pg 4 of 12
MODEL 404
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
JARVIS
®
6205006;:
parts diagram

pg 5 of 12 MODEL 404
JARVIS
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
6205006;:
®
blades, blade supports
and accessories
ITEM
OLD
PART NO.
JARVIS
PART NO. PART NAME QTY
1 1063112 501022--005 Brush Cap 2
2 1063111 501022--004 Brush and Spring 2
3 1063110 501022--003 Brush Holder 2
4 1015006 501174 Deflector 2
5 1002191 501002 Top Cap 1
6 1055428 100101--004 Screw 4
7 1021215 100403--003 Ball Bearing 1
8 1063119 501224--003 Stator, 115V 1
1063120 501224--004 Stator, 230V 1
9 1027040 501021 Stator Stud 2
10 1007164 100105--001 Lock Nut 4
11 1063117 501224--001 Armature, 115V 1
1063118 501224--002 Armature, 230V 1
12 1026072 501225 Pinion Gear 1
13 1021227 100422--004 Ball Bearing 1
14 1035193 501120--001 Seal 1
15 1035192 501103 Seal 2
16 1036116 501171 Bushing 1
17 1027041 501046 Rod Stud 1
18 3065010 501172 Push Rod and Stud 1
19 1012050 501350 Clamp Ring 1
20 1055422 100034--038 Set Screw, 1/4 inch 1
21 8030031 100099--001 Hex Key 1
22 1002206 501003--001 Blade Support Cover 1
23 1007162 100022--006 Cap Nut 6
24 1055439 100102--002 Screw 5
25 1002203 501004 Handle Cover 1
26 1055438 100101--003 Screw (set of 12) 3
27 1012046 501042 “S” Clip 1
28 1012047 501043 “U” Clip (rubber) 1
29 1027048 501272 Stud 3
30 1036120 501273 Insert Bushing 3
31 1005038 100739--001 Switch 1
32 1017033 501187 Info Label 115V, Eng. 1
1017034 501179 Info Label 230V, Eng.
1017054 Info Label 115V, French
1017234 Info Label 230V, French
1045013 Label Retaining Rivet 4
33 1027043 501081 Drive Stud 1
34 1029185 501082 Spacer 1
35 1035191 501008 Gasket 1
36 1002193 501005 Bottom Plate 1
37 1055426 100101--001 Screw (set of 12) 4
38 3028030 501053 Connecting Rod & Brg 1
39 1013310 100069--013 Snap Ring 1
40 1020133 501377 Gear Shaft 1
41 3026024 501223 Gear and Stud (33) 1
42 1021216 100424--001 Needle Bearing 2
43 1021218 100425--001 Needle Thrust Bearing 1
44 1004149 100426--001 Thrust Bearing Race 1
45 3001011 501337 Cord and Plug, 230V 1
46 1063125 501294 Strain Relief 1
47 1013137 501295 Clamp Ring 1
48 1063109 100647 Grommet 1
49 1016199 501001--006 Housing 1
50 1007166 501376 Gear Shaft Nut 1
ITEM
OLD
PART NO.
JARVIS
PART NO. PART NAME QTY
replacement kits
ITEM
OLD
PART NO.
JARVIS
PART NO. PART NAME
3063010 501351--001 Armature and Bearing
(no pinion gear) 115V
3063011 501351--002 Armature and Bearing
(no pinion gear) 230V
3063007 501235--001 Armature, Bearing
and Pinion Gear, 115V
3063008 501235--002 Armature, Bearing
and Pinion Gear, 230V
3063013 501232 Armature and Pinion,115V
3063014 501233 Armature and Pinion,230V
3001008 501006 Cord Assembly, 115V
3001010 501089 Cord Assembly, 230V
3001017 Cord Assy, 230V Europe
3026023 501088 Gear And Bearing Assy
3016119 501169--001 Housing & Bushing Assy
1062003 Gear Grease (1 lb can)
ITEM
OLD
PART NO.
JARVIS
PART NO. PART NAME QTY
51 3001008 501006 Cord and Plug with
strain relief, 115V
3001017 European Line Cord
with strain relief, without
plug.
52 1006021 501066 Knob 1
53 1055429 100102--003 Screw 2
54 1027042 501065 Handle Stud 1
1027049 501378 Heavy Duty Stud
55 1058071 501175T Blade Support 8” End Cut 1
1058070 501128T Blade Sup. 16” End Cut
56 1023122 501246 Blade 8” End Cutting 1
1023121 501247 Blade 16” End Cutting
57 1058075 502077T Blade Sup. 8” Heavy Duty 1
1058074 502076T Blade Sup. 16” Heavy Duty
58 1023123 501319 Blade 8” Heavy Duty 1
1023124 501320 Blade 16” Heavy Duty
parts list

pg 6 of 12
MODEL 404
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
JARVIS
®
6205006;:
SPECIFICATIONS
Motor Power 1 hp 745 W
Operating Volt/Amp 230V/3.5A, 1 phase, 50/60 Hz
115V/7A, 1 phase, 50/60 Hz
Stroke 1.13 in 29 mm
Blade Speed 8000 strokes / min
Control Handle Single Trigger Electric
Blade Length 8 in 203 mm
16 in 406 mm
Overall Length (w/16 in blade) 32 in 813 mm
Weight (w/o blade) 9.8 lbs 4.5 kg
INSTALLATION INSTRUCTIONS
These instructions have been prepared to assure you of
satisfactory operation through proper use of your Jarvis
Wellsaw.
Read them carefully and keep them for future reference.
POWER SUPPLY
Your Jarvis Wellsaw operates on 50 or 60 Hz., single
phase alternating current. Its voltage rating is indicated
on the name plate (either 115 or 230 Volt). If an exten-
sion cord is to be used, be sure that the wire size is ade-
quate to maintain full line voltage to the tool.
GROUNDING
Your Jarvis Wellsaw should be grounded to prevent the
user from electric shock or electrocution.TheJarvis
Wellsaw is equipped with an approved three conductor
cord and three prong grounding--type plug to fit the prop-
er grounding--type receptacle. The green conductor in
the cord is the grounding wire. Never connect the green
wire to a live terminal. If your Jarvis Wellsaw is the 115
volt model, it has a plug that looks like figure ”A”. If
your Jarvis Wellsaw is the 230 volt model, it has a plug
that looks like figure ”B”.
figure A figure B
grounding blade grounding blade
Do not use any adapters with the Jarvis Wellsaw
EXTENSION CORDS
Make sure your extension cord is in good condition.
When using an extension cord, be sure to use one heavy
enough to carry the current your Jarvis Wellsaw will
draw. An undersized cord will cause a drop in line volt-
age resulting in loss of power and overheating. The table
below shows the correct size to use depending on cord
length and nameplate ampere rating. If in doubt, use the
next heavier gage. The smaller the gage number, the
heavier the cord.
Minimum Wire Gage for Extension Cords
Volts TotalLengthofCordinFeet
120 0--25 26--50 51--100 101--150
240 0--50 51--100 101--200 201--300
Amp Rating Wire Size (AWG)
0--6 18 16 16 14
6--10 18 16 14 12
When tool is used outdoors, use only extension cords la-
beled for outdoor use.
installation instructions

pg 7 of 12 MODEL 404
JARVIS
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
6205006;:
®
GENERAL SAFETY INSTRUCTIONS
For Operators, Employers and Maintenance Personnel
WARNING:When using electric tools, basic safety precautions should always be followed to
reduce the risk of fire, electric shock and personal injury, including the following:
1.
READ ALL INSTRUCTIONS.
•
Know your Jarvis Wellsaw and understand safety notices, manuals and instructions
in the literature provided. Become familiar with the Jarvis Wellsaw, its dangers,
limitations and applications.
2. INSTALL THE TOOL PROPERLY .
• Ground the tool. See instructions provided in the installation section of this manual.
• Use the proper extension cord. See instructions provided in the installation section of this
manual.
3. USE THE RIGHT TOOL AND ATTACHMENTS.
•
Select the proper tool to do the job. The Jarvis Wellsaw is designed for meat and bone
cutting; wood cutting; non--woven and geo--textile cutting. Do not use the Jarvis Wellsaw
for non--intended purposes.
4. KEEP WORK AREAS CLEAN AND WELL LIT.
•
Cluttered, oily and poorly lit work areas invite accidents.
• Keep visitors a safe distance from the work areas.
5. AVOID DANGEROUS ENVIRONMENTS.
•
Do not expose the power tool to rain.
• Do not use the tool in presence of flammable liquids or gases.
6.
WEAR PROPER APPAREL.
•
Avoid being pulled by moving parts of the Jarvis Wellsaw. Do not wear loose clothing or
dangling objects. Restrain long hair.
• Wear safety glasses when operating the tool.
7. MAINTAIN THE JARVIS WELLSAW AND ACCESSORIES WITH CARE.
•
Keep the Jarvis Wellsaw sharp and clean for the best and safest performance.
• Follow the instructions for lubricating and changing the blades.
• Inspect the Jarvis Wellsaw regularly. If the Jarvis Wellsaw is malfunctioning, remove it
from service and report any problems to your supervisor immediately.
• Keep the handles dry, clean and free from oil and grease.
8.
STAY ALERT.
•
Watch what you are doing and use common sense.
9. SAVE THESE INSTRUCTIONS.
general safety instructions

pg 8 of 12
MODEL 404
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
JARVIS
®
6205006;:
OPERATION INSTRUCTIONS
Before starting regular operation of the Jarvis Wellsaw,
we recommend that you make a few cuts with a fine pitch
blade to acquaint yourself with the operation of the tool
before using any of the coarser blades.
A. AVERAGE CUTTING AND RIPPING:
1. Place your work piece on a solid support at a
convenient working height.
2. Adjust the material so that the line of cut will be
close to the support. Secure it firmly.
3. To prevent starting torque of the motor from
pulling the saw away from line of cut, the opera-
tor should make a few short strokes until the
blade has cut into the material about 1/4 inch be-
fore squeezing trigger switch.
4. Both hands should be on the saw at all times
while cutting. Continue holding the tool with
both hands until the saw blade comes to a
complete stop.
5. The saw should be kept at a 90 degree angle to
the work piece while cutting material that is
thicker than 1 inch.
6. The saw should be pushed firmly into the mate-
rial while cutting.
7. Do not allow the saw blade or the blade support
to leave the work piece while cutting.
8. Never allow the saw blade to float into the mate-
rial while cutting.
9. Never permit any part of the saw, except the
blade and the blade support, to contact the work
piece during the cut.
B. LARGE CROSS SECTIONS:
1. Rocking the saw in the cut will speed up the cut-
ting action.
C. SINKING THE BLADE THROUGH A SUR-
FACE:
1. Your power hand saw is not designed for regular
use in starting its own hole by sinking blades
through a surface, commonly called “plunge
cutting”. If attempted, the operator must:
a. Keep the saw blade as parallel to the work
as possible.
b. Immediately, as the blade makes contact
with the work piece, start to draw the saw
back slowly from the starting point.
c. Repeat the operation outlined in “b”, if nec-
essary.
d. Have room to draw the saw at least 4--6 in-
ches before cutting through a 1 inch thick-
ness.
e. Do not force the saw blade, but keep it
moving slowly on the draw back from the
starting point. After a break through cut
has been made and the end of the blade sup-
port extends through the material at least
1--1/2 inches, the saw may be tipped to a
normal cutting angle.
D. NOT FOR CUTTING SMALL RADII:
E. ALWAYS KEEP A SHARP BLADE ON THE
SAW:
1. Cutting with a dull or badly worn blade can
overload the saw and cause damage from over-
heating.
2. New blades can be purchased from Jarvis.
operation instructions

pg 9 of 12 MODEL 404
JARVIS
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
6205006;:
®
MAINTENANCE INSTRUCTIONS
Always disconnect the saw from its power supply
before performing any maintenance.
Item numbers: refer to the parts diagram on page 4.
A. LUBRICATION:
1. The gear case should be kept 1/3 full of grease.
To check the grease level, remove the bottom
plate (item 36) and its gasket (item 35). It should
be checked every thirty days for saws that are
used moderately and every two weeks for saws
that are used daily. If replacement grease is re-
quired it should be obtained from Jarvis.
B. BLADE SUPPORT INSTALLATION:
1. Tap (3) inserts (item 30) gently into the bores on
blade support clamp (item 22).
2. Align the blade support clamp (item 22) onto
saw housing (item 49), making sure the inserts
stay in place.
3. Assemble (3) studs (item 29) with cap nuts (item
23) and place them through the saw housing and
the blade support clamp.
4. Draw down all (3) cap nuts (item 23) evenly un-
til the inserts are bottomed out into the saw hous-
ing.
5. Remove the cap nuts (item 23) and the blade
support clamp (item 22). (The inserts should
now be properly set into the saw housing).
6. Assemble blade support (item 55 or 57) over the
inserts on the saw housing. Place the blade sup-
port clamp (item 22) on the saw housing and fas-
ten it with the studs (item 29), the cap nuts (item
23) and the phillips screws (item 24).
7. Install handle stud (item 54) using two larger
phillips screws (item 53).
C. BLADE REMOVAL:
NOTE: Your Jarvis Wellsaw is equipped with a
hex key (item 21) for removing the blade. This
wrench is located in the housing directly behind
the blade support knob (item 52).
1. Insert the hex key through the hole in the outer
end of blade (item 56 or 58) and pull the blade
to the outer end of stroke.
2. Loosen the blade holding set screw (item 20)
about 1/2 turn.
3. Reinsert the hex key in the hole at the outer end
of the blade and pull the blade out.
D. BLADE INSTALLATION:
1. Insert hex key (item 21) into set screw (item 20).
2. Thread the set screw (item 20) into the hole in
the end of push rod (item 18). Do not tighten.
3. STANDARD BLADE SUPPORT (End Cutting):
a. Align blade (item 56) with blade support
(item 55). The blade should extend approx-
imately three inches from the end of the
blade support.
b. Slide the blade onto the blade support until
the crimp in the blade is touching the end of
the blade support.
c. Use a rubber hammer and tap the end of the
blade towards the body of the saw until the
crimp in the blade slides into the slot in the
blade support.
HEAVY DUTY BLADE SUPPORT (Heavy Duty):
a. Place the grooved end of blade (item 58)
into the guide in the blade support (item
57).
maintenance instructions

pg 10 of 12
MODEL 404
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
JARVIS
®
6205006;:
b. Slide the blade over the blade support to-
wards the body of the saw. Make sure that
the tabs on the blade extend over each side
of the blade support.
4. Slide the blade into the push rod as far as it will
go.
5. Tighten the set screw with the hex key.
E. GENERAL DISASSEMBLY:
1. Remove blade (item 56 or 58) and blade support
(item 55 or 57).
2. Remove handle cover (item 25).
3. Remove switch (item 31). Remove the top two
wires by inserting a 1/16 inch diameter pin
punch directly adjacent to the stator wires.
4. Remove brush cap (item 1) and brushes (item 2).
5. Remove deflectors (item 4).
6. Slide off top cap (item 5) -- stator (item 8) will
be attached.
7. Remove armature (item 11). Hold the armature
in one hand and tap housing (item 49) with a rub-
ber hammer with the other hand to loosen the ar-
mature. (Pinion gear -- item 12 -- on the arma-
ture has a left hand thread).
8. Remove bottom plate (item 36) and gasket (item
35).
9. Insert a small block of wood between the con-
necting rod (item 38) and the housing (item 49)
to stop the rotation of the connecting rod. Re-
move lock nuts (item 10). Remove the connect-
ing rod.
10. Using a 5/16 inch hex key, loosen gear shaft
(item 40) -- left hand thread. Be sure not to spin
gear stud nut (item 50). Remove items 33 and
41--44.
11. Remove the push rod and stud (item 18) through
the center of the housing.
12. Clean the gear housing cavity to remove any
contaminated lubricant.
13. Remove and replace any faulty parts and reas-
semble by reversing these steps.
NOTE (when reassembling):
a. Step 10: Use Loctite 271 on gear shaft nut
(item 50) before fastening gear stud (item
40).
b. Step 7: Reassemble armature (item 11) in
housing (item 49) by using a center punch
to tap the armature until its bearing is fully
seated.
maintenance instructions

pg 11 of 12 MODEL 404
JARVIS
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
6205006;:
®
notes

pg 12 of 12
MODEL 404
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
JARVIS
®
6205006;:
PRODUCTS CORPORATION
®
JARVIS
6205006;:
PRODUCTS CORPORATION
33 ANDERSON ROAD, MIDDLETOWN, CONNECTICUT 06457--4926
UNITED STATES OF AMERICA E--MAIL
[email protected]
FAX [phone] TEL. [phone] WWW .jarvisproducts.com
